*44487056*
44487056
Power Supply
These instructions cover the following parts:
:
IN G
R N
W A
!
:
IN G
R N
W A
!
ER
NG
DA
!
F1
:
ER
N G
D A
!
PS914
Power Supply
Pages 1-3
Input
Output
Enclosure
Temperature Range
Fuse
Compliance
Compatible Boards
(Optional, 2 boards maximum)
Fire Alarm Input Board (Optional) 900-FA (Requires one option board above)
Battery Backup Board (Optional)
AC Monitor Output
Inputs I1,I2
Outputs O1,O2
Board Input Power
Temperature Range
Compliance
Fire Alarm Input
To avoid risk of electric shock, turn off AC power before
installing or servicing PS914 power supply
900-KL Keylock
(optional)
Page 2
PS914 Power Supply Specifications:
120/240 VAC, 1.4 A, 50/60Hz, High Voltage Class 1 Wiring Required
4 Amp DC @ 12/24 VDC
May be used to power Von Duprin & Falcon EL device at 24VDC, 16A, 300ms
14" H x 12" W x 4" D (8 knockouts, 1/2" or 3/4" )
32°-120° F (0°- 49° C)
F1, T6.3A
250 VAC
For protection against risk of fire, replace fuse with same type and rating
UL 294, ULC-S318, RoHS, & FCC Part 15, Class 2 Output
900-2RS
900-2Q
900-4R
900-4RL
900-8F
900-8P
900-BB
Form C Contacts, 30 VDC, 1 Amp, Resistive Load
900-2RS Specifications:
Dry contacts required (Closed = Active)
Connect control contacts between SC (Signal Common) and any input
• 12/24VDC, 3A (wet) when AC powered • 9.6-13.2VDC or 19.2-26.4VDC when battery powered
• May be used with PS914 to power EL device at 24VDC, 16A, 300ms
• Maximum load cannot exceed power supply ratings or 3A for outputs combined
Board requires 0.1A max. of power supply output current to operate
32°-120° F (0°- 49° C)
UL 294, ULC-S318, RoHS, & FCC Part 15
Accepts 900-FA Fire Alarm Board (Optional)
PS914
DANGER
900-BB Battery Backup
(optional)
Page 3
INST. INSTRUCTIONS - 44487056
INST. INSTRUCTIONS - 44487098
INST. INSTRUCTIONS - 44487106
INST. INSTRUCTIONS - 44487080
INST. INSTRUCTIONS - 44487106
INST. INSTRUCTIONS - 44487106
INST. INSTRUCTIONS - 44487072
INST. INSTRUCTIONS - 44487064
Installation Instructions
900-2RS (optional) - Page 4
(2 Zone EL Control -
Individual/Sequential)
CAUTION
