- Page 1 4-466-489-11(1) Portable Memory Recorder Interface Unit Operating Guide HXR-IFR5...
-
Page 2: Overview
Overview By connecting this unit to the AXS-R5 portable recorder, signals output from an NEX-FS700 series camcorder can be converted and recorded in the NEX-FS700 series’s RAW image format to the AXS-R5. You can also view video recorded in the AXS-R5 using simple playback functionality of this unit. -
Page 3: Identifying Parts And Controls
Identifying parts and controls A LCD monitor Press the N/PLAY/EXEC button while the menu screen is displayed to execute the B MENU button selected menu item. Press the MENU button to display the menu H >/v button screen. Press the >/v button to view a next clip. To end the menu screen, press the MENU Press and hold the >/v button during button again. - Page 4 Identifying parts and controls (Continued) N Mounting screw hole Use a tripod with a screw shorter than 5.5 mm (7/32 in.).
-
Page 5: Screen Indicators
Screen indicators The numbers in ( ) are reference pages. A SYNC REC (15) L Power state The REC TRIGGER setting is displayed. B KEY HOLD Power state is displayed in five levels. The icon appears on the screen when the The icon flashes when the battery charge is HOLD switch is set to on. -
Page 6: Table Of Contents
Table of Contents Overview ....................2 Identifying parts and controls ..............3 Screen indicators ..................5 Getting Started Step 1: Checking bundled items .............. 7 Step 2: Connecting the unit to the AXS-R5 and NEX-FS700 series ..8 Basic Operation Recording .................... -
Page 7: Getting Started
Make sure that you have following items supplied with your unit. The number in the parentheses indicates the number of that item supplied. Portable Memory Recorder Interface Unit (HXR-IFR5) (1) CD-ROM (Manuals for Portable Memory Recorder Interface Unit) (1) Operating Guide (1) Warranty (1) -
Page 8: Step 2: Connecting The Unit To The Axs-R5 And Nex-Fs700 Series
Step 2: Connecting the unit to the AXS-R5 and NEX-FS700 series NEX-FS700 series HXR-IFR5 (this unit) Battery pack BNC cable AXS-R5 Press the release button (1) of Insert the projection of the AXS- the AXS-R5 to pop up the ejection... - Page 9 Attach a battery pack to the AXS- Set the POWER ON/OFF switch of R5 or connect a DC power cable the unit to ON. to the DC IN connector of the The power of the unit is turned on. AXS-R5. Insert the battery pack into the battery pack attaching part of the AXS-R5, then slide the battery pack down to lock it in...
- Page 10 Step 2: Connecting the unit to the AXS-R5 and NEX-FS700 series (Continued) Removing the unit Inserting an AXS memory card b Notes • Remove the battery pack and the DC power Open the cover by sliding the cable from the DC IN of the AXS-R5 before memory slot cover open/close removing the AXS-R5 from the unit.
- Page 11 Removing an AXS memory card Open the cover of the AXS-R5, press the EJECT button and remove the AXS memory card. b Notes • Data integrity is not guaranteed if the power is turned off or a memory card is removed while it is being accessed.
-
Page 12: Basic Operation
Basic Operation Recording Stop recording by operating the NEX- After connecting the NEX-FS700 series, you are ready to record on this unit. FS700 series Press the START/STOP button again. • You can start/stop recording by pressing the Make sure that the necessary START/STOP button when the [REC devices (NEX-FS700 series, etc.) TRIGGER] is set to [SDI RMT] (default... -
Page 13: Playing A Recorded Video
Playing a recorded video You can play the clip that is recorded on the z Tips AXS memory card in the AXS-R5 by • You can play the clips without pressing the developing simply. SELECT button of the AXS-R5. The playback signal is output from the AUX-OUT connector of the AXS-R5. -
Page 14: Using The Menu
Using the Menu Setting the setup menus You can change various settings or make detailed adjustments using the menu items Select the desired menu item by displayed on the LCD screen. pressing the /V button or > v button, then press the N/ MENU button N/PLAY/ EXEC button... -
Page 15: Menu List
Menu List The function, setting value and content of each menu item are as follows. The default settings are marked with B. Menu items Setting values Contents CAMERA ID A~Z (BA) Sets the camera ID. REEL NUMBER 001~999 (B001) Sets the Reel Number. DELETE CLIP Deletes all content of a single clip recorded in the recording media. -
Page 16: Troubleshooting
2 Disconnect the power source, reconnect the power source after about 1 minute and turn on your unit. 3 Reset the unit by setting [ALL RESET] (p. 15). 4 Consult your Sony dealer or local authorized Sony service facility. Power sources The unit gets warm. -
Page 17: Notes And Warning Indicators
• Incompatible memory card is inserted. the symptoms yourself. If the problem persists even after you have tried a couple of times, contact your Sony dealer or local - (Warning indicator pertaining authorized Sony service facility. to the write-protect of the memory... -
Page 18: Additional Information
Additional Information Recording formats and AUX-OUT outputs AUX-OUT output format Recording Recording Playback format Image Audio Time code Image Audio Time code 4K-60p 1920 × 1080 60i 1920 × 1080 60i 4K-30p 1920 × 1080 60i 1920 × 1080 30p 4K-24p 1920 ×... -
Page 19: Clip Naming System
Clip Naming System In Separate mode, each clip recorded with z Tips this unit is given a clip name different from • If a recorded clip exists in an AXS memory the one set in the NEX-FS700 series. card, subsequent clip names will run sequentially after the name of the last clip on the Example: card. -
Page 20: Recording Time Of Movies
Recording time of movies Approximate recording/playback Estimated recording time of time of each battery connected to movies an AXS-R5 When using memory card AXS- Approximate time available when using a 512S24 BP-FL75. (unit: minute) Continuous recording time 2048 × 1080/24p (unit: minute) 2048 ×... -
Page 21: About Handling Of Your Unit
• If any solid object or liquid gets inside the casing, unplug your unit and have it checked by a Sony dealer before operating it any further. • Avoid rough handling, disassembling, modifying, physical shock, or impact such as hammering, dropping or stepping on the product. -
Page 22: Specifications
(including the AXS-R5, an AXS Power requirements memory card and the battery pack (BP- DC 11V-DC 17V FL75)) Average power consumption (HXR-IFR5 only, via AXS-R5 DC IN 16.8V) 5.0W SDI IN(RAW) when inputting 4K/60p 4.9W SDI IN(RAW) when inputting 4K/50p Operating temperature 0 °C to 40 °C (32 °F to 104 °F) -
Page 23: Index
Index Battery pack ......8 Bundled items ......7 Clip name......19 Connecting ......8 Getting started......7 Memory card......10 Format ......11 Remove......11 Menu ........14 Menu List......15 Notes and Warning indicators ..........17 Playback........13 Recording......12 Recording time .....20 Screen indicators.....5 Setting the menus....14 Specifications......22 Troubleshooting....16... - Page 24 © 2013 Sony Corporation...
