Page 1 NMS USER MANUAL WAP-EN Series Wireless Access Points Version 1.2, June 2017...
Page 2 Copyright Copyright© 2017 Comtrend Corporation. All rights reserved. The information contained herein is proprietary to Comtrend Corporation. No part of this document may be translated, transcribed, reproduced, in any form, or by any means without the prior written consent of Comtrend Corporation. This program is free software: you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version. This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details. You should have received a copy of the GNU General Public License along with this program. If not, see http://www.gnu.org/licenses/ NOTE: This document is subject to change without notice.
Page 3: Product Information
I. Product Information The Network Management Suite (NMS) supports the central management of a group of access points, otherwise known as an AP Array. NMS can be installed on one access point and support up to 5 access points or on a Wireless LAN Controller (WLC) and support up to 50 access points. Access points can be deployed and configured according to your requirements. This flexibility creates a powerful network architecture which can be easily managed and expanded in the future. The easy to use interface and a full range of functionality make the NMS system ideal for small and mid-sized office environments.
Page 4: Table Of Contents
Table of Contents I. Product Information ............................3 II. Quick Setup ................................7 III. Software Layout .............................. 10 IV. Features ................................15 IV-1. LOGIN, LOGOUT & RESTART .......................... 15 IV-2. DASHBOARD ..............................17 IV-2-1. System Information ............................ 18 IV-2-2. Devices Information ........................... 18 IV-2-3. Managed AP ............................... 19 IV-2-4. Managed AP Group ............................ 20 IV-2-5. Active Clients .............................. 21 IV-2-6. Active Users ............................... 21 IV-3. ZONE PLAN ..............................22 IV-4. NMS MONITOR .............................. 24 IV-4-1.
Page 5 V-5-13-3. System Accounts ........................... 81 IV-6. Local Network ..............................83 IV-6-1. Network Settings ............................83 IV-6-1-1. LAN-Side IP Address ..........................83 IV-6-1-2. LAN Port Settings ............................ 86 IV-6-1-3. VLAN ................................ 87 IV-6-2. 2.4GHz 11bgn (Not available on the WLC-6404) ..................88 IV-6-2-1. Basic ................................ 88 IV-6-2-2. Advanced ..............................89 IV-6-2-3. Security ..............................91 IV-6-2-3-1. No Authentication ..........................92 IV-6-2-3-2. WEP ..............................92 IV-6-2-3-3. IEEE802.1x/EAP ..........................93 IV-6-2-3-4.
Page 6 IV-6-7. WMM (Not available on the WLC-6404) ....................113 IV-6-8. Internal Server ............................114 IV-6-8-1. Internal RADIUS Server ......................... 114 IV-6-8-2. RADIUS Accounts ..........................116 IV-6-9. Schedule ..............................117 IV-7. Local Settings ............................... 118 IV-7-1. Operation Mode (Not available on the WLC-6404) .................. 118 IV-7-2. System Settings ............................118 IV-7-2-1. System Information ..........................118 IV-7-2-2. Wireless Clients (Not available on the WLC-6404) ................121 IV-7-2-3. Wireless Monitor (Not available on the WLC-6404) ................122 IV-7-2-4. Log ................................. 123 IV-7-3. Management ............................125 IV-7-3-1.
Page 7: Ii. Quick Setup
II. Quick Setup One device is designated as the AP Controller (master) and other connected APs are designated as Managed APs (slaves). Using the NMS you can monitor, configure and manage all Managed APs. Up to 5 APs can be managed from an EN-Series Wireless Access Point in AP Controller Mode or 50 APs can be managed from a dedicated WLC-6404 Wireless Access Point Controller. Follow the steps below: Connect all APs to an Ethernet or PoE switch which is connected to a gateway/router. You can use your router as a DHCP server or you can later configure your AP Controller as a DHCP server. Ensure all APs are powered on and check the LED status.
Page 8 Connect the AP Controller, which will manage all other connected APs, to power and turn the device on. Connect a computer to the AP Controller using an Ethernet cable. Open a web browser and enter the AP Controller’s IP address in the address field. The default IP address is listed in the User Manual for your controller. Typically it is either 192.168.2.1 or 192.168.2.2. DHCP is enabled on the access point by default. Consult the DHCP Table of your network for the Controller’s IP Address. If no DHCP Service is found, the access point will default to the default IP address listed in the User Manual. Typical default IP addresses are either 192.168.2.1 or 192.168.2.2. Your computer’s IP address must be in the same subnet as the AP Controller. 192.168.2.10 is being used in this example. Enter the username & password to login. The default username & password are admin & 1234 respectively.
Page 9 If using an EN-Series AP as a controller, you will arrive at the Access Point Information screen. Go to !“Operation Mode” and select “AP Controller Mode” from the drop down menu to initiate Controller Mode. Click “Apply” to save the settings. Your Controller AP & Managed APs should be fully functional. Use the top menu to navigate around the NMS. Use Local Network & Local Settings to configure your Controller AP. Use Dashboard, Zone Plan, NMS Monitor & NMS Settings to configure Managed APs. Use Toolbox to diagnose connection issues.
Page 10: Iii. Software Layout
III. Software Layout The top menu features 7 panels: Dashboard, Zone Plan, NMS Monitor, NMS Settings, Local Network, Local Settings & Toolbox. Screenshots displayed are examples. The information shown on your screen will vary depending on your configuration and device being used as a controller. Dashboard The Dashboard panel displays an overview of your network and key system information, with quick links to access configuration options for Managed APs and Managed AP groups. Each panel can be refreshed, collapsed or moved according to your preference. (Available settings will vary depending on the device being used as an AP Controller.)
Page 11 Zone Plan Zone Plan displays a customizable live map of Managed APs for a visual representation of your network coverage. Each AP icon can be moved around the map, and a background image can be uploaded for user-defined location profiles using NMS Settings ! Zone Edit. Options can be configured using the menu on the right side and signal strength is displayed for each AP. (Available settings will vary depending on the device being used as an AP Controller.) NMS Monitor The NMS Monitor panel provides more detailed monitoring information about the AP Array than found on the Dashboard, grouped according to categories in the menu down the left side. (Available settings will vary depending on the device being used as an AP Controller.)
Page 12 NMS Settings NMS Settings provides extensive configuration options for the AP Array. You can manage each access point, assign access points into groups, manage WLAN, RADIUS as well as upgrade firmware across multiple access points. The Zone Plan can also be configured using “Zone Edit”. (Available settings will vary depending on the device being used as an AP Controller.) Local Network Local Network settings are for your AP Controller. You can configure the IP address and DHCP server of the AP Controller in addition to 2.4GHz & 5Ghz Wi-Fi and security, with WPS, RADIUS server, MAC filtering and WMM settings...
Page 13 also available. (Available settings will vary depending on the device being used as an AP Controller.) Local Settings Local Settings are for your AP Controller. You can set the operation mode and view network settings (clients and logs) specifically for the AP Controller, as well as other management settings such as date/time, admin accounts, firmware and reset. (Available settings will vary depending on the device being used as an AP Controller.)
Page 14 Toolbox The Toolbox panel provides a network diagnostic tools: ping and trace route.
Page 15: Iv. Features
IV. Features Descriptions of the functions of each main panel Dashboard, Zone Plan, NMS Monitor, NMS Settings, Local Network, Local Settings & Toolbox can be found below. (Available settings will vary depending on the device being used as an AP Controller.) When using the NMS, click “Apply” to save changes: Screenshots displayed are examples. The information shown on your screen will vary depending on your configuration. IV-1. LOGIN, LOGOUT & RESTART It is recommended that you login to the AP Controller to make configuration changes to Managed APs. LOGIN 1. Connect a computer to the designated AP Controller using an Ethernet cable: 2. Open a web browser and enter the AP Controller’s IP address in the address field. The default IP address is listed in the User Manual for your controller. Typically it is either 192.168.2.1 or 192.168.2.2. Your computer’s IP address must be in the same subnet as the AP Controller. Refer to V-1. Configuring your IP Address for more help. DHCP is enabled on the access point by default. Consult the DHCP Table of your network for the Controller’s IP Address. If no DHCP Service is found, the access point will default to the default IP address listed in the User Manual. Typical default IP addresses are either 192.168.2.1 or 192.168.2.2.
Page 16 If using a DHCP server on the network, it is advised to use your DHCP server’s settings to assign the AP Controller a static IP address. 3. Enter the username & password to login. The default username & password are admin & 1234. RESTART You can restart your AP Controller or any Managed AP using the NMS. To restart your AP Controller go to Local Settings ! Advanced ! Reboot and click “Reboot”. To restart Managed APs click the Restart icon for the specified AP on the Dashboard:...
Page 17: Iv-2. Dashboard
IV-2. DASHBOARD The dashboard displays an overview of your AP array: Use the blue icons above to refresh or collapse each panel in the dashboard. Click and drag to move a panel to suit your preference. You can set the dashboard to auto-refresh every 1 minute, 30 seconds or disable auto-refresh:...
Page 18: Iv-2-1. System Information
IV-2-1. System Information System Information displays information about the AP Controller: Product Name (model), Host Name, MAC Address, IP Address, Firmware Version, System Time, Uptime, CPU Usage and Memory Usage. IV-2-2. Devices Information Devices Information is a summary of the number of all devices in the local network: Access Points, Clients Connected, and Rogue (unidentified) Devices.
Page 19: Iv-2-3. Managed Ap
IV-2-3. Managed AP Managed AP displays information about each Managed AP in the local network: Index (reference number), MAC Address, Device Name, Model, IP Address, 2.4GHz & 5GHz Wireless Channel Number, No. of Clients connected to each access point, and Status (connected, connecting or disconnected). The search function can be used to locate a specific Managed AP. Type in the search box and the list will update: The Status icon displays grey (disconnected), yellow (connecting) or green (connected) for each Managed AP. Each Managed AP has “Action” icons with the following functions: 1. Disallow Remove the Managed AP from the AP array and disable connectivity. 2. Edit Edit various settings for the Managed AP (refer to IV-5-1. Access Point). 3. Blink LED The Managed AP’s LED will flash temporarily to help identify & locate access points. 4. Buzzer The Managed AP’s buzzer will sound temporarily to help identify & locate access points. 5. Network Connectivity Go to the “Network Connectivity” panel to perform a ping or traceroute. 6. Restart Restarts the Managed AP.
Page 20: Iv-2-4. Managed Ap Group
IV-2-4. Managed AP Group Managed APs can be grouped according to your requirements. Managed AP Group displays information about each Managed AP group in the local network: Group Name, MAC Address, Device Name, Model, IP Address, No. of Clients connected to each access point, and Status (connected or disconnected). To edit Managed AP Groups go to NMS Settings ! Access Point (refer to IV-5-1. Access Point). The search function can be used to locate a specific Managed AP Group. Type in the search box and the list will update: The Status icon displays grey (disconnected), yellow (connecting) or green (connected) for each individual Managed AP. Each Managed AP has “Action” icons with the following functions: 1. Disallow Remove the Managed AP from the AP array and disable connectivity. 2. Edit Edit various settings for the Managed AP (refer to IV-5-1. Access Point) 3. Blink LED The Managed AP’s LED will flash temporarily to help identify & locate access points. 4. Buzzer The Managed AP’s buzzer will sound temporarily to help identify & locate access points. 5. Network Connectivity Go to the “Network Connectivity” panel to perform a ping or traceroute.
Page 21: Iv-2-5. Active Clients
6. Restart Restarts the Managed AP. IV-2-5. Active Clients Active Clients displays information about each client in the local network: Index (reference number), Client MAC Address, Device Name, Model, IP Address, 2.4GHz & 5GHz Wireless Channel Number, No. of Clients connected to each access point, and Status (on or off). The search function can be used to locate a specific client. Type in the search box and the list will update: IV-2-6. Active Users Active Users displays information about each user in the local network: Index (reference number), User Name, MAC Address, IP Address, SSID, Creator, Creation Time, Expire Time, Usage Percentage, Vendor, Platform and Action. The search function can be used to locate a specific user. Type in the search box and the list will update:...
Page 22: Iv-3. Zone Plan
IV-3. ZONE PLAN The Zone Plan can be fully customized to match your network environment. You can move the AP icons and select different location images (upload location images in NMS Settings ! Zone Edit) to create a visual map of your AP array. Use the menu on the side to make adjustments and mouse-over an AP icon in the zone map to see more information. Click an AP icon in the zone map to select it and display action icons. Click and drag an AP icon to move the icon around the zone map. The signal strength for each AP is displayed according to the “Signal” key in the menu on the right side: Location Select a pre-defined location from the drop down menu. When you upload a location image in NMS Settings ! Zone Edit, it will be available for selection here.
Page 23 AP Group You can select an AP Group to display in the zone map. Edit AP Groups in NMS Settings ! Access Point. Search Use the search box to quickly locate an AP. Radio Use the checkboxes to display APs according to 2.4GHz or 5GHz wireless radio frequency. Signal Signal strength key for the signal strength display around each AP in the zone map. Zoom Use the slider to adjust the zoom level of the map. Transparency Use the slider to adjust the transparency of location images. Scale Zone map scale. Device/Number Displays number and type of devices in the zone map.
Page 24: Iv-4. Nms Monitor
IV-4. NMS MONITOR IV-4-1. Access Point IV-4-1-1. Managed AP Displays information about each Managed AP in the local network: Index (reference number), MAC Address, Device Name, Model, IP Address, 2.4GHz & 5GHz Wireless Channel Number, No. of Clients connected to each access point, and Status (connected, connecting or disconnected). The search function can be used to locate a specific Managed AP. Type in the search box and the list will update: The Status icon displays the status of each Managed AP. Status Icons Icon Color Status Definition Managed AP is disconnected. Check the network connection and ensure the Grey Disconnected Managed AP is in the same IP subnet as the AP Controller. System security must be the same for all access points in the AP array. Please Authentication check security settings (refer to IV-5-12-1. Failed System Security). Red Access points must use the same version of NMS as the Controller. Use the AP Incompatible Controller’s firmware upgrade function NMS Version (refer to IV-5-11. Firmware Upgrade) to synchronize the NMS version.
Page 25 Configuring or Managed AP is making configuration Orange Upgrading changes or upgrading the firmware. Yellow Connecting Managed AP is connecting. Green Connected Managed AP is connected. Waiting for Blue Managed AP is waiting for approval. Approval Each Managed AP has “Action” icons with the following functions: 1. Disallow Remove the Managed AP from the AP array and disable connectivity. 1. Edit Edit various settings for the Managed AP (refer to IV-5-1. Access Point). 2. Blink LED The Managed AP’s LED will flash temporarily to help identify & locate access points. 3. Buzzer The Managed AP’s buzzer will sound temporarily to help identify & locate access points. 4. Network Connectivity Go to the “Network Connectivity” panel to perform a ping or traceroute. 5. Restart Restarts the Managed AP.
Page 26: Iv-4-1-2. Managed Ap Group
IV-4-1-2. Managed AP Group Managed APs can be grouped according to your requirements. Managed AP Group displays information about each Managed AP group in the local network: Group Name, MAC Address, Device Name, Model, IP Address, 2.4GHz & 5GHz Wireless Channel Number, No. of Clients connected to each access point, and Status (connected or disconnected). To edit Managed AP Groups go to NMS Settings ! Access Point (refer to IV-5-1. Access Point). The search function can be used to locate a specific Managed AP Group. Type in the search box and the list will update: The Status icon displays grey (disconnected), red (authentication failed/incompatible NMS version), orange (upgrading firmware), yellow (connecting), green (connected) or blue (waiting for approval) for each individual Managed AP. Refer to IV-4-1-1. Managed AP: Status Icons for full descriptions. Each Managed AP has “Action” icons with the following functions: 2. Disallow Remove the Managed AP from the AP array and disable connectivity.
Page 27 3. Edit Edit various settings for the Managed AP (refer to IV-5-1. Access Point). 4. Blink LED The Managed AP’s LED will flash temporarily to help identify & locate access points. 5. Buzzer The Managed AP’s buzzer will sound temporarily to help identify & locate access points. 6. Network Connectivity Go to the “Network Connectivity” panel to perform a ping or traceroute. 7. Restart Restarts the Managed AP.
Page 28: Iv-4-2. Wlan
IV-4-2. WLAN IV-4-2-1. Active WLAN Displays information about each SSID in the AP Array: Index (reference number), Name/SSID, VLAN ID, Authentication, Encryption, IP Address and Additional Authentication. To configure encryption and VLANs for Managed APs go to NMS Settings ! WLAN. The search function can be used to locate a specific SSID. Type in the search box and the list will update:...
Page 29: Iv-4-2-2. Active Wlan Group
IV-4-2-2. Active WLAN Group WLAN groups can be created according to your preference. Active WLAN Group displays information about WLAN group: Group Name, Name/SSID, VLAN ID, Authentication, Encryption, IP Address and Additional Authentication. The search function can be used to locate a specific Active WLAN Group. Type in the search box and the list will update: IV-4-3. Clients IV-4-3-1. Active Clients Displays information about clients currently connected to the AP Array: Index(reference number),Client MAC Address, AP MAC Address, WLAN (SSID), User Name, Radio (2.4GHz or 5GHz), Signal Strength received by Client, Connected Time, Idle Time, Tx & Rx (Data transmitted and received by Client in KB), and the Vendor of the client device. You can set or disable the auto-refresh time for the client list or click “Refresh” to manually refresh. The search function can be used to locate a specific client. Type in the search box and the list will update:...
Page 30: Iv-4-4. Users
IV-4-4. Users IV-4-4-1. Active Users Displays information about each user in the local network via guest portals: Index (reference number), User Name, MAC Address, IP Address, SSID, Creator, Create Time, Expire Time, Usage Percentage, Traffic Progress, Vendor and Platform of the user device. The search function can be used to locate a specific client. Type in the search box and the list will update: IV-4-4-2. Users Log Displays a detailed information log of users and activity on the network via guest portals: ID, Date and Time of entry, Category of entry, Severity, Users, Event/Activities details. The search function can be used to locate a specific client. Type in the search box and the list will update:...
Page 31: Iv-4-5. Rogue Devices
IV-4-5. Rogue Devices Rogue access point detection can identify any unauthorized access points which may have been installed in the network. Click “Start” to scan for rogue devices: Unknown Rogue Devices displays information about rogue devices discovered during the scan: Index (reference number), Channel, SSID, MAC Address, Security, Signal Strength, Type, Vendor and Action. The search function can be used to locate a known rogue device. Type in the search box and the list will update:...
Page 32: Iv-4-6. Information
IV-4-6. Information IV-4-6-1. All Events/Activities Displays a log of time-stamped events for each access point in the Array – use the drop down menu to select an access point and view the log. IV-4-6-2. AP Monitoring Displays graphical monitoring information about access points in the Array for 2.4GHz & 5GHz: Traffic Tx (data transmitted in MB), Traffic Rx (data received in MB), No. of Clients, Wireless Channel, Tx Power (wireless radio power), CPU Usage and Memory Usage. Use the drop down menus to select an access point and date. You can set or disable the auto-refresh time for the data:...
Page 33: Iv-4-6-3. Ssid Overview
IV-4-6-3. SSID Overview Displays graphical monitoring information about different SSIDs for 2.4GHz & 5GHz, including Traffic Tx (data transmitted in Kbps), Traffic Rx (data received in Kbps), and also the Client Number for each SSID. You can use Refresh to run the manual refresh: 2.4GHz & 5GHz Traffic shows currently how much Tx/Rx traffic (in KBps) utilized in each SSID. The blue diagram represents the 2.4GHz radio band, and the green diagram represents the 5GHz radio band.
Page 34 Client Number shows currently how many current users on each SSID. The blue diagram represents the 2.4GHz radio band, and the green diagram represents the 5GHz radio band.
Page 35: Iv-5. Nms Settings
IV-5. NMS Settings IV-5-1. Access Point Displays information about each access point and access point group in the local network and allows you to edit access points and edit or add access point groups. The search function can be used to locate an access point or access point group. Type in the search box and the list will update: The Status icon displays grey (disconnected), red (authentication failed/incompatible NMS version), orange (upgrading firmware), yellow (connecting), green (connected) or blue (waiting for approval) for each individual Managed AP. Refer to IV-4-1-1. Managed AP: Status Icons for full descriptions. The “Action” icons enable you to allow or disallow an access point: Select an access point or access point group using the check-boxes and click “Edit” to make configurations, or click “Add” to add a new access point group:...
Page 36 The Access Point Settings panel can enable or disable Auto Approve for all Managed APs. When enabled, Managed APs will automatically join the AP Array with the Controller AP. When disabled, Managed APs must be manually approved to join the AP Array with the Controller AP. Access Point Settings Auto Approve Enable or disable Auto Approve for all Managed APs. To manually approve a Managed AP, use “the allow Action” icon for the specified access point: Edit Access Point Configure your selected access point on your LAN. You can set the access point as a DHCP client or specify a static IP address for your access point, and assign the access point to an AP group, as well as edit 2.4GHz & 5GHz wireless radio settings. An events log is displayed at the bottom of the page. You can also use Profile Settings to assign the access point to WLAN, RADIUS and Access Control groups independently from Access Point Group settings. Check the “Override Group Settings” box to use different individual settings for access points assigned to AP Groups:...
Page 37 Basic Settings Name Edit the access point name. The default name is AP + MAC address. Description Enter a description of the access point for reference e.g. 2 Floor Office. MAC Address Displays MAC address. AP Group Use the drop down menu to assign the AP to an AP Group. You can edit AP Groups from the NMS Settings ! Access Point page. IP Address Select “DHCP Client” for your access point to Assignment be assigned a dynamic IP address from your router’s DHCP server, or select “Static IP” to manually specify a static/fixed IP address for your access point (below). Check the box “Override Group Setting” if the AP is a member of an AP Group and you wish to use a different setting than the AP Group setting. IP Address Specify the IP address here. This IP address will be assigned to your access point and will replace the default IP address. Subnet Mask Specify a subnet mask. The default value is...
Page 38 255.255.255.0 Default Gateway For DHCP users, select “From DHCP” to get default gateway from your DHCP server or “User-Defined” to enter a gateway manually. For static IP users, the default value is blank. Primary DNS DHCP users can select “From DHCP” to get primary DNS server’s IP address from DHCP or “User-Defined” to manually enter a value. For static IP users, the default value is blank. Secondary DNS DHCP users can select “From DHCP” to get secondary DNS server’s IP address from DHCP or “User-Defined” to manually enter a value. For static IP users, the default value is blank. Radio Settings Wireless Enable or disable the access point’s 2.4GHz or 5GHz wireless radio. When disabled, no SSIDs on that frequency will be active. Band Select the wireless standard used for the access point. Combinations of 802.11b,...
Page 39 802.11g, 802.11n & 802.11ac can be selected. Auto Pilot Enable/disable auto channel selection. Auto channel selection will automatically set the wireless channel for the access point’s 2.4GHz or 5GHz frequency based on availability and potential interference. When disabled, select a channel manually. Auto Pilot Range Select a range from which the auto channel setting (above) will choose a channel. Auto Pilot Interval Specify a frequency for how often the auto channel setting will check/reassign the wireless channel. Check/uncheck the “Change channel even if clients are connected” box according to your preference. Channel Bandwidth Set the channel bandwidth or use Auto (automatically select based on interference level). BSS BasicRateSet Set a Basic Service Set (BSS) rate: this is a series of rates to control communication frames for wireless clients. These settings are for experienced users only. Please do not change any of the values on this page unless you are already familiar with these functions. Changing these settings can adversely affect the performance of your access point. Advanced Settings Contention Slot Select “Short” or “Long” – this value is used for contention windows in WMM (see IV-6-7. WMM). Preamble Type Set the wireless radio preamble type. The preamble type in 802.11 based wireless communication defines the length of the CRC (Cyclic Redundancy Check) block for communication between the access point and roaming wireless adapters. The default value is “Short Preamble”.
Page 40 802.11g Protection Enable/disable 802.11g protection, which increases reliability but reduces bandwidth (clients will send Request to Send (RTS) to access point, and access point will broadcast Clear to Send (CTS), before a packet is sent from client.) 802.11n Protection Enable/disable 802.11n protection, which increases reliability but reduces bandwidth (clients will send Request to Send (RTS) to access point, and access point will broadcast Clear to Send (CTS), before a packet is sent from client.) DTIM Period Set the DTIM (delivery traffic indication message) period value of the wireless radio. The default value is 1. RTS Threshold Set the RTS threshold of the wireless radio. The default value is 2347. Fragment Set the fragment threshold of the wireless Threshold radio. The default value is 2346. Multicast Rate Set the transfer rate for multicast packets or use the “Auto” setting. Tx Power Set the power output of the wireless radio. You may not require 100% output power. Setting a lower power output can enhance security since potentially malicious/unknown users in distant areas will not be able to access your signal. Beacon Interval Set the beacon interval of the wireless radio. The default value is 100. Station idle Set the interval for keep alive messages from timeout...
Page 41 Profile Settings WLAN Group Assign the access point’s 2.4GHz or 5GHz SSID(s) to a WLAN Group. You can edit WLAN groups in NMS Settings ! WLAN. RADIUS Group Assign the access point’s 2.4GHz SSID(s) to a RADIUS group. You can edit RADIUS groups in NMS Settings ! RADIUS. Access Control Assign the access point’s 2.4GHz SSID(s) to a Group RADIUS group. You can edit RADIUS groups in NMS Settings ! Access Control Add/Edit Access Point Group Configure your selected access point group. Access point group settings apply to all access points in the group, unless individually set to override group settings. You can use Profile Group Settings to assign the access point group to WLAN, RADIUS and Access Control groups. The Group Settings panel can be used to quickly move access points between existing groups: select an access point and use the drop down menu or search to select access point groups and use << and >> arrows to move APs between groups. Basic Group Settings Name Edit the access point group name. Description Enter a description of the access point group for reference e.g. 2 Floor Office Group.
Page 42 Radio Group Settings Wireless Enable or disable the access point group’s 2.4GHz or 5GHz wireless radio. When disabled, no SSIDs on that frequency will be active. Band Select the wireless standard used for the access point group. Combinations of 802.11b, 802.11g, 802.11n & 802.11ac can be selected. Auto Pilot Enable/disable auto channel selection. Auto channel selection will automatically set the wireless channel for the access point group’s 2.4GHz or 5GHz frequency based on availability and potential interference. When disabled, select a channel manually. Auto Pilot Range Select a range from which the auto channel setting (above) will choose a channel. Auto Pilot Interval Specify a frequency for how often the auto channel setting will check/reassign the wireless channel. Check/uncheck the “Change channel even if clients are connected” box according to your preference. Channel Bandwidth Set the channel bandwidth or use Auto...
Page 43 (automatically select based on interference level). BSS BasicRateSet Set a Basic Service Set (BSS) rate: this is a series of rates to control communication frames for wireless clients. These settings are for experienced users only. Please do not change any of the values on this page unless you are already familiar with these functions. Changing these settings can adversely affect the performance of your access points. Advanced Settings Contention Slot Select “Short” or “Long” – this value is used for contention windows in WMM (see IV-6-7. WMM). Preamble Type Set the wireless radio preamble type. The preamble type in 802.11 based wireless communication defines the length of the CRC (Cyclic Redundancy Check) block for communication between the access point and roaming wireless adapters. The default value is “Short Preamble”. Guard Interval Set the guard interval. A shorter interval can improve performance. 802.11g Protection Enable/disable 802.11g protection, which increases reliability but reduces bandwidth (clients will send Request to Send (RTS) to access point, and access point will broadcast Clear to Send (CTS), before a packet is sent from client.) 802.11n Protection Enable/disable 802.11n protection, which increases reliability but reduces bandwidth (clients will send Request to Send (RTS) to access point, and access point will broadcast Clear to Send (CTS), before a packet is sent from client.) DTIM Period...
Page 44 RTS Threshold Set the RTS threshold of the wireless radio. The default value is 2347. Fragment Set the fragment threshold of the wireless Threshold radio. The default value is 2346. Multicast Rate Set the transfer rate for multicast packets or use the “Auto” setting. Tx Power Set the power output of the wireless radio. You may not require 100% output power. Setting a lower power output can enhance security since potentially malicious/unknown users in distant areas will not be able to access your signal. Beacon Interval Set the beacon interval of the wireless radio. The default value is 100. Station idle Set the interval for keep alive messages from timeout the access point to a wireless client to verify if the station is still alive/active. Profile Group Settings WLAN Group Assign the access point group’s 2.4GHz or...
Page 45 5GHz SSIDs to a WLAN Group. You can edit WLAN groups in NMS Settings ! WLAN. RADIUS Group Assign the access point group’s 2.4GHz SSIDs to a RADIUS group. You can edit RADIUS groups in NMS Settings ! RADIUS. Access Control Assign the access point’s 2.4GHz SSIDs to a Group RADIUS group. You can edit RADIUS groups in NMS Settings ! Access Control.
Page 46: Iv-5-2. Wlan
IV-5-2. WLAN Displays information about each WLAN and WLAN group in the local network and allows you to add or edit WLANs & WLAN Groups. When you add a WLAN Group, it will be available for selection in NMS Settings ! Access Point access point Profile Settings & access point group Profile Group Settings. The search function can be used to locate a WLAN or WLAN Group. Type in the search box and the list will update: Select a WLAN or WLAN Group using the check-boxes and click “Edit” or click “Add” to add a new WLAN or WLAN Group:...
Page 47 Add/Edit WLAN WLAN Settings Name/ESSID Edit the WLAN name (SSID). Description Enter a description of the SSID for reference e.g. 2 Floor Office HR. SSID Select which SSID to configure security settings for. VLAN ID Specify the VLAN ID. Broadcast SSID Enable or disable SSID broadcast. When enabled, the SSID will be visible to clients as an available Wi-Fi network. When disabled, the SSID will not be visible as an available Wi-Fi network to clients – clients must manually enter the SSID in order to connect. A hidden (disabled) SSID is typically more secure than a visible (enabled) SSID. Wireless Client Enable or disable wireless client isolation. Isolation Wireless client isolation prevents clients connected to the access point from communicating with each other and improves security. Typically, this function is useful for corporate environments or public hot spots...
Page 48 and can prevent brute force attacks on clients’ usernames and passwords. Load Balancing Load balancing limits the number of wireless clients connected to an SSID. Set a load balancing value (maximum 50). Authentication Select an authentication method from the Method drop down menu. Additional Select an additional authentication method Authentication from the drop down menu. Various security options (wireless data encryption) are available. When data is encrypted, information transmitted wirelessly cannot be read by anyone who does not know the correct encryption key. It’s essential to configure wireless security in order to prevent unauthorised access to your network. Select hard-to-guess passwords which include combinations of numbers, letters and symbols, and change your password regularly. Please refer to IV-6-2-3. Security for more information on authentication and additional authentication types. WLAN Advanced Settings RSSI Threshold Set a RSSI Threshold level.
Page 49 Add/Edit WLAN Group When you add a WLAN Group, it will be available for selection in NMS Settings ! Access Point access point Profile Settings& access point group Profile Group Settings. WLAN Group Settings Name Edit the WLAN Group name. Description Enter a description of the WLAN Group for reference e.g. 2 Floor Office HR Group. Members Select SSIDs to include in the group using the checkboxes and assign VLAN IDs.
Page 50: Iv-5-3. Radius
IV-5-3. RADIUS Displays information about External & Internal RADIUS Servers, Accounts and Groups and allows you to add or edit RADIUS Servers, Accounts & Groups. When you add a RADIUS Group, it will be available for selection in NMS Settings ! Access Point access point Profile Settings& access point group Profile Group Settings. The search function can be used to locate a RADIUS Server, Account or Group. Type in the search box and the list will update: Make a selection using the check-boxes and click “Edit” or click “Add” to add a new WLAN or WLAN Group:...
Page 51 Add/Edit External RADIUS Server Name Enter a name for the RADIUS Server. Description Enter a description of the RADIUS Server for reference. RADIUS Server Enter the RADIUS server host IP address. Authentication Set the UDP port used in the authentication Port protocol of the RADIUS server. Value must be between 1 – 65535. Shared Secret Enter a shared secret/password between 1 – 99 characters in length. This should match the “MAC-RADIUS” password. Session Timeout Set a duration of session timeout in seconds between 0 – 86400. Accounting Enable or disable RADIUS accounting. Accounting Port When accounting is enabled (above), set the UDP port used in the accounting protocol of the RADIUS server. Value must be between 1 – 65535.
Page 52 Add/Edit Internal RADIUS Server Upload EAP Certificate File EAP Certificate File Displays the EAP certificate file format: Format PCK#12(*.pfx/*.p12) EAP Certificate File Click “Upload” to open a new window and select the location of an EAP certificate file to use. If no certificate file is uploaded, the internal RADIUS server will use a self-made certificate. Internal RADIUS Server Name Enter a name for the Internal RADIUS Server. Description Enter a description of the Internal RADIUS Server for reference. EAP Certificate File Displays the EAP certificate file format: Format PCK#12(*.pfx/*.p12) EAP Certificate File Click “Upload” to open a new window and select the location of an EAP certificate file to use. If no certificate file is uploaded, the internal RADIUS server will use a self-made certificate.
Page 53 EAP Internal Select EAP internal authentication type from Authentication the drop down menu. Shared Secret Enter a shared secret/password for use between the internal RADIUS server and RADIUS client. The shared secret should be 1 – 99 characters in length. Session Timeout Set a duration of session timeout in seconds between 0 – 86400. Termination Action Select a termination-action attribute: “Reauthentication” sends a RADIUS request to the access point, “Not-Reathentication” sends a default termination-action attribute to the access point, “Not-Send” no termination-action attribute is sent to the access point. Add/Edit RADIUS Accounts The internal RADIUS server can authenticate up to 256 user accounts. The “RADIUS Accounts” page allows you to configure and manage users.
Page 54 RADIUS Accounts User Name Enter the user names here, separated by commas. Add Click “Add” to add the user to the user registration list. Reset Clear text from the user name box. User Registration List Select Check the box to select a user. User Name Displays the user name. Password Displays if specified user name has a password (configured) or not (not configured). Customize Click “Edit” to open a new field to set/edit a password for the specified user name (below). Delete Selected Delete selected user from the user registration list. Delete All Delete all users from the user registration list. Edit User Registration List User Name Existing user name is displayed here and can be edited according to your preference. Password Enter or edit a password for the specified user.
Page 55 Add/Edit RADIUS Group When you add a RADIUS Group, it will be available for selection in NMS Settings ! Access Point access point Profile Settings & access point group Profile Group Settings. RADIUS Group Settings Group Name Edit the RADIUS Group name. Description Enter a description of the RADIUS Group for reference. 2.4GHz RADIUS Enable/Disable primary & secondary RADIUS servers for 2.4GHz. 5GHz RADIUS Enable/Disable primary & secondary RADIUS servers for 5GHz. Members Add RADIUS user accounts to the RADIUS group (Maximum 5).
Page 56: Iv-5-4. Access Control
IV-5-4. Access Control MAC Access Control is a security feature that can help to prevent unauthorized users from connecting to your access point. This function allows you to define a list of network devices permitted to connect to the access point. Devices are each identified by their unique MAC address. If a device which is not on the list of permitted MAC addresses attempts to connect to the access point, it will be denied. The Access Control panel displays information about MAC Access Control & MAC Access Control Groups and Groups and allows you to add or edit MAC Access Control & MAC Access Control Group settings. When you add an Access Control Group, it will be available for selection in NMS Settings ! Access Point access point Profile Settings& access point group Profile Group Settings. The search function can be used to locate a MAC address or MAC Access Control Group. Type in the search box and the list will update: Make a selection using the check-boxes and click “Edit” or click “Add” to add a new MAC Address or MAC Access Control Group:...
Page 57 Add/Edit MAC Access Control Add MAC Address Enter a MAC address of computer or network device manually e.g. ‘aa-bb-cc-dd-ee-ff’ or enter multiple MAC addresses separated with commas, e.g. ‘aa-bb-cc-dd-ee-ff,aa-bb-cc-dd-ee-gg’ Add Click “Add” to add the MAC address to the MAC address filtering table. Reset Clear all fields. MAC address entries will be listed in the “MAC Address Filtering Table”. Select an entry using the “Select” checkbox. Select Delete selected or all entries from the table. MAC Address The MAC address is listed here. Delete Selected Delete the selected MAC address from the list. Delete All Delete all entries from the MAC address filtering table. Export Click “Export” to save a copy of the MAC filtering table. A new window will pop up for you to select a location to save the file.
Page 58 Add/Edit MAC Access Control Group When you add an Access Control Group, it will be available for selection in NMS Settings ! Access Point access point Profile Settings& access point group Profile Group Settings. MAC Filter Group Settings Group Name Edit the MAC Access Control Group name. Description Enter a description of the MAC Access Control Group for reference. Action Select “Blacklist” to deny access to specified MAC addresses in the group, and select “Whitelist” to permit access to specified MAC address in the group. Members Add MAC addresses to the group.
Page 59: Iv-5-5. Guest Network
IV-5-5. Guest Network You can setup an additional “Guest” Wi-Fi network so guest users can enjoy Wi-Fi connectivity without accessing your primary networks. The “Guest” screen displays settings for your guest Wi-Fi network. The Guest Network panel displays information about Guest Networks and Guest Network Groups and allows you to add or edit Guest Network and Guest Network Group settings. When you add a Guest Network Group, it will be available for selection in NMS Settings ! Access Point access point Profile Settings & access point group Profile Group Settings. The search function can be used to locate a Guest Network or Guest Network Group. Type in the search box and the list will update: Make a selection using the check-boxes and click “Edit” or click “Add” to add a new Guest Network or Guest Network Group.
Page 60 Add/Edit Guest Network Guest Network Settings Name/ESSID Edit the Guest Network name (SSID). Description Enter a description of the Guest Network for reference e.g. 2 Floor Office HR. VLAN ID Specify the VLAN ID. Broadcast SSID Enable or disable SSID broadcast. When enabled, the SSID will be visible to clients as an available Wi-Fi network. When disabled, the SSID will not be visible as an available Wi-Fi network to clients – clients must manually enter the SSID in order to connect. A hidden (disabled) SSID is typically more secure than a visible (enabled) SSID. Wireless Client Enable or disable wireless client isolation.
Page 61 Isolation Wireless client isolation prevents clients connected to the access point from communicating with each other and improves security. Typically, this function is useful for corporate environments or public hot spots and can prevent brute force attacks on clients’ usernames and passwords. Load Balancing Load balancing limits the number of wireless clients connected to an SSID. Set a load balancing value (maximum 50). Authentication Select an authentication method from the Method drop down menu. Additional Select an additional authentication method Authentication from the drop down menu. Various security options (wireless data encryption) are available. When data is encrypted, information transmitted wirelessly cannot be read by anyone who does not know the correct encryption key. It’s essential to configure wireless security in order to prevent unauthorised access to your network. Select hard-to-guess passwords which include combinations of numbers, letters and symbols, and change your password regularly. Guest Access Policy Guest Portal Select a guest portal to use for this guest SSID. Guest portals can be configured in NMS Settings ! Guest Portal. Traffic Shaping Enable or disable traffic shaping for the guest network. Downlink Enter a downlink limit in MB. Uplink Enter an uplink limit in MB. IP Filtering Select “Deny” or “Allow” to deny or allow specified IP addresses to access the guest...
Page 62: Iv-5-6. Users
the Deny or Allow rule specified above and check the box for each IP address to be filtered. Guest Network Advanced Settings Schedule Group Assign guest SSID to a specified schedule (schedule must be pre-configured in NMS Settings ! Schedule.) Add/Edit Guest Network Group When you add a Guest Network Group, it will be available for selection in NMS Settings ! Access Point access point Profile Settings & access point group Profile Group Settings. Guest Network Group Settings Group Name Edit the Guest Network Group name. Description Enter a description of the Guest Network for reference. Members Add SSIDs to the Guest Network group. You can override individual VLAN ID & schedule settings and assign a different VLAN ID or schedule. IV-5-6. Users User accounts can be created, monitored and managed for use with the controller’s guest portal function. Guest portal settings can be found at IV-5-7. Guest Portal (NMS Settings ! Guest Portal).
Page 63 When a guest portal is enabled, users who connect to the Guest SSID will automatically arrive at the customizable guest portal page. From there a user account login is required to access the network. These user accounts are created and grouped here, and then selected as the Authentication User Group at NMS Settings ! Guest Portal. The guest portal also generates a Front Desk URL which allows staff/admins to login and quickly create/manage user accounts and expiry times, and generate & print tickets with login credentials to give to guest users. These staff/admin accounts are created and grouped here, and selected as the Front Desk User Group at NMS Settings ! Guest Portal. Information on the Users page is displayed about each user account and user account group. The search function can be used to locate a user or user group. Type in the search box and the list will update: The Status icon displays grey (logged out), yellow (expired), red (locked) or green (active) for each user. The Action icons can lock/unlock or revive (an expired) user account. Select a user or user group using the check-boxes and click “Edit” to make configurations, or click “Add” to add new users and groups:...
Page 64 Add/Edit User User Settings Name Edit the user account name. Description Enter a description of the user account name e.g. Guest Portal 1 Password Specify a password for the account. Confirm Password Confirm the password for the account. User Group Assign the user account to a user group so it can be utilized by the guest portal. Add/Edit User Group User Group Settings Name Edit the user group name. Description Enter a description of the user group name e.g. Front Desk or Guest Users. Role Type Select whether the group is for Guest Portal users or Front Desk managers. Members Select which user accounts to include in the group.
Page 65 IV-5-7. Guest Portal Displays information about guest portals and allows you to edit guest portal settings. Guest portals require users to be created at NMS Settings ! Users. When a guest portal is enabled, users who connect to the Guest SSID will automatically arrive at the customizable guest portal page. From there a user account login is required to access the network. These user accounts are created and grouped at NMS Settings ! Users, and then selected as the Authentication User Group here. The guest portal also generates a Front Desk URL which allows staff/admins to login and quickly create/manage user accounts and expiry times, and generate & print tickets with login credentials to give to guest users. These staff/admin accounts are created and grouped at NMS Settings ! Users and then selected as the Front Desk User Group here. Guest Portal Settings Idle Timeout Specify a duration of idle time after which the guest portal will timeout. Login Password Specify number of incorrect login attempts Retry Lockout before the user account is locked.
Page 66: Iv-5-7-1. Add/Edit Guest Portal
IV-5-7-1. Add/Edit Guest Portal Add a guest portal or edit an existing guest portal for use with the guest network. Guest Portal Settings Name Edit the name of the guest portal for reference. Description Enter a description of the guest portal for reference. Guest Portal Type Select a guest portal type. Refer below for more information about available types. Authentication Select an authentication server: Local Server Database is the default setting. Front Desk User Select a user group for front desk access. Group Front Desk Displays the URL of your Front Desk page. See Generation URL below for more information. Front Desk Printout Edit the content of Front Desk printout ticket. Message Refer below for more information. Authentication Select a user group for login to the guest User Group network. Landing Page Specify a landing page for users after successful login.
Page 67: Iv-5-7-1-1. Front Desk Url
IV-5-7-1-1. Front Desk URL Go to this URL in a web browser and members of the Front Desk User Group can login to create guest accounts, set expiry limits and printout tickets. Guest Portal Type Dynamic must be selected to use Front Desk. 1. Login with an account from the Front Desk User Group (NMS Settings ! Users). 2. The Guest Account Wizard allows you to setup a new user account and configure the valid period & SSID, or upload a bulk guest list in .csv format. Click Next to continue.
Page 68 3. A summary of the new account(s) is displayed with quick links to print tickets for individual or all new accounts. 4. The Guest Account Monitor displays all guest accounts along with status and quick action icons to print, revive expired accounts or lock/unlock (disable/enable) accounts. Yellow: Expired Red: Locked Grey: Logged out Green: Active Mouseover a status or action icon for a description, and use the arrows to reorder the list according to S/N or Status. Anytime you choose to print account(s) your browser will open a print dialog box where you can select your print destination and configure print settings as usual:...
Page 69: Iv-5-7-1-2. Front Desk Printout
IV-5-7-1-2. Front Desk Printout Edit and preview the content of the Front Desk printout in the text box using the variables listed in the Definition Table. E.g. (USERNAME) will display on the printout as the specified username. Guest Portal Type Dynamic must be selected to use Front Desk.
Page 70: Iv-5-7-1-3. Guest Portal Type
IV-5-7-1-3. Guest Portal Type Four types of guest portal are available from the drop down menu: Free Redirects users to the specified landing page, with no user login required. Service Level Agreement Requires users to accept terms and conditions, with no user login required. Static Users Requires user login and accept terms and conditions. Users must be created in NMS at NMS Settings ! Users. Front Desk is not used. Dynamic Users Requires user login and accept terms and conditions. Allows Front Desk to create user accounts in addition to NMS.
Page 71: Iv-5-7-1-4. Guest Portal Customization
IV-5-7-1-4. Guest Portal Customization Guest portal customization varies according to guest portal type. Click Edit to make changes. Login Portal Settings Header Image Select an 800 x 200 header image. Logo Image Select a 200 x 50 logo image. Title Message Enter a title message for the guest portal page. Background Color Specify a background color as a HEX value. Terms of Use Enter your terms of use.
Page 72 IV-5-8. Zone Edit Zone Edit displays information about zones for use with the Zone Plan feature and allows you to add or edit zones. The search function can be used to find existing zones. Type in the search box and the list will update: Make a selection using the check-boxes and click “Edit” or click “Add” to add a new zone.
Page 73 Add/Edit Zone Upload Zone Image Choose File Click to locate an image file to be displayed as a map in the Zone Plan feature. Typically a floor plan image is useful. Zone Setting Name/Location Enter a name of the zone/location. Description Enter a description of the zone/location for reference. Members Assign access points to the specified zone/location for use with the Zone Plan feature.
Page 74: Iv-5-9. Schedule
IV-5-9. Schedule You can define schedules according to day, start time and end time - and group multiple schedules together into schedule groups. Schedule groups can be assigned to WLANs, WLAN Groups & Guest Network at NMS Settings ! WLAN and NMS Settings ! Guest Network. Add/Edit Schedule Use the checkboxes and drop-down menus to setup your schedule.
Page 75 Add/Edit Schedule Group WLAN Group Settings Name Edit the schedule group name. Description Enter a description of the schedule group for reference. Members Select individual schedules to include in the schedule group using the checkboxes.
Page 76: Iv-5-10. Smart Roaming
IV-5-10. Smart Roaming Smart Roaming enables you to setup the Roaming groups and the Used WLAN SSID, WAN Group and AP Number. Before setup the roaming group, the WLAN Settings need to be configured first. For example, please click NMS Settings >> WLAN, check 2.4GHz SSID, and then click Edit. Configure 802.11k as Enable. Please note, don't configure the Authentication as OPEN. Then click Save and Apply. Please wait about 3 minutes.
Page 77 Roaming Group Setting Procedure: (1) Enter Name of this setting. (2) Enter 4 characteristics on Mobility Domain. (3) Enter 32 characteristics on Encryption Key. (4) Select WLAN Group, and select WLAN. (5) It will display APs using this WLAN Setting. (6) Click Edit icon on 1st AP. (7) Enter 2nd AP MAC Address, click Save and Close. (8) Click Edit icon on 2nd AP. (9) Enter 1st AP MAC Address, click Save and Close. ...
Page 78: Iv-5-11. Device Monitoring
Then, click Save and Apply, and wait about 3 minutes. Congratulations, you have configured 802.11r and 802.11k successfully. IV-5-11. Device Monitoring Device monitoring enables you to specify and monitor the status any IP devices on the network such as IP cameras. The description and status of each device is displayed in the table. Add or Edit IP devices by entering the IP address.
Page 79: Iv-5-12. Firmware Upgrade
IV-5-12. Firmware Upgrade Firmware Upgrade allows you to upgrade firmware to Access Point Groups. First, upload the firmware file from a local disk or external FTP server: locate the file and click “Upload” or “Check”. The table below will display the Firmware Name, Firmware Version, NMS Version, Model and Size. Then click “Upgrade All” to upgrade all access points in the Array or select Access Point groups from the list using check-boxes and click “Upgrade Selected” to upgrade only selected access points.
Page 80: Iv-5-13. Advanced
IV-5-13. Advanced IV-5-13-1. System Security Configure the NMS system name and security key for communication between AP Controller and Managed APs. V-5-13-2. Date & Time Configure the date & time settings of the AP Array. The date and time of the access points can be configured manually or can be synchronized with a time server. Date and Time Settings Local Time Set the access point’s date and time manually using the drop down menus. Acquire Current Click “Acquire Current Time from Your PC” to Time from your PC enter the required values automatically according to your computer’s current time and date.
Page 81: V-5-13-3. System Accounts
NTP Time Server Use NTP The access point also supports NTP (Network Time Protocol) for automatic time and date setup. Server Name Enter the host name or IP address of the time server if you wish. Update Interval Specify a frequency (in hours) for the access point to update/synchronize with the NTP server. Time Zone Time Zone Select the time zone of your country/ region. If your country/region is not listed, please select another country/region whose time zone is the same as yours. V-5-13-3. System Accounts Import the API Key which was received Google Developers. This is for the Online Map feature in Zone Plan page. Graphical zone plans with Google Maps integration and setup wizards are available for expanding and managing large networks with multiple access points Note: Please go to https://console.developers.google.com/flows/enableapi?apiid=maps_backen d&keyType=CLIENT_SIDE&reusekey=true to apply for an API key first to utilize this feature set.
Page 83: Iv-6. Local Network
IV-6. Local Network IV-6-1. Network Settings IV-6-1-1. LAN-Side IP Address The “LAN-side IP address” page allows you to configure your AP Controller on your Local Area Network (LAN). You can enable the access point to dynamically receive an IP address from your router’s DHCP server or you can specify a static IP address for your access point, as well as configure DNS servers. You can also set your AP Controller as a DHCP server to assign IP addresses to other devices on your LAN. LAN-side IP Address IP Address Select “Static IP” to manually specify a Assignment static/fixed IP address for your access point. Select “DHCP Client” for your access point to be assigned a dynamic IP address from your router’s DHCP server, or select “DHCP Server” for your access point to act as a DHCP server and assign IP addresses on your LAN. Static IP Address IP Address Specify the IP address here. This IP address will be assigned to your access point and will replace the default IP address. Subnet Mask Specify a subnet mask. The default value is 255.255.255.0 Default Gateway For DHCP users, select “From DHCP” to get default gateway from your DHCP server or...
Page 84 “User-Defined” to enter a gateway manually. For static IP users, the default value is blank. Primary DNS For static IP users, the default value is blank. Address Secondary DNS For static IP users, the default value is blank. Address DHCP Client IP Address When “DHCP Client” is selected this value cannot be modified. Subnet Mask When “DHCP Client” is selected this value cannot be modified. Default Gateway Select “From DHCP” or select “User-Defined” and enter a default gateway. Primary DNS Select “From DHCP” or select “User-Defined” Address and enter a primary DNS address. Secondary DNS Select “From DHCP” or select “User-Defined” Address and enter a secondary DNS address.
Page 85 DHCP Server IP Address Specify the IP address here. This IP address will be assigned to your access point and will replace the default IP address. Subnet Mask Specify a subnet mask. The default value is 255.255.255.0 IP Address Range Enter the start and end IP address of the IP address range which your access point’s DHCP server will assign to devices on the network. Domain Name Enter a domain name. Lease Time Select a lease time from the drop down menu. IP addresses will be assigned for this period of time. Default Gateway Enter a default gateway. Primary DNS Enter a primary DNS address. Address Secondary DNS Enter a secondary DNS address. Address Your access point’s DHCP server can be configured to assign static (fixed) IP addresses to specified network devices, identified by their unique MAC address: DHCP Server Static IP Address MAC Address Enter the MAC address of the network device...
Page 86: Iv-6-1-2. Lan Port Settings
to be assigned a static IP address. IP Address Specify the IP address to assign the device. Add Click to assign the IP address to the device. IV-6-1-2. LAN Port Settings The “LAN Port” page allows you to configure the settings for your AP Controllers wired LAN (Ethernet) ports. Wired LAN Port Identifies LAN port 1 or 2. Enable Enable/disable specified LAN port. Speed & Duplex Select a speed & duplex type for specified LAN port, or use the “Auto” value. LAN ports can operate up to 1000Mbps and full-duplex enables simultaneous data packets transfer/receive. Flow Control Enable/disable flow control. Flow control can pause new session request until current data processing is complete, in order to avoid device overloads under heavy traffic. 802.3az Enable/disable 802.3az. 802.3az is an Energy Efficient Ethernet feature which disables unused interfaces to reduce power usage.
Page 87: Iv-6-1-3. Vlan
IV-6-1-3. VLAN The “VLAN” (Virtual Local Area Network) page enables you to configure VLAN settings. A VLAN is a local area network which maps workstations virtually instead of physically and allows you to group together or isolate users from each other. VLAN IDs 1 – 4094 are supported. VLAN IDs in the range 1 – 4094 are supported. VLAN Interface Wired LAN Identifies LAN port 1 or 2 and wireless SSIDs Port/Wireless (2.4GHz or 5GHz). VLAN Mode Select “Tagged Port” or “Untagged Port” for specified LAN interface. VLAN ID Set a VLAN ID for specified interface, if “Untagged Port” is selected. Management VLAN VLAN ID Specify the VLAN ID of the management VLAN. Only the hosts belonging to the same VLAN can manage the device.
Page 88: Iv-6-2. 2.4Ghz 11Bgn (Not Available On The Wlc-6404)
IV-6-2. 2.4GHz 11bgn (Not available on the WLC-6404) The “2.4GHz 11bgn” menu allows you to view and configure information for your access point’s 2.4GHz wireless network across four categories: Basic, Advanced, Security and WDS. IV-6-2-1. Basic The “Basic” screen displays basic settings for your access point’s 2.4GHz Wi-Fi network(s). When auto channel is disabled, select a wireless channel manually: Channel Select a wireless channel from 1 – 11. Channel Bandwidth Set the channel bandwidth: 20MHz (lower performance but less interference), 40MHz (higher performance but potentially higher interference) or Auto (automatically select based on interference level). BSS BasicRate Set Set a Basic Service Set (BSS) rate: this is a series of rates to control communication frames for wireless clients.
Page 89: Iv-6-2-2. Advanced
IV-6-2-2. Advanced These settings are for experienced users only. Please do not change any of the values on this page unless you are already familiar with these functions. Changing these settings can adversely affect the performance of your access point. Contention Slot Select “Short” or “Long” – this value is used for contention windows in WMM (see IV-6-7. WMM). Preamble Type Set the wireless radio preamble type. The preamble type in 802.11 based wireless communication defines the length of the CRC (Cyclic Redundancy Check) block for communication between the access point and roaming wireless adapters. The default value is “Short Preamble”. Guard Interval Set the guard interval. A shorter interval can improve performance. 802.11g Protection Enable/disable 802.11g protection, which increases reliability but reduces bandwidth (clients will send Request to Send (RTS) to access point, and access point will broadcast Clear to Send (CTS), before a packet is sent from client.)
Page 90 802.11n Protection Enable/disable 802.11n protection, which increases reliability but reduces bandwidth (clients will send Request to Send (RTS) to access point, and access point will broadcast Clear to Send (CTS), before a packet is sent from client.) DTIM Period Set the DTIM (delivery traffic indication message) period value of the wireless radio. The default value is 1. RTS Threshold Set the RTS threshold of the wireless radio. The default value is 2347. Fragment Set the fragment threshold of the wireless Threshold radio. The default value is 2346. Multicast Rate Set the transfer rate for multicast packets or use the “Auto” setting. Tx Power Set the power output of the wireless radio. You may not require 100% output power. Setting a lower power output can enhance security since potentially malicious/unknown users in distant areas will not be able to access your signal. Beacon Interval Set the beacon interval of the wireless radio. The default value is 100. Station idle Set the interval for keep alive messages from timeout the access point to a wireless client to verify if the station is still alive/active.
Page 91: Iv-6-2-3. Security
IV-6-2-3. Security The access point provides various security options (wireless data encryption). When data is encrypted, information transmitted wirelessly cannot be read by anyone who does not know the correct encryption key. It’s essential to configure wireless security in order to prevent unauthorised access to your network. Select hard-to-guess passwords which include combinations of numbers, letters and symbols, and change your password regularly. SSID Select which SSID to configure security settings for. Broadcast SSID Enable or disable SSID broadcast. When enabled, the SSID will be visible to clients as an available Wi-Fi network. When disabled, the SSID will not be visible as an available Wi-Fi network to clients – clients must manually enter the SSID in order to connect. A hidden (disabled) SSID is typically more secure than a visible (enabled) SSID. Wireless Client Enable or disable wireless client isolation. Isolation Wireless client isolation prevents clients connected to the access point from communicating with each other and improves security. Typically, this function is useful for corporate environments or public hot spots and can prevent brute force attacks on clients’ usernames and passwords.
Page 92: Iv-6-2-3-1. No Authentication
Load Balancing Load balancing limits the number of wireless clients connected to an SSID. Set a load balancing value (maximum 50). Authentication Select an authentication method from the drop Method down menu and refer to the information below appropriate for your method. Additional Select an additional authentication method Authentication from the drop down menu and refer to the information below (IV-6-2-3-6.) appropriate for your method. IV-6-2-3-1. No Authentication Authentication is disabled and no password/key is required to connect to the access point. Disabling wireless authentication is not recommended. When disabled, anybody within range can connect to your device’s SSID. IV-6-2-3-2. WEP WEP (Wired Equivalent Privacy) is a basic encryption type. For a higher level of security consider using WPA encryption. Key Length Select 64-bit or 128-bit. 128-bit is more secure than 64-bit and is recommended. Key Type Choose from “ASCII” (anyalphanumericalcharacter0-9, a-z and A-Z) or “Hex” (any characters from 0-9,a-f and A-F). Default Key Select which encryption key (1 – 4 below) is the default key. For security purposes, you can set up to four keys (below) and change which is the default key. Encryption Key 1 – Enter your encryption key/password according to the format you selected above.
Page 93: Iv-6-2-3-3. Ieee802.1X/Eap
IV-6-2-3-3. IEEE802.1x/EAP Key Length Select 64-bit or 128-bit. 128-bit is more secure than 64-bit and is recommended. IV-6-2-3-4. WPA-PSK WPA-PSK is a secure wireless encryption type with strong data protection and user authentication, utilizing 128-bit encryption keys. WPA Type Select from WPA/WPA2 Mixed Mode-PSK, WPA2 or WPA only. WPA2 is safer than WPA only, but not supported by all wireless clients. Please make sure your wireless client supports your selection. Encryption Select “TKIP/AES Mixed Mode” or “AES” encryption type. Key Renewal Specify a frequency for key renewal in Interval minutes. Pre-Shared Key Choose from “Passphrase” (8 – 63 Type alphanumeric characters) or “Hex” (up to 64 characters from 0-9, a-f and A-F). Pre-Shared Key Please enter a security key/password according to the format you selected above. IV-6-2-3-5. WPA-EAP WPA Type Select from WPA/WPA2 Mixed Mode-EAP, WPA2-EAP or WPA-EAP. Encryption Select “TKIP/AES Mixed Mode” or “AES” encryption type. Key Renewal Specify a frequency for key renewal in Interval minutes.
Page 94: Iv-6-2-3-6. Additional Authentication
IV-6-2-3-6. Additional Authentication Additional wireless authentication methods can also be used: MAC Address Filter Restrict wireless clients access based on MAC address specified in the MAC filter table. See IV-6-6.MAC Filter to configure MAC filtering. MAC Filter & MAC-RADIUS Authentication Restrict wireless clients access using both of the above MAC filtering & RADIUS authentication methods. MAC-RADIUS Authentication Restrict wireless clients access based on MAC address via a RADIUS server, or password authentication via a RADIUS server. See IV-6-5.RADIUS to configure RADIUS servers. WPS must be disabled to use MAC-RADIUS authentication. See IV-6-4. for WPS settings. MAC RADIUS Select whether to use MAC address or Password password authentication via RADIUS server. If you select “Use the following password”, enter the password in the field below. The password should match the “Shared Secret” used in IV-6-5. RADIUS.
Page 95: Iv-6-2-4. Wds
IV-6-2-4. WDS Wireless Distribution System (WDS) can bridge/repeat access points together in an extended network. WDS settings can be configured as shown below. When using WDS, configure the IP address of each access point to be in the same subnet and ensure there is only one active DHCP server among connected access points, preferably on the WAN side. WDS must be configured on each access point, using correct MAC addresses. All access points should use the same wireless channel and encryption method.
Page 96 2.4GHz WDS Functionality Select “WDS with AP” to use WDS with access point or “WDS Dedicated Mode” to use WDS and also block communication with regular wireless clients. When WDS is used, each access point should be configured with corresponding MAC addresses, wireless channel and wireless encryption method. Local MAC Address Displays the MAC address of your access point. WDS Peer Settings WDS # Enter the MAC address for up to four other WDS devices you wish to connect. WDS VLAN VLAN Mode Specify the WDS VLAN mode to “Untagged Port” or “Tagged Port”. VLAN ID Specify the WDS VLAN ID when “Untagged Port” is selected above. WDS Encryption method Encryption Select whether to use “None” or “AES” encryption and enter a pre-shared key for AES consisting of 8-63 alphanumeric characters.
Page 97: Iv-6-3. 5Ghz 11Ac 11An (Not Available On The Wlc-6404)
IV-6-3. 5GHz 11ac 11an (Not available on the WLC-6404) The “5GHz 11ac 11an” menu allows you to view and configure information for your access point’s 5GHz wireless network across four categories: Basic, Advanced, Security and WDS. IV-6-3-1. Basic The “Basic” screen displays basic settings for your access point’s 5GHz Wi-Fi network (s). Wireless Enable or disable the access point’s 5GHz wireless radio. When disabled, no 5GHz SSIDs will be active. Band Select the wireless standard used for the...
Page 98 access point. Combinations of 802.11a, 802.11n & 802.11ac can be selected. Enable SSID Number Select how many SSIDs to enable for the 5GHz frequency from the drop down menu. A maximum of 16 can be enabled. SSID# Enter the SSID name for the specified SSID (up to 16). The SSID can consist of any combination of up to 32 alphanumeric characters. VLAN ID Specify a VLAN ID for each SSID. Auto Channel Enable/disable auto channel selection. Auto channel selection will automatically set the wireless channel for the access point’s 5GHz frequency based on availability and potential interference. When disabled, select a channel manually as shown in the next table. Auto Channel Range Select a range from which the auto channel setting (above) will choose a channel. Auto Channel Specify a frequency for how often the auto Interval channel setting will check/reassign the wireless channel. Check/uncheck the “Change channel even if clients are connected” box according to your preference. Channel Bandwidth Set the channel bandwidth: 20MHz (lower performance but less interference), Auto 40/20MHz or Auto 80/40/20MHz (automatically select based on interference level). BSS BasicRate Set Set a Basic Service Set (BSS) rate: this is a series of rates to control communication frames for wireless clients. When auto channel is disabled, select a wireless channel manually: Channel Select a wireless channel.
Page 99: Iv-6-3-2. Advanced
BSS BasicRate Set Set a Basic Service Set (BSS) rate: this is a series of rates to control communication frames for wireless clients. IV-6-3-2. Advanced These settings are for experienced users only. Please do not change any of the values on this page unless you are already familiar with these functions. Changing these settings can adversely affect the performance of your access point. Guard Interval Set the guard interval. A shorter interval can improve performance. 802.11n Protection Enable/disable 802.11n protection, which increases reliability but reduces bandwidth (clients will send Request to Send (RTS) to access point, and access point will broadcast Clear to Send (CTS), before a packet is sent from client.) DTIM Period Set the DTIM (delivery traffic indication message) period value of the wireless radio. The default value is 1. RTS Threshold Set the RTS threshold of the wireless radio. The default value is 2347. Fragment Set the fragment threshold of the wireless Threshold radio. The default value is 2346. Multicast Rate Set the transfer rate for multicast packets or use the “Auto” setting.
Page 100: Iv-6-3-3. Security
Tx Power Set the power output of the wireless radio. You may not require 100% output power. Setting a lower power output can enhance security since potentially malicious/unknown users in distant areas will not be able to access your signal. Beacon Interval Set the beacon interval of the wireless radio. The default value is 100. Station idle Set the interval for keep alive messages from timeout the access point to a wireless client to verify if the station is still alive/active. IV-6-3-3. Security The access point provides various security options (wireless data encryption). When data is encrypted, information transmitted wirelessly cannot be read by anyone who does not know the correct encryption key. It’s essential to configure wireless security in order to prevent unauthorised access to your network. Select hard-to-guess passwords which include combinations of numbers, letters and symbols, and change your password regularly. SSID Select which SSID to configure security settings for. 100...
Page 101 Broadcast SSID Enable or disable SSID broadcast. When enabled, the SSID will be visible to clients as an available Wi-Fi network. When disabled, the SSID will not be visible as an available Wi-Fi network to clients – clients must manually enter the SSID in order to connect. A hidden (disabled) SSID is typically more secure than a visible (enabled) SSID. Wireless Client Enable or disable wireless client isolation. Isolation Wireless client isolation prevents clients connected to the access point from communicating with each other and improves security. Typically, this function is useful for corporate environments or public hot spots and can prevent brute force attacks on clients’ usernames and passwords. Load Balancing Load balancing limits the number of wireless clients connected to an SSID. Set a load balancing value (maximum 50). Authentication Select an authentication method from the drop Method down menu and refer to the information below appropriate for your method. Additional Select an additional authentication method Authentication from the drop down menu and refer to the information below appropriate for your method. Please refer back to IV-6-2-3. Security for more information on authentication and additional authentication types. 101...
Page 102: Iv-6-3-4. Wds
IV-6-3-4. WDS Wireless Distribution System (WDS) can bridge/repeat access points together in an extended network. WDS settings can be configured as shown below. When using WDS, configure the IP address of each access point to be in the same subnet and ensure there is only one active DHCP server among connected access points, preferably on the WAN side. WDS must be configured on each access point, using correct MAC addresses. All access points should use the same wireless channel and encryption method. 5GHz WDS Mode WDS Functionality Select “WDS with AP” to use WDS with access point or “WDS Dedicated Mode” to use WDS and also block communication with regular wireless clients. When WDS is used, each access point should be configured with corresponding MAC addresses, wireless channel and wireless encryption method. Local MAC Address Displays the MAC address of your access point. 102...
Page 103: Iv-6-4. Wps (Not Available On The Wlc-6404)
WDS Peer Settings WDS # Enter the MAC address for up to four other WDA devices you wish to connect. WDS VLAN VLAN Mode Specify the WDS VLAN mode to “Untagged Port” or “Tagged Port”. VLAN ID Specify the WDS VLAN ID when “Untagged Port” is selected above. WDS Encryption Encryption Select whether to use “None” or “AES” encryption and enter a pre-shared key for AES with 8-63 alphanumeric characters. IV-6-4. WPS (Not available on the WLC-6404) Wi-Fi Protected Setup is a simple way to establish connections between WPS compatible devices. WPS can be activated on compatible devices by pushing a WPS button on the device or from within the device’s firmware/configuration interface (known as PBC or “Push Button Configuration”). When WPS is activated in the correct manner and at the correct time for two compatible devices, they will automatically connect. “PIN code WPS” is a variation of PBC which includes the additional use of a PIN code between the two devices for verification. Please refer to manufacturer’s instructions for your other WPS device. 103...
Page 104: Iv-6-5. Radius (Not Available On The Wlc-6404)
WPS Check/uncheck this box to enable/disable WPS functionality. WPS must be disabled when using MAC-RADIUS authentication (see IV-6-2-3-6. & IV-6-5). Product PIN Displays the WPS PIN code of the device, used for PIN code WPS. You will be required to enter this PIN code into another WPS device for PIN code WPS. Click “Generate PIN” to generate a new WPS PIN code. Push-Button WPS Click “Start” to activate WPS on the access point for approximately 2 minutes. This has the same effect as physically pushing the access point’s WPS button. WPS by PIN Enter the PIN code of another WPS device and click “Start” to attempt to establish a WPS connection for approximately 2 minutes. WPS Status WPS security status is displayed here. Click “Release” to clear the existing status. IV-6-5. RADIUS (Not available on the WLC-6404) The RADIUS sub menu allows you to configure the access point’s RADIUS server settings, categorized into three submenus: RADIUS settings, Internal Server and RADIUS accounts. A RADIUS server provides user-based authentication to improve security and offer wireless client control – users can be authenticated before gaining access to a network. 104...
Page 105 The access point can utilize both a primary and secondary (backup) RADIUS server for each of its wireless frequencies (2.4GHz & 5GHz). External RADIUS servers can be used or the access point’s internal RADIUS server can be used. To use RADIUS servers, go to “Local Network” ! “Security” ! “Additional Authentication” and select “MAC RADIUS Authentication” (see IV-6-2-3.&IV-6-3-3). 105...
Page 106: Iv-6-5-1. Radius Settings
IV-6-5-1. RADIUS Settings Configure the RADIUS server settings for 2.4GHz & 5GHz. Each frequency can use an internal or external RADIUS server. 106...
Page 107: Iv-6-5-2. Internal Server
RADIUS Type Select “Internal” to use the access point’s built-in RADIUS server or “external” to use an external RADIUS server. RADIUS Server Enter the RADIUS server host IP address. Authentication Set the UDP port used in the authentication Port protocol of the RADIUS server. Value must be between 1 – 65535. Shared Secret Enter a shared secret/password between 1 – 99 characters in length. This should match the “MAC-RADIUS” password used in IV-3-1-3-6 or IV-3-2-3. Session Timeout Set a duration of session timeout in seconds between 0 – 86400. Accounting Enable or disable RADIUS accounting. Accounting Port When accounting is enabled (above), set the UDP port used in the accounting protocol of the RADIUS server. Value must be between 1 – 65535. IV-6-5-2. Internal Server The access point features a built-in RADIUS server which can be configured as shown below used when “Internal” is selected for “RADIUS Type” in the “Local Network” ! “RADIUS Settings” menu. To use RADIUS servers, go to “Wireless Settings” ! “Security”“Additional Authentication” and select “MAC RADIUS Authentication” (see IV-6-2-3.&IV-6-3-3). 107...
Page 108 Internal Server Check/uncheck to enable/disable the access point’s internal RADIUS server. EAP Internal Select EAP internal authentication type from Authentication the drop down menu. EAP Certificate File Displays the EAP certificate file format: Format PCK#12(*.pfx/*.p12) EAP Certificate File Click “Upload” to open a new window and select the location of an EAP certificate file to use. If no certificate file is uploaded, the internal RADIUS server will use a self-made certificate. Shared Secret Enter a shared secret/password for use between the internal RADIUS server and RADIUS client. The shared secret should be 1 – 99 characters in length. This should match the “MAC-RADIUS” password used in IV-6-2-3-6 or IV-6-3-3. Session Timeout Set a duration of session timeout in seconds between 0 – 86400. Termination Action Select a termination-action attribute: “Reauthentication” sends a RADIUS request to the access point, “Not-Reathentication” sends a default termination-action attribute to the access point, “Not-Send” no termination-action attribute is sent to the access point. 108...
Page 109: Iv-6-5-3. Radius Accounts
IV-6-5-3. RADIUS Accounts The internal RADIUS server can authenticate up to 256 user accounts. The “RADIUS Accounts” page allows you to configure and manage users. User Name Enter the user names here, separated by commas. Add Click “Add” to add the user to the user registration list. Reset Clear text from the user name box. Select Check the box to select a user. User Name Displays the user name. Password Displays if specified user name has a password (configured) or not (not configured). Customize Click “Edit” to open a new field to set/edit a 109...
Page 110 password for the specified user name (below). Delete Selected Delete selected user from the user registration list. Delete All Delete all users from the user registration list. Edit User Registration List User Name Existing user name is displayed here and can be edited according to your preference. Password Enter or edit a password for the specified user. 110...
Page 111: Iv-6-6. Mac Filter (Not Available On The Wlc-6404)
IV-6-6. MAC Filter (Not available on the WLC-6404) Mac filtering is a security feature that can help to prevent unauthorized users from connecting to your access point. This function allows you to define a list of network devices permitted to connect to the access point. Devices are each identified by their unique MAC address. If a device which is not on the list of permitted MAC addresses attempts to connect to the access point, it will be denied. To enable MAC filtering, go to “Local Settings” ! “Security” ! “Additional Authentication” and select “MAC Filter” (see IV-6-2-3.&IV-6-3-3). The MAC address filtering table is displayed below: 111...
Page 112 Add MAC Address Enter a MAC address of computer or network device manually e.g. ‘aa-bb-cc-dd-ee-ff’ or enter multiple MAC addresses separated with commas, e.g. ‘aa-bb-cc-dd-ee-ff,aa-bb-cc-dd-ee-gg’ Add Click “Add” to add the MAC address to the MAC address filtering table. Reset Clear all fields. MAC address entries will be listed in the “MAC Address Filtering Table”. Select an entry using the “Select” checkbox. Select Delete selected or all entries from the table. MAC Address The MAC address is listed here. Delete Selected Delete the selected MAC address from the list. Delete All Delete all entries from the MAC address filtering table. Export Click “Export” to save a copy of the MAC filteringtable. A new window will pop up for you to select a location to save the file. 112...
Page 113: Iv-6-7. Wmm (Not Available On The Wlc-6404)
IV-6-7. WMM (Not available on the WLC-6404) Wi-Fi Multimedia (WMM) is a Wi-Fi Alliance interoperability certification based on the IEEE 802.11e standard, which provides Quality of Service (QoS) features to IEE 802.11 networks. WMM prioritizes traffic according to four categories: background, best effort, video and voice. Configuring WMM consists of adjusting parameters on queues for different categories of wireless traffic. Traffic is sent to the following queues: Background Low High throughput, non time sensitive bulk Priority data e.g. FTP Best Effort Medium Traditional IP data, medium throughput and Priority delay. Video High Time sensitive video data with minimum Priority time delay. Voice High Time sensitive data such as VoIP and Priority streaming media with minimum time delay. Queues automatically provide minimum transmission delays for video, voice, multimedia and critical applications. The values can further be adjusted manually: 113...
Page 114: Iv-6-8. Internal Server
CWMin Minimum Contention Window (milliseconds): This value is input to the initial random backoff wait time algorithm for retry of a data frame transmission. The backoff wait time will be generated between 0 and this value. If the frame is not sent, the random backoff value is doubled until the value reaches the number defined by CWMax (below). The CWMin value must be lower than the CWMax value. The contention window scheme helps to avoid frame collisions and determine priority of frame transmission. A shorter window has a higher probability (priority) of transmission. CWMax Maximum Contention Window (milliseconds): This value is the upper limit to random backoff value doubling (see above). AIFSN Arbitration Inter-Frame Space (milliseconds): Specifies additional time between when a channel goes idle and the AP/client sends data frames. Traffic with a lower AIFSN value has a higher priority. TxOP Transmission Opportunity (milliseconds): The maximum interval of time an AP/client can transmit. This makes channel access more efficiently prioritized. A value of 0 means only one frame per transmission. A greater value effects higher priority. IV-6-8. Internal Server IV-6-8-1. Internal RADIUS Server The controller features a built-in RADIUS server which can be configured as shown below used when “Internal” is selected for “RADIUS Type” in the “Local Network” ! “RADIUS Settings” menu. To use RADIUS servers, go to “Wireless Settings” ! “Security”“Additional Authentication” and select “MAC RADIUS Authentication” (see IV-6-2-3. & IV-6-3-3).
Page 115 Internal Server Check/uncheck to enable/disable the access point’s internal RADIUS server. EAP Internal Select EAP internal authentication type from Authentication the drop down menu. EAP Certificate File Displays the EAP certificate file format: Format PCK#12(*.pfx/*.p12) EAP Certificate File Click “Upload” to open a new window and select the location of an EAP certificate file to use. If no certificate file is uploaded, the internal RADIUS server will use a self-made certificate. Shared Secret Enter a shared secret/password for use between the internal RADIUS server and RADIUS client. The shared secret should be 1 – 99 characters in length. This should match the “MAC-RADIUS” password used in IV-6-2-3-6 or IV-6-3-3. Session Timeout Set a duration of session timeout in seconds between 0 – 86400. Termination Action Select a termination-action attribute: “Reauthentication” sends a RADIUS request to the access point, “Not-Reathentication” sends a default termination-action attribute to the access point, “Not-Send” no termination-action attribute is sent to the access point. 115...
Page 116: Iv-6-8-2. Radius Accounts
IV-6-8-2. RADIUS Accounts The internal RADIUS server can authenticate up to 256 user accounts. The “RADIUS Accounts” page allows you to configure and manage users. User Name Enter the user names here, separated by commas. Add Click “Add” to add the user to the user registration list. Reset Clear text from the user name box. Select Check the box to select a user. User Name Displays the user name. Password Displays if specified user name has a password (configured) or not (not configured). Customize Click “Edit” to open a new field to set/edit a password for the specified user name (below). 116...
Page 117: Iv-6-9. Schedule
Delete Selected Delete selected user from the user registration list. Delete All Delete all users from the user registration list. Edit User Registration List User Name Existing user name is displayed here and can be edited according to your preference. Password Enter or edit a password for the specified user. IV-6-9. Schedule Schedule allows the user to configure specific times and dates when the radio of the wireless account will be disabled. This is designed to prevent unwanted access during non-application hours. 117...
Page 118: Iv-7. Local Settings
IV-7. Local Settings IV-7-1. Operation Mode (Not available on the WLC-6404) Set the operation mode of the access point. AP mode is a standalone access point, AP controller mode acts as the designated master of the AP array, and Managed AP mode acts as a slave AP within the AP array. IV-7-2. System Settings IV-7-2-1. System Information The “System Information” page displays basic system information about the access point. 118...
Page 119 System Model Displays the model number of the access point. Product Name Displays the product name for reference, which consists of “AP” plus the MAC address. Uptime Displays the total time since the device was turned on. Boot From Displays information for the booted hardware, booted from either USB or internal memory. Version Displays the firmware version. MAC Address Displays the access point’s MAC address. Management VLAN Displays the management VLAN ID. IP Address Displays the IP address of this device. Click “Refresh” to update this value. Default Gateway Displays the IP address of the default gateway. DNS IP address of DNS (Domain Name Server) DHCP Server IP address of DHCP Server. Wired LAN Port Settings Wired LAN Port Specifies which LAN port (1 or 2). Status Displays the status of the specified LAN port 119...
Page 120 (connected or disconnected). VLAN Mode/ID Displays the VLAN mode (tagged or untagged) and VLAN ID for the specified LAN port. See IV-6-1-3. VLAN Wireless 2.4GHz (5GHz) Status Displays the status of the 2.4GHz or 5GHz wireless (enabled or disabled). MAC Address Displays the access point’s MAC address. Channel Displays the channel number the specified wireless frequency is using for broadcast. Transmit Power Displays the wireless radio transmit power level as a percentage. Wireless 2.4GHZ (5GHz) / SSID SSID Displays the SSID name(s) for the specified frequency. Authentication Displays the authentication method for the Method specified SSID. See IV-6. Wireless Settings Encryption Type Displays the encryption type for the specified SSID. See IV-6. Wireless Settings VLAN ID Displays the VLAN ID for the specified SSID. See IV-6-1-3. VLAN Additional Displays the additional authentication type for Authentication the specified SSID. See IV-6. Wireless Settings Wireless Client Displays whether wireless client isolation is in Isolation use for the specified SSID. See IV-6-1-3. VLAN Wireless 2.4GHZ (5GHz) / WDS Status MAC Address Displays the peer access point’s MAC address.
Page 121: Iv-7-2-2. Wireless Clients (Not Available On The Wlc-6404)
IV-7-2-2. Wireless Clients (Not available on the WLC-6404) The “Wireless Clients” page displays information about all wireless clients connected to the access point on the 2.4GHz or 5GHz frequency. Refresh time Auto Refresh Time Select a time interval for the client table list to automatically refresh. Manual Refresh Click refresh to manually refresh the client table. 2.4GHz (5GHz) WLAN Client Table SSID Displays the SSID which the client is connected to. MAC Address Displays the MAC address of the client. Displays the total data packets transmitted by the specified client. Displays the total data packets received by the specified client. Signal (%) Displays the wireless signal strength for the specified client. Connected Time Displays the total time the wireless client has been connected to the access point. Idle Time Client idle time is the time for which the client has not transmitted any data packets i.e. is idle. Vendor The vendor of the client’s wireless adapter is displayed here. 121...
Page 122: Iv-7-2-3. Wireless Monitor (Not Available On The Wlc-6404)
IV-7-2-3. Wireless Monitor (Not available on the WLC-6404) Wireless Monitor is a tool built into the access point to scan and monitor the surrounding wireless environment. Select a frequency and click “Scan” to display a list of all SSIDs within range along with relevant details for each SSID. Wireless Monitor Site Survey Select which frequency (or both) to scan, and click “Scan” to begin. Channel Survey After a scan is complete, click “Export” to save Result the results to local storage. Site Survey Results Displays the channel number used by the specified SSID. SSID Displays the SSID identified by the scan. MAC Address Displays the MAC address of the wireless router/access point for the specified SSID. Security Displays the authentication/encryption type of the specified SSID. Signal (%) Displays the current signal strength of the SSID. Type Displays the 802.11 wireless networking standard(s) of the specified SSID. Vendor Displays the vendor of the wireless router/access point for the specified SSID. 122...
Page 123: Iv-7-2-4. Log
IV-7-2-4. Log The system log displays system operation information such as up time and connection processes. This information is useful for network administrators. When the log is full, old entries are overwritten. Save Click to save the log as a file on your local computer. Clear Clear all log entries. Refresh Refresh the current log. 123...
Page 124 The following information/events are recorded by the log: " USB Mount & unmount " Wireless Client Connected &disconnected Key exchange success & fail " Authentication Authentication fail or successful. " Association Success or fail " WPS M1 - M8 messages WPS success " Change Settings " System Boot Displays current model name " NTP Client " Wired Link LAN Port link status and speed status " Proxy ARP Proxy ARP module start & stop " Bridge Bridge start & stop. " SNMP SNMP server start &stop. " HTTP HTTP start & stop. "...
Page 125: Iv-7-3. Management
IV-7-3. Management IV-7-3-1. Admin You can change the password used to login to the browser-based configuration interface here. It is advised to do so for security purposes. If you change the administrator password, please make a note of the new password. In the event that you forget this password and are unable to login to the browser based configuration interface, see IV-7-4-4. Factory Default for how to reset the access point. Account to Manage This Device Administrator Set the access point’s administrator name. Name This is used to log in to the browser based configuration interface and must be between 4-16 alphanumeric characters (case sensitive). Administrator Set the access point’s administrator password. Password This is used to log in to the browser based configuration interface and must be between 125...
Page 126 4-32 alphanumeric characters (case sensitive). Advanced Settings Product Name Edit the product name according to your preference consisting of 1-32 alphanumeric characters. This name is used for reference purposes. Management Check/uncheck the boxes to enable/disable Protocol specified management interfaces (see below). When SNMP is enabled, complete the SNMP fields below. SNMP Version Select SNMP version appropriate for your SNMP manager. SNMP Get Enter an SNMP Get Community name for Community verification with the SNMP manager for SNMP-GET requests. SNMP Set Enter an SNMP Set Community name for Community verification with the SNMP manager for SNMP-SET requests. SNMP Trap Enable or disable SNMP Trap to notify SNMP manager of network errors. SNMP Trap Enter an SNMP Trap Community name for Community verification with the SNMP manager for SNMP-TRAP requests. SNMP Trap Specify the IP address or sever name (2-128 Manager alphanumeric characters) of the SNMP manager. HTTP Internet browser HTTP protocol management interface HTTPS Internet browser HTTPS protocol management interface...
Page 127: Iv-7-3-2. Date And Time
IV-7-3-2. Date and Time You can configure the time zone settings of your access point here. The date and time of the device can be configured manually or can be synchronized with a time server. Date and Time Settings Local Time Set the access point’s date and time manually using the drop down menus. Acquire Current Click “Acquire Current Time from Your PC” to Time from your PC enter the required values automatically according to your computer’s current time and date. NTP Time Server Use NTP The access point also supports NTP (Network Time Protocol) for automatic time and date setup. Server Name Enter the host name or IP address of the time server if you wish. Update Interval Specify a frequency (in hours) for the access point to update/synchronize with the NTP server. Time Zone Time Zone Select the time zone of your country/ region. If 127...
Page 128: Iv-7-3-3. Syslog Server
your country/region is not listed, please select another country/region whose time zone is the same as yours. IV-7-3-3. Syslog Server The system log can be sent to a server, attached to USB storage or sent via email. Syslog Server Settings Transfer Logs Check/uncheck the box to enable/disable the use of a syslog server, and enter a host name, domain or IP address for the server, consisting of up to 128 alphanumeric characters. Copy Logs to Check/uncheck the box to enable/disable Attached USB Device copying logs to attached USB storage. Syslog Email Settings Email Logs Check/uncheck the box to enable/disable email logs. When enabled, the log will be emailed according to the settings below. Email Subject Enter the subject line of the email which will be sent containing the log. SMTP Server Specify the SMTP server address for the sender Address email account. SMTP Server Port Specify the SMTP server port for the sender email account. 128...
Page 129: Iv-7-3-4. I'm Here
Sender Email Enter the sender’s email address. Receiver Email Specify the email recipient of the log. Authentication Select “Disable”, “SSL” or “TLS” according to your email authentication. Account When authentication is used above, enter the account name. Password When authentication is used above, enter the password. IV-7-3-4. I’m Here The access point features a built-in buzzer which can sound on command using the “I’m Here” page. This is useful for network administrators and engineers working in complex network environments to locate the access point. The buzzer is loud! Duration of Sound Set the duration for which the buzzer will sound when the “Sound Buzzer” button is clicked. Sound Buzzer Activate the buzzer sound for the above specified duration of time. 129...
Page 130: Iv-7-4. Advanced
IV-7-4. Advanced Wi-Fi Multimedia (WMM) is a Wi-Fi Alliance interoperability certification based on the IEEE 802.11e standard, which provides Quality of Service (QoS) features to IEE 802.11 networks. WMM prioritizes traffic according to four categories: background, best effort, video and voice. IV-7-4-1. LED Settings The access point’s LEDs can be manually enabled or disabled according to your preference. Power LED Select on or off. Diag LED Select on or off. IV-7-4-2. Update Firmware The “Firmware” page allows you to update the system firmware to a more recent version. Updated firmware versions often offer increased performance and security, as well as bug fixes. This firmware update is for an individual access point. To update firmware for multiple access points in the AP array, go to NMS Settings ! Firmware Upgrade. Do not switch off or disconnect the access point during a firmware upgrade, as this could damage the device. 130...
Page 131 Update Firmware Select “a file on your PC” to upload firmware From from your local computer or from an attached USB device. Firmware Update File Click “Browse” to open a new window to locate and select the firmware file in your computer. Update Click “Update” to upload the specified firmware file to your access point. 131...
Page 132: Iv-7-4-3. Save/Restore Settings
IV-7-4-3. Save/Restore Settings The access point’s “Save/Restore Settings” page enables you to save/backup the access point’s current settings as a file to your local computer or a USB device attached to the access point, and restore the access point to previously saved settings. Save / Restore Settings Using Device Select “Using your PC” to save the access point’s settings to your local computer or to an attached USB device. Save Settings to PC Save Settings Click “Save” to save settings and a new window will open to specify a location to save the settings file. You can also check the “Encrypt the configuration file with a password” box and enter a password to protect the file in the field underneath, if you wish. Restore Settings from PC Restore Settings Click the browse button to find a previously saved settings file on your computer, then click “Restore” to replace your current settings. If your settings file is encrypted with a password, check the “Open file with password” box and enter the password in the field underneath. 132...
Page 133: Iv-7-4-4. Factory Default
IV-7-4-4. Factory Default If the access point malfunctions or is not responding, then it is recommended that you reboot the device (see IV-7-4-5.) or reset the device back to its factory default settings. You can reset the access point back to its default settings using this feature if the location of the access point is not convenient to access the reset button. Factory Default Click “Factory Default” to restore settings to the factory default. A pop-up window will appear and ask you to confirm. After resetting to factory defaults, please wait for the access point to reset and restart. IV-7-4-5. Reboot If the access point malfunctions or is not responding, then it is recommended that you reboot the device or reset the access point back to its factory default settings (see IV-7-4-4). You can reboot the access point remotely using this feature. Reboot Click “Reboot” to reboot the device. A countdown will indicate the progress of the reboot. 133...
Page 134: Iv-8. Toolbox
IV-8. Toolbox IV-8-1. Network Connectivity IV-8-1-1. Ping Ping is a computer network administration utility used to test whether a particular host is reachable across an IP network and to measure the round-trip time for sent messages. Destination Address Enter the address of the host. Execute Click execute to ping the host. IV-8-1-2. Trace Route Traceroute is a diagnostic tool for displaying the route (path) and measuring transit delays of packets across an IP network. Destination Address Enter the address of the host. Execute Click execute to execute the traceroute command. 134...
Page 135: Best Practice
V. Best Practice How to Create and Link WLAN & Access Point Groups You can use NMS to create individual SSIDs and group multiple SSIDs together into WLAN groups. You can then assign individual access points to use those WLAN group settings and/or group multiple access points together into access point groups, which you can also assign to use WLAN group settings. Follow the example below to: A. Create a WLAN group. B. Create an access point group. C. Assign the access point group to use the SSID group settings. 1. Go to NMS Settings ! WLAN and click “Add” in the WLAN panel: 2. Enter an SSID name and set authentication/encryption and click “Apply”: 3. The new SSID will be displayed in the WLAN panel. Repeat to add additional SSIDs according to your preference, and then click “Add” in the WLAN Group panel: 4. Enter a name for the SSIDgroup and check the boxes to select which SSIDs to include within the group. Click “Apply” when done. 135...
Page 136 5. The new WLAN group will be displayed in the WLAN Group panel. Repeat to add additional WLAN groups according to your preference: 1. Go to NMS Settings ! Access Point and click “Add” in the Access Point Group Panel: 2. Enter a Name and then scroll down to the Group Settings panel and use the << button to add selected access points into your group from the box on the right side. Click “Apply” when done. 136...
Page 137 3. The new access point group will be displayed in the Access Point Group panel. Repeat to add additional access point groups according to your preference: 1. Go to NMS Settings ! Access Point and select an access point group using the checkboxes in the Access Point Group panel. Click “Edit”: 2. Scroll down to the Profile Group Settings panel and check the “Override Group Settings” box for WLAN Group (2.4GHz and/or 5GHz). Select your WLAN group from the drop-down menu and click “Apply”: 3. Repeat for other access point groups according to your preference. COPYRIGHT Copyright ©2017 by this company. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company This company makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Any software described in this manual is sold or licensed "as is". Should the programs prove defective following their purchase, the buyer (and not this company, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software. Further, this company reserves the right to revise this publication and to make changes from time to time in the contents thereof without obligation to notify any person of such revision or changes. 137...
