QUICK REFERENCE GUIDE DTVS-T1
• Connect mains plug last, ensure your receiver is connected to the TV
and Antenna before plugging in to mains power.
• Please follow this guide for a successful first time set up.
• Read all the safety instructions carefully before use and keep the
instruction manual for future reference.
1
CONNECTING YOUR UHF ANTENNA
Connecting your UHF Antenna
UHF Antenna
c) Connecting via Scart
UHF Antenna
2
CONNECT TO YOUR TV. USE ANY OF THE FOLLOWING 4 OPTIONS
a) Connecting via HDMI
Mains cable
UHF Antenna
To Mains
socket
d) Connecting with Composite
TV
Scart input
UHF Antenna
Mains cable
To Mains
socket
HDMI input
TV
Mains cable
To Mains
socket
AV in
TV
Mains cable
To Mains
socket
b) Connecting via Component
YPbPr input
UHF Antenna
Attach the supplied SCART to Composite
adapter. Then connect the receiver with the
AV cable to the TV.
Audio input
TV
Mains cable
To Mains
socket
