- Page 1 DC SOLAR PUMP CONTROLLER MODEL:RSC-PV1230 Add : Icon Industrial Park, 300 Barolong Road, Sunderland Ridge 0157 Tel : ( 012) 161-0010 Email : Info@solarwize.net...
-
Page 2: System Feature
Thanks for using our products . Please strictly obey all the instructions in this manual and pay attention to all the warning and operation information . It is not advisable to install or operate the machine before reading this manual . System Feature This controller is fully supported by DC Power from PV Solar Panel (17V/30W), No Eskom power is required. -
Page 3: Troubleshooting
Troubleshooting LED light Problem Possible Solution status Component reasons for problem Blue light is off Solar PV panel The panel was To ensure maximum efficiency the panel installed facing should be installed on the north facing south part of the roof and at a angle of(30-37degrees) The panel is The panel must never at anytime during... -
Page 4: Installation
damaged or not controller( cannot be pulled off with a firm tightly secure tug). Check that there is no damage to on solar the temperature sensor wire. If there is controller damages the temperature sensor will connector port need to be replaced Installation -please ensure the installation is done by a qualified plumber and conforms to the countries installation requirements. - Page 5 -To connect the various components to the controller unit. The screws on the side of the unit must first be removed. The wires from the various components can be neatly passed through the small opening provided at the bottom of the unit( see diagram below) -Please ensure that all components are connected to the correct sockets on the controller and that the solar PV panel and water pump are connected...
-
Page 6: Warranty
Warranties solely cover any defects which has arisen due to the use of faulty material or faults which occurred during the manufacturing process. If there is a fault in any component , while it is still under warranty, Solarwize will repair or replace the faulty component.
