Notice to Installer
This manual contains important information about the installation, operation and safe use
of this product. Once installation is complete, this manual must be given to the owner/
operator of this equipment.
aquaguardpoolsystems.com
CrystalPro
Pool Cartridge Filter
Owner's Manual
Installation, Operation and Service
Models: CP120, CP150
WARNING
This equipment must be installed and serviced by a qualified
technician in accordance with all applicable codes and
ordinances. Improper installation can create hazards which could
result in property damage, serious injury or death. Improper
installation will void the warranty.
The NOTICE label indicates special instructions that are
important but not related to hazards.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aquaguard CP120
Summary of Contents for Aquaguard CP120
- Page 1 CrystalPro Pool Cartridge Filter Owner’s Manual Installation, Operation and Service Models: CP120, CP150 WARNING This equipment must be installed and serviced by a qualified technician in accordance with all applicable codes and ordinances. Improper installation can create hazards which could result in property damage, serious injury or death.
-
Page 2: Table Of Contents
Table of Contents Safety Information ................2 Winterizing ..................5 Installation ................... 3 Trouble Shooting ................6 Initial Startup of Filter ..............3 CrystalPro Parts Listing ..............7 Product Specifications ..............4 Warranty ....................8 Cartridge Cleaning ................5 • Air trapped in the system can cause an explosion. Open Safety Information the air relief valve to vent all air from the system before operating or testing the system. -
Page 3: Installation
As a result, the gauge pressure will rise and the flow will decrease. When the pressure rises 7-10 psi (.49-.70 Bar) above the starting pressure, or when flow decreases below desired rate, clean or replace the filter cartridge. AquaGuard | CrystalPro... -
Page 4: Product Specifications
*** Dictated by state or local codes. Typically 100 ppm. Common Specifications Maximum Working Maximum Continuous Net. Filtration Rate Design-flow rate Pressure Water Temperature Model Weight (lbs.) M3/h CP120 11.1 27.3 104° 40° 24.2 CP150 13.9 27.3 104° 40° 24.2 Pressure Gauge... -
Page 5: Cartridge Cleaning
In areas where sub-freezing temperatures can be expected the filter should be drained and/or removed from its operating location and stored indoors. Remove and clean cartridge. Reinstall cartridge in filter tank. Tighten locking-ring only a few turns when storing. AquaGuard | CrystalPro... -
Page 6: Trouble Shooting
Trouble Shooting Short Cycle Time Plugged Cartridge Cycle time will vary between installations and different areas Over time, the filter media will become clogged and will of the country. Check the following to remedy this problem: not perform properly. If the cartridge cannot be cleaned, replace it. -
Page 7: Crystalpro Parts Listing
Drain Plug with Gasket AGX310302 Filter Head AGX310303 Locking Ring AGX310304 Locking Ring Latch AGX310930 Filter Tank O-Ring AGX310301 Filter Body AGX912160 Plug with O-Ring 2" AGX220360 120 Ft² Cartridge Element for CP120 AGX220370 150 Ft² Cartridge Element for CP150 AquaGuard | CrystalPro... -
Page 8: Warranty
Please contact the store you purchased the filter from for service or return authorization and instructions. DO NOT MAIL THIS FORM. Use this form only to maintain your records. MODEL NO. SERIAL NO. INSTALLATION DATE Thank you for choosing AquaGuard! aquaguardpoolsystems.com...
