MULTI MEASURING INSTRUMENTS CO.,LTD. HCL-9000S Instruction Manual

DIGITAL CLAMP TESTER
1. FEATURES
* Safe AC current measurement on circuit having internal voltage from AC 80V
to AC 23KV.
* Provides wide range of current measurement from AC 0.01A to 600A.
* Useful analog signal data output for the recorder.
* Sealed to withstand water and contaminants
* Provides the smooth and easy clamping for the cable with special made
"PUSH TO OPEN" mechanism.
2. CAUTION
* Before operating this instrument, familiarize yourself with instruction outlined
in this manual. .
* Always check to make sure that the function switch is set to the proper position.
* To avoid electrical shock, operate this instrument very carefully, especially for
the measurement of the circuit with more than AC 1000V.
* As the high voltage circuit is very dangerous, those who do not have such
specialized knowledge must not use this instrument.
* Never make measurements for uninsulated conductors or bus bars.
* Do not use this instrument, if you find any damage on the instrument of CT and or
body case.
* Through this instrument is sealed to withstand water, avoid the operation of this
instrument under heavy rain and humidity for the safety.
* Do not disassemble this instrument.
* When [B] sign appears on the display during the use of this instrument, replace the
batteries to new ones, as the operation voltage gets below than normal use for the
measurement.
* This model is high precision measuring instrument.
It may cause defect, if the CT part receives damage.
INSTRUCTION MANUAL
MODEL HCL-9000S
MULTI
