Subpac M2X Quick Start Manual

SUBPAC_M2X QUICK START GUIDE ARTWORK_ 2017-04-07
QUICK START GUIDE
CHARGE
SUBPAC is powered by an internal battery pack. Use
the provided power supply to plug into power outlet
for a full charge. A full charge should take up to 4
hours.
INTENSITY
Prior to turning on, make sure that the intensity knob
is set at the lowest level. WARNING: IF LED FLASHES
RED, LOWER INTENSITY TO AVOID POTENTIAL
DAMAGE.
WIRED AUDIO SOURCE
Connect your listening device/output source to the
"LINE IN" port on the control box using the supplied
3.5mm audio cable. Then slowly increase the
intensity to your desired level.
HEADPHONE
Plug your headphones into the headphone port on
the control box. Bluetooth headphones not
supported.
BLUETOOTH AUDIO SOURCE
For Bluetooth pairing, power off the device, unplug
the audio cable, and then hold down the power
botton for 4 seconds to make your SUBPAC visible to
devices. The Bluetooth LED will turn solid blue.
Search for "SUBPAC M2X" in your transmitting
device's Bluetooth settings and pair with it as per the
manufacturer's recommendations. When paired the
blue LED will flash until audio is played where it will
turn solid again. Note that plugging in the "LINE IN"
cable will automatically turn off Bluetooth.
© 2 0 1 7 S U B P A C
115mm
4 sec
FRONT SIDE
FIT ADJUSTABILITY
Strap the SUBPAC on as shown in
the illustration. Adjust the straps
so that it fits tightly against your
body. An optional waist strap is
provided with every unit.
This product is not intended for medical use.
Consult your doctor prior to using this product if:
-You are pregnant or could be pregnant.
-You have a pacemaker or heart condition.
-You have any health concerns that could be
affected by use of this SUBPAC.
Not recommended for use by diabetics, please
consult a medical professional before use.
Never leave device unattended especially if
children are present.
Never cover the device when it is in operation.
Extensive use, especially at high intensity
setting could lead to the device excessively
heating. Should this occur please discontinue
use and allow the unit to cool before operating
again. Never use this product directly on
swollen or inflamed areas or skin eruptions.
DO NOT use this product while in bed, where
there is a possibility of falling asleep with it
powered on.
Visit www.subpac.com/M2X for a complete Start Guide and Warranty
ENGLISH
3.175mm BLEED MARGINS
© 2 0 1 7 S U B P A C
115mm
SAFEGUARDS
TO REDUCE THE RISK OF FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO
WATER, RAIN, OR MOISTURE.
DO NOT expose your SUBPAC to direct sunlight or
extreme temperatures for an extended amount
of time.
Adult supervision is required for setup.
Excessive use of audio equipment at high
volume may lead to hearing loss, please listen
responsibility and use common sense.
Children under the age of 13 should not use
this product without parental supervision.
DO NOT wash or soak unit with water. If the cover
becomes wet please disconnect power immediately
and do not use again until totally dry.
The cover is not designed to be removed. The
cover is water resistant but not waterproofed.
DO NOT attempt to remove the electronics or
wiring of your device, doing so will void the
warranty. The SUBPAC can be cleaned with a
damp cloth and a mild detergent.
To avoid injury or death from electrical shock,
never open the control box or remove the
front cover of your SUBPAC.
ESPAÑOL FRANÇAIS ITALIANO DEUTSCHE PORTUGUÊS
한국어
BACK SIDE
CAUTION
日本語
中文
