Use 2.0 inch dial indicator
extension with ¼ inch dial indicator
flat tip. Contact arbor shaft on
smooth surface [not threads].
Rotate arbor by hand. Readings
should be in the .001 inch range.
Using the round tip on the dial
indicator, make contact with the
saw blade near the top of blade.
Rock the blade gently side to side
to check bearing wear. Check
with the saw manufacturer for
bearing wear allowances.
TABLE SAW
Wipe face flange clean and run fingers
across flange to insure there are no burrs.
If there are – carefully remove them with a
file.
HINT: Remove Level Arm, with dial
indicator attached and relocate below
table and clamp on a part of the structure.
Direct dial indicator perpendicular to flange
face for the most accurate readings.
