Eaton OnGuard Quick Manual

Quick guide
OnGuard
Thank you for purchasing the OnGuard command console. Your new console was designed and manufactured
in a US facility by tenured craftsmen and engineers dedicated to providing you a quality, durable solution to
withstand the rigors of your 24/7/365 work environment.

IMPORTANT TO NOTE BEFORE ASSEMBLY

Assembly of your Eaton command console must be performed
by qualified personnel. Connecting the command console to your
building's grounding network must be performed by a licensed
electrician.
Before assembling the console, the assembler must read and
understand all of the important safety information provided in the
OnGuard command console installation and user guide.
Eaton strongly recommends the use of personal protective
equipment during assembly, as listed in the OnGuard command
console installation and user guide.
Some of the OnGuard command console components are very
heavy. To reduce risk of personal injury and product damage,
always ensure a sufficient amount of personnel are present when
unpacking, moving and assembling the console system and
components.

Technical Support

If you need additional support with installation, email a detailed
description of the problem, as well as your contact information, to
Technical Support at: ToSupportESWorcesterMA@eaton.com.

Prepping for Assembly and Set-up

The following document is required in order to assemble the
command console. These documents are available at
Eaton.com/furniture.
• OnGuard command console installation guide, #IB210002EN
command console quick guide
ACCQG-17R
Sales Contact Information
Contact your Eaton sales representative using one of the methods
below:
Phone: 800-225-7348 (US Only) or 508-852-4300
Email: InfoESWorcesterMA@Eaton.com
Web: Visit us at www.eaton.com/wrightline

Optional Accessory Guides

In order to ensure proper installation of optional accessories for
the OnGuard command console, refer to the third party accessory
guides that may be included in your console.
Hard copy user guides are included in the accessory cartons, and
will be left by an Eaton installation contractor for future reference.
Additional copies of some guides are also available on third
party sites.
• Electric Lift System (Model DL6 lift motor, Model CBD6 control
box, and Model DP1C control pad)
Reference: Linak-US.com
• Personal Environment System (Model ME200)
Reference: www.airinnovations.com
• Monitor Poles and Arms:
Description #
20" Monitor mounting column & base plate kit
30" Monitor mounting column & base plate kit
Pitch/pivot column head kit
Dynamic height adjustable column arm kit
Articulating column arm kit
Articulating dual monitor array column arm kit
Large universal interface bracket
Reference: http://powerquality.eaton.com/Products-services/
Technical-Office-Furniture/flat-panel-display.asp
Part #
KONWLC20B
KONWLC30B
KONWLK0B
KONWLK1B
KONWLK2B
KONWLK2DUOB
TOACJSBUB
