Wet Sounds XS-808 Owner's Manual

Thank You for purchasing this Wet Sounds product !
Wet Sounds professional marine audio products represent the ultimate in high
performance marine audio. Wet Sounds speakers are specifically engineered to
withstand the rigorous marine environment. These speakers were designed to
provide amazing output combined with a cutting edge style. Utilizing state of the
art acoustic engineering and three dimensional computer aided design, the Wet
Sounds marine speakers represent the most advanced marine speakers in the
world.
Please take a moment to read the instruction manual before starting your
installation. If you have any questions or concerns, please contact your certified
Wet Sounds dealer or Wet Sounds at 877-938-7757.

SPEAKER SPECIFICATIONS

SW-808B (Black Cone) SW-808W (White Cone)
XS-808S (Silver Cone) XS-808B (Black Cone)
RMS Watts 125 Watts
Peak Watts 250 Watts
Mid Bass 8.0 inch composite woofer with rubber surround
High Frequency Titanium Dome Tweeter coaxially/separatelly mounted
Impedance 4 ohm
Frequency Response 35Hz to 22KHz
Sensitivity 92dB at 1W/1m
The Wet Sounds XS-808 and SW-808 is a unique speaker system that is a
"convertible" mount system.
The 808 system can be installed as a coaxial based system with the tweeter
mounted in the center of the grille for easy installation. Or the tweeter can be
mounted with the supplied flush mount or surface mount tweeter housing,
giving you an upgrade option for installations where there was currently a
component style speaker or in new installations for added flexibility for tweeter
placement.
Using advanced materials throughout such as our exclusive Nylas™ frame and
grill and rubber spider. Nylas™ is a composite mix of Nylon and Fiberglass
providing improved marine stability and strength over conventional materials
normally used in marine speakers. Wet Sounds has also developed a rubber
spider for the 808 series. Rubber is used for the spider as most marine speakers
use cloth that will deteriorate over time. The 808 series speakers are built to last
in the harshest environments. A full passive crossover network is frame
mounted to the mid bass driver making installation easier without the need to
mount a separate crossover box. With the 808's 8 inch mid bass and 1 inch
titanium tweeter, you have a speaker system that has the ability to produce
amazing volume and details.

Limited Warranty

What this warranty Covers

This is a "Limited warranty. This warranty covers any defects in materials
and workmanship and this warranty only applies to the original purchaser
and is not transferable. This warranty is also only valid if the original
purchase was made from an authorized Wet Sounds

How Long Coverage Last

This warranty runs for two years from the date of the purchase. It
is recommended to REGISTER your warranty online within 45 days of
your purchase at www.wetsounds.com - click "warranty registration".

What is Not Covered

This warranty does not cover fading or discoloration caused by exposure to
sunlight or chemicals such as ammonia, household bleach, or any cleaning
material that contains abrasive substances. Wet Sounds, Inc. does not
cover Blown Speakers and the cost for removal and reinstallation.
Additionally, shipping TO Wet Sounds, Inc. is covered by the purchaser.
This warranty is void and inapplicable if Wet Sounds
product was abused or misused: including but not limited to damage
caused by accident, mishanding, improper installation, negligence, normal
wear and tear, excessive water or heat damage, freight damage or
speakers that have been disassembled by anyone other than Wet Sounds
TM
techinical staff. Wet Sounds shall not be responsible for any incidental or
consequential damages, except to the extent provided ( or prohibited ) by
applicable law. This warranty gives you specific legal rights, and you may
also have other rights which vary from state.

What Wet Sounds, Inc.Will Do

Wet Sounds, Inc will repair any part of your product that proves to be
defective in materials or workmanship. In the event repair is not possible,
Wet Sounds, Inc will replace the product in questions. If it is deemed
necessary Wet Sounds, Inc. Will either replace the entire product with a
refurbished unit or it will be replaced with a model that is similar in price if
that model is no longer available. Labor cost and materials needed to
complete this service will be at no charge to the purchaser. Additionally, the
cost of shipping TO the consumer is also covered under this warranty.

How To Get Service

Contact Wet Sounds, Inc. either by phone at 877-938-7757 or by email at
warranty@wetsounds.com. A service representative will assist you in the
necessary actions to concur that the problem that you are experiencing is
covered under warranty and what to do if it needs to be shipped to Wet
Sounds, Inc.

Internet Warning

W et Sounds, Inc. products sold on any non authorized web site or internet
auction site are void of any and all manufacture's warranty. Please contact
TM
Wet Sounds at 877-938-7757 or
www.wetsounds.com to search for an authorized site and/or an authorized
retailer near you.
Wet Sounds Inc.
1-877-938-7757
www.wetsounds.com
info@wetsounds.com
TM
dealer.
TM
deems that the
visit our web site at
323099/248 20.03.12
SW-808 / XS-808

Marine Speakers
