A-ADT8H/16H QUICK REFERENCE GUIDE
EVENT ACTION SETTINGS
1. Highlight the Alarm-In, Motion Detection and Video Loss
in the Event menu and press the
Setting and Actions setup screens will appear.
2. In each Event Actions screen, you can set the actions
(Record, Alarm-Out, Notify, PTZ and Spot Monitor) the DVR
will take whenever it senses alarm input, detects motion
and loses video.
3. Highlight the System Event in the Event menu and press the
System Event setup screen will appear.
4. In the System Event Actions screen, you can set the actions (Alarm-Out and
Notify) the DVR will take when it detects system events.
CLIP-COPY
The Clip-Copy screen can be used to copy video to an internal DVD RW, or
external USB hard disk or flash drives. The clip copy can be simply done by
pressing the "CLIP COPY" button on the front panel, or selecting Clip-Copy
or A-B Clip-Copy in the Search menu.
*NOTE: The Clip Copy feature requires the camera title or number along
with the date and time of the recorded images to be copied. To view
the copied images, remove the disk from the DVD RW device and insert
it into any PC with a CD or DVD reader. On the PC access the CD or
DVD drive device and select the image file name. The executable Clip
Player software program will open automatically displaying playback
controls for viewing the video clip.
SEARCH AND PLAYBACK
1. Press the "PLAYBACK" button on the front panel or select
in the Live Monitoring menu to enter the Playback mode. If a user who has
Search authority logs into the system, the user can view recorded images.
2. Press the "MENU" button while in the Search mode or move the mouse pointer
to the top of the screen to display the Search Menu. Select the type of search
using the arrow buttons and press the
Search Go To
Alarm Reset Panic
FEATURES AND FUNCTIONS (2)
button. The Event
button. The
(Search Mode)
button.
Export Camera Menu
Data Source Exit
Event Search
1. Select <Event Log Search> or < Motion Search > in the Search Menu.
2. The event log list will be shown on the screen. Highlight the event you
would like to see and press the
For more specific search conditions, select <Option> and enter search
parameters then select <Search>. The search results will be displayed
in each screen.
3. Pressing the button will start playing the "event" video segment. Press
the "PLAYBACK" button to return to live monitoring.
Calendar Search
1. Select <Search> <Calendar Search> in the Search Menu.
2. Days with recorded video display on the calendar with white numbers.
Once you have highlighted a day, press the
Record Table Search
3. Select <Search> <Record Table Search> in the Search Menu.
4. Recording information about video images currently displayed on the
screen displays on the recording status bar. To search specific video,
move the vertical line by using the Left or Right arrow buttons on the
front panel or by clicking the mouse on the desired segment.
Compact View
Standard View
Go To Search
1. Select <Go To> in the Search Menu. Selecting <Go to the First> displays
the first recorded image, selecting < Go to the Last> displays the last
recorded image, and selecting < Go to the Date/Time> displays the Go
to the Date/Time screen.
2. Enter a specific date and time and select "OK" by pressing the
The button and arrow buttons to review the video.
button.
button to select it.
Expanded View
button.
V1.0
