- Page 1 SENTRON Europe BV Manual TITAN SENTRON pH Meter Type TITAN Operations manual SENTRON Europe B.V. Aan de Vaart 3 P.O. Box 125 9300 AC Roden The Netherlands Tel: +31(0)50 501 38 00 Fax: +31(0)50 501 68 34 E-mail: info@sentron.nl Page 1 of 35...
- Page 2 Manual TITAN, SENTRON Ref. number E7500176, rev. 06, July 2007 In case your pH meter has this label and you are located in Europe, it means that in case the meter cannot be used any more, you have to send it back to Sentron to be destroyed in an environmental safe way.
-
Page 3: Table Of Contents
Calibration data recall ..........................233 7.3.7. Allow measurement data deletion....................244 TROUBLESHOOTING..........................25 8.1. ATT C ............................25 ODES 8.2..............................28 ESET AVAILABLE SENTRON PH PROBES....................29 SYSTEM SPECIFICATIONS........................ 30 DEFAULT SETTINGS ........................... 31 CLEANING PROCEDURE ........................32 Page 3 of 35... - Page 4 SENTRON Europe BV Manual TITAN WARRANTY ............................323 KEYWORDS............................344 Page 4 of 35...
-
Page 5: Introduction
We advise to read the Quickstart-card carefully and act according to the instructions to ensure that the SENTRON TITAN system will work enjoyably for a long time. This manual can be of help when further details on features are required. -
Page 6: Layout Of The Meter
Manual TITAN 1.4. Layout of the meter 1.4.1. Keypad The ‘controls’ of the SENTRON pH meter are condensed to only six keys located on the keypad. The names ‘Power’, ‘Enter’ and ‘Arrow’ keys (‘Left’, ‘Right’, ‘Up’ and ‘Down’) will be used consistently throughout this manual. -
Page 7: Display
Manual TITAN 1.4.2. Display The TITAN’s display is a graphics Liquid Crystal Display (LCD). The pH value can be shown in 1 or 2 decimal resolution and temperature can be shown or be omitted. In chapter 3 these settings are explained in detail. - Page 8 SENTRON Europe BV Manual TITAN These smaller digits represent the actual temperature in C/ºF, see paragraph 7.3.1. Battery status indication When the remaining operational time is less than approximately 5 hours, a “low” indication will appear. When charging the battery, two alternating “+” symbols are shown on the right hand side of the battery symbol.
-
Page 9: Connections
Physically different connections guarantee that it is impossible to fit connectors to the wrong receptacle. Connectors are placed on the backside of the TITAN meter as shown in figure 3. Figure 3: Connectors available on TITAN From left to right, following connectors are available: Probe connector. -
Page 10: Help-Function
SENTRON Europe BV Manual TITAN HELP-Function The TITAN meter is equipped with an elaborate on-board help function, designed to provide to-the-point assistance. The HELP function presents a situation dependant overview of the meter’s functionality which will in most cases be sufficient for the user to continue operation. -
Page 11: Calibration
Manual TITAN Calibration To obtain reliable readings from the TITAN system it must first be calibrated, using correct buffers, for maximum accuracy at the same temperature as the sample will The TITAN has four built-in tables of 5 buffers versus temperature. When performing a calibration, the bufferset chosen is shown on the display. -
Page 12: 1-Point Calibration
SENTRON Europe BV Manual TITAN Slope values can be interpreted as follows: Slope % Interpretation 98.0 – 105.0 % Probe gives maximum performance 94.0 – 97.9 % Probe functions fine. Some maintenance, cleaning with water, toothbrush, and a mild detergent as described in the Probe Insert can bring it up to maximum performance. -
Page 13: 2- Or 3- Point Calibration
SENTRON Europe BV Manual TITAN The text on the status text line will change to “Stabilizing” and the pH value is blinking until a stable signal is reached. The 1-point calibration is now complete, and the meter automatically returns to the Main menu. -
Page 14: Autoread: Stability Function
8 seconds to confirm stability; Hence, the measurement value will blink at least 8 seconds. SENTRON systems continuously monitor the sample’s pH value, i.e. the stable value is not fixed on the display, and when the sample’s pH changes, the value shown on the display will change accordingly. -
Page 15: Measurement Data Handling
SENTRON Europe BV Manual TITAN Measurement data handling The TITAN can store 300 Measurement Data Sets, including date and time. These Measurement Data Sets can be recalled on the display for future reference. 6.1. Sample identification In order to simplify data recognition, a 9-character identification is allocated to the sample. - Page 16 SENTRON Europe BV Manual TITAN The last measurement stored is shown on the display as follows: pH 12.34 - 123.4 °C SAMPLE-000 Recall Next Help Prev Selct Back Figure 4: Recall menu The probe status symbol is not shown in this menu. The text “Recall” is blinking on the status text line.
-
Page 17: Data Deletion
6.4.2. Delete data The TITAN has a memory that allows storage of 300 Measurement Data Sets. In the Store menu, the amount of free memory slots is continuously indicated in the status text line as “xxx free”. -
Page 18: Additional System Configuration
7.1. Bias option In some cases it is possible that there is a difference in measurement results between a Sentron pH measuring system and a classic glass electrode system. This difference can be eliminated by entering a “bias”. Use the arrow keys to go to the menu option “bias”. This is a submenu of option “config”. -
Page 19: Display Contrast
Especially with battery powered meter operation, energy conservation is important to optimize the operational time of the meter. The TITAN can automatically switch itself off after a pre-defined period of inactivity. In the Main menu, go to “Config” and press ‘Enter’. -
Page 20: Select Language
7.3.4. Calibration buffers Following sections list the buffersets built into the meter as Buffervalue versus Temperature. The SENTRON Bufferset is the factory set default. To change to another bufferset, in the Main menu go to “Config” and press ‘Enter’. Go to “Params”, press ‘Enter’ again. -
Page 21: Sentron Bufferset
SENTRON bufferset The SENTRON bufferset is the factory default setting. It is a set of 5 NIST-traceable, SENTRON provided buffers with pH values 2.00, 4.00, 7.00, 10.00 and 12.00 at 25 ºC. The full table of Buffervalue versus Temperature is given below. -
Page 22: Nist Bufferset
SENTRON Europe BV Manual TITAN 7.3.4.3. NIST bufferset Below table shows the Buffervalue versus Temperature of the NIST buffers stored in the TITAN memory: ºC 1.67 4.00 6.95 9.40 13.21 1.67 4.00 6.90 9.28 12.81 1.68 4.01 6.87 9.18 12.45 1.69... -
Page 23: Mv Reading
Note When performing a manual slope calculation, note that for an ISFET a theoretical sensitivity of 52,5 mV/pH should be used. 7.3.6. Calibration data The TITAN allows for storage, retrieval and export of the last calibration data sets. Following sections describe the various options available. 7.3.6.1. -
Page 24: Allow Measurement Data Deletion
SENTRON Europe BV Manual TITAN Go to “Prev” and press ‘Enter’ to bring the previous calibration data set on the display. Similarly, “Next” brings the next data set on the display. The calibration data is shown, consisting of the probe status and the chosen bufferset. -
Page 25: Troubleshooting
“ATTxxx” will be shown on the status text line. The built-in helptexts will state the situation at hand and recommend a remedial action. In case of multiple messages, the TITAN itself handles priorities to make sure that only one ATT code is shown. - Page 26 SENTRON Europe BV Manual TITAN ATT006: The ISFET Check if the probe is in the right buffer. output is too Recalibrate using fresh buffers. close to the If this does not help, replace the probe. ISFET output in the previous buffer.
- Page 27 Refer to paragraph 8.2. No data or Check RS-232 cable for proper connection. illegible Check that baudrate is the same for TITAN and characters sent external device. to external In case of printer, check that a serial printer is used.
-
Page 28: Reset
SENTRON Europe BV Manual TITAN 8.2. Reset In case the user has tuned the display contrast to an unreadable setting, it may be required to reset the meter. Also, unforeseen circumstances that hamper the meter’s functioning may require a meter reset. -
Page 29: Available Sentron Ph Probes
This instrument can only perform up to its specifications in combination with one of the SENTRON ISFET pH probes. The SENTRON “Red-line” series of probes is designed for general purpose use and offers various kinds of probe tips to suit your application. Probe-tips available in the Red-Line series are Standard, ConeFET The SENTRON “Hot-line”... -
Page 30: System Specifications
1-, 2- or 3-point calibration with automatic buffer recognition. Buffer tables: Sets of DIN, NIST and JIS buffers, a set of 5 SENTRON supplied, NIST traceable buffers. Data logging: 300 measurement data can be stored and retrieved on screen. Environment: Temperature: Measurement 0°... -
Page 31: Default Settings
SENTRON Europe BV Manual TITAN 11. Default settings Following table shows the minimum and maximum values and the factory set default value for various parameters. Parameter Minimum Maximum Default Power saving Meter 1 minute 55 minutes/ Continuous Continuous Options: Display... -
Page 32: Cleaning Procedure
SENTRON Europe BV Manual TITAN 12. Cleaning procedure In many cases of returned probes, the probe does not work due to a polluted diaphragm. This is caused by the fluid in which the end-user is measuring. If the customer does not clean de probe regularly, the diaphragm will block the internal electrode. - Page 33 Representations and warranties made by any person, including dealers, representatives and employees of SENTRON, which are inconsistent or in conflict with the terms of this warranty, shall not be binding upon SENTRON unless in writing and signed by one of its officers.
- Page 34 SENTRON Europe BV Manual TITAN 14. Keywords AC Power ..............10 Fahrenheit ..............19 Accuracy..............12; 30 Alarm................8 AR ................9; 15 Arrow-keys..............7; 9 Assistance..............11 Help function ..............11 ATC................11 Highlight ................. 9 ATT Code..............25 Hot-line ................. 29 AutoR ................15 Humidity ............... 30 Autoread ..............9;...
- Page 35 Resolution ............8; 11, 30 Time................8 Right-key ................ 7 Up-key ................7 Sample identification ............ 16 SAMPLE-000 ............... 16 Select language ............. 20 SENTRON Buffers ..........12; 21 Serial number ..............7 Warranty ..............3; 32 Slope ................12 Page 35 of 35...
