MANUAL for INSTALLATION,
RUNNING and MAINTENANCE
Patio-heaters:
KALIENTE E/M and SOLFLAME E/M
models
KALOR M and SOLEIL M
models
(manual start-up)
SIABS S.r.l. – ITALY
via Del Lavoro, 7
20010 – Casorezzo (MILAN)
Manual_UK_K_K_rev. 1_10_2013
made in
Phone +39 02 90384081
Fax +39 02 9029538
IT
Y!
E-mail
commerciale@siabs.it
Web page
www.siabs.com
pag. 1
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Siabs KALIENTE E
Summary of Contents for Siabs KALIENTE E
- Page 1 MANUAL for INSTALLATION, RUNNING and MAINTENANCE Patio-heaters: KALIENTE E/M and SOLFLAME E/M models KALOR M and SOLEIL M models (manual start-up) SIABS S.r.l. – ITALY Phone +39 02 90384081 E-mail commerciale@siabs.it via Del Lavoro, 7 Fax +39 02 9029538 Web page www.siabs.com...
-
Page 2: Table Of Contents
CONTENT General instruction 3 and 4 For Your safety Warranty terms CE declaration of conformity Labels . plate with technical data . packing label Technical data 7 and 8 . patio-heaters KALIENTE M & E . patio-heaters KALOR M & E Dimensions MINIMUM distance of installation Installation... - Page 3 GENERAL INSTRUCTIONS for INSTALLER, USER and MAINTENANCE PERSONNEL Thank you for your preference and trust granted! SIABS is pleased to have You among his Customers; our appliances are designed and manufactured to the most modern and rational processing systems and we do think you will appreciate the pleasant comfort and their use will be fully satisfactory.
-
Page 4: General Instruction 3 And
• for remote control of patio-heaters KALIENTE E & SOLFLAME E = model AAA • for gas group of patio-heaters KALIENTE E & SOLFLAME E = model type Torch Patio-heaters with MANUAL start-up • for gas group of patio-heaters KALIENTE M & SOLEIL M = model AA note –... -
Page 5: For Your Safety
Warranty SIABS guarantees its products, whether installed by authorized personnel, for a period of 24 months from the invoice date. The warranty does not cover the components supplied by third parties, these are subject to the conditions of the original warranty. -
Page 6: Labels
On each unit you will find a plate with technical data – do not remove – placed inside the gas bottle compartment, on the burner cover. Apparatus type A1, Plate label (example: patio-heater KALIENTE Electronic, gas type G31 propane) Essential features of the appliance are given on the packing label, outside on the packing box. Manual_UK_K_K_rev. -
Page 7: Patio-Heaters Kaliente M & E
TECHNICAL DATA, patio-heaters KALIENTE E / M – SOLFLAME E/M Country Category Pressure Pressure II 2H3B/P 20 mbar G30 / G31 50 mbar II 2E+,I3+ G20 / G25 20 / 25 mbar G30 / G31 28-30 / 37 mbar II 2ELL3B/P G20 / G25... -
Page 8: Technical Data 7 And
• Weight = approx. 30 kg TECHNICAL DATA, patio-heaters KALOR M – SOLEIL M Country Category Pressure Pressure II 2H3B/P 20 mbar G30 / G31 50 mbar II 2E+,I3+ G20 / G25 20 / 25 mbar G30 / G31 28-30 / 37 mbar II 2ELL3B/P G20 / G25 20 mbar G30 / G31... -
Page 9: Dimensions
OVERALL DIMENSIONS, patio-heaters KALIENTE & KALOR & SOLFLAME & SOLEIL NOTE – we recommend to make use of the 4 adjustable feet, to ensure always optimal vertical position, and avoid floor / surface damage. MINIMUM distance of installation, Manual_UK_K_K_rev. 1_10_2013 pag. -
Page 10: Minimum Distance Of Installation
patio-heaters KALIENTE & KALOR & SOLFLAME & SOLEIL By minimum distance of installation we mean the distance to be kept between the patio-heater and any component potentially flammable. We recommend to keep at least 0.5 mt between the cover / top of the patio-heaters and the ceiling. The best comfort is at a distance of approx. -
Page 11: Room Ventilation
25 % open surface NOTICES SIABS patio-heater is a product with modern aesthetics, designed to give comfort in all spaces which need complete or partial heating. SIABS patio-heaters must be installed in partly protected areas: it is not designed to be subject to direct action of atmospheric agents (snow, raining, hail). -
Page 12: Description Of Patio-Heaters
All heaters are controlled and calibrated to the correct pressure values (depending on the type of gas and the country of destination), and then tested in the company by SIABS personal. On each heater you will find a technical data plate (see page 6 of this manual), according to norms, to which the installer has to refer for any future action. -
Page 13: Put In Operation And First Start-Up
HANDLING: for all movements of the patio-heater, for secure and easier handling we recommend to use only SIABS device for transport / handling (optional), named “kit for transport”, fixing it to the lower part of gas bottle compartment (Picture 2), with n. 4 M8 bolts, included in the supplied. -
Page 14: Suggested Gas Bottle
Gas bottles respond to a series of rules issued by the bodies that determine the materials and testing. SIABS patio- heaters are suitable for use of 10 – 15 kg LPG bottles. -
Page 15: Start-Up
START-UP Carried out the above steps successfully, you can turn on the power to the heater. ELECTRONIC VERSION patio-heater model KALIENTE E/SOLFLAME E: press the POWER button on the remote control, after a few seconds the ignition device (pilot), by the detection electrode, will give positive input for total opening of the gas valve, and then turning on the heater takes place;... - Page 16 • for remote control of patio-heaters KALIENTE E & SOLFLAME E = model AAA • for gas group of patio-heaters KALIENTE E & SOLFLAME E = model type Torch MANUAL VERSION patio-heater model KALIENTE M / SOLFLAME M • press and turn counter-clockwise about 15 ° the gas valve / knob •...
-
Page 17: Start-Up
AA note – they are inside the piezo starter POSSIBILITY of ADJUST POWER: all SIABS patio-heaters, offer the possibility to adjust the heating power (max-min-med) reducing it by approx. 20%, in case you want to enjoy a different level of comfort or fit it to different external temperatures. -
Page 18: Safety Devices
SAFETY DEVICES on PATIO-HEATERS N.B. – SIABS patio-heaters are delivered ready for operation, already set according to the type of gas and the country of destination, and equipped with a pressure reducer: does not require additional settings, or other accessories; shall not be permitted any change in burner pressure running: guarantee will not be valid anymore. -
Page 19: Ordinary Maintenance
Depending on the quality of gas used, it may cause blackening of the tubular glass (model KALIENTE E & M) due to the components added to the mixture of propane gas and dirt in general; for cleaning the inside of the glass tube, it can be used a wet soft cloth, restoring the starting transparency. -
Page 20: Nozzle Replacement
In case there is the need to change the type of gas, different from that the heater has been tested, it is necessary to require SIABS the correct conversion kit specifying the appliance model, serial number (inside the gas bottle compartment, Picture 13) and the new gas type. -
Page 21: Trouble Shooting
Picture 16 Trouble shooting Patio-heaters KALIENTE M-SOLFLAME M, MANUAL version Trouble Possible cause Solution A1 Fault with gas tap A1 Replace gas tap A Pilot on, main burner not B1 Lack of gas B1 Check opening of gas valve, placed on B Continues to sparkle, gas bottle, check the gas reducer the pilot does not light... -
Page 22: Kaliente Electronic
Trouble shooting Patio-heaters KALIENTE E/SOLFLAME E, ELECTRONIC version Trouble Possible cause Solution A1 Spark sensor not connected A1 Check spark cable connection A Pilot on, spark continuosly A2 Fault with spark electrode A2 Replace electrode running A3 Fault with command control... -
Page 23: Kalor Manual And Electronic
Trouble shooting Patio-heaters KALOR M/SOLEIL M, MANUAL version Trouble Possible cause Solution A1 Lack of gas A1 Check opening of gas valve, placed on A Continues to sparkle, gas bottle, check the gas reducer the burner does not start A2 Gas valve blocked A2 Blow with air at low pressure the valve group A3 Fault with thermocouple... -
Page 24: Suggested Spare-Parts List
List of suggested spare-parts SPARE-PARTS list Description Code Quantity . anti-tilt sensor FD4SWITCK ____ . pressure regulator RG13.855800 ____ . gas conversion kit (nozzle + technical plate) various ____ Patio-heater KALIENTE/SOLFLAME ELECTRONIC . glass pipe 001TOBF1200 ____ . pilot, complete 440.1221.13 ____ . -
Page 25: Service Sheet
CE certificate Manual_UK_K_K_rev. 1_10_2013 pag. 25... - Page 26 Service sheet DATE and STAMP OPERATION / NOTE DATE and STAMP OPERATION / NOTE DATE and STAMP OPERATION / NOTE DATE and STAMP OPERATION / NOTE Manual_UK_K_K_rev. 1_10_2013 pag. 26...
-
Page 27: Decommissioning And Disposal (Norms For User)
Decommissioning and disposal INFORMATION TO USERS "Implementation of Directives 2002/95/EC, 2002/96/EC and 2003/108/EC, relating to the use of hazardous substances in electrical and electronic equipment, as well as waste disposal” The product at the end of its useful life must be separated from other waste. You should therefore give the equipment at end of its working life to appropriate separate collection centres of electric and electronic waste, or return it to the dealer when purchasing a new device to be equivalent in terms of one to one. - Page 28 SIABS S.r.l. via Del Lavoro, 7 20010 – Casorezzo (MI) ITALIA _______________________________________________________________ To contact us: Phone +39 02 90384081 +39 02 9029538 E-mail commerciale@siabs.it Web page www.siabs.com Continuous development to improve the product could cause changes of above without notice.
