McNeilus 1487747 Operation, Service, & Parts

Street smart vision systems extreme monitor/dvr system ssv extreme 9 inch monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

SSV Extreme 9" Monitor
O p e r a t i o n ,
S e r v i c e ,
&
P a r t s
Monitor P/N: 1487747
© 2014 McNeilus Truck and Manufacturing, Inc.
Manual P/N : 1489226
Rev. 1216

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1487747 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for McNeilus 1487747

Summary of Contents for McNeilus 1487747

  • Page 1 O p e r a t i o n , S e r v i c e , & P a r t s Monitor P/N: 1487747 © 2014 McNeilus Truck and Manufacturing, Inc. Manual P/N : 1489226 Rev. 1216...
  • Page 2 Extreme Monitor/DVR System Disclaimer: This manual must not be used to repair your vehicle. Repair information is available by calling McNeilus Customer Service at (888) 686-7278. The information in this Manual will be your guide to operation, service, and basic maintenance for this equipment.

  • Page 3: Table Of Contents

    Important Safety Information ........................3 Operation Precautions ..........................3 Federal Communications Commission (FCC) Statement ................. 3 COMPONENT FEATURES Monitor Features 9" Part Number 1487747 ....................4 Camera Features ............................5 INSTALLATION Basic Installation for Monitor 9" and its Components ................7 Monitor 9"...
  • Page 4 TROUBLESHOOTING Troubleshooting Chart ..........................43 COMPONENTS FOR INDIVIDUAL SALE Selected Component Images ........................48 COMPONENT SPECIFICATIONS Monitor Specifications for P/N 1487747 ....................51 Camera Specifications for P/N 1470028 ....................52 PRECO PREVIEW RADAR SYSTEM Preco Electronics PreView® Radar Systems .................53 PreView Single Sensor System for P/N 1479540 (For Front and Side Loader Applications Only) ..

  • Page 5: Foreword

    • Preco Electronics PreView® Radar Systems • Warranty To order a free replacement manual, contact the McNeilus Street Smart Parts and Service at 888-686-7278 or visit www.streetsmartparts.com to download a free PDF copy. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 6: Parts And Service Locations

    Foreword Parts and Service Locations Contact your McNeilus Street Smart Parts and Service location to order parts, receive service information, or for other assistance. Contact by phone or visit www.streetsmartparts.com. We have factory owned parts and service centers near you.

  • Page 7: Safety

    Street Smart Parts and Service™ for no ® charge. Please contact your McNeilus parts and service location to order parts, additional manuals, or if you have any questions about the information in this manual, this product, or safe operating procedures.

  • Page 8: Component Features

    Component Features Monitor Features 9" Part Number 1487747 • 9 inch color high resolution, crystal clear display • Distance Grid • Backlighted buttons • Professional metal case with Certified Anti-Shock Design up to 15G • LCD • Touchscreen capable • Night brightness modes •...

  • Page 9: Camera Features

    3. Keep pressing the IR button on the back of the camera until the view of your hand goes black on the monitor. The IR is now turned off. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 10: Installation

    Installation Monitor 9" 1487747 Installation and Menu and DVR Functions © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 11: Basic Installation For Monitor 9" And Its Components

    Mount products) for purchase, see ® Page 46. McNeilus recommends using P/N 1476231 mount with one of the three possible double socket clamps (P/N 1476232, 14789033, 14789034), see Page 46 for specific descriptions. When using this system, it is recommended to use Blue #2 Loctite on the bolts to attach the RAM Mount ball to the back of the monitor.

  • Page 12: Master Cable Harness

    For Driver / Facing Forward Camera Connect BLACK (Color Wire 4 Pin Connector) CAMERA E For Front / Hopper Connect GPS ANTENNA CONNECTOR To connect the GPS Antenna to the monitor © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 13: Power Accessory Harness

    NOTE: Using a directional turn signal to activate a camera will require the use of the 2-second off delay module (P/N 1452176). Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 14: Camera Connection Pin Assignment

    LCD screen is turned off (see Ignition Off Setup). © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 15: Monitor 9" Functions

    Navigates downward/ to the left in the OSD Menu and adjusts the volume down on the monitor’s speaker. Menu Button/ Knob Jump Button Power Button Navigation Figure 1: Front Panel buttons and On Screen Display (OSD) Main Menu Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 16: Osd Main Menu Functions Remote Control For Osd Menu Functions

    • In the menu mode, navigate to a function by pressing the Up Arrow and Down Arrow buttons. • Press ENTER to select a function when in the OSD Menu. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 17: Main Menu Functions

    Choose EXIT on the OSD Main changes to settings. Menu to exit from the entire OSD Menu. The automatic exit function exits you from the OSD Menu after approximately 10 seconds of inactive use. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 18: Input Source

    NOTE: Shown is the screen without any cameras selected to record. Figure 2: Camera Settings and DVR Settings. NOTE The OK button MUST be pressed to accept/save changes to settings. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 19: Screen Settings

    • Tint (recommended value is 16) • Sharpness (recommended value is 30) • Mode - (recommended value is 16:9) • Dimmer Figure 3: Screen Settings Menu and LCD Setup. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 20: Camera Settings

    • Trigger Record: Select ON if you want the triggered camera to record when it appears on the screen. Figure 5: Trigger Setup Main Menu and Trigger Setup for Camera (A). © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 21: Auto Scan Time

    Up arrows on the Remote Control). Press the OK button on the touchscreen to save the setting. • Camera System - formatting for NTSC (North and South America) or PAL (Europe) (Figure 6). Figure 6: Auto Scan Time and Camera System. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 22: Rear Grid Setting

    With the parking brake applied, power up the monitor system by turning the vehicle’s ignition to “on” and placing the transmission in reverse gear. DO NOT START THE ENGINE UNLESS IT IS NECESSARY TO ENGAGE REVERSE GEAR. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...
  • Page 23 Main Menu Functions The following measurements are recommended by McNeilus. 1. Select Rear Grid Setting. 2. Select the camera that you want to set up with a distance grid. 3. Turn the display of the grid on/off on the monitor.
  • Page 24 For each line dimension, press the right arrow to increase or the left arrow to decrease the achieve the desired measurement. Press OK to save. Dimensions move in 1/2 foot increments. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...
  • Page 25 DO NOT START THE ENGINE UNLESS IT IS NECESSARY TO ENGAGE REVERSE GEAR. The following measurements are recommended by McNeilus. 1. Select Grid. 2. Select the camera that you want to set up with a distance grid.
  • Page 26 *H1 and H2 refer to the left and right distance from the center line of the vehicle (see Horizontal Line Set Up). 4.5 ft. 4.5 ft. H1 = 0ft. 0ft. = H1 © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 27: Motion (Motion Detection)

    Motion Detect record function from less sensitive to more sensitive. Figure 8: Motion Detection Setup and Motion Sensitivity Setup. NOTE The OK button MUST be pressed to accept/save changes to settings. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 28: Dvr Main Menu Options

    IMPORTANT active, the DVR recording will resume as was previously set. The image displayed on the monitor McNeilus recommends installing and uninstalling the SD is what is recorded. Card through the DVR Menu to ensure that the SD Card is formatted when installed.

  • Page 29: Dvr Record Source

    Playback - Page 26 Frame - Page 26 Date/Time - Page 27 Record Mode - Page 27 Format - Page 29 Figure 11: DVR Menu (general settings of the DVR). Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.
  • Page 30 For ease of viewing files, it is not recommended to use the Playback mode. Instead, download the McNeilus SSV Analytics software to your computer and view the SD card on your computer. See McNeilus SSV Analytics software information below.
  • Page 31 • Video Mode - formatting for NTSC (North and South America) or PAL (Europe) (Figure 15). Figure 15: Record Mode Main Menu, Auto/Manual Recording setting, and Video Mode selection. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.
  • Page 32 G-Sensor ratings set to High, Medium, or Low will not allow the SD Card to loop (continuously record). McNeilus recommends the G-Sensor rating be set to OFF to allow the SD Card to continue to loop. SSV Analytics allows for viewing and/or sorting separated files triggered by a G-Shock.

  • Page 33: Mute Icon

    Figure 20: Language setup for the Menu to exit from the entire OSD Menu. The automatic Monitor. exit function exits you from the OSD Menu after approximately 10 seconds of inactive use. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 34: Ignition Off Setup

    - Turns on/off the beeping sound emitted when pressing buttons on the touchscreen. • Factory Defaults - Resets the Monitor settings to factory default (Figure 22). Figure 22: Factory Default for Monitor/OSD. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 35: Passcode

    Figure 23: Set Passcode, Passcode locked unlocked is set and OSD Menu is locked, Passcode is not set and OSD Menu is unlocked. Exit Use the Exit button to exit the OSD menu. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 36: Ssv Analytics Software

    SSV Analytics Software SSV Analytics Software Screenshot To view, download the McNeilus SSV Analytics software to your computer and view the SD card on your computer. See McNeilus SSV Analytics software information below. To play the recorded images from the SD Card on a computer, users must first go to http://www.mcneilus-ssv.com/Extreme9/McNeilus-SSV-Analytics.exe...
  • Page 37 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 38: Camera And Cable Installation

    Camera and Cable Installation Camera and Cable Installation © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 39: Camera And Cable Installation

    NOTE: If the provided bracket does not allow for positioning the camera in the best location, see Page 41 for bracket options available through McNeilus Parts at 888-686-7278 or www.streetsmartparts.com. If you require a different bracket for the camera, use that bracket as a template for drilling the holes.

  • Page 40: Front End Loader

    When installing a hopper camera on a dump body truck, it is necessary to purchase an 82’ cable (P/N 1431526). For reference number 9, the IR on the camera must be turned off. See Page 5 for instructions to turn off IR. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 41: Rear End Loader

    If the crossbeam does not have the hole, or you wish to have the camera mounted outside the crossbeam, brackets 1484152 and 1484153 must be used in conjunction with each other. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 42: Autoreach

    When installing reference numbers 8 and 9, it may be necessary to purchase a 16' cable (P/N 1433196). For reference number 9, the IR on the camera must be turned off. See Page 5 for instructions to turn off IR. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 43: Zero Radius

    When installing reference numbers 8 and 9, it may be necessary to purchase a 16' cable (P/N 1433196). For reference number 9, the IR on the camera must be turned off. See Page 5 for instructions to turn off IR. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 44: Mixer

    For reference number 9, the IR on the camera must be turned off. See Page 5 for instructions to turn off IR. IMPORTANT Do NOT get muriatic acid or any other acid on cameras when rinsing concrete from the Mixer. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 45: Camera Bracket Illustrations

    Camera Locations Camera Bracket Illustrations 1140988 1483269 1483253 1395593 1260747 1260752 1428569 1145490 1431792 1143992 1408134 1235556 1486114 1150000 1260649 1166535 1484152 1484153 1408138 1408136 1321476 1178933 0084330 1483254 1494170 Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.
  • Page 46 Troubleshooting Components for Individual Sale Component Specifications Preco PreView Installation Hardware Warranty © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 47: Troubleshooting Chart

    Troubleshooting Chart The sequence below will help isolate a problem or malfunction and often permit a quick repair. If further assistance is required, refer to the applicable section of this manual or contact McNeilus Street Smart Parts and Service at 507-374-6321.
  • Page 48 Check the SD Card. installed in its port. 3. Format the SD Card. See Page 29 to format the SD Card. 4. Replace the SD Card. (Recommended replacement is McNeilus SD Card, see Page 48.) © 2014 McNeilus Truck and Manufacturing, Inc.
  • Page 49 1. Relocate the GPS antenna to the cab dash or inside windshield in full view of display correctly in Location satellites. Analytics. P. Camera Displays Poor Quality (Grainy) Picture Contact Street Smart Parts™ at 507-374-6321 Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.
  • Page 50 1489033 RAM Mount, Double Socket, 1.5" Ball, 8"L 1489034 Hex Cap Screw M5-.8X10* (x4) 1496858 Flat Washer M5x10x1* (x4) 1496859 *Use 1496858 and 1496859 when using P/N 1476231 mount. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...
  • Page 51 Monitor Camera Harness 1541952 Monitor GPS Harness 1541953 Monitor Splitter Cable Adaptor* 1543316 *Use this splitter if you want two different mounting locations for one monitor. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 52: Components For Individual Sale Selected Component Images

    Camera/Monitor SSP P/N 1431526 82' Cable Camera/Monitor SSP P/N 1511546 Power Accessory Harness P/N 1476860 Remote Control P/N 1453457 32GB Memory Card P/N 1484556 Triangle Driver Bit SD Card Cover © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...
  • Page 53 Mount, Double Socket, P/N 1491922 Night 1.5" Ball, 8"L Vision Light SSV P/N 1477198 Polymer Camera Bracket P/N 1452176 - 2-Second Off Delay Module P/N 1507413 Camera Hardware Kit Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.
  • Page 54 P/N 1480152 - 4 Camera Harness Camera Harness P/N 1462085 SV Cable P/N 1541953 to SSV Camera Monitor GPS Harness P/N 1541952 P/N 1543316 Monitor Camera Monitor Splitter Harness Cable Adaptor © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 55: Component Specifications

    Weight 5 lb (2300g) Safety FCC / CE / e13 / ROHS Environment Operating Temperature -4°F — 158°F (-20° — 70°C) Storage Temperature -4°F — 158°F (-20° — 70°C) Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 56: Camera Specifications For P/N 1470028

    AV Video/Audio TV System NTSC or PAL system Audio Microphone Dimensions Overall Dimension 92mm x 72mm x 65mm Weight 16 oz. Environment Operating Temperature -67°F — 158°F (-55°C — 70°C) © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 57: Preco Preview Radar System

    Street Smart Vision Systems are compatible with PreView Radar System by Preco Electronics . The PreView ® ® Radar System may be mounted and used on any McNeilus Refuse vehicle. ® READ AND UNDERSTAND THESE INSTALLATION INSTRUCTIONS BEFORE INSTALLING THE PRECO PREVIEW RADAR SYSTEM.
  • Page 58 2. Connect the 1483926 Monitor Adaptor/Cable between the monitor and the camera cable. 3. Plug the black Deutsch connector from the 1483926 Monitor Adaptor/Cable into the VideoLink (see Figure 26). Figure 26: 1483926 Monitor Adaptor/Cable and 1483927 VideoLink © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...
  • Page 59 3. Turn on the SSV Extreme Monitor/DVR System to verify the PreView system is operational. ® NOTE The sensor mating connector is fully waterproof if Figure 29: Connect Cab Adaptor Cable (P/N 1483928) to mated properly. VideoLink Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.
  • Page 60 7. Connect the other end of the red wire to the reverse light power circuit. 8. Install the buzzer into the buzzer bracket. 9. Secure the bracket in a location in the cab where it can be heard by the vehicle's operator. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...
  • Page 61 ~ 3 ft. (1 m) ~ 3 ft. (1 m) Figure 32: Detection Zone as viewed through the monitor. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.

  • Page 62: Preview ® Single Sensor System For P/N 1504244 (For Rear Loader Application Only)

    Reposition the sensor in another location until nothing is detected in the zone. Figure 33 © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...
  • Page 63 2. Connect the 1483926 Monitor Adaptor/Cable between the monitor and the camera cable. 3. Plug the black Deutsch connector from the 1483926 Monitor Adaptor/Cable into the VideoLink (see Figure 35). Figure 35: 1483926 Monitor Adaptor/Cable and 1483927 VideoLink Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.
  • Page 64 3. Turn on the SSV Extreme Monitor/DVR System to verify the PreView system is operational. ® NOTE The sensor mating connector is fully waterproof if Figure 37: Connect Cab Adaptor Cable (P/N 1483928) to mated properly. VideoLink © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...
  • Page 65 7. Connect the other end of the red wire to the reverse light power circuit. 8. Install the buzzer into the buzzer bracket. 9. Secure the bracket in a location in the cab where it can be heard by the vehicle's operator. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.
  • Page 66 5. The final detection zone, as viewed through the monitor, should look similar to Figure 40. The Xs indicate the points of detection of the assistant on the monitor. Approximate Pattern Figure 40: Detection Zone as viewed through the monitor. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 67: Preview ® Dual Sensor System For P/N 1474028

    15 degrees down toward the ground. 10° Dual PreView Sensor (P/N 1407329) 15° PreView PreView Camera Dual PreView Sensor Bracket (P/N 1483959) Figure 41: Mount the Dual PreView Sensors on Rear End Loader. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.
  • Page 68 See Figure 42. 10° Camera PreView PreView Dual PreView Sensor Dual PreView Sensor Bracket (P/N 1483959) (P/N 1407329) Figure 42: Mount the Dual PreView Sensor on Front End or Side Loaders. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...
  • Page 69 4. From the VideoLink Monitor Adaptor, connect the red wire to accessory power, the black wire to ground, and the blue wire to reverse light power circuit. 5. Turn on the SSV Extreme Monitor/DVR System to verify the PreView system is operational. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.
  • Page 70 Figure 47: Install and connect the PreView VideoLink Harness on Front End or Side Loaders. Legend for Both Cable Installation Images Tailgate Harness VideoLink Camera Adaptor P/N 1483962 P/N 1483963 VideoLink Monitor Adaptor Existing Camera System Cable P/N 1483964 © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...
  • Page 71 9. Connect the other end of the red wire to the reverse light power circuit. 10. Install the buzzer into the buzzer bracket. 11. Secure the bracket in a location in the cab where it can be heard by the vehicle's operator. Extreme 9" Monitor/DVR System © 2014 McNeilus Truck and Manufacturing, Inc.
  • Page 72 ~ 3 ft. (1 m) ~ 3 ft. (1 m) Figure 50: Detection Zone as viewed through the monitor. © 2014 McNeilus Truck and Manufacturing, Inc. Extreme 9" Monitor/DVR System...

  • Page 73: Hardware Warranty

    Street Smart Parts and Service™ provides a four-year comprehensive warranty on this product. ® This McNeilus Street Smart Parts and Service product is protected for four years from the original date of purchase from McNeilus Street Smart Parts and Service against defects in material and workmanship. McNeilus will repair or replace, at McNeilus’s sole discretion and without charge, any part which under normal and proper...
  • Page 74 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 75 w w w . s t r e e t s m a r t p a r t s . c o m 8 8 8 . 6 8 6 . 7 2 7 8...
