- Page 1 Product Specifications SSR Motorsports 12825 Alondra Blvd, Norwalk CA 90650...
-
Page 2: Table Of Contents
Table of Contents Chapter I Product Introduction ................1 Chapter II Name of Parts of the Complete Vehicle and Outline Drawing ..... 3 Chapter III Main Technical Parameters ..............4 Chapter IV Operation Methods and Precautions ............ 6 I. Precautions for Safe Driving ...................... 6 II. - Page 3 III. Scope and Content Not Covered by Warranty ..............222 IV. Warranty Principles ..............Error! Bookmark not defined.
-
Page 4: Chapter I Product Introduction
Chapter I- Introduction to the Product This electric scooter features 3D technology design, which is characterized by pleasant modeling, fashionable and casual appearance, unique style, really simple but extraordinary structure, and noble and amiable nature, we believe that you will love it at first sight! The main features are as follows: 1. - Page 5 technology, and the advanced CNC processing technology, make bringing the vehicle to a stop simple and easy. 7. Handlebar: The streamlined human body engineering leisure design with tough and firm natures makes you have a free and easy control. 8. Rolling handle: With the soft rubber molding injection, it makes your hands feel comfortable 9.
-
Page 6: Chapter Ii Name Of Parts Of The Complete Vehicle And Outline Drawing
Chapter II- Name of Parts of the Complete Vehicle and Outline Drawing Handlebar Ignition Switch Battery indicator Bell Handlebar Grip Throttle assembly Front brake lever Rear brake lever Main seat Frame Front fender Rear fender Front tire Front brake rotor Rear disc brake caliper Connecting seat Rear brake disc... -
Page 7: Chapter Iii Main Technical Parameters
Chapter III - Main Technical Parameters I. Main Technical Parameters of the II. Main Technical Parameters of the Complete Vehicle Battery 1. Overall dimensions: 1756×700×1200mm 1. Battery type: Power lithium battery □ □ □ 2. Wheel base: 1296mm 2. Capacity: 12Ah 15Ah 20Ah... - Page 8 Note: The above parameters will be changed V. Main Technical Parameters of the without further notice. For details of vehicle charger models, see the company’s technical parameter 1. Input voltage (AC): AC140~240V 50/60Hz database! 2. Output voltage (DC):71.4±0.4V 3. Charging time (depending on the residual electricity): 6~8h Attention: In order to facilitate maintenance, repair and service, these scooters will have a...
-
Page 9: Chapter Iv Operation Methods And Precautions
Chapter IV - Operation Methods and Precautions I. Precautions for Safe Driving 1. Please follow all traffic rules to ensure safe driving. The speed is recommended to be controlled within the safe range (note that the safe speed shall be controlled to 12 mph max). 2. -
Page 10: Correct Operation Method
dangerous if its front pedal is used to carry cargo and a person. II. Correct Operation Method 1. Driving method ① You can drive while standing if you keep a natural posture. ② Driving while seated: Please sit in the middle of the seat cushion to avoid dangers due to the front wheel load reduction and/or handlebar vibration. - Page 11 3. Operation of the electric battery meter: Switch on the ignition lock and the voltage indicator lamp will come on. In case of full charging, the green, blue and yellow lamps will be on. If the green lamp is off, it means that the electric quantity is only 60% of the rated capacity; if the blue lamp is off, it means that the electric quantity is only 40% of the rated capacity;...
- Page 12 pads, press out one brake pad with a clean slotted screwdriver to empty the space to take another pad. After replacement of the new brake pads, the brake pad adjusting screw on the brake handle shall be returned to the proper position (the position where you have a comfortable hand feeling). ③...
- Page 13 (1) Operation method: ① During charging, insert the battery box plug first, and then insert the commercial electricity AC120V plug. After charging, first remove the commercial electricity AC120V plug, and then remove the battery box plug; ② During normal charging, the charger indicator lamp will show red; after full charging, the charger indicator lamp will show green;...
- Page 14 ⑤ DO NOT remove or replace components within the charger. ⑥ DO NOT allow the charger to charge non-rechargeable batteries. ⑦ DO NOT use in a combustible gas environment, which may cause explosion or fire. ⑧ DO NOT get the charger near water or wet, which may cause fire or electric shock. ⑨...
- Page 15 ⑦ The charger will become hot during charging, which is normal if the temperature is not higher than 140°F ⑧ Please put the charger and the electric scooter in a stable and dry place without inflammable and explosive articles which can’t be touched by children during charging. ⑩...
- Page 16 (3) Storage ① In case of a long time storage (more than 1 month), it is recommended to charge the battery by 60%~80%. The battery shall be recharged every three months during the storage period, which shall also be recharged before use. ②...
-
Page 17: Checking, Cleaning And Maintenance
III. Checking, Cleaning and Maintenance: (I) Regular or daily pre-ride checklist 1. Please ensure to check over the electric scooter in a safe place. 2. Check whether the abnormal operation of the previous day will affect operation today. 3. The braking effect: Check whether the brake handle can be moderately applied, whether the gap is proper, and whether it can be normally braked. -
Page 18: Common Fault And Troubleshooting Method
IV. Common Fault and Troubleshooting Method Fault Phenomenon Fault Reason Troubleshooting Method ① The battery voltage is too low; ①Completely charge the battery; The throttle fails or ② . The throttle is damaged; ② . Find a dealer and ask for a replacement; the maximum speed ③The spring in the throttle is stuck or is reduced... - Page 19 Fault Phenomenon Fault Reason Troubleshooting Method ① . The charger socket is loose or the ① . Fasten the socket or the plug-in connection between the plug and the socket is loose; component; The battery can’t be ② . The fuse of the battery box is burnt ②...
-
Page 20: Chapter V Electric Principles
Chapter V- Electrical Diagram S1 electric switch Hall device Speed regulation Left and right brake cranks... -
Page 21: Chapter Vi Quality Assurance And After-Sales Service
Chapter VI- Quality Assurance and After-sales Service I. Warranty Terms and Conditions 1. Please check the electric scooter during your purchase. You can request the sales staff to provide a bill-of-sale, a warranty card, and an address / telephone of your primary dealership. 2. -
Page 22: Warranty Identification Standard
SEEV Warranty Identification Standard Warranty “Replacement” Standard “No Replacement” Standard Part Name Period The handlebar pipe is deformed, cracked or Handlebars Crack damaged due to artificial factors or improper 1 year The handlebar pipe is deformed, cracked or Front fork Crack, welding seam damaged due to artificial factors or improper 2 years... - Page 23 Warranty “Replacement” Standard “No Replacement” Standard Part Name Period 1. It is deformed, cracked or damaged due to artificial factors or improper use 2. The appearance is eroded and polluted; Bearing crack, enclosure Motor 3. The parts are missing and unmatched; 1 year structure damage 4.
- Page 24 Warranty “Replacement” Standard “No Replacement” Standard Part Name Period Oil leakage and damage of 1. Damages are caused due to artificial factors upper and lower oil pumps, or improper use; brake handle crack due to Disc brake The user change its state without 1 year manufacturing defects, oil...
- Page 25 5. There is no warranty registration for the electric scooter; 6. The wearing parts and consumer goods will not be covered by SSR Motorsports; 7. The secondary fault is caused by the condition that the user still continues using the defective electric scooter;...
- Page 26 Warranty Registration Card for SEEV Electric Scooter No.: 90650 Manufacturer SSR Motorsports Postal code Location 12825 Alondra, Norwalk CA Telephone number Model and name SEEV-800 Electric bike code Electric bike color Frame number Motor number Telephone number/ Distribution unit (seal)
- Page 27 Maintenance Record Date Warranty Content Remarks __________ _________________________________ ___________ __________ _________________________________ ___________ __________ _________________________________ ___________ __________ _________________________________ ___________ __________ _________________________________ ___________ __________ _________________________________ ___________ __________ _________________________________ ___________ __________ _________________________________ ___________ __________ _________________________________ ___________ __________ _________________________________ ___________ __________ _________________________________ ___________...
- Page 28 SSR Motorsports Address: 12825 Alondra Blvd, Norwalk CA 90650 Website: www.ssrmotorsports.com...
