Windlass Systems
Side-Power MAXI
31/32/34/40/43/44
Installation and user manual
EN
Rev3.9
SLEIPNER MOTOR AS
P.O. Box 519
N-1612 Fredrikstad
Norway
Tel: +47 69 30 00 60
Fax: +47 69 30 00 70
www.side-power.com
sidepower@sleipner.no
© Sleipner Motor AS 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAXI 31 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Side-Power MAXI 31

Summary of Contents for Side-Power MAXI 31

  • Page 1 Windlass Systems Side-Power MAXI 31/32/34/40/43/44 Installation and user manual Rev3.9 SLEIPNER MOTOR AS P.O. Box 519 N-1612 Fredrikstad Norway Tel: +47 69 30 00 60 Fax: +47 69 30 00 70 www.side-power.com sidepower@sleipner.no © Sleipner Motor AS 2017...

  • Page 2: Table Of Contents

    Fitting of auto stopp and fitting the stop indicator/brass wire........................18 Wiring diagram.......................................20 Electrical installation.......................................21 Electrical wiring.......................................21 Fitting control unit......................................22 Dimensions........................................24 Maintenance and service....................................27 Technical data........................................30 Troubleshooting ......................................31 Operations and Functions .....................................32 Installations Examples....................................33 SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 3: Introduction Of Maxi- Series

    Introduction of MAXI 31, 32, 34, 40, 43, 44 Side-Power MAXI windlasses are a generic term for Side-Power windlass with 1000 or 1500 W, 12 or 24V. Some of the models is suitable for mounting stern, some on the bow and some both stern and bow. Side-Power MAXI is intended for boats larger than approx.

  • Page 4: User Guide

    Once the boat has begun to move backwards, you can release the up button and then run the windlass in periods. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 5 Always turn off the power to the windlass when it is not being operated. • The anchor must always be secured to the boat while the boat is sailing. Use the safety line supplied. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 6: Before Installation

    See the specific descriptions for the separate windlass models. Note! Remember to attach the end of the rope somewhere inside the boat. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 7 The windlass can then only be operated at low speed until it stops for the second time once the anchor is seated correctly in its bracket – ready to be dropped next time. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 8: Installation

    39-76000 or the simple 39-79000 to lead the rope through the hull. The line guide may be installed with studs as shown in picture. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 9 Installation Anchor brackets Standard platform roller, long Hinged platform roller Tilt bracket Anchor davit SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 10: Fitting Maxi31

    Fitting Maxi 31 The Maxi 31 is designed for fitting outside on the stern or inside on the stern side of a vertical bulkhead. The Maxi 31 has the line wheel on the right-hand side of the windlass, seen from behind.

  • Page 11: Fitting Maxi 32

    Note! This space is normally sufficient for 50 m x 16 mm rope or 30 m chain. Remember! When pulling in the rope for the first time, you must keep the rope tight, so the rope run correctly. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 12 Note! The box is normally sufficient for 50 m x 16 mm rope or 30 m chain. Tilt bracket mounted on a box. Tilt bracket 61-30006/61-30007 Fixed to the angled surface on the stern end of the box. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 13: Fitting Maxi 34

    2 holes in towards each other with a 20 mm hole-cutter. Then remove the material between the holes.) Remember! When pulling in the rope for the first time, you must keep the rope tight, so the rope run correctly. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 14 Note! The bolt (pos 17) that attaches the line wheel to the axle must be secured with contact adhesive (e.g. Locktite or similar). Recommened torque for bolts, 20Nm. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 15 Finally, fasten the cover in place. Remember! When pulling in the rope for the first time, you must keep the rope tight, so the rope run correctly. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 16: Fittting Maxi 40

    Use the windlass to wind it up. Remember! When pulling in the rope for the first time, you must keep the rope tight, so the rope run correctly. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 17: Fitting Maxi 43/44

    Fixed to the angled surface on the stern end of the box. Fit the box roller with the angled side of the bracket down. Tilt bracket 61-30006/61-30007 Fixed to the angled surface on the stern end of the box. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 18: Fitting Of Auto Stopp And Fitting The Stop Indicator/Brass Wire

    (Picture 10). Note! The brass wire indicators may become worn by the sheave – especially under heavy loads – and you must therefore check them regularly. Replace damaged wire if necessary SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 19 If the anchor does not seat firmly in the anchor bracket, you may need to post-adjust the brass wire indicator that signals the second auto stop. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 20: Wiring Diagram

                                  SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 21: Electrical Installation

    1 pcs switch panel • Cables are optinal and come in various lengths. • Cable is a 4-way Side-Power cable that easy can be attached to contact on controlbox unit. • The cable must be attached to 150810 contact unit •...

  • Page 22: Fitting Control Unit

    See control unit manual for configuring and more installation   information.                   SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 23 Fig 2. WARNING! Fig1 Wrong, improper use or wrong connection of such high current components will generate a lot of heat which in worst case can cause fire. OFF button Fig2 SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 24: Dimensions

    A:Height above deck 200 mm B: Length above deck 255 mm C:Width above deck, incl. line wheel 230 mm D: Width excl. line wheel 160 mm E: Height below deck 150 mm SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 25 Maxi 34 A: Height above deck 200 mm B: Length above deck 271 mm C: Width above deck, incl. line wheel 220 mm D: Width excl. line wheel 120 mm SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 26 D: Height center wheel incl bracket 116 mm E: Width bracket 86 mm F: Length bracket 150 mm G: Length center wheel incl motor 273 mm H: Length between holeson bracket 100 mm SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 27: Maintenance And Service

    The rope guide should be able to move easily and freely above the hinged bolt when the spring is not fitted. Only then will the spring be able to exert the required pressure on the rope guide. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 28 Reverse the process to assemble and fit the new outer sheav. Note! Put contact adhesive (e.g. Locktite) on the screw (17) before tightening it. Note! Recommened torque for bolts, 20Nm SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 29 Reverse the process to assemble and fit the new outer sheav. Note! Put contact adhesive (e.g. Locktite) on the screw (16) before tightening it. Note! Recommened torque for bolts, 20Nm SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 30: Technical Data

    Anchor (Multiple types) Anchor bracket (Multiple types) Mounting brackets Battery cable Lead rope or chain Fuse w/holder Hull conduit for rope or chain Wireless remote control Switch panel Cables Control box unit SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 31: Troubleshooting

    The anchor might not release from the bracket if mounted incorrectly. If the windlass still does not work normally after you have tried these procedures, the fault is in the windlass itself. Contact your nearest dealer. SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 32: Operations And Functions

    Operations and functions SP MAXI 31 32 34 40 43 44 Rev3.9 2017...

  • Page 33: Installations Examples

    Installation Examples for Maxi windlasses Maxi 31 vs Maxi 40 SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 34 SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 35 SP MAXI 31 32 34 40 43 44 Rev3.9 2017...
  • Page 36 SLEIPNER MOTOR AS P.O. Box 519 N-1612 Fredrikstad Norway Tel: +47 69 30 00 60 Fax:+47 69 30 00 70 www.side-power.com sidepower@sleipner.no The information given in the document was correct at the time it was published. However, Sleipner Motor AS can not accept liability for any inaccuracies or omissions it may contain.
