4-Port Ethernet over Fiber
PoE+ Hardened Switches

Installation Guide

Models include:
NetWay4EWP
- Includes Fiber Optic SFP 1G Link,
4-port PoE+ switch and power supply.
- NEMA4/4X, IP66 rated Outdoor enclosure.
NetWay4EWPX
- Includes Fiber Optic SFP 1G Link,
4-port PoE+ switch and power supply.
- NEMA4/4X, IP66 rated Outdoor enclosure.
- Accommodates up to four (4)
12VDC/4AH batteries.
NetWay4EX
- Includes Fiber Optic SFP 1G Link,
4-port PoE+ switch and power supply.
- NEMA1 rated Indoor enclosure.
I.T.E. 43KC
DOC#: NetWay4EWP Rev. 090616
NetWay4EWPN
- Includes Fiber Optic SFP 1G Link and
4-port PoE+ switch
(uses external power supply).
- NEMA4/4X, IP66 rated Outdoor enclosure.
NetWay4EPL
- Includes Fiber Optic SFP 1G Link,
4-port PoE+ switch and power supply.
- Backplane version.
(Not currently evaluated by UL)
NetWay4EB
- Fiber Optic SFP 1G Link and
4-port PoE+ switch
- Board only.
(Not currently evaluated by UL)
More than just power.
Embedded
™
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NetWay4EWP and is the answer not in the manual?

Questions and answers

Related Manuals for Netway NetWay4EWP

Summary of Contents for Netway NetWay4EWP

  • Page 1: Installation Guide

    - Fiber Optic SFP 1G Link and 4-port PoE+ switch - Includes Fiber Optic SFP 1G Link, - Board only. 4-port PoE+ switch and power supply. (Not currently evaluated by UL) - NEMA1 rated Indoor enclosure. I.T.E. 43KC More than just power. DOC#: NetWay4EWP Rev. 090616...

  • Page 2: Agency Listings

    Overview: Altronix NetWay Spectrum Indoor/Outdoor PoE+ Hardened Switches provide a 1Gb SFP port and four (4) PoE+ (30W) ports or up to two (2) Hi-PoE (60W) ports, passing data and power to PoE/PoE+ compliant devices. Cameras/edge devices may be located up to 100m from the unit. Features also include an integral battery charger for applications requiring backup and embedded LINQ Technology to monitor, control and report power and diagnostics from anywhere.

  • Page 3: Installation Instructions

    2. NetWay4EB: Connect 56VDC/120W max power source to terminal marked [+] and [–]. Installation: 1. NetWay4EWP, NetWay4EWPX, NetWay4EX, and NetWay4EPL: Before powering unit, set input voltage selection switch to proper Input Voltage position (Fig. 3a, pg. 6). Units are factory set for 115VAC.

  • Page 4: Technical Specifications

    4. Connect structured cables from port marked [Port 1] to [Port 4] on NetWay unit to PoE compliant cameras/edge devices (Fig. 3, pg. 6). Note: All interconnected devices must be UL Listed. 5. Insert SFP module into port marked [SFP], then connect cable to the SFP module on NetWay4EB to the corresponding input of an SFP switch (Fig.

  • Page 5: Network Settings

    3. Open a browser on the computer and enter “192.168.168.168” into the address bar. A dialog box Authentication Required will appear requesting both user name and password. Enter the default values here. Click on the button labeled Log In. 4. The status page of the NetWay4E will appear. Click on the tab labeled Network Settings. This will open the Network Setting screen.

  • Page 6: Factory Reset

    Factory Reset NetWay4EB Factory Reset PORT 4 30W / 60W PORT 3 PORT 4 PORT 2 30W / 60W PORT 1 + INPUT --- PORT 2 30W 60W 5A 250VA 230VAC 115VAC + BAT – --- DC + - 6 - NetWay4E Series...
  • Page 7 NetWay4EB Factory Reset PORT 4 30W / 60W PORT 3 PORT 4 30W 60W PORT 2 30W / 60W PORT 1 + INPUT --- PORT 2 30W 60W NetWay4E Series - 7 -...

  • Page 8: Wall Mount Installation

    Wall Mount Installation 1- Place unit at desired location and secure with mounting screws (not included) (Fig. 5, pg. 8). Fig. 5 Pole Mounting Using Optional Pole Mount Kit PMK1 (not included): This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 is intended for use with Altronix outdoor rated power supplies or accessories housed in WP1, WP2, WP3 and WP4 enclosures.
  • Page 9 NetWay4EX Mechanical Drawing and Dimensions (H x W x D approx.): 13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm) 1.40” 4.85” 4.85” 1.40” (36mm) (123mm) (123mm) (36mm) 1.20” (31mm) 3.25” (83mm) 12.5” (318mm) 1.20” 1.20” 0.75” 0.75” (31mm) 11.0”...
  • Page 10 NetWay4EPL Mechanical Drawing and Dimensions (H x W x D approx.): 10.75” x 8.875” x 2.375” (273.1mm x 225.4mm x 60.3mm) 8.875” (225.4mm) 8.25” (209.5mm) 0.25” (6.4mm) 10.25” 10.75” (260.3mm) (273.1mm) - 10 - NetWay4E Series...
  • Page 11 NetWay4EWP and NetWay4EWPN Mechanical Drawing and Dimensions (H x W x D approx.): 13.31” x 11.31” x 5.59” (338.1mm x 287.3mm x 142mm) - 11 - NetWay4E Series...
  • Page 12 NetWay4EWPX Mechanical Drawing and Dimensions (H x W x D approx.): 17.53” x 15.3” x 6.67” (445.3mm x 388.6mm x 169.4mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
