Chilipepper CP-2011 Installation Instructions

Chilipepper CP2011
Installation Instructions
WARNING: Risk of electric shock. This pump is supplied with a
grounding conductor and a grounding-type attachment plug. To
reduce the risk of electric shock, be certain that it is connected
only to a properly grounded grounding-type receptacle.

Package Contents.

The Chilipepper Appliance
Hex Adjusting Tool
Temperature Adjusting Screw Driver
One push button with cable
Two brass "T" fittings
ANY OF THESE ITEMS CAN VOID THE WARRANTY
* Flexible hosing MUST be used. The Chilipepper was NOT
designed for rigid pipe connections.
* Be careful connecting or disconnecting the hoses to the
Chilipepper, too much torque could damage or break the pump
head.
* DO NOT USE pipe dope on the connections to the Chilipepper,
(Teflon tape is OK)
impeller and slow it down or burn up the pump.
* The Chilipepper IS NOT waterproof. Dry off the unit as soon as
possible if it gets wet.

INSTALLING THE CHILIPEPPER

1. Turn off the Hot and Cold water shut-off valves under the sink that
supply water to the sink fixture. (Fig 1)
2. Open the faucet to relieve any system pressure.
3. Disconnect the existing hoses from both shut-off valves.
4. Connect the brass T's to the shut-off valves. (Fig 2)
( Most homes have 3/8 in. compression fittings on the shut-off
valves
but if the thread size is different a brass adaptor will be needed.)
5. Inspect the rubber washers in the hoses to make sure they can be
reused and then connect the two existing hoses to the brass T's.
(Fig 3)
6. Connect two new hoses to the Chilipepper, placing the unit
on the floor of the cabinet. (Fig 4)
Pipe Dope could get into the pump
