Industrial
Managed Ethernet Switch
iES12G User Manual
Version 1.1
July 2015
iS5 Communications Inc.
#3-7490 Pacific Circle,
Mississauga, Ontario, L5T 2A3
Tel: + 905- 670- 0004
Fax: + 289- 401- 5206
Website:
www.iS5Com.com
E-mail:
support@iS5Com.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iES12G and is the answer not in the manual?

Questions and answers

Related Manuals for iS5 iES12G

Summary of Contents for iS5 iES12G

  • Page 1 Industrial Managed Ethernet Switch iES12G User Manual Version 1.1 July 2015 iS5 Communications Inc. #3-7490 Pacific Circle, Mississauga, Ontario, L5T 2A3 Tel: + 905- 670- 0004 Fax: + 289- 401- 5206 Website: www.iS5Com.com E-mail: support@iS5Com.com...

  • Page 2: All Rights Reserved

    Registered Trademarks iS5Com™, is a trademark of iS5 Communications Inc. Other designations in this manual might be trademarks whose use by third parties for their own purposes would infringe the rights of the owner. Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries.

  • Page 3: Table Of Contents

    Installation on DIN-Rail ..........................8 2.1.1 Mount on DIN-Rail ......................... 8 Wall Mounting ............................9 2.2.1 Mount the iES12G on a Wall or Panel ....................9 Hardware Overview ..................10 Front Panel .............................. 10 Front Panel LEDs ........................... 11 Bottom View ............................12 Cables ......................
  • Page 4 User’s Manual WEB Management ..................17 Configuration by Web Browser ........................ 17 5.1.1 About Web-based Management ..................... 17 5.1.2 Basic Setting ..........................19 5.1.2.1 System Information ......................19 Admin & Password ......................19 5.1.2.2 5.1.2.3 IP Setting ..........................20 Configure the switch-managed IP information on this page.
  • Page 5 User’s Manual 5.1.8.3 Storm Control ........................70 5.1.8.4 Wizard ..........................71 5.1.9 IGMP Snooping ..........................72 5.1.9.1 IGMP Snooping ......................... 72 5.1.9.2 IGMP Snooping Status ...................... 73 5.1.10 Security ............................74 5.1.10.1 ACL ............................. 74 5.1.10.2 802.1x ..........................75 5.1.11...

  • Page 6: Caution: Laser

    This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. Changes or modifications not expressly approved by iS5 Communications Inc. could invalidate specifications, test results, and agency approvals, and void the user's authority to operate the equipment.

  • Page 7: Introduction

    INTRODUCTION 1.1 About the iES12G Industrial Switch The iES12G is a managed industrial switch capable of operating under wide temperature ranges, dusty environments and humid conditions. It can be managed by a Windows Utility (iManage), WEB interface, TELNET, Console connection or third-party SNMP software.

  • Page 8: Hardware Features

    User’s Manual 1.3 Hardware Features Redundant dual low-voltage DC power inputs (10-48VDC) Operating Temperature: -40 to 85 Storage Temperature: -40 to 85 Operating Humidity: 5% to 95%, non-condensing Casing: IP-40 8 x Gigabit combo ports with 100/1000Base-X SFP & 10/100/1000Base –T(X)

  • Page 9: Hardware Installation

    User’s Manual ardware Installation 2.1 Installation on DIN-Rail Each switch has a DIN-Rail bracket on the rear panel. The DIN-Rail bracket helps secure the switch onto the DIN-Rail. 2.1.1 Mount on DIN-Rail Step 1: Slant the switch and mount the metal spring to Din-Rail.

  • Page 10: Wall Mounting

    2.2.1 Mount the iES12G on a Wall or Panel Option 1: Fix mounting brackets to the side of the switch using the 4 screws included in the package. Step 2: Use 6 screws that can be found in the package to combine the wall mount panel. Just like the picture shows below: Note: To avoid damage to the unit please use the screws provided to mount the brackets.

  • Page 11: Hardware Overview

    User’s Manual ardware Overview 3.1 Front Panel The following table describes the labels affixed to the iES12G Port Description 4 1000BaseX on SFP port SFP ports 8 100/1000Base-X on SFP port and 8 10/100/1000Base-T(X) COMBO Port Use RS-232 with RJ-45 connector to manage switch.

  • Page 12: Front Panel Leds

    User’s Manual LED for PWR2 LED for R.M (Ring Master). When the LED is on the switch is the ring master LED for Ring. When the LED is on i-Ring is activated. LED for Fault. When the LED is on a power failure or port down/fail has occurred...

  • Page 13: Bottom View

    User’s Manual 3.3 Bottom View The bottom panel component of iES12G is shown below: 1. Terminal block includes: PWR1, PWR2 (10-48V DC) 2. Chassis ground threaded lug iS5 Communications Inc.

  • Page 14: Cables

    4.1 Ethernet Cables The iES12G switch has standard Ethernet ports and can use CAT 3, 4, 5,5e UTP cables to connect to other network devices (PCs, servers, switches, routers, or hubs). Please refer to the following table for cable specifications.
  • Page 15 BI_DC- BI_DB- BI_DD+ BI_DD- The iES12G switch supports auto MDI/MDI-X operation. You can use a straight-through cable to connect PC to switch. The following table shows the 10BASE-T/ 100BASE-TX MDI and MDI-X port pin outs. 10/100 Base-T MDI/MDI-X pins assignment...

  • Page 16: Sfp

    4.3 Console Cable The iES12G switch can be managed via the console port using the RS232 / DB-9 to RJ-45 cable provided. Connect to the PC via the RS-232/DB9 connector and the RJ45 connector to the console port of the switch.
  • Page 17 User’s Manual iS5 Communications Inc.

  • Page 18: Web Management

    User’s Manual EB Management 5.1 Configuration by Web Browser This section introduces the configuration by Web browser. 5.1.1 About Web-based Management An embedded HTML web site resides in flash memory on the CPU board. It contains advanced management features and allows you to manage the switch from anywhere on the network through a standard web browser such as Microsoft Internet Explorer.

  • Page 19: Main Interface

    User’s Manual The login screen appears. Key in the username and password. The default username and password is “admin”. Click “Enter” or ”OK” button, then the main interface of the Web-based management appears. Login screen Main Interface Main interface...

  • Page 20: Basic Setting

    User’s Manual 5.1.2 Basic Setting 5.1.2.1 System Information The switch system information is provided here. System Information interface Label Description The textual identification of the contact person for this managed node, together with information on how to contact this person. The allowed...

  • Page 21: Ip Setting

    User’s Manual Label Description Old Password Enter the current system password. If this is incorrect, the new password will not be set. New Password The system password. The allowed string length is 0 to 31, and the allowed content is the ASCII characters from 32 to 126.
  • Page 22 User’s Manual Label Description Enable the DHCP client by checking this box. If DHCP fails and the DHCP Client configured IP address is zero, DHCP will retry. If DHCP fails and the configured IP address is non-zero, DHCP will stop and the configured IP settings will be used.

  • Page 23: Https

    User’s Manual 5.1.2.4 HTTPS Label Description Indicates the HTTPS mode operation. Possible modes are: Mode Enabled: Enable HTTPS mode operation. Disabled: Disable HTTPS mode operation. Indicates the HTTPS redirect mode operation. Automatic redirect web browser to HTTPS during HTTPS mode enabled. Possible modes are: Automatic Redirect Enabled: Enable HTTPS redirect mode operation.

  • Page 24: Lldp

    User’s Manual 5.1.2.6 LLDP LLDP Parameters This page allows the user to inspect and configure the current LLDP port settings. Label Description The switch is periodically transmitting LLDP frames to its neighbors for having the network discovery information up-to-date. The interval Tx Interval between each LLDP frame is determined by the Tx Interval value.
  • Page 25 User’s Manual Enabled The switch will send out LLDP information, and will analyze LLDP information received from neighbors. LLDP Neighbor Information This page provides a status overview for all LLDP neighbors. The displayed table contains a row for each port on which an LLDP neighbor is detected.

  • Page 26: Lldp Statistics

    User’s Manual Check this box to enable an automatic refresh of the page at regular intervals. Opens information screen in new browser windows LLDP Statistics This page provides an overview of all LLDP traffic. Two types of counters are shown. Global counters are counters that refer to the whole stackswitch, while local counters refer to counters for the currently selected switch.
  • Page 27 User’s Manual known as "Too Many Neighbors" in the LLDP standard. LLDP frames require a new entry in the table when the Chassis ID or Remote Port ID is not already contained within the table. Entries are removed from the table when a given port links down, an LLDP shutdown frame is received, or when the entry ages out.

  • Page 28: Backup/Restore Configuration

    User’s Manual 5.1.2.7 Backup/Restore Configuration You can save/view or load the switch configuration. The configuration file is in XML format with a hierarchy of tags: 5.1.2.8 Firmware Update This page facilitates an update of the firmware controlling the switch.

  • Page 29: Dhcp Dynamic Client List

    User’s Manual 5.1.3.2 DHCP Dynamic Client List When the DHCP server function is activated, the system will collect the DHCP client information and display in here. 5.1.3.3 DHCP Client List You can assign the specific IP address which is in the assigned dynamic IP range to the specific port. When the device is connecting to the port and asks for dynamic IP assigning, the system will assign the IP address that has been assigned before in the connected device.
  • Page 30 User’s Manual Label Description Port This is the logical port number for this row. The current link state is displayed graphically. Green indicates the link is Link up and red that it is down. Current Link Speed Provides the current link speed of the port.

  • Page 31: Rate Limit

    User’s Manual power savings mode parameters per port. Disabled: All power savings mechanisms disabled. ActiPHY: Link down power savings enabled. PerfectReach: Link up power savings enabled. Enabled: Both link up and link down power savings enabled. Total Power Usage Total power usage in board, measured in percent.

  • Page 32: Port Trunk

    User’s Manual Configure the unit of measure for the port policer rate as kbps or Mbps. Policer Unit The default value is "kbps". Shaper Enabled Enable or disable the port shaper. The default value is "Disabled". Configure the rate for the port shaper. The default value is "500". This Shaper Rate value is restricted to 500-1000000 when the "Policer Unit"...
  • Page 33 User’s Manual Label Description Group ID Indicates the group ID for the settings contained in the same row. Group ID "Normal" indicates there is no aggregation. Only one group ID is valid per port. Port Members Each switch port is listed for each group ID. Select a radio button to include a port in an aggregation, or clear the radio button to remove the port from the aggregation.

  • Page 34: Lacp Port Configuration

    User’s Manual 5.1.4.3.2 LACP Port Configuration This page allows the user to inspect the current LACP port configurations, and possibly change them as well. Label Description Port Indicates the group ID for the settings contained in the same row. Group ID "Normal"...

  • Page 35: Lacp System Status

    User’s Manual Click to save changes. Click to undo any changes made locally and revert to previously saved values. 5.1.4.3.3 LACP System Status This page provides a status overview for all LACP instances. Label Description Aggr ID The Aggregation ID associated with this aggregation instance. For LLAG...

  • Page 36: Lacp Status

    User’s Manual 5.1.4.3.4 LACP Status This page provides a status overview for LACP status for all ports. Label Description Port The switch port number. LACP 'Yes' means that LACP is enabled and the port link is up. 'No' means that LACP is not enabled or that the port link is down.

  • Page 37: Redundancy

    User’s Manual Label Description Port The switch port number LACP Transmitted Shows how many LACP frames have been sent from each port LACP Received Shows how many LACP frames have been received at each port. Discarded Shows how many unknown or illegal LACP frames have been discarded at each port.
  • Page 38 User’s Manual The following table describes the labels in this screen. Label Description Mark to enable Ring. Redundant Ring There should be one and only one Ring Master in a ring. However if there are two or more switches which set Ring Leader to enable, the...

  • Page 39: Ichain

    User’s Manual 5.1.5.2 iChain iChain provides the ability to add network redundancy to any existing backbone network. iChain allows multiple redundant network rings based on different redundancy protocols to join and function together as a larger and more robust compound network topology.

  • Page 40: Mstp

    User’s Manual The secondary (backup) ring port Ring Port Click “Save” to remember the configurations 5.1.5.4 MSTP Bridge Settings This page allows you to configure RSTP system settings. The settings are used by all RSTP Bridge instances in the Switch Stack.

  • Page 41: Msti Mapping

    User’s Manual Click to undo any changes made locally and revert to previously saved values. MSTI Mapping This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly change them as well. Label Description The name identifying the VLAN to MSTI mapping.

  • Page 42: Msti Priorities

    User’s Manual The list of VLAN's mapped to the MSTI. The VLANs must be separated with comma and/or space. A VLAN can only be mapped to one MSTI. VLANS Mapped An unused MSTI should just be left empty. (I.e. not having any VLANs mapped to it.)
  • Page 43 User’s Manual This page contains settings for physical and aggregated ports. The aggregation settings are stack global. Label Description Port The switch port number of the logical STP port. STP Enabled Controls whether STP is enabled on this switch port.

  • Page 44: Msti Ports

    User’s Manual will be selected as an Alternate Port after the Root Port has been selected. If set, it can cause lack of spanning tree connectivity. It can be set by a network administrator to prevent bridges external to a core region of the network influencing the spanning tree active topology, possibly because those bridges are not under the full control of the administrator.
  • Page 45 User’s Manual Label Description The switch port number of the corresponding STP CIST (and MSTI) Port port. Controls the path cost incurred by the port. The Auto setting will set the path cost as appropriate by the physical link speed, using the 802.1D recommended values.

  • Page 46: Stp Port Status

    User’s Manual Click to undo any changes made locally and revert to previously saved values. STP Bridges This page provides a status overview for all STP bridge instances. The displayed table contains a row for each STP bridge instance, where the column displays the...

  • Page 47: Stp Statistics

    User’s Manual Label Description Port The switch port number of the logical STP port. The current STP port role of the CIST port. The port role can be one of CIST Role the following values: AlternatePort BackupPort RootPort DesignatedPort.

  • Page 48: Vlan

    User’s Manual The number of legacy STP Configuration BPDU's received/transmitted on the port. The number of (legacy) Topology Change Notification BPDU's received/transmitted on the port. The number of unknown Spanning Tree BPDU's received (and discarded) Discarded Unknown on the port.
  • Page 49 User’s Manual The VLAN is enabled on the selected stack switch unit when you click on "Save". The VLAN is thereafter present on the other stack switch units, but with no port members. A VLAN without any port members on any stack unit will be deleted when you click "Save".
  • Page 50 User’s Manual (For egress port) 1. VLAN Membership Configuration setting port 2 & VID=50 2. VLAN Port 2 Configuration-->don't care VLAN Aware 3. VLAN Port 2 Configuration-->Mode=specific,ID=50 (any packet can enter egress port ) iS5 Communications Inc.
  • Page 51 User’s Manual 802.1Q Access port Setting (For ingress port) 1. VLAN Membership Configuration setting port & VID=50 2. VLAN Port Configuration-->Enable VLAN Aware iS5 Communications Inc.
  • Page 52 User’s Manual 3. VLAN Port Configuration-->Mode=specific,ID=50 (For egress port) 1. VLAN Membership Configuration setting port & VID=50 2. VLAN Port Configuration-->Disable VLAN Aware 3. VLAN Port Configuration-->Mode=specific,ID=50 (untagged & tag=50 packet can enter egress port ) iS5 Communications Inc.
  • Page 53 User’s Manual 802.1Q Trunk port setting (multi-tag) (For ingress port) 1. VLAN Membership Configuration setting port & VID=11,22,33 2. VLAN Port Configuration-->Enable VLAN Aware iS5 Communications Inc.
  • Page 54 User’s Manual 3. VLAN Port Configuration-->Mode=specific,ID=11 (when enterring packet is untagged frame, added tag = 11 When entering the tagged frame, only VID = 11,22,33 three kinds of packets can pass) (For egress port) 1. VLAN Membership Configuration setting port, VID=11,22,33...
  • Page 55 User’s Manual 2. VLAN Port Configuration-->Enable VLAN Aware 3. VLAN Port Configuration-->Mode=none (egress port can receive tag=11,22,33 packet iS5 Communications Inc.
  • Page 56 User’s Manual In addition ,only tag=11packet can enter egress port ) Q-in-Q VLAN Setting ingress Port 1------------------->egress Port 2 (For ingress port-----Port 1) 1. VLAN Membership Configuration setting port 1、2、3 & VID=50 iS5 Communications Inc.
  • Page 57 User’s Manual 2. VLAN Port Configuration-->Disable Port 1 VLAN Aware 3. VLAN Port Configuration-->Port 1 Mode=specific,ID=50 iS5 Communications Inc.
  • Page 58 User’s Manual (For egress port ----Port 2) 1. VLAN Membership Configuration setting port & VID=50 2. VLAN Port Configuration-->Enable Port 2、3 VLAN Aware. 3. VLAN Port Configuration-->Mode=none (only tag=50 packet can enter egress port ) iS5 Communications Inc.

  • Page 59: Private Vlan

    User’s Manual 5.1.6.2 Private VLAN The Private VLAN membership configurations for the switch can be monitored and modified in this section Private VLANs can be added or deleted. Port members of each Private VLAN can be added or removed. Private VLANs are based on the source port mask, and there are no connections to VLANs.
  • Page 60 User’s Manual Label Description Delete Check to delete the entry. It will be deleted during the next save. Private VLAN ID Indicates the ID of this particular private VLAN. MAC Address The MAC address for the entry. A row of check boxes for each port is displayed for each private VLAN ID.

  • Page 61: Snmp

    User’s Manual When unchecked, port isolation is disabled for that port. By default, port isolation is disabled for all ports. 5.1.7 SNMP 5.1.7.1 SNMP-System Label Description Indicates the SNMP mode operation. Possible modes are: Mode Enabled: Enable SNMP mode operation.
  • Page 62 User’s Manual Label Description Indicates the SNMP trap mode operation. Possible modes are: Trap Mode Enabled: Enable SNMP trap mode operation. Disabled: Disable SNMP trap mode operation. Indicates the SNMP trap supported version. Possible versions are: SNMP v1: Set SNMP trap supported version 1.
  • Page 63 User’s Manual Enabled: Enable SNMP trap link-up and link-down mode operation. Disabled: Disable SNMP trap link-up and link-down mode operation. Indicates the SNMP trap inform mode operation. Possible modes are: Trap Inform Mode Enabled: Enable SNMP trap inform mode operation.

  • Page 64: Snmp-Communities

    User’s Manual Indicates the SNMP trap security engine ID. SNMPv3 sends traps and informs using USM for authentication and privacy. A unique engine ID for Trap Security these traps and informs is needed. When "Trap Probe Security Engine ID" is Engine ID enabled, the ID will be probed automatically.
  • Page 65 User’s Manual Label Description Delete Check to delete the entry. It will be deleted during the next save. An octet string identifying the engine ID that this entry should belong to. The string must contain an even number between 10 and 64 hexadecimal digits, but all-zeros and all-'F's are not allowed.

  • Page 66: Snmp-Groups

    User’s Manual protocol, the allowed string length is 8 to 40. The allowed content is the ASCII characters from 33 to 126. Indicates the privacy protocol that this entry should belong to. Possible privacy protocols are: Privacy Protocol None: None privacy protocol.

  • Page 67: Snmp-Views

    User’s Manual 5.1.7.5 SNMP-Views Configure SNMPv3 views table on this page. The entry index keys are View Name and OID Subtree. Label Description Delete Check to delete the entry. It will be deleted during the next save. A string identifying the view name that this entry should belong to. The...

  • Page 68: Traffic Prioritization

    User’s Manual Label Description Delete Check to delete the entry. It will be deleted during the next save. A string identifying the group name that this entry should belong to. The Group Name allowed string length is 1 to 32, and the allowed content is the ASCII characters from 33 to 126.

  • Page 69: Qos Control List

    User’s Manual Label Description A check box is provided for each port of a private VLAN. When checked, port isolation is enabled for that port. Port When unchecked, port isolation is disabled for that port. By default, port isolation is disabled for all ports.
  • Page 70 User’s Manual This classification can be based on parameters such as VLAN ID, UDP/TCP port, IPv4/IPv6 DSCP or Tag Priority. Frames not matching any of the QCEs are classified to the default QoS Class for the port. Label Description...

  • Page 71: Storm Control

    User’s Manual : Edits the QCE. : Moves the QCE up the list. : Moves the QCE down the list. : Deletes the QCE. : The lowest plus sign adds a new entry at the bottom of the list of QCL.

  • Page 72: Wizard

    User’s Manual 64, 128, 256, 512, 1K, 2K, 4K, 8K, 16K, 32K, 64K, 128K, 256K, 512K, or 1024K. The 1 kpps is actually 1002.1 pps. 5.1.8.4 Wizard This handy wizard helps you set up a QCL quickly. Label Description Set up Group ports into several types according to different QCL policies.

  • Page 73: Igmp Snooping

    User’s Manual Set up VLAN Tag Set up the traffic class mapping to the User Priority value (3 bits) when Priority Mapping receiving VLAN tagged packets. 5.1.9 IGMP Snooping 5.1.9.1 IGMP Snooping This page provides IGMP Snooping related configuration.

  • Page 74: Igmp Snooping Status

    User’s Manual Enable the IGMP Querier in the VLAN. The Querier will send out if no Querier received in 255 seconds after IGMP Querier Enabled. Each Querier's IGMP Querier interval is 125 second, and it will stop act as an IGMP Querier if received any Querier from other devices.

  • Page 75: Security

    User’s Manual Click to refresh the page immediately. Clears all Statistics counters. Check this box to enable an automatic refresh of the page at regular intervals. 5.1.10 Security 5.1.10.1 ACL Configure the ACL parameters (ACE) of each switch port. These parameters will affect frames received on a port unless the frame matches a specific ACE.

  • Page 76: Client Configuration

    User’s Manual Enabled: Frames received on the port are stored in the System Log. Disabled: Frames received on the port are not logged. The default value is "Disabled". Please note that the System Log memory size and logging rate is limited.
  • Page 77 User’s Manual Label Description Client The Client for which the configuration below applies. Authentication Metohd Authentication Method can be set to one of the following values: none : authentication is disabled and login is not possible. local : use the local user database on the switch stack for authentication.
  • Page 78 User’s Manual RADIUS Authentication Server Configuration The table has one row for each RADIUS Authentication Server and a number of columns, which are: Label Description The RADIUS Authentication Server number for which the configuration below applies. Enable Enable the RADIUS Authentication Server by checking this box.

  • Page 79: Warning

    User’s Manual 5.1.11 Warning 5.1.11.1 Fault Alarm When any selected fault event is happened, the Fault LED in switch panel will light up and the electric relay will signal at the same time. The following table describes the labels in this screen.

  • Page 80: Monitor And Diagnosis

    User’s Manual The following table describes the labels in this screen. Label Description The remote SYSLOG Server IP address. IP Address Click “Save” to set the configurations. Save Reset server to 0.0.0.0 Reset 5.1.12 Monitor and Diagnosis 5.1.12.1 MAC Table The MAC Address Table is configured on this page.
  • Page 81 User’s Manual By default, dynamic entries are removed from the MAC after 300 seconds. This removal is also called aging. Configure aging time by entering a value here in seconds; for example, Age time seconds. The allowed range is 10 to 1000000 seconds.

  • Page 82: Mirroring

    User’s Manual uncheck as needed to modify the entry. Click to add a new entry to the static Adding a New Static Entry MAC table. Specify the VLAN ID, MAC address, and port members for the new entry. Click "Save".

  • Page 83: System Log Information

    User’s Manual Note: For a given port, a frame is only transmitted once. It is therefore not possible to mirror Tx frames for the mirror port. Because of this, mode for the selected mirror port is limited to Disabled or Rx only.

  • Page 84: Traffic Overview

    User’s Manual 5.1.12.4 Traffic Overview This page provides an overview of general traffic statistics for all switch ports. Label Description Port The logical port for the settings contained in the same row. Packets The number of received and transmitted packets per port.
  • Page 85 User’s Manual Label Description Rx and Tx Packets The number of received and transmitted (good and bad) packets. The number of received and transmitted (good and bad) bytes. Includes FCS, Rx and Tx Octets but excludes framing bits. Rx and Tx Unicast The number of received and transmitted (good and bad) unicast packets.

  • Page 86: Ping

    User’s Manual 5.1.12.6 Ping This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues. After you press , 5 ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply. The page refreshes automatically until responses to all packets are received, or until a timeout occurs.

  • Page 87: Veriphy

    User’s Manual 5.1.12.7 VeriPHY This page is used for running the VeriPHY Cable Diagnostics. Press to run the diagnostics. This will take approximately 5 seconds. If all ports are selected, this can take approximately 15 seconds. When completed, the page refreshes automatically, and you can view the cable diagnostics results in the cable status table.

  • Page 88: Factory Defaults

    User’s Manual Label Description Click to reboot device. Click to return to the Port State page without rebooting. Factory Defaults You can reset the configuration of the stack switch on this page. Only the IP configuration is retained. Label Description Click to reset the configuration to Factory Defaults.

  • Page 89: Command Line Interface Management

    User’s Manual ommand Line Interface Management About CLI Management Along with WEB-based management, the iES12G also supports CLI management. You can use console or telnet to management switch by CLI. CLI Management by RS-232 Serial Console (115200, 8, none, 1, none) Before Configuring by RS-232 serial console, use an RJ45 to DB9-F cable to connect the Switches’...
  • Page 90 User’s Manual Step 2. Input a name for new connection Step 3. Select to use COM port number iS5 Communications Inc.
  • Page 91 User’s Manual Step 4. The COM port properties setting, 115200 for Bits per second, 8 for Data bits, None for Parity, 1 for Stop bits and none for Flow control. Step 5. The Console login screen will appear. Use the keyboard to enter the Username and Password (The same with the password for Web Browser), then press “Enter”.
  • Page 92 User’s Manual CLI Management by Telnet Users can use “TELNET” to configure the switches. The default value is as below: IP Address: 192.168.10.1 Subnet Mask: 255.255.255.0 Default Gateway: 192.168.10.254 User Name: admin Password: admin Follow the steps below to access the console via Telnet.
  • Page 93 User’s Manual Command Groups System Configuration [all] [<port_list>] Reboot Restore Default [keep_ip] Contact [<contact>] Name [<name>] Location [<location>] System> Description [<description>] Password <password> Username [<username>] Timezone [<offset>] Log [<log_id>] [all|info|warning|error] [clear] Syslog Syslog> ServerConfiguration [<ip_addr>] Configuration DHCP [enable|disable] IP>...
  • Page 94 User’s Manual SNTP [<ip_addr_string>] Auth Configuration Timeout [<timeout>] Deadtime [<dead_time>] RADIUS [<server_index>] [enable|disable] [<ip_addr_string>] [<secret>] [<server_port>] Auth> ACCT_RADIUS [<server_index>] [enable|disable] [<ip_addr_string>] [<secret>] [<server_port>] Client [console|telnet|ssh|web] [none|local|radius] [enable|disable] Statistics [<server_index>] Port Configuration [<port_list>] State [<port_list>] [enable|disable] Mode [<port_list>] [10hdx|10fdx|100hdx|100fdx|1000fdx|auto] Flow Control [<port_list>] [enable|disable] MaxFrame [<port_list>] [<max_frame>]...
  • Page 95 User’s Manual Key [<port_list>] [<key>] Role [<port_list>] [active|passive] Status [<port_list>] Statistics [<port_list>] [clear] Configuration Version [<stp_version>] Non-certified release, v Txhold [<holdcount>]lt 15:15:15, Dec 6 2007 MaxAge [<max_age>] FwdDelay [<delay>] bpduFilter [enable|disable] bpduGuard [enable|disable] recovery [<timeout>] CName [<config-name>] [<integer>] Status [<msti>] [<port_list>] Msti Priority [<msti>] [<priority>]...
  • Page 96 User’s Manual State [<port_list>] [macbased|auto|authorized|unauthorized] Authenticate [<port_list>] [now] Reauthentication [enable|disable] Period [<reauth_period>] Timeout [<eapol_timeout>] Statistics [<port_list>] [clear|eapol|radius] Clients [<port_list>] [all|<client_cnt>] Agetime [<age_time>] Holdtime [<hold_time>] IGMP Configuration [<port_list>] Mode [enable|disable] State [<vid>] [enable|disable] Querier [<vid>] [enable|disable] IGMP> Fastleave [<port_list>] [enable|disable] Router [<port_list>] [enable|disable]...
  • Page 97 User’s Manual Lookup <mac_addr> [<vid>] Agetime [<age_time>] Learning [<port_list>] [auto|disable|secure] Dump [<mac_max>] [<mac_addr>] [<vid>] Statistics [<port_list>] Flush VLAN Configuration [<port_list>] Aware [<port_list>] [enable|disable] PVID [<port_list>] [<vid>|none] VLAN> FrameType [<port_list>] [all|tagged] Add <vid> [<port_list>] Delete <vid> Lookup [<vid>] PVLAN Configuration [<port_list>] Add <pvlan_id>...
  • Page 98 User’s Manual QCL Lookup [<qcl_id>] [<qce_id>] Mode [<port_list>] [strict|weighted] Weight [<port_list>] [<class>] [<weight>] Rate Limiter [<port_list>] [enable|disable] [<bit_rate>] Shaper [<port_list>] [enable|disable] [<bit_rate>] Storm Unicast [enable|disable] [<packet_rate>] Storm Multicast [enable|disable] [<packet_rate>] Storm Broadcast [enable|disable] [<packet_rate>] Configuration [<port_list>] Action [<port_list>] [permit|deny] [<rate_limiter>] [<port_copy>] [<logging>] [<shutdown>]...
  • Page 99 User’s Manual Trap Inform Retry Times [<retries>] Trap Probe Security Engine ID [enable|disable] Trap Security Engine ID [<engineid>] Trap Security Name [<security_name>] Engine ID [<engineid>] Community Add <community> [<ip_addr>] [<ip_mask>] Community Delete <index> Community Lookup [<index>] User Add <engineid> <user_name> [MD5|SHA] [<auth_password>] [DES] [<priv_password>]...
  • Page 100 User’s Manual interval [<integer>] coladdr [<ip_addr>] colport [<integer>] show iS5 Communications Inc.

  • Page 101: T Echnical Specifications

    User’s Manual echnical Specifications Switch Model iES12G Physical Ports Ggiabit Combo Port with 10/100/1000Base-T(X) and 100/1000Base-X SFP ports 1000Base-X SFP Port Technology IEEE 802.3 for 10Base-T, IEEE 802.3u for 100Base-T(X) and 100Base-FX IEEE 802.3z for 1000Base-X IEEE 802.3ab for 1000Base-T, IEEE 802.3x for Flow control...
  • Page 102 User’s Manual IGMP Snooping IP based bandwidth management Application based QoS management DOS/DDOS auto prevention Port configuration, status, statistics, monitoring, security DHCP Client/Server ITS-Ring Network Redundancy STP / RSTP / MSTP compatible RS-232 Serial Console Port RS-232 in RJ45 connector with console cable. 115200bps, 8, N, 1...
