Bottle Loading
Set-Up Instructions
Remove the cooler from the shipping box and verify that there is no
•
damage to cooler.
Ensure cooler is located on a level floor out of direct sunlight.
•
•
Wipe water bottle with a damp cloth and remove label from the No
Spill cap. Insert dip tube into bottle.
Place the bottle on the base and close the door until it is in the
•
locked position.
Ensure that the hot tank switch on back of unit is in the "Off"
•
position.
Connect cooler to power source
•
This water cooler is intended to be plugged into a receptacle of the
ground fault circuit interrupting type (GFCI).
The AquaCafe® r has a self-priming feature that takes
•
approximately 5 minutes to fill both the hot and cold tanks. After
that time, dispense water from both the hot and cold tanks to
confirm that they have filled. Then turn on the hot tank.
Note: The maximum water supply should not exceed 80 psi.
MTN Products, 1770 Brackett Street, La Verne, CA 91750, 909-629-7301
ACB210r-T QSG
(do not use an extension
cord).
Rev: 12/16/2015
AquaCafé® r (Touch with Bottle Water)
MTN Products
Quick Start Guide
Advertisement
Related Manuals for MTN Products Aquacafe R
Summary of Contents for MTN Products Aquacafe R
- Page 1 Then turn on the hot tank. Note: The maximum water supply should not exceed 80 psi. MTN Products, 1770 Brackett Street, La Verne, CA 91750, 909-629-7301 ACB210r-T QSG Rev: 12/16/2015...
- Page 2 is reached to brew coffee. When it stops flashing, press the Button Descriptions Dispense button (#2) to brew coffee or tea. • When the water bottle is empty, the No Water indicator light will flash (#1 below). Load a new bottle of water and push the dispense button (#2) to continue operation.
