Sierra AirLink ES Series Quick Start Manual

®
AirLink ES Series Quick Start Guide
This guide provides instructions for quickly getting your Sierra Wireless
For more information refer to the:
• AirLink ES Series Hardware User Guide
®
• ALEOS Software Confi guration User Guide
Both are available for download from the Sierra Wireless web site (source.sierrawireless.com).

STEP 1 Install the SIM Card

1. Remove the four screws attaching the cover to the gateway's body.
2. Slide the SIM card into the SIM card holder.
Note the location of the notched corner for correct alignment.
3. Re-attach the cover using the screws removed in step 1.

STEP 2 Connect the Gateway

NOTE: If you want to confi gure all your gateways at the same time using AirVantage
to register your gateways before applying power.
© 2015 Sierra Wireless All Rights Reserved
1. Connect the primary
RF antenna.
4. After applying power, connect a Windows
an Ethernet cable. If required by your application, connect the RS-232
port and / or the USB port.
PN 2400427 Rev. 2
® AirLink ® ES Series gateway confi gured and connected.
® Management Service, follow the instructions on page 2
2. Connect the secondary RF antenna.
®
Page 1
3. Connect the power cable to the gateway and
apply power. The gateway starts auto matically,
as indicated by the fl ashing LEDs.
computer to the gateway with
