SEI Industries BAMBI MAX Service Manual

Hide thumbs Also See for BAMBI MAX:
Table of Contents

Advertisement

Quick Links

Download this manual
BAMBI MAX
(1518–3542 MODELS)
SERVICE
MANUAL
2016 VERSION E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAMBI MAX and is the answer not in the manual?

Questions and answers

Related Manuals for SEI Industries BAMBI MAX

Summary of Contents for SEI Industries BAMBI MAX

  • Page 1 BAMBI MAX (1518–3542 MODELS) SERVICE MANUAL 2016 VERSION E...
  • Page 2 Phone: (604) 946-3131 Fax: (604) 940-9566 E-Mail: seisales@sei-ind.com Website: www.sei-ind.com USA Patent # 9,265,977 Australia Patent Pending Canada Patent Pending COPYRIGHT © 2016 SEI INDUSTRIES LTD. ALL RIGHTS RESERVED – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 3: Table Of Contents

    Section 1: Introduction Bambi MAX (Models 1518–3542) .................1 Valve System ........................2 System Overview ....................2 System Description ..................2 Section 2: Deploying the Bambi MAX Deployment Instructions ....................6 Attaching to the Cargo Hook ................6 Connecting Power ..................8 Using Longlines ....................9 Instant Deployment System (IDS) ................12 Section 3: Using Accessories Using the PowerFill System ..................13...
  • Page 4 Section 7: Valve Maintenance Bambi MAX Valve Repair and Replacement ..............31 Linkage Adjustment ..................31 Valve Removal .....................31 Installing the Valve ..................33 Bambi MAX Seal Replacement ..............34 Drive Cable Replacement ................40 Changing the Guide Bushings ..............45 Section 8: Repair Quick Guide Overview of Repair Categories ...................46...
  • Page 5 Section 10: Specifications and Parts Capacity and Weight Specifications ................73 Bambi MAX Capacity and Weight Chart ............73 Bambi Max with PowerFill Snorkel Capacity and Weight Chart ....73 Parts Listings ......................74 Bambi MAX Valve 16" Shell Assembly ............74 Bambi MAX Valve 16" Valve Installation ............75 Bambi MAX Valve 16"...

  • Page 6: Section 1: Introduction

    SEI Industries Ltd. offers complete parts supply and repair services for the Bambi MAX. For a repair facility in your area, please contact SEI. For maintenance and repair purposes, parts diagrams and descriptions are provided in this manual.

  • Page 7: Valve System

    System Overview The Bambi MAX uses a tubular type valve with seals located on the top and bottom of the tube. When in the default closed position, the seals make contact with top plate and bottom ring of the valve assembly.
  • Page 8 The control signal is provided in the aircraft via a momentary push button and relay. Caution The control enclosure is hermetically sealed. Unauthorized opening will void the warranty. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 9 Valve Open Making Adjustments. There is a status indicator lamp on the side of the control Sensor Fault enclosure which indicates where the controller thinks the valve is. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 10 To reset the motor protection, turn off power to the circuit using the aircraft's circuit breaker. Wait for approximately 10 seconds and turn the power back on again. The valve should return to its normally closed state. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 11: Section 2: Deploying The Bambi Max

    Attaching to the Cargo Hook Caution The Bambi MAX may not be suitable for a direct hook-up to the cargo hook. The actual hook-up will be different for various aircraft and operators must comply with all instructions and bulletins supplied by the aircraft manufacturer. It is the operator’s responsibility to ensure that the Bambi MAX is correctly fitted to the helicopter.
  • Page 12 Important Note If you are using a swivel with an electrical connection, then it is acceptable for the Bambi MAX to be flown without the ballast facing forward. The Bambi MAX has been tested with some aerospace swivel arms and performs very well despite rotating in flight.

  • Page 13: Connecting Power

    If an additional new plug is required, an IP67 or better must be used. The purpose of this type of plug is to offer a clean breakaway if the Bambi MAX has to be jettisoned from the aircraft in an emergency. It is suggested that the plug be lightly taped together with vinyl tape, while in use, to ensure that wind action does not separate the plug during flight.

  • Page 14: Using Longlines

    50’ long. Longlines should be at least 50 ft. long to keep the Bambi MAX well clear of the helicopter’s tail rotor. When using a longline, care must be taken in selecting the correct gauge of control cable. See the chart below for recommendations.
  • Page 15 Checking Suspension Cable Length Warning Using a Bambi MAX with a greater overall length than the distance from the cargo hook to the front tip of the tail rotor on your helicopter could result in a tail rotor strike and possible loss of control of the helicopter which could result in injury or death.
  • Page 16 Important Note To avoid potential rotor strikes when using the Bambi MAX, the operator must measure the extended length of the Bambi MAX and the distance from the belly hook to the closest possible point of the tail rotor. A) Always measure the overall extended length of your Bambi MAX and B) Measure the distance from the belly hook to the closest possible point on the tail rotor.

  • Page 17: Instant Deployment System (Ids)

    The instant deployment system uses a hub and spoke mechanism to automatically expand the mouth of the bucket as soon as the weight of the Bambi MAX is taken up by the suspension cables. When the bucket is full, the IDS deployment cable and hub restrainer cables should be slack as they should not bear any load.

  • Page 18: Section 3: Using Accessories

    The system can also be transported separately from the bucket, if required. The Bambi MAX, equipped with the PowerFill Snorkel, has the same handling, ease of transport and collapsibility as other Bambi MAX buckets in this size range. Bambi bucket with PowerFill installed. System Description The pump is 28 volt DC powered, compact, light weight and efficient.

  • Page 19: Flying With The Powerfill Snorkel System

    Flying with the PowerFill Snorkel System No prior experience is required to quickly master using the PowerFill Snorkel since flying a Bambi MAX with the PowerFill Snorkel will not adversely affect the flight characteristics of the bucket. To assist operators with installation of the PowerFill Snorkel in an aircraft, this manual contains a suggested wiring diagram.
  • Page 20 Excessive run time will require more frequent lubrication of the pump output shaft. See this manual’s section 6 on Maintenance and Troubleshooting for the shaft seal lubrication procedure. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 21: Using Foam

    Using Foam Section 3: Using Accessories Using Foam The Bambi MAX is designed to be effective with foam. All materials used in the manufacture of the Bambi MAX are resistant to the chemical action of foam. Caution After using foam or retardants, cycle through several dumps with water only or hose down with fresh water.

  • Page 22: Compatible Bambi Max/Sacksafoam Models

    Compatible Bambi MAX/Sacksafoam Models Model For Bambi Bucket Reservoir USG Capacity Liters Sacksafoam I 004338 BBX1518-BBX1821 004339 BBX2024-BBX4453 Sacksafoam II 004344 BBX1518-BBX4453 Sacksafoam Plus 004350 Sacksafoam II & III – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 23: Section 4: Making Adjustments

    With the valve in the closed position, locate the set screw on the top of the sensor cam which locks the cam to the cable drum. It should be at approximately the 12 o'clock position. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 24 • Check to see if set screw is tight. • Note the position of the reference line or draw a new line at the correctly adjusted position. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 25: Section 5: Packing And Storage

    Always leave the valve open 1 to 2 inches as this prevents the bottom seal from collapsing during long periods of storage, leading to longer seal life. Collapse the IDS by pushing the hub into the bucket. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 26 Tape the lines together in two bunches. Insert the operations manual into the storage bag. Gather the suspension lines into a coil and stow inside the bucket. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 27 Place the head on top of the collapsed bucket. Roll the bucket into a bundle and wrap with straps supplied. Rotate shell until head is under the shell. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 28 Take the carrying bag and drape it over the bucket. 10. Roll the bucket over and insert the manual. 11. Close with zipper and store with label showing. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 29: Storing The Bambi Max

    The following guidelines will help to ensure the longevity of your Bambi MAX: Do not pile heavy objects on the Bambi MAX in storage. This may result in creases in the neoprene seal in the dump valve, which may cause leakage.

  • Page 30: Section 6: Troubleshooting And Maintenance

    Damaged drive cable Replace drive cable. Controller / sensor Contact service center. failure Damaged seals Replace seals. Valve Leaks Yellow Valve adjusted too high Adjust valve down. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 31: Checking Aircraft / Longline Wiring

    If a longline is being used, re-connect the longline into the aircraft wiring harness and repeat the above procedure for the receptacle on the bottom of the longline. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 32: Powerfill Snorkel Troubleshooting

    Pump impeller worn or damaged. Repair / replace pump impeller. Fill Times Excessive Excessive voltage drop in longline. Use larger gauge cables. Damage to cables. Repair / replace cables. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 33: Maintenance Procedures

    Inspect the motor conductors for cuts or signs of chafing or wear. Immediately repair any damage to the conductor cable installation. Ensure each cable connector is securely attached to its cable and free from cracks or damage. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 34: Pump Output Shaft Lubrication

    Check for dirt of gravel accumulation between the seal cup and the bottom shank of the impeller. Also, clean out any dirt and debris that may have accumulated inside the filter basket. Re-install the filter basket. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 35: Unscheduled Maintenance

    Upon reassembly, apply a small amount of silicone RTV sealant to re-seal the cable. Important Note A good seal at the filter mount ring will prevent pump cavitation in water less than 16" deep. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 36: Section 7: Valve Maintenance

    Whenever any valve maintenance, such as seal changes or maintenance on the valve cycling, has to be done, we recommend that you remove the valve from the Bambi Max shell. To remove the valve, follow the steps listed below. Tools required: ratchet and 9/16" socket, side cutter.
  • Page 37 Now, remove the Note location of arrows four bolts holding for bolts. the valve to the bottom plate. Roll valve out of shell and move to repair area. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 38: Installing The Valve

    Some rotation may be necessary to line up the standoffs to the bottom plate holes. When lining up the holes, always move the standoff to the nearest bottom plate hole. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 39: Bambi Max Seal Replacement

    To remove the valve, please refer to the valve removal section in the maintenance section of this manual. Once the valve has been removed, follow the directions below. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 40 If you have several Bambi MAX buckets, a Power Pack is available from SEI. This Power Pack can...
  • Page 41 Tighten the tensioner clamps. Make sure to tighten each clamp equally as this will eliminate a problem of the clamp releasing as one of the tensioners is not engaged enough to hold the clamp. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions...
  • Page 42 Remove all the Allen head bolts from the top clamping ring. These bolts are extra long to give us maximum holding strength in plastic. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 43 Slip the new seal over the bolts and return the ring with seal to the shell. Pass the control cable through the ring, making sure to pass the cable through from the seal side. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions...
  • Page 44 6" back into the bucket. Reattach the control cable to the head as shown in the picture using four tie wraps. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 45: Drive Cable Replacement

    Important Note Use cyanoacrylate glue (crazy glue) on the ends of the cable, if available, to prevent fraying. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 46 Secure the cable retainer to the lift bar. Trim the short end of the drive cable and insert the cable through the cable bushing. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 47 Weight 3/8" spacer Turn on the power. The valve will close. Pull the cable tight and secure with cable anchor screws. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 48 Remove the weight and spacer from the lift bar, install the cable over the five sheaves and trim the end of the cable. Now, pass the cable to the inside of the carrier cross bolt, through the cable bushing in the top plate. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 49 Cut off the excess cable as close to cable anchor as possible. 11. Adjust valve to correct position (see Section 4 for more information). Actuator cam. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 50: Changing The Guide Bushings

    If slowing or jamming still occurs, loosen the guide bushing bolts on the opposite side and repeat the operations of step 5. The valve should be opened and closed several times. If it operates as it should, the bushings are changed correctly. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 51: Section 8: Repair Quick Guide

    If more information is required, refer to the Bambi Bucket Operations manual, the Bambi Bucket Service manual (for the model being used) or the Bambi Bucket Repair Assessment manual. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions...

  • Page 52: Bucket Shell Repair Criteria

    Wear and abrasions to webbing protective strips. • Up to 4” (102 mm) of peeled weld on panel strip. • Up to four broken battens. Category 4: Okay Does not need repair. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 53: Cables Repair Criteria

    • Wear, broken strands, kinks and twisting in cable that do not exceed the limits defined in Category 2 defects. Category 4: Okay Does not need repair. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 54: Ids Hub Repair Criteria

    Monitor and/or repair if condition deteriorates. • Wear on IDS hub. • Dents, abrasions and wear on spokes. • Clevis pin and shell bracket wear. Category 4: Okay Does not need repair. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 55: M-Straps And Top Chains Repair Criteria

    Damage to an M-strap that does not exceed 25% of the fabric. • Minor wear, impact marks or corrosion on chains. • Minor wear, impact marks or corrosion on shackles. Category 4: Okay Does not need repair. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 56: Control Head Repair Criteria

    Any visible crack or break on the head. • Visibly bent shackles. • Broken or missing safety wire on shackle pins. • Broken or exposed electrical conductors. • Broken or missing break-away plug. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 57: Section 9: General Repairs

    If you are unable to locate a metal bar, a wooden block will work, however, make sure to drill the hole into the end grain. Center holding sleeve. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 58: M-Strap Replacement

    The length of the M-strap is critical to the proper functioning of the Bambi MAX and we recommend that you replace worn straps with factory-supplied equipment. There are two types of straps; long webbing and short webbing. Long webbing are used for the diagonal straps while short webbing are used for the vertical straps.

  • Page 59: Removing Old M-Straps

    Fully insert the pliers at the far left hand side of the top layer. Holding the pliers tight, turn your hand clockwise. Repeat the operation until the knot is loose enough to remove the strap. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 60: Installing New M-Straps (Short)

    Once the old straps have been removed, the new strap installation can begin. Rotate the strap until the joint is centered. Pass the strap through the loop. Twist the loop eye 180 degrees. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 61 Repair Instructions Section 9: General Repairs Rotate the eye to the opposite side. Pull strap end through the eye. Pull strap tight. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 62: Installing New M-Straps (Long)

    Once the old straps have been removed, the new strap installation can begin. Locate the center of the strap. Pass the strap through the loop. Twist the loop eye 180 degrees. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 63 Repair Instructions Section 9: General Repairs Rotate the eye to the opposite side. Pull strap end through the eye. Pull the strap tight. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 64: Bottom Loop Repairs

    If the bottom loops require replacement, they should receive an overlay of heavy duty wear-resistant webbing. Bucket Patching Please see Bucket Repairs in this section. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 65: Ids Hub/Spokes Replacement

    Remember to re-attach the tripline to the dump valve, passing the line through the hub. Also, attach the IDS deployment cable to the control head small adjustment chain. Attach the two restrainer cables. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 66 This will likely produce a good fit. If the IDS is still too tight remove another spoke and repeat the above steps. These two spokes are across from each other. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 67: Bambi Max Shell Repairs

    Important Note Dura-Seal glue has been designed specifically for the SEI family of fabrics. The shelf life of this adhesive is about one year. Fresh adhesive can be obtained directly from SEI Industries Ltd. – 2016 Bambi MAX Service Manual...

  • Page 68: Repairing In High Humidity

    When using a warm air fan, either use one which is rated EXPLOSION PROOF or make sure that there is a steady flow of air past the work area to remove fumes as they are generated. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 69: Making Temporary Repairs With Sealing Clamps

    Use caution if deciding to enlarge the slit to insert a clamp. It is very easy to make the slit too large. Keeping hold of the string, slip one half of the repair clamp through the hole as indicated. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 70 Place the top of the clamp over the bolt. Caution Tightening the nut with tools may break the bolt away from the lower clamp. Overtightening can also deform the clamp and cause leaks. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 71: Temporary Repairs Using Glue

    Apply the second coat within four hours of the first coat. Clean and apply masking tape on the backside of the tear. Squeeze glue around the tear and spread with fingers. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 72: Gluing With Patches

    Wipe with a rag, dampened with solvent, to remove any residue from cleaning. Check to see if the area is totally clean and all coated surfaces and edges are dull. If not, repeat the cleaning. This is critical for a good glue bond. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 73: Cutting The Patch

    This expels trapped air. Once the patch is rolled down, do not let it lift up. This will prevent air from getting under the patch which causes a weak bond. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 74 Painting the patch also provides protection from ultra violet light and weather. Allow the bond to harden for 24 hours at room temperature before using the item. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 75: Hot Air Gun Patching

    Injury, especially to hands and fingers, can occur when using a hot air gun. Most welding will occur at temperatures of 800-1000 degrees F. Wear gloves to protect skin from overheating, burning and blistering. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 76: Hot Air Gun Procedure

    Let the repaired area cool down. Attempt to peel off at the edges with your fingers. If there is even a slight peel, repeat the operation locally. Otherwise, the repair is finished. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 77: Repair Kits

    Section 9: General Repairs Repair Kits Bambi Repair Kit 003613 (no glue) Used for Bambi MAX’s or other product lines where no glue is required or allowed. Important Note It is the responsibility of the dealer and end user to ensure that the importation of glue is allowed in the country of use.

  • Page 78: Section 10: Specifications And Parts

    Caution The selection of a Bambi MAX model for a specific aircraft is dependent on many factors including aircraft weight, fuel weight, operation elevation and atmospheric conditions. The helicopter operator must select a bucket model which is appropriate for their specific situation.

  • Page 79: Parts Listings

    Parts Listings Section 10: Specifications and Parts Parts Listings Bambi MAX Valve 16" Shell Assembly PART NUMBER ITEM MODEL DESCRIPTION 004226 GASKET, SHELL, 16” 007138 RING, BASE, 16” BBX1518 007141 RING, CLAMP, 16” – 006881 GUARD, VALVE, 16”, BBX3542 000393...

  • Page 80: Bambi Max Valve 16" Valve Installation

    Parts Listings Section 10: Specifications and Parts Bambi MAX Valve 16" Valve Installation PART NUMBER ITEM MODEL DESCRIPTION 002298 VALVE, 16” ASSY, 1518MX-3542MX BBX1518 012339 BOLT, HX 3/8-16 X 7/8, SS – BBX3542 001848 WASHER, LOCK, SPLIT, 3/8”, SS –...

  • Page 81: Bambi Max Valve 16" Seals

    Parts Listings Section 10: Specifications and Parts Bambi MAX Valve 16" Seals ITEM MODEL PART NUMBER DESCRIPTION 007041 TUBE, VALVE, 16”, MACHINED 006374 SEAL,VALVE, BOTTOM, 16” 011522 CLAMP, GEAR, 8” SS 010736 RING, SEAL, SPACER, 16” 005769 RING, SEAL, SUPPORT, 16”...

  • Page 82: Bambi Max Valve 16" Actuator And Controller

    Parts Listings Section 10: Specifications and Parts Bambi MAX Valve 16" Actuator and Controller PART NUMBER ITEM MODEL DESCRIPTION BBX1518 000210 ACTUATOR, ASSEMBLY – 000206 IVC, ASSEMBLY BBX3542 001606 SCREW, 10-24 x ¾”, HXSL,SS 001848 WASHER, LOCK, SPLIT, #10, SS –...

  • Page 83: Bambi Max Valve 16" Actuator

    Parts Listings Section 10: Specifications and Parts Bambi MAX Valve 16" Actuator ITEM MODEL PART NUMBER DESCRIPTION 000222 CAM, SENSOR 000220 DRUM, CABLE 000221 ANCHOR, CABLE 000214 BRACKET, MOTOR 000224 PLUG DESICCANT, ASSEMBLY 000225 GASKET, MOTOR BBX1518 000267 ENCLOSURE, 7.4 x 4.3 x 3.1, AL –...

  • Page 84: Bambi Max Valve 16" Actuator 2

    Parts Listings Section 10: Specifications and Parts Bambi MAX Valve 16" Actuator 2 PART NUMBER ITEM MODEL DESCRIPTION 000215 PLATE, MOTOR, FRONT 007789 MOTOR, GEAR, 24VDC, 4.0A, 61RPM 000217 COVER, SEAL 000218 HUB, MOTOR 002928 SEAL, LIP BBX1518 – 006335...

  • Page 85: Bambi Max Valve 16" Sheave Bar And Guide Rods

    Parts Listings Section 10: Specifications and Parts Bambi MAX Valve 16" Sheave Bar and Guide Rods ITEM MODEL PART NUMBER DESCRIPTION 007135 PLATE, TOP 16” 001618 BUSHING, CABLE 000226 BAR, SHEAVE, 16” 001617 SHEAVE, CABLE 000231 ROD, GUIDE 000229 ROD, SUPPORT...

  • Page 86: Bambi Max Valve 16" Lift Bar And Linkage

    Parts Listings Section 10: Specifications and Parts Bambi MAX Valve 16" Lift Bar and Linkage PART NUMBER ITEM MODEL DESCRIPTION 000233 BAR, LIFT, 16” 008660 ARM, LINKAGE, SHORT, 16” 008662 ARM, CARRIER, SHORT, 16” 008664 SPACER, SOLID, CARRIER BBX1518 008874 SPACER, TUBE, CARRIER –...

  • Page 87: Bambi Max Valve 16" Lift Bar

    Parts Listings Section 10: Specifications and Parts Bambi MAX Valve 16" Lift Bar PART NUMBER ITEM MODEL DESCRIPTION 000233 BAR, LIFT, 16” 000236 BUSHING, GUIDE, 16” 001619 RETAINER, CABLE BBX1518 001615 CABLE, DRIVE, ASSEMBLY – 000012 BOLT, HX, 10-32 x 1-17/32”, CAD...

  • Page 88: Bambi Max Head

    Section 10: Specifications and Parts Bambi MAX Head ITEM MODEL PART NUMBER DESCRIPTION 007272 HEAD, SMALL BBX1518 001794 SHACKLE, ANCHOR, SCREW, 3/8” GLV – BBX3542 001795 SHACKLE, ANCHOR, SCREW, 1/2” GLV – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 89: Bambi Max Shell, Models 1518-1821

    Parts Listings Section 10: Specifications and Parts Bambi MAX Shell, Models 1518-1821 ITEM MODEL PART NUMBER DESCRIPTION BBX1518 008642 SHELL BBX1821 008643 BBX1518 005420 BATTEN, FIBREGLASS, 31-5/8” BBX1821 005421 BATTEN, FIBREGLASS, 34-3/4” 001788 SHACKLE, ANCHOR, GALV.1/4” 003844 CHAIN, 3/16,GR30,GLV 60”...

  • Page 90: Bambi Max Shell, Models 2024-3542

    Parts Listings Section 10: Specifications and Parts Bambi MAX Shell, Models 2024-3542 – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 91: Bambi Max Shell, Models 2024-3542 (Continued)

    Parts Listings Section 10: Specifications and Parts Bambi MAX Shell, Models 2024-3542 (continued) ITEM MODEL PART NUMBER DESCRIPTION BBX2024 008644 BBX2024S BBX2226 008645 SHELL ONLY BBX2732 008646 BBX2732S BBX3542 008647 BBX2024 BBX2024S 005422 BATTEN FIBREGLASS 35-1/2” BBX2226 BBX2732 005424 BATTEN FIBREGLASS 38-1/2”...

  • Page 92: Rigging, Models 1518-1821

    Section 10: Specifications and Parts Rigging, Models 1518-1821 ITEM PART NUMBER DESCRIPTION 005467 M-STRAP, LOOP, 16” 005468 M-STRAP, STRAIGHT, 35” 005545 CABLE, SUSPENSION, PAIR 004057 LINK, CONNECTING – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 93: Rigging, Models 2024-3542

    Parts Listings Section 10: Specifications and Parts Rigging, Models 2024-3542 – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 94: Rigging, Models 2024-3542 (Continued)

    CHAIN, TOP, 18-1/2” BBX3542 BBX2024 BBX2024S 005525 CHAIN, TOP, 16-1/2” BBX2226 BBX2732 BBX2732S 005527 CHAIN, TOP, 20-1/2” BBX3542 013134 SHACKLE, ANCHOR, 5/16”, SCREW, SS 004057 LINK, CONNECTING, 1/4, PLT – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 95: Ids System, Model 1518-1821

    Parts Listings Section 10: Specifications and Parts IDS System, Model 1518-1821 IDS deployed inside a Bambi bucket. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 96: Ids System, Model 1518-1821 (Continued)

    001660 NUT, HEX, NYLOCK, 10-24 HX,SS 001703 PIN, CLEVIS, 1/4 X 1-1/8 SS 001705 PIN, CLEVIS, 1/4 X 11/4 SS 001710 PIN, COTTER, 1/16 X 3/4 PLT – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 97: Ids System, Models 2024-3542

    Parts Listings Section 10: Specifications and Parts IDS System, Models 2024-3542 – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 98: Ids System, Models 2024-3542 (Continued)

    001697 PIN, CLEVIS, 5/16 X 1-3/4, SS 001703 PIN, CLEVIS, 1/4 1-1/8, SS 001710 PIN, COTTER, 1/16 X 3/4 PLT 001713 PIN, COTTER, 3/32 X 3/4 PLT – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 99: Ballast Systems, Models 1518

    NUT, HX, NYLOCK,1/4-20, SS 000493 SCREW,10-24 X 1/2",PNPH, SS 001855 WASHER, FLAT, #10 X 3/4, SS 001660 NUT, HX, NYLOCK, SS, 10-24, SS 006184 BALLAST POUCH, ASSEMBLY, COMPLETE – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 100: Ballast Systems, Models 1821-3542

    Parts Listings Section 10: Specifications and Parts Ballast Systems, Models 1821-3542 – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 101 WASHER, FLAT, #10 X 3/4,FND, SS 001660 NUT,HX, NYLOCK,10-24, SS BBX1821 006185 BBX2024 BBX2024S 006186 BBX2024PF BALLAST, POUCH, ASSEMBLY, COMPLETE BBX2226 BBX2226PF BBX2732 006187 BBX2732S BBX3542 006188 – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 102: Powerfill Snorkel Drawing

    Parts Listings Section 10: Specifications and Parts PowerFill Snorkel Drawing Note: PowerFill Snorkel is available on models 2024, 2732 and 3542 only. – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 103: Filter Basket Assembly

    Parts Listings Section 10: Specifications and Parts Filter Basket Assembly – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 104 2.6 FT 2226 2.6 FT 2732 3.0 FT 003844 CHAIN, 3/16”, GR30, GLV. 3542 3.7 FT 4453 4.0 FT 5566 4.3 FT 001788 SHACKLE, ANCHOR, SCREW, 1/4, GLV – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 105: Motor Assembly

    Parts Listings Section 10: Specifications and Parts Motor Assembly – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 106 WASHER, FLAT, 0.28 x 0.69 x 0.036, SS 001834 WASHER, FLAT, 0.28 x 0.75 x 1.125, SS 001662 NUT, HEX, NYLOCK, 1/4-20, SS 001734 PIN, SPLIT, 1/8 x 3/8, SS – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 107: Recuperator

    Parts Listings Section 10: Specifications and Parts Recuperator – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 108 001134 BASKET, FILTER, PF2, ASSEMBLY, 5566 000388 BOLT, HEX, 5/16-18 x 1-1/2, SS 000068 WASHER, FLAT, 0.34 x 0.75 x 0.047, SS 001664 NUT, HEX, 5/16-18, SS – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 109: Discharge Hose Assembly

    Parts Listings Section 10: Specifications and Parts Discharge Hose Assembly – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)
  • Page 110 003060 CLAMP, T-BOLT, 4.5”, SS 006516 SCREW, SC 5/16-18 x 2, SS 006702 WASHER, FLAT. 0.34 x 0.69 x 0.08, SS 001664 NUT, HEX, NYLOCK, 5/16-18, SS – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 111: Flapper Valve Assembly

    WASHER, FLAT, 3/16 x 1 x 1/8, NEO 001855 WASHER, FLAT, 0.20 x 0.75 x 0.036, SS 001833 WASHER, FLAT, 0.28 x 0.69 x 0.036, SS 001660 NUT, HEX, NYLOCK, 10-24, SS – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 112: Flange Assembly For Shell

    BATTEN, FIBREGLASS, 1-5/8 X 12-1/2” 2024 006491 BATTEN, FIBREGLASS, 1-5/8 X 20-3/4 2226 2732 006616 BATTEN, FIBREGLASS, 1-5/8 X 20-1/4 3542 006618 BATTEN, FIBREGLASS, 1-5/8 X 27-1/2 – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 113: Bambi Max Carrying Bags

    Parts Listings Section 10: Specifications and Parts Bambi MAX Carrying Bags PART NUMBER DESCRIPTION 005598 BAG, CARRY, BAMBI MAX 1518-1821 005602 BAG, CARRY, BAMBI MAX 2024-3542 Troubleshooter Kit PART NUMBER DESCRIPTION QTY. 001615 CABLE, DRIVE, ASSEMBLY 000236 BUSHING, GUIDE 002328 CLAMP, HOSE, 1/2", SS...

  • Page 114: Section 11: Warranty

    Section 11: Warranty Section 11: Warranty SEI Industries Ltd. (the Company) agrees to grant a warranty for a period of one year from the date of purchase of Bambi MAX systems on the following conditions: a) The company’s sole obligation under this warranty is limited to repairing or replacing, at the company’s sole discretion, any product shown to be defective.

  • Page 115: Appendix: Drawings

    Appendix: Drawings Appendix: Drawings Pilot Controls – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 116: Pilot Controls, Us Interagency

    Appendix: Drawings Pilot Controls, US Interagency – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 117: Crew Controls (Using Remote Power Supply)

    Appendix: Drawings Crew Controls (using remote power supply) – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

  • Page 118: Powerfill Pump

    Appendix: Drawings PowerFill Pump – 2016 Bambi MAX Service Manual Models 1518-3542 We Engineer Solutions (Version E)

This manual is also suitable for:

1518-3542

Table of Contents
