- Page 1 ® ® Pending UL325 compliant UL991 WWW.ALLOMATIC.NET compliant SW-350DC & SW-300DC Installation Manual Copyright © 2008 all-o-matic inc. www.allomatic.net...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important safety instructions ............2&3 Different UL 325 class types............. Concrete pad Specs for SW-300DC..........Concrete pad Specs for SW-350DC..........Concrete Operator & Arm Layout..........7,8&9 Compact Installation................ Torque limiter & Arm adjustment............Gate travel adjustment..............Directional settings................ -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of injury: READ THE FOLLOWING DIRECTIONS. DO NOT EVEN THINK OF STARTING UNTIL YOU HAVE READ AND UNDERSTAND THESE DIRECTIONS. IF THERE IS SOMETHING YOU DO NOT UNDERSTAND CALL US. Never let children operate or play with gate controls. Keep the remote control away from children. - Page 4 INSTALL THE GATE OPERATOR ONLY WHEN YOU HAVE READ THE FOLLOWING: *Confirm that the gate operator being installed is appropriate for the application. *Confirm that the gate is designed and built according to current published industry standards. *Confirm that all appropriate safety features and safety accessory devices are being incorporated, including both primary and secondary entrapment protection devices.
-
Page 5: Different Ul 325 Class Types
DIFFERENT UL 325 CLASS TYPES Class one: Residential A vehicle gate operator intended for use at a home of one to four single family dwellings, garages or parking area. Class Two: Commercial or General Public Access A vehicular gate operator intended for use at a commercial location or building such as a multi-family housing unit (five or more single family units), hotel, garages, retail stores, other buildings servicing the general public. -
Page 6: Concrete Pad Specs For Sw-300Dc
CONCRETE PAD FOR SW-300DC Four red head Bolts ” ” Operator plastic Cover 24” 13.5” Area for Conduit(s) Operator Concrete Operator frame 9.5” 24” 25.5” 23” When possible Install 4” above Ground 4” Low voltage Single Conduit for Master/Slave 24” Footing for Gate operator High voltage... -
Page 7: Concrete Pad Specs For Sw-350Dc
CONCRETE PAD FOR SW-350DC 25 ” Operator plastic Four red head cover ” Bolts ” 15” 9” 24” Area for Conduit(s) Operator concrete pad Operator frame ” 30” 17 / ” ” When possible install 4” above ground 4” Low voltage single conduit for Master/Slave 24”... -
Page 8: Compact Installation
OPERATOR AND ARM DIMENTIONS HINGE CENTER OUTSIDE POST Refer to This distance is from INSIDE note the gate in open 2” position to edge of the below. pad. Refer to note CONCRETE PAD Dimentions Chart Gate Minimum length Distance Less than 12”... - Page 9 OPERATOR AND ARM LAYOUT Hinge point “A” Point Bracket Mark ground under Bracket gate bracket with gate closed. This will Point be point Mark ground under 14” gate bracket with gate open. This will be point Bracket Hinge point Point Bracket Point Draw a line from point...
- Page 10 ARM LAYOUT & OPERATOR PLACEMENT CONTINUED Bracket Hinge point Point Bracket Point Measure distance from the point And point Say distance is 60”, divide this number by 2,which =30”. This is the length of primary arm in next drawing. PLEASE BE EXACT!!! Center shaft of Operator This ARM section is half the...
-
Page 11: 7,8&9 Compact Installation
SWINGER COMPACT INSTALLATON To use this installation the gate must be 12’ or less. HINGE CENTER 27” OUTSIDE INSIDE 8” 35” 20” Use these measurements, only if the distance between the wall and the gate in the open position is 20” to 34”. If you have more than 34”... -
Page 12: Torque Limiter & Arm Adjustment
20” Pipe wrench Torque limiter adjusting nut. Side view Top view SW-350DC SW-300DC Use a pad lock or a ARM ADJUSTMENT: bolt to hold the arm lever in closed MASTER position. With the arm lever closed tighten the arm adjusting screw as tight as possible. -
Page 13: Gate Travel Adjustment
GATE TRAVEL ADJUSTMENT Locate limit switch. Step 1: Turn the power off on operator. Step 2: Use an allen wrench to loosen up the limit cams. Turn the limit Cams to desired direction. Step 3: tighten the allen screw. Step 4: Turn the operator back on. Step 5: Run gate operator. -
Page 14: Directional Settings
OPENING DIRECTION SETTINGS OPEN L/R dipswitch to change the opening direction on the operator. left hand opening right hand opening. LED’s will show opening or closing directions when gate is running. Opening to the left Opening to the right... -
Page 15: Electrical Power Connections
ELECTRICAL CONNECTION OPERATORS BE PROPERLY GROUNDED! MUST Power switch When applying 230V to NOTE: operator make sure voltage GRD LINE 1 LINE 2 switch is flipped to 230V position. 120 Volt Electrical Plug. Power connection | 115VAC | 220VAC Single Phase 115V N 220V LINE 1 LINE 1... -
Page 16: Typical Loop Layout
SWINGER LOOP LAYOUT Outside Safety loop WIRED IN SERIES Center Phantom loop Gate in open Gate in open position position 1/4 IN 1/4 IN TWISTED 6 TURNS Inside Safety loop PER FOOT Exit loop WHEN USED This is a normal loop layout. Remember when connecting to an All-O- from Matic circuit board you use the your... -
Page 17: General Loop Installation Guidelines
GENERAL LOOP INSTALLATION GUIDELINES The following loop installation guidelines are for installing typical driveway loops for access control applications (i.e. parking gates, sliding gates, swing gates etc...) Always consult with loop detector manufacturers for specific equipment guidelines. This will confirm that the proper configuration and installation techniques are applied for your application. -
Page 18: Accessory Connections
ACCESSORY CONNECTIONS The circuit board 12 or 24VDC output provides up to mAmps of power for accessories. More than two or three accessories will require a separate power supply. 12 or 24VDC Accessories only. NOTE: Remove wire jumper from SAFETY when See page 14 for plugin loop a safety device is... -
Page 19: Multiple Safety Device Connections
MULTIPLE SAFETY DEVICES CONNECTIONS Multiple SAFETY devices installed together must be connected “ in series ” Locate the white loop rack safety wire and connect with common wire of second device. Dry contact (N.C.) from second device goes to SAFETY the circuit board B efore installing the accessory devices, remove the wire jumper from the... -
Page 20: Plugin Detector Installation
® LPR-1 LOOP RACK INATALLATION This is a typical loop configuration for a gated driveway. Remember when connecting to an All-O-Matic circuit board the safety (reverse) uses from the loop normally closed contacts detector, the wire jumper from the safety connector needs to be removed when a safety loop is inatalled. -
Page 21: Leading Edge Installation
LEADING EDGE CONNECTION wire to 12VDC wire to COMMON BLACK LEADING EDGE SENSOR Connect one of the wires from leading edge and/or one of the grey wires from a wireless edge receiver to COMMON connector control board. Connect the other wire from leading edge and/or the other wire from a wireless edge receiver to EDGE connector... -
Page 22: Three Button Station
THREE BUTTON STATION SYSTEM See push button connections below. A three button station was integrated on the board to make adjustments easier when setting limit switches and adjusting ERDs. PED-SW Jumper Connect the COMMON from all the push buttons COMMON input on the board. -
Page 23: Magnetic/Solenoid Lock Installation
MAGNETIC/SOLENOID LOCK CONNECTIONS Magnetic lock installation requires a step down transformer with appropriate voltage for the specific lock accessory. Operator will provide a 120VAC outlet for the step down transformer. Plug the lock device transformer to the 120VAC outlet plug. Connections: Connect one wire from transformer directly to one wire of the magnetic lock, For Magnetic lock:... -
Page 24: Master/Slave Connections
MASTER/SLAVE CONNECTION Before connecting master/slave gate operators together, test and adjust limit switches and the ERDs for each operator as “ stand alone ” machines. All accessories must be installed on the master board, no exception. See page 27 for dip switch settings. Use a two wire and run it through a UL listed conduit for master/slave connection. -
Page 25: Radio Receiver Hookup
RADIO RECEIVER CONNECTIONS 4 wire receiver: connect the two relay wires to & terminals. Black wire to terminal and Red wire to terminal negative positive receiver strip outside control box as shown below. Pcb also provides 12VDC & 24VDC Inputs. 3 = 12V 2 = Relay Receiver terminal strip... -
Page 26: Open & Close Electronic Reversing Sensor(Erd) Adjustment
OPEN AND CLOSE ELECTRONIC REVERSING SENSOR(ERDs) ADJUSTMENT Open and Close ERD I0615 SENSITIVITY F260 DR127-330 43CL07 E HFK. Coilcraft Coilcraft 360G CMX-309FB C 8.0000 M 535202 ERD’S must be adjusted Counter clockwise maximum sensitivity by qualified technician. Clockwise minimum sensitivity The gate operator ERDs must be adjusted so that the gate provides regular, reliable and safe cycles. -
Page 27: Timer Adjustment
TIMER ADJUSTMENT TIMER ON: Timer to close, can be set from 1 to 60 seconds. TIMER OFF: Gate operation is push button to open, push button to close. OVERRIDE THE TIMER: Turn the RADIO switch to the “ON” position. This will allow the radio receiver to close the gate before the timer. TIMER ADJUSTMENT Turn potentiometer counter clockwise for more time. -
Page 28: Dip Switch Functions
DIP SWITCH FUNCTIONS TIMER switch “ ” activates the TIMER. See page 21 TIMER TIMER for details RADIO RADIO switch “ ” allows the radio receiver to override RADIO FAIL SF/SC the timer. See page 21 for details. 1-PASS SLAVE switch “... -
Page 29: Emergency Release For Sw-350Dc
EMERGENCY RELEASE SW-350DC Procedures to release gate: 1. Turn power OFF. 2. Push pedal down & move pedal lightly to the right to hold pedal down in position 3. Push gate open. See page 11 for emergency release of SW-300 Operator. -
Page 30: Solar Panel Installation
SOLAR PANEL CONNECTION The solar panel input will take a 12VDC panel or two 12VDC panels wired in sires to make 24VDC . The charging circuit is limited by 1 Amp max. NOTE: For information on what solar panel to use on any other type of installation call ALL O MATIC for Assistance. -
Page 31: Led Diagnostics
LED DIAGNOSTICS Will be lit when AC power is ON. AC/PWR ON: Will be lit when master/slave communication is active. M/S LINK: Two states. ALARM: 1st state: LED will blink(horn will beep also) every 30 seconds when battery is low, bad or disconnected. -
Page 32: Swinger Arm Parts
SWINGER ARM PARTS ROUND ARM PIPE KNUCKLES QUICK RELEASE ARM BUSHING SECONDARY PIPE ARM 3 SET SCREWS GATE BRACKET PRIMARY FLAT BAR FLAT BAR QUICK RELEASE ARM BUSHING SECONDARY GATE BRACKET PRIMARY RECTANGULAR ARM...
