BroadLink RC10 User Manual

I.

Introduction

RC10 is a mini wireless remote control with 4 buttons. As an important
part of Kaipule wireless alarm host, it has the functions of panic button
& household host remote control. With novel design & unique emitter with
4 buttons, it is convenient to carry and can be regarded as a decoration.
It gets extremely high sensitivity within 70M. Through codes setting,
RC10 can control wireless devices easily & conveniently. What's more,
you can use traditional away arming / disarming, and send emergency
information through panic button. Simple operation can protect your life
and property more effectively. High quality is your first choice for modern
smart home system.
II.

Specifications

Model No.: RC 10
Effective Range: ≤70 m
Operating Voltage: CR 2032, 3V lithium battery (1 year working life)
Information Transmitting: press the button for more than 1s,
LED light flashes at the same time
Working Environment: - 20 ℃ ~ 55 ℃
Operating Current: ≤15mA
Humidity: ≤80%
Non-condensing Quiescent Current: ≤1uA
Dimensions: 58 * 31 * 1 0mm Weight: 30 g
Color: white
IV.

Usage

1, Away arming：press the away
arming button for 2 seconds
Wireless Intelligent Remote Control User Manual
2, Home arming: press the home
arming button for 2 seconds
Away Arming
Home Arming
III.

Main Functions

A. 4 independent functional buttons
B. Remote arming / disarming, convenient & simple; remote
emergency call, securely hidden
C. Away arming / home arming
D. Comfortable & exquisite design; foolproof graphic interpretation button.
E. Low transmission power; signal output indicator is visible.
F. Compatible with all wireless hosts or other alarm systems of Kaipule..
LED light
Disarming
Emergency
Button
Case
Rear Cover
(with screw holes)
Hanging Ring
3, Disarming: press the disarming
button for 2 seconds
4, Emergency call & securely hidden:
press the panic button for 2 seconds
