GE616
PROXIMITY READER
USER'S MANUAL
GE616
V5.2.0
Proximity Reader
MANUAL 20050308
- 1 -
GE616

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GE616 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GE Security GE616

  • Page 1 GE616 PROXIMITY READER USER’S MANUAL GE616 V5.2.0 Proximity Reader MANUAL 20050308 - 1 - GE616...
  • Page 2: Table Of Contents

    GE616 PROXIMITY READER CONTENTS 1. Introduction page 3 2. Identifying supplied parts page 3 3. Specification page 3 4. Installation page 4 5. Wire Color Table of the Reader page 5 6. Wire Connection to Controller page 5 7. Operation page 6 8.
  • Page 3: Introduction

    PROXIMITY READER 1. Introduction The GE616 is an elegant looking and an attractive 4" read range proximity reader which can be mounted to metal door frame(mullion) or any flat wall surface. The GE616 use the same electronics module in epoxy potting that ensure you successful operation even in harsh environments. The different bezels allow you to interchange the bezel for different applications or wall conditions.
  • Page 4: Installation

    GE616 PROXIMITY READER 4. Installation 4-1. Mullion/Wall Mount Drill two 6-32 or M3 holes 3.3"(8.38cm) apart in vertical and drill one 1/2" hole for the reader cable 1.7"(4.31cm) apart from the top hole. (If you have installed electric gang box then skip this step.) 4-2.
  • Page 5: Wire Color Table Of The Reader

    GE616 PROXIMITY READER 5. Wire Color Table of the Reader POWER Power(DC +5V~+17V) DC(+) Red wire Power(DC Ground) DC(-)(GND) Black wire INPUT Buzzer control input BUZZER Blue wire LED control input Yellow wire OUTPUT(Wiegand Format) Wiegand Data-0 Data-0 Green wire...
  • Page 6: Operation

    GE616 PROXIMITY READER 7. Operation 7-1. Apply power and you can see Red LED is on indicating the reader is in standby. 7-2. Present proximity card to the reader until you hear beep sound and the LED is changing the color to Green simultaneously and the reader send RF card data to the controller then LED changes the color to Red again for next reading.
  • Page 7: Fcc Registration Information

    GE616 PROXIMITY READER 8. FCC REGISTRATION INFORMATION FCC REQUIREMENTS PART 15 Caution: Any changes or modifications in construction of this device which are not expressly approved by the responsible for compliance could void the user's authority to operate the equipment.
  • Page 8: Warranty And Service

    GE616 PROXIMITY READER 9. Warranty and Service The following warranty and service information applies only to the United States of America and Republic of Korea. For the information in other countries, please contact your local distributor. To obtain in or out of warranty service, please prepay shipment and return the unit to the appropriate facility listed below.
