- Page 1 Massage System Model 737R (RPX) User Manual Foot Health International Limited PO Box 13540 Tauranga www.recoverypump.co.nz L98005H1R-A...
-
Page 3: Table Of Contents
® RecoveryPump Model 737R (RPX) User Manual Table of Contents Important Safety Information ............1 ® RecoveryPump Specifications and Dimensions......3 Labels ..................... 3 Indications for Use ................ 5 ® About RecoveryPump ..............5 ® Components of the RecoveryPump System ......9 ®... -
Page 5: Important Safety Information
® RecoveryPump Model 737R (RPX) User Manual 1. Important Safety Information ® Read all instructions before using the RecoveryPump system for the first time. Warning: • This system is intended for use by people in good health. This system is not recommended for people who have heart problems, or vascular problems, have a condition requiring the use of any medical device, or have any condition that might affect their normal well-being. - Page 6 ® RecoveryPump Model 737R (RPX) User Manual Caution: • ® Do not operate the RecoveryPump system during transit. • ® Do not store or transport the RecoveryPump system beyond the specified temperature, humidity, and atmospheric pressure ranges (see Chapter 8 - Maintenance and Storage). •...
-
Page 7: Specifications And Dimensions
® RecoveryPump Model 737R (RPX) User Manual ® 2. RecoveryPump Specifications and Dimensions Model: 737R, appliance coupler, transportable, rated: 100-240 VAC, 50-60 Hz Type of protection against electric shock Class II Degree of protection against electric shock Type BF Degree of protection against ingress of water IP21 Degree of safety of application in the Equipment not suitable for use in the presence of a flammable anesthetic mixture... - Page 8 ® RecoveryPump Model 737R (RPX) User Manual Symbol Description Location Separate collection for waste electrical and electronic On base of console equipment Serial number of the console On base of console Fragile, handle with care On package Keep dry On package This side Up On package Keep away from sunlight...
-
Page 9: Indications For Use
® RecoveryPump Model 737R (RPX) User Manual 4. Indications for Use ® The RecoveryPump powered inflatable tube massager is indicated for the temporary relief of minor muscle aches and pains, and for temporary increase in circulation to the treated areas in people who are in good health. The ®... - Page 10 ® RecoveryPump Model 737R (RPX) User Manual The Recovery and Pre-Train Programs The Recovery and Pre-Train programs use the Sequential cycle mode that applies a directional massage, starting at the base of the treated area, and progresses upwards towards the torso and then releases (see Figure 1). This applies a deep, slow massage.
- Page 11 ® RecoveryPump Model 737R (RPX) User Manual The Rehab Program The Rehab program uses the ISO cycle mode that applies a directional massage to a smaller area. Only two adjacent cells in the garment are inflated. The first cell inflates, and after a few seconds, the second cell starts to inflate until both cells reach the set pressure.
- Page 12 ® RecoveryPump Model 737R (RPX) User Manual Custom Programs ® The RecoveryPump console contains three custom programs. Each custom program allows the user to select either the Sequential or ISO cycle mode. The user can change the treatment parameters (pressure, time, pause, and hold) during treatment, but not the selected cycle.
-
Page 13: System
® RecoveryPump Model 737R (RPX) User Manual ® 6. Components of the RecoveryPump System ® The RecoveryPump Console (See Figure 3 - a) The console takes air from the room environment, and sends it to the individual air chambers in the garment in a sequence that starts from the base of the garment and continues to the top, according to the selected mode. - Page 14 ® RecoveryPump Model 737R (RPX) User Manual Prong Plug (See Figure 3 - c) If you are using only one garment, insert this plug into the unused air outlet ® on the front of the RecoveryPump console, to seal it off and prevent air from escaping (see Figure 7).
- Page 15 ® RecoveryPump Model 737R (RPX) User Manual b. Hose Bundles (provided with ® a. RecoveryPump Console RecoveryCore™ garment only) c. Prong Plug d. DC Power Adapter e. Battery Pack ® ® f. RecoveryBoots g. RecoveryArms h. RecoveryCore™ Garment Garment Arm/Shoulder Garment ®...
- Page 16 ® RecoveryPump Model 737R (RPX) User Manual ® 7. How to Operate the RecoveryPump System Following is a description of the console operating panel and the various settings and displays (see Figure 4 and Table 2). Please read this section before operating the console for the first time.
- Page 17 ® RecoveryPump Model 737R (RPX) User Manual The Console Display Screen Display Screen Icons The following icons are displayed at the top of the screen. Table 3 - Display Screen Icons Displayed Icon Function General Warning (displayed only when the console detects an error or internal problem) Air Leak (displayed only when the console detects an air leak) DC power adapter connected to 115-Volt wall outlet (displayed...
- Page 18 ® RecoveryPump Model 737R (RPX) User Manual Program & Cycle Mode Display Screens The following programs and cycle modes are displayed on the screen. Table 4 - Program & Cycle Display Screens Displayed Function Program/Cycle Mode Program 1 - Recovery selection Program 2 - Pre-Train selection Sequential Cycle Mode display Program 3 - Rehab selection...
- Page 19 ® RecoveryPump Model 737R (RPX) User Manual Treatment Parameters Display Screens The following treatment parameters are displayed for all programs Table 5 - Treatment Parameters Display Screens Displayed Function Icon/Screen Display screen during Treatment Pressure setting Display screen during Treatment Time setting Display screen during Pause Time setting Display screen during Hold Time setting L98005H1R-A...
- Page 20 ® RecoveryPump Model 737R (RPX) User Manual ® Step 1: Set up the RecoveryPump Console Place the console on a flat stable surface from where it will not slip or fall The front of the console must be at least six inches from the edge of the surface.
- Page 21 ® RecoveryPump Model 737R (RPX) User Manual Arm/Shoulder Garment Note: Remove any jewelry or wristwatches before putting on the arm sleeve. a. Insert the arm into the sleeve. b. Pull the sleeve over the shoulder to cover it. c. Wrap the fastening strap around the body, under the untreated arm. Fasten the strap and adjust the buckle for a comfortable fit.
- Page 22 ® RecoveryPump Model 737R (RPX) User Manual All Garments The garment should not fit too tightly; you should be able to insert three fingers into the garment when it is zipped closed before inflation. If the garment is too tight, you will need a larger size. Contact Recovery Pump LLC.
- Page 23 ® RecoveryPump Model 737R (RPX) User Manual ® Step 4: Connect the Air Hoses to the RecoveryPump Console Note: Hold the console handle with one hand while connecting or disconnecting the hose bundle with your other hand. a. Securely insert the garment hose bundle connectors, with the logo facing up, into the air sockets on the console (see Figure 6).
- Page 24 ® RecoveryPump Model 737R (RPX) User Manual c. Make sure the air hoses are not bent, kinked, or pinched. Note: When only one garment is used, the second outlet must be plugged with the Prong Plug. Otherwise the console will stop working and the alarm buzzer will beep.
- Page 25 ® RecoveryPump Model 737R (RPX) User Manual Guidelines for Selecting Pressure Changing the pressure level will change the intensity of the massage by increasing the amount of air pushed into each air chamber. A lower pressure setting will apply a lighter massage; while a higher pressure setting will apply a more intense massage (see Table 6 as a guide for pressure selection).
- Page 26 ® RecoveryPump Model 737R (RPX) User Manual Step 9: Set Cycle Mode (Rehab and Custom Programs) Table 7 - Cycle Mode Selection for Rehab and Custom Programs Program Set Cycle Mode 1. Press the Mode button. The following screen appears: 2.
- Page 27 ® RecoveryPump Model 737R (RPX) User Manual Step 10: Set Pause Time a. Press the Mode button. The Pause Time screen is displayed. b. Press the Up/Down Button to select the Pause Time. Note: Pause time is the duration between treatment cycles, and can be set between 10-70 seconds.
- Page 28 ® RecoveryPump Model 737R (RPX) User Manual Step 11: Set Hold Time Considerations for Choosing Hold Time The Hold mode changes the time in which the air pressure is maintained in the garments at the end of the massage cycle, before deflation. If you like the sensation of a longer hold at the top of the garment, you may increase the Hold time.
- Page 29 ® RecoveryPump Model 737R (RPX) User Manual Step 12: Starting the Massage Session Now you are ready to operate the console and begin your treatment. Note: Hold the console handle with one hand while turning On / Off the Main Switch with your other hand.
- Page 30 ® RecoveryPump Model 737R (RPX) User Manual Step 13: Ending the Massage Session a. When the massage time is complete, the massage will stop. If you need to stop the massage in the middle, press the Start/Stop button. b. At the end of the massage session, turn OFF the console using the Main Switch. c.
-
Page 31: Maintenance And Storage
® RecoveryPump Model 737R (RPX) User Manual 8. Maintenance and Storage Replacing the Battery Pack a. Open the cover of the battery pack compartment using a Philips screwdriver. b. Carefully remove the used battery pack from its compartment. c. Disconnect the battery pack cable. d. - Page 32 ® RecoveryPump Model 737R (RPX) Recovery Pump LLC User Manual ® Cleaning the RecoveryPump Console Caution: Disconnect the console from electrical outlet before cleaning. Let it dry completely before reconnecting it to the electrical outlet. Wipe clean using a slightly damp cloth.
-
Page 33: Troubleshooting
If beeps. inserted into unused all air connections are OK and problem air outlet. persists, contact Recovery Pump LLC. The console works at a Defective garment Replace garment and check again. very low pressure, Internal malfunction Contact Recovery Pump LLC. -
Page 34: Warranty And Contact Information
® RecoveryPump Model 737R (RPX) User Manual 10. Warranty and Contact Information Manufacturer Address Mego Afek AC Ltd. Kibbutz Afek, 3004200 Israel Warranty ® • Mego Afek AC Ltd. warrants the RecoveryPump Model 737R and ® RecoveryPump garments to be free of defects in materials and workmanship •... -
Page 35: Emc Manufacturer Declarations
® RecoveryPump Model 737R (RPX) User Manual 11. EMC Manufacturer Declarations Electromagnetic Compatibility (EMC) Statement for Home Healthcare Environment ® The RecoveryPump system has been evaluated to international standard IEC 60601-1-2 "General requirements for basic safety and essential performance - Collateral standard: Electromagnetic compatibility - Requirements and tests". - Page 36 ® RecoveryPump Model 737R (RPX) User Manual Model 737R - electromagnetic emissions - manufacturer declaration The Model 737R is intended for use in the electromagnetic environment specified below. The customer or the user of the Model 737R should assure that it is used in such an environment. Emissions Test Compliance Electromagnetic environment - guidance...
- Page 37 ® RecoveryPump Model 737R (RPX) User Manual Model 737R - electromagnetic immunity - manufacturer's declaration The Model 737R is intended for use in the electromagnetic environment specified below. The customer or the user of the Model 737R should assure that it is used in such an environment. IEC 60601 test Compliance Immunity test...
