Page 1: Quick Start Guide
Quick Start Guide Wired Mode www.agilitycorp.com...
Page 2 See rescue in a whole new way. www.agilitycorp.com...
Page 3 Congratulations and thank you for purchasing FirstLook360. Your department now has the markets first streaming wireless 360° multipurpose technical rescue camera ever developed for Fire & Emergency Services. Over time, will be offering new features to the FL360 camera allowing you to have the latest software by simply updating the app.
Page 4 LETS DO THIS! Step 1. Download the detailed user manual at our website shown below so you can familiarize yourself with all the hardware provided and to make sure you’ve received everything. Step 2. Take the provided Multi-Charger provided in the kit and plug into a power source and insert all 4 x FL360 Li-ion Protected Batteries to check current power capacity and start charging if needed.
Page 5 Step 3. Once the batteries are fully charged, take the provided 4mm Hex Battery Compartment Tool and unscrew both 4mm screws and remove the Speaker/Mic Lid from the FL360 camera housing. www.agilitycorp.com...
Page 6 Step 4. Once the Speaker/Mic Lid is removed, take two (2) fully charged FL360 batteries and insert them into the camera. Each battery is marked positive and negative so make sure they line up correctly in the battery housing. It is also important to lay both batteries on the orange ribbon as shown below.
Page 7 Step 5. Now that you’ve installed the batteries, you can now install the Speaker/Mic Lid back onto the camera. Make sure you have the lid positioned correctly (shown below), then tighten the screws using the provided 4mm Hex Battery Compartment Tool. Make sure not to over tighten but enough that the lid is lined up with the housing and secure.
Page 8 Telescoping Boom Coiled Tethering Cable Installation Step 1. To install the boom coiled tethering cable, make sure you’ve collapsed the telescoping boom completely. Step 2. Insert the circular tethering connector into the opening at the rear of the boom pole. www.agilitycorp.com...
Page 9 Step 3. Slowly twist the boom coiled tethering cable clockwise while at the same time pushing it toward the the the camera head attachment point. Step 4. When the circular tethering connector is visible in slot of the red anodized pole coupler, feed it out and connect the tethering connector to high speed wired connector port located at the rear of the FL360 camera.
Page 10 Step 5. The right-angle connector on other end of the boom coiled tethering cable will nestle into the cut out of the boom poles rear coupler. Step 6. Connect the provided tablet tethering right-angle connector to the right-angle boom coiled tethering cable. These two connectors match right-angle to right-angle and must be tightened once fitted together.
Page 11 Step 7. To finish the wired connection, make sure to take the other end of the tablet tethering cable and insert the micro-usb connector into the tablet. www.agilitycorp.com...
Page 12 Step 8. Turn on the camera by holding the power button for 4 seconds. To notify you the camera is on, the Multifunction LED light will turn on and flash blue for 37 seconds while loading the on board system module in the camera. When this is complete the camera will go into pairing mode and flash blue/red.
Page 13 Step 9. Power up the Tablet and open the FL360 app. Step 10. In the app, find the Tethering icon on the lower left and press it. It will automatically take you to the Mobile Hotspot and Tethering settings within the tablet. Turn on Tethering, head back to the FL360 App where you will notice the USB Tethering icon is green.
Page 14 Step 12. To live stream, press the green START icon on the lower right of the diagnostics screen and the screen will go live. At this point you’re ready to use the camera in full 360°. Use your finger on the screen to view or use the virtual joystick to move around the space.
Page 15 Support, FAQ’s and troubleshooting. For all your support needs, FAQ’s, user input and additional details, please visit agilitycorp.com/resources. Things can and do change from time to time so please visit our website, social media properties, or call us direct to keep up-to-date on new features, application updates, and hardware features.
