  • Page 1 Operation Manual LCR Meter TX7410 DAE KWANG T&M CO.,LTD http://www.kdk.co.kr TEL :02)2617-0787...

  • Page 2: Table Of Contents

    Content CHAPTER 1 GENERAL INTRODUCTION ..................1 1.1 F ............................1 OREWORD 1.2 O ......................... 2 PERATING ONDITIONS 1.2.1 Power requirements ..................... 2 1.2.2 Opearing temperature and humidity ................2 1.2.3 Warm-up time ........................ 3 1.2.4 Notices ..........................3 1.3 D &...
  • Page 3 CHAPTER 4 OPERATION INSTRUCTIONS.................. 18 4.1 T ..................... 18 URNING ON THE NSTRUMENT 4.2 F ......................... 18 UNCTION PERATIONS 4.2.1 Primray parameter setup ................... 18 4.2.2 Secondary parameter setup ..................18 4.2.3 Frequency setup ......................19 4.2.4 Signal voltage ......................19 4.2.5 Measurement speed ....................

  • Page 4: Chapter 1 General Introduction

    TX7410 is a precision LCR meter with high accuracy, good stability, and wide measurement range. Controlled by a 16 bits MPU, TX7410 can be used for evaluating LCR components, materials and semiconductor devices over a wide range of frequencies (50 Hz to 100 kHz) and test signal levels (0.1V, 0.3V, 1V).

  • Page 5: Operating Conditions

    TX7410 has the file function to store the set parameters, limit parameters and list sweep parameters as a file in the internal nonvolatile memory, so that the setups can be easily reloaded, and the defult file will be automatically reloaded when TX7410 is turned on.

  • Page 6: Warm-Up Time

    TX7410 Operation Manual 1.2.3 Warm-up time More than 20 minutes after the instrument is turned on. 1.2.4 Notices Please do not operate the instrument in the place that is vibrative, dusty, under direct  sunlight, or where there is corrosive air.

  • Page 7: Electromagnetic Compatibility

    TX7410 Operation Manual DO NOT attempt service or adjustment alone  Do not attempt internal service or adjustment unless another person, capable of rendering first aid and resuscitation, is present. DO NOT substitute parts or modify instrument  Because of the danger of introducing additional hazards, do not install substitute parts or perform unauthorized modifications to the instrument.
  • Page 8 TX7410 Operation Manual FREQ frequency go to local group execution trigger GPIB general-purpose interface Bus Handler interface index interface clear internal KBEEP kep beep KLOCK key lock primary inductance by 2-wire measurement secondary inductance by 2-wire measurement liquid crystal display...
  • Page 9 TX7410 Operation Manual SREJ secondary reject SRES source resistor TRGEG trigger edge TRIG trigger reactance, imaginary part of impedance impedance θ phase angle 4-terminal pair...

  • Page 10: Chapter 2 Basic Specifications

    TX7410 Operation Manual Chapter 2 Basic Specifications 2.1 Measurement Functions 2.1.1 Measurement parameters L: inductance C: capacitance R: resistance Z: impedance X: reactance D: dissipation θ: phase angle Q: quality factor 2.1.2 Combinations of measurement parameters Primary paratmeter Secondary parameters θ°...

  • Page 11: Range

    When the trigger mode is set to BUS trigger mode, the instrument performs a single measurement every time the *TRG common command is sent to TX7410 via GPIB. The BUS trigger mode cannot be set on the front panel. Send the TRIGger:SOURce BUS command via GPIB or RS232C to set the trigger mode to the BUS trigger mode.

  • Page 12: Measurement Terminal Mode

    TX7410 Operation Manual 2.1.7 Measurement terminal mode Common measurement: 4-terminal pair Hcur: high current (abbreaviation: Hc) Lcur: low current (abbreaviation: Lc) Hpot: high potential (abbreaviation: Hp) Lpot: low potential (abbreaviation: Lp) Transformer measurement: 2-terminal Hpot---Lpot: transformer’s primary (winding A) Hcur---Lcur: transformer’s secondary (winding B) Note: Make sure shielding terminals of Hcur and Lcur are reliably short with low impedance when the test fixtures or cables used don’t come standard with the instrument.

  • Page 13: Output Impedance

    TX7410 Operation Manual Accuracy: ±(10%×set value+2mV) 2.2.3 Output impedance 30Ω±5%, 100±5% (fixed at 100Ω source impedance at bias mode) 2.2.4 Measurement display range Parameter Display range 0.001μH～99.999kH 0.001pF～9999.9μF R, X, Z 0.0001Ω～99.999MΩ 0.0001～9.9999 0.0001～9999.9 Angle: -179.99°～179.99° θ Radian: -3.1415～3.1415 -99.999%～999.99% If non-percentage data is out of display range, it will be displayed as 99999.

  • Page 14: Parameter Display

    TX7410 Operation Manual AUX BI N : Primary parameter is within limits, but whose secondary parameter measurement result is not within limits. Sorting mode: ABS (absolute deviation): absolute deviation between measured result and nominal value is compared with bin limit.

  • Page 15: Memory

    TX7410 Operation Manual 2.3.6 Memory The instrument’s measurement parameter, such as frequency and level, measurement setups, comparator’s limit data can be stored in nonvolatile storage in the form of files. When they’re needed, they can be loaded directly from file menu to save time. And the latest saved and loaded file will be automatically loaded when the instrument is turned on next time.

  • Page 16: Chapter 3 Panel Introductions

    TX7410 Operation Manual Chapter 3 Panel Introductions 3.1 A Tour of Front Panel Figure 3-1 Front panel overview Figure 3-2 Softkeys Brand and Model The registered brand of our company and model of the instrument are printed. 240×64 dot-matrix Liquid Crystal Display (LCD) displays measurement results, test conditions, etc.
  • Page 17 TX7410 Operation Manual Power on/off Power on/off switch. In the “I” position all operating voltages are applied to the instrument. In the “O” position NO operating voltages are applied to the instrument. Softkeys They have functions of three levels: a) Functions by directly pressing softkeys...

  • Page 18: A Tour Of Rear Panel

    TX7410 Operation Manual UNKNOWN terminals These are the UNKNOWN Terminals used to connect a four-terminal pair test fixture or test leads for measuring the device under test. HD(H ): High current drive HS(H ): High potential sense LS(L ): Low potential sense...

  • Page 19: Display Description

    If the power cord doesn’t ground or isn’t reliably grounding, please connect grounding line! 6）LINE input receptacle AC power cord receptacle. Fuse holder Fuse holder for TX7410 line fuse, 220Vac, 1A. 3.3 Display Description Figure 3-4 Display area Alarm display “...
  • Page 20 AC parameters, so current display and operatable range can be switched. Secondary parameter indicator It indicates secondary parameters of the currently measured component. TX7410 has the following secondary parameters: θ° (angle), θr (radian), R, X, Q, D. 10) Comparator indicator “COMP” on: Comparator function is turned on.

  • Page 21: Chapter 4 Operation Instructions

    —— X; —— θr (radian); 4.2.2 Secondary parameter setup TX7410 has the following common secondary parameters: θ° (angle), θr (radian), R, X, Q, TX7410 also has the function of measuring DC resistance and transformer parametersw. Secondary parameters differ with parimary parameters:...

  • Page 22: Frequency Setup

    TRIGGER key once. 4.2.7 Range setup TX7410 totally has 9 ranges: 10Ω, 30Ω, 100Ω, 300Ω, 1kΩ, 3kΩ, 10kΩ, 30kΩ, 100k. Please select range accoding to the impedance of the device under test. Please refer to the following table for range and its corresponding measurement range.

  • Page 23: Open Correction

    4.2.8 Open correction Press SHIFT + OPEN to enter open correction menu. TX7410’s open correction function can eliminate the effect of test cable, test fixture and stray admittance in parallel with the device under test, such as stray capacitance. Perform the following steps to perform open correction: 1.

  • Page 24: Short Correction

    4.2.9 Short correction Press SHIFT + SHORT to enter short correction menu. TX7410’s open correction can eliminate the effect of test cable, test fixture and stray impedance in series with the device under test, such as lead resistance or lead inductance.

  • Page 25: Comparator

    TX7410 Operation Manual For example: 1. The current display mode is DIR, and “DIR” is displayed on LCD, as shown in Figure4-5. Figure 4-5 Direct display mode 2. Press SHIFT key, “SHIFT” at left corner is on. 3. Press DISP key, “...
  • Page 26 When the trigger mode is set to BUS trigger mode, the instrument performs a single measurement every time the *TRG common command is sent to TX7410 via GPIB. The BUS trigger mode cannot be set on the front panel. Send the TRIGger:SOURce BUS command via GPIB or RS232C to set the trigger mode to the BUS trigger mode.
  • Page 27 TX7410 Operation Manual b) Press 【▲】or【▼】 to select “INT”, “MAN”, or “EXT”. DELAY Programmable delay from the trigger command to the start of the measurement, 0 to 60.000 s in 1 ms steps. Perform the following steps to set delay time (unit: ms) a) Select “DELAY”...
  • Page 28 TX7410 Operation Manual Figure 4-11 Resistance selection DCHR Perform the following steps to turn on or off discharging test: Select “DCHR” through 【 】key, as shown in Figure4-12. 】or【 b) Press 【▲】or【▼】key to select “ON” or “OFF”. Press 【ENTER】key or 【ESC】key to exit.

  • Page 29: Limit List Setup

    TX7410 Operation Manual Figure 4-15 Correction switch 4.2.13 Limit list setup TX7410 can set 3-bin limit data of primary parameter, and 1-bin limit data of secondary parameter. The comparison result can be indicated through sorting indicators: OUT: fail; pass bin 1;...
  • Page 30 TX7410 Operation Manual Measurement completes Higher primary parameter (PHI) Primary parameter comparison Lower primary parameter (PLO) BIN 1 comparison first; If fails, BIN 2 comparison; No pass bins FAIL BIN (OUT) If fails, BIN 3 comparison Primary parameter passes some bin...
  • Page 31 TX7410 Operation Manual BIN3L: low limit of primary parameter 3; BIN3H: high limit of primary parameter 3; SEC L: low limit of secondary parameter; SEC H: high limit of secondary parameter; At limit setup page, press 【 】 key to select item, press【▲】or 【▼】 key 】or 【...
  • Page 32 TX7410 Operation Manual point to twinkle, then press【▲】or【▼】key to move it. If multiple needs modifying, press 【 】key to select the unit and multiple 】or【 to twinkle, then press【▲】or【▼】key to modify multiple. g) After setting, press 【ENTER】key to ensure the modification, or【ESC】key to cancel it.

  • Page 33: File Operation Function

    TX7410 Operation Manual Figure 4-22 Limit setup of secondary parameter 4.2.15 File operation function Perform the following steps to enter file operation page: At test status, press SHIFT key, and “SHIFT” at left corner is on. Press FILE key to enter file operation page, and the instrument first displays currently-used file No., (if no file is loaded, the default setup of file No.

  • Page 34: System Function Setup

    TX7410 Operation Manual Figure 4-24 Loading file ERASE Perform the following steps to erase file: Select “ERASE” at file operation page through【 】key, as shown in 】or【 Figure4-25. b) Press 【 ▲】 or 【 ▼】 key to select erasing file No. Displayed “Y” means the file has existed, and “N”...
  • Page 35 Press 【ESC】key to exit. Figure 4-27 Communication address setup BAUD TX7410’s RS232C supports 8 common baud rates: 4800bps, 9600bps, 11520bps, 12800bps, 14400bps, 19200bps, 28800bps, and 38400bps. Perform the following steps to select baud rate: At system setup page, select “BAUD” through 【...
  • Page 36 TX7410 Operation Manual Figure 4-28 Baud rate setup DELIM TX7410 supports to send several common ending symbols: line change symbol (ASCII ode 100); CR： enter symbol (ASCII code 13); CR +LF: enter to change line Perform the following steps to select: At system setup page, select “DELIM”...
  • Page 37 】or【 4-32. b) Press 【▲】or【▼】key to select HOLD or CLEAR. Press 【ENTER】key or【ESC】key to exit. Figure 4-32 HANDLER interface’s signal hold ALARM TX7410 provides alarm function for sorting result. OFF: alarm off; N OGO: alarm at fail (no good); AUX: alarm at auxiliary bin;...
  • Page 38 TX7410 Operation Manual There are 6 sounds available: LO.SHT: low and short; LO.LON: low and long; LO.TW O: two short and low; HI .SHT: high and short; HI .LON : high and long; HI .TW O: two short and high Perform the following steps to set sound: At system setup page, select “SOUND”...
  • Page 39 TX7410 Operation Manual Figure 4-36 Keylock on/off setup After keylock is set, function keys on panel can’t be available. Press SHIFT, then SYSTEM to enter “KLOCK” operation, press 【▲】or【▼】to unlock. 12) SAVE Perform the following steps to save setups: Select “SAVE” through 【...

  • Page 40: Chapter 5 Remote Control

    TX7410 has the RS232C serial interface and the parallel GPIB (optional) interface. Both interfaces can be used to remotely control TX7410 , but they can not be used at the same time. The two interfaces share the same program commands, but they have different hardware configurations and different communication protocols.

  • Page 41: Communication With A Computer

    GND(5) (5) GND RTS(7) CTS(8) There may be some difference between TX7410 ’s RS232 interface and a standard RS232C interface. You can make the connection cable by yourself according the diagram or order one from our company. Note: Pin 4 and 6, pin 7 and 8 are shorted respectively at the end of controller.
  • Page 42 The controller sends the command using the ASCII code with NL as the end character. TX7410 executes the command after the end character NL is received. The character received by TX7410 will be sent back to the controller again. The controller will not send the next character until the last return character is received correctively from TX7410 .
  • Page 43 For some commands that will take a long time to execute, for example Correction command, the controller should keep waiting to avoid the next command being lost when TX7410 is executing the former command. Sample Program for Serial Interface ...
  • Page 44 & 256 ) { c = read_port( PORT ); break; if( n ) break;/*TX7410 /C not ready for receive*/ if( c != 0xcc )/*check receive*/ { printf( "\ nE10:Serial Port HandShake Failure!" ); exit(1); /*handshake success,begin send string：*/ for( ;*ps;...
  • Page 45 TX7410 Operation Manual if( c == '\ n' ) break; *ps = c; ps++; *ps = 0; /* send a character to serial port */ void send_port( int port,char c ) union REGS r; r.x.dx = port; /* serial port */ r.h.ah = 1;...

  • Page 46: Gpib Interface Introduction

    TX7410 Operation Manual { union REGS r; r.x.dx = port; /* serial port */ r.h.ah = 0; /* int14 function0:initial serial port */ r.h.al = code; /* initialization code */ int86( 0x14,&r,&r ); 5.2 GPIB Interface Introduction 5.2.1 GPIB connection When configuring a GPIB system, the following restrictions must be adhered to.
  • Page 47 TX7410 Operation Manual Typical GPIB System Interconnection-1 Figure 5-2 Typical GPIB System Interconnection-1 Typical GPIB System Interconnection-2 Figure 5-3 Typical GPIB System Interconnection-2...

  • Page 48: Gpib Interface Functions

    TX7410 's GPIB address is stored in non-volatile memory and can be set to any address from 0 to 30 by front panel key entry in the System Config page. When TX7410 is shipped from the factory, the default GPIB address is 8. For more information, refer to “ 4.2.16 GPIB Address”.

  • Page 49: Data Format

    TX7410 Operation Manual 5.2.5 Data format TX7410 outputs the measurement results using the ASCII via the GPIB bus. The Format 1 M easDisplay BinN o. Disp Bin Count is used by page, page and page, while Format 2 is List Sw eep used by page.

  • Page 50: Chapter 6 Handler Interface

    The handler interface also has an input for an external trigger signal. Using these signals, TX7410 can easily be combined with a component handler and a system controller to fully automate component testing, sorting, and quality control data processing to increase production efficiency.
  • Page 51 All bin sorting signal outputs are opto-isolated open collector. /TRIG External Trigger: TX7410 is triggered on the rising edge of a pulse applied to /TRIG this pin when the trigger mode is set to EXT mode. EXV2 External DC voltage 2:...
  • Page 52 TX7410 Operation Manual COM2 COM1 Common for EXTV1 COM1 COM1 Table 6-2 Pin assignments for comparator function PHI（OUT） Primary BIN 1 Parameter BIN 2 SREJ（AUX） SREJ（AUX） BIN 3 PLO（OUT） Secondary Parameter Figure 6-1 /PHI, /PLO, /SREJ signal’s area example Figure 6-2 Pin assignment for handler interface connector...

  • Page 53: Electrical Characteristics

    TX7410 Operation Manual T1 T2 /TRIG /IDX /EOM Result previous valid data valid data hold or clea one measurement period next period Time delay measurem calculating & display measurem triggger setup ent time comparing time ent delay Time Min. value Max.
  • Page 54 TX7410 Operation Manual the internally supplied voltage (+5V), or to an externally applied voltage ( EXTV: +5V to +24V) by setting jumpers. The electrical characteristics of the DC isolated outputs are divided into two types (See Table 6-4). Since the power source for the Comparison Output and Control Output signals are different, two circuit commons (COM1, COM2) are made available.
  • Page 55 TX7410 Operation Manual HANDLER interface board HANDLER interface connector 14,15 EXV2 internal +5V power J203 pull-up resistance 4.7k /IDX /EOM 32,33 COM2 J204 grounding *Default jumper wire position Figure 6-6 Simplified diagram of the control output signals HANDLER interface board...

  • Page 56: Dc Isolated Input

    TX7410 Operation Manual 6.3.2 DC Isolated Input HANDLER interface board HANDLER interface connector Iternal +5V power 14,15 EXV2 J203 12,13 /TRIG 1.2k 2.2k trigger resistance with J205 limit current 32,33 COM2 J204 grounding *Default jumper wire position Figure 6-8 Simplified digram of HANDLER interface’s trigger input signals...

  • Page 57: Chapter 7 Packing & Warranty

    TX7410 Operation Manual Chapter 7 Packing & Warranty 7.1 Packing The contents are listed as follows: Description Quantity TX7410 LCR Meter TX7003 Test Fixture TX7000 Kelvin Test Cable TX26010 Shorting Plate Three-Wire Power Cord 1A Fuse Operation Manual Test Report Check the contents when you receive the instrument.
