5. Press the N button to start the
countdown.
6. Output switched to ON during the
countdown period.
7. Press the N button to pause the
countdown (output switched to OFF)
8. To resume countdown simply press the
N button again.
9. Press and hold the N button for more
than 3 seconds to exit the countdown
function.
MANUAL OVERRIDE
1. When in normal clock mode, pressing
the N button will scroll through the
following switching options.
• ALWAYS ON - timer is permanently
ON.
• PROG - timer is in programme
ON mode, will switch off at the next
programme OFF time.
• ALWAYS OFF - timer is permanently
OFF
• PROG - timer is in programme OFF
mode, will switch on at the next
programme ON time.
SUMMER TIME SETTING
1. Press the Y button, then use the + or -
buttons to scroll through to "summer"
(flashing).
2. Press the Y button again to access the
summer time setting.
3. Press the + or - button to change
between summer on or off.
4. Press Y to confirm summer setting,
time will advance by 1 hour.
5. A "SUMMER" icon will appear in the
display.
6. Use the same procedure to remove the
"SUMMER" icon when reverting to
GMT in the winter.
RANDOM SETTING
The random setting allows the timer to
switch ON and OFF with a random delay
of between 2 and 32 minutes. This
function will only operate if one or more
switching programmes have been
programmed into the timer.
1. Press the Y button, then use the + or -
buttons to scroll through to "RANDOM"
(flashing).
2. Press the Y button again to access the
random setting.
3. Pressing the + or - buttons will toggle
the random icon on and off.
4. Press the Y button to confirm random
function.
5. A "RANDOM" function icon will appear
in the display.
6. Timer will now operate in the random
mode.
7. To cancel random feature use the
procedure above to remove the
"RANDOM" icon from the display.
Pressing the reset button R with a pencil or
similar will reset all programmed times
and set time of day to zero.
READING YOUR
PROGRAMMED TIMES
1. Press the Y button twice to enter
programme mode.
2. Press the + or - buttons to scroll
through the 24 ON/OFF programmes
to check settings.
3. Press the N button to exit and revert to
clock mode.
BATTERY REPLACEMENT
If the display disappears when the timer is
unplugged or during a power failure, the
AAA battery needs replacing. Remove the
battery cover at the top rear of the timer,
and replace battery with a new AAA
non-chargeable battery. Ensure that the
battery polarities (+ and -) match those
inside the battery compartment. Replace
into timer and check display. Current time
of day and programmes can now be
entered.

TECHNICAL DATA

Switching
capacity:
Ambient
temperature:
Running reserve:
Memory location:
Shortest
switching time:
Programmable:
GUARANTEE
Your KingShield 7 Day Electronic
Plug-in Timer is guaranteed for 12
months from the date of purchase. This
does not affect your statutory rights.
PLEASE KEEP THESE INSTRUCTIONS
SAFE FOR FUTURE REFERENCE
WEST ROAD . HARLOW
ESSEX . CM20 2BG . UK
sales@greenbrook.co.uk
W W W. G R E E N B R O O K . C O . U K
RESET
230 Vac, 3000W,
13A resistive
2A inductive
-10°C to +55°C
150 HOURS +
24
1 minute
Every minute
