Summary of Contents for Agility Technologies FL360
-
Page 1: Quick Start Guide
Quick Start Guide Wireless Mode www.agilitycorp.com... - Page 2 See rescue in a whole new way. www.agilitycorp.com...
- Page 3 360° multipurpose technical rescue camera ever developed for Fire & Emergency Services. Over time, will be offering new features to the FL360 camera allowing you to have the latest software by simply updating the app. Keep up to date by following us on social media, website, email or just give us call.
- Page 4 Step 2. Take the provided Multi-Charger provided in the kit and plug into a power source and insert all 4 x FL360 Li-ion Protected Batteries to check current power capacity and start charging if needed. The provided Multi-Charger user manual will show you how to use the charger and read the LCD screen.
- Page 5 Step 3. Once the batteries are fully charged, take the provided 4mm Hex Battery Compartment Tool, unscrew both 4mm screws and remove the Speaker/Mic Lid from the housing. www.agilitycorp.com...
- Page 6 Step 4. Once the Speaker/Mic Lid is removed, take two (2) of the FL360 batteries supplied in the kit and insert them into the camera. Each battery is marked positive and negative so make sure they line up correctly in the battery housing. It is also important to lay both batteries on the orange ribbon as shown below.
- Page 7 Step 5. Now that you’ve installed the batteries, you can now install the Speaker/Mic Lid back onto the camera. Make sure you have the lid positioned correctly (shown below), then tighten the screws using the provided 4mm Hex Battery Compartment Tool. Make sure not to over tighten but enough that the lid is lined up with the housing.
- Page 8 Step 6. Turn on the camera by holding the power button for four (4) seconds. To notify you the camera is on, the Multifunction LED will flash blue. Camera Head LED Camera Head LED Power Button Multifunction LED www.agilitycorp.com...
- Page 9 Step 7. Once the FL360 camera is on, the Multifunction LED will remain blue for 30 seconds while the camera loads. After 30 seconds the, the FL360 camera will go into pairing mode. The Multifunction LED will flash blue/red letting you know you can now connect to the tablet.
- Page 10 Step 11. Now that you’re tablet is powered on, you’re ready to use the FL360 app. Find the FL360 app icon and open it. Once the app is open, you’ll be presented with the FL360 app dashboard. Go ahead and press the Wireless tiled icon.
- Page 11 Step 9. Once you’ve pressed the Wireless tiled icon a pop up will appear titled “List of Available Cameras.” Find the FL360 camera network, select it and press “CONNECT.” The pop window will disappear and much of the dashboard will be coloured green.
- Page 12 Step 12. To live stream, press the green START icon on the lower right of the dashboard and the screen will go live. At this point you’re ready to use the camera in full 360°. Use your finger on the screen to view or use the virtual joystick to move around the space.
- Page 13 Support, FAQ’s and troubleshooting. For all your support needs, FAQ’s, user input and additional details, please visit agilitycorp.com/resources. Things can and do change from time to time so please visit our website, social media properties, or call us direct to keep up-to-date on new features, application updates, and hardware features.
- Page 14 ADVANCING TECHNICAL RESCUE 2017 Agility Technologies Corp. All Rights Reserved. For a complete list of patents, please contact us at info@agilitycorp.com. www.agilitycorp.com...
