Bauhn ASPB-1115 Getting Started Manual

Solar Power Bank
Model Number: ASPB-1115
GETTING STARTED GUIDE
This Solar Power Bank is suitable for charging various mobile phones, cameras, GPS systems, MP3/MP4 players, tablets
and other appropriate mobile devices when you cannot connect to the mains supply or computer for recharging. However,
some devices may require a designated charging cable, which is not supplied, but should be included with your
device accessories.
NOTE: Refer to the instruction manual of your device and make sure it has a battery charge rating of DC 5V 2A for optimum
charging.
BOTTOM VIEW
25% 50%
1 2
1. USB output A
2. ON/OFF button
3. LED battery capacity indicator
4. Micro USB charging input
5. USB output B
6. Solar panel
1300 886 649
AUS
75% 100%
3 4 5
FRONT VIEW
6

IMPORTANT!

• Make sure to charge this device at least once every
month in order to maintain the battery in good
condition and avoid potential battery damage.
• When the power bank is charging, its battery
indicator light will glow.

Charging the Power Bank

Connect the Micro USB end of the supplied cable to the
input port and the other end of the cable to your charger.
The charging time of the power bank varies between 4-5
hours via the charging adapter with 5V/2A output. In case
of an emergency, you can use sunlight or other sources of
direct light to charge the inbuilt battery.

Charging a phone or mobile device

Connect the standard USB end of the supplied cable to the
output port and the other end to the Micro USB port of your
mobile device or tablet. Your Solar Power bank will detect
the connection and start charging your unit automatically.
NOTE:
If the Solar Power Bank does not start to charge your unit
automatically, press the ON/OFF button to begin charging.

Checking the remaining battery capacity

Press the ON/OFF button to check the remaining battery
capacity via the battery capacity indicator.

5 Safety Protection Controls

Charge control, charge and discharge protection, overload
protection and short circuit protection.

Specifications

Input DC 5V, 2000mA
Output Dual USB DC 5V, 2100mA (Total)
Solar Charging Up to 180mA
Output
Battery Capacity 7200mAh
Battery Type Li-Polymer
Model: ASPB-1115 Product Code: 51977 12/2015
