Using The Midi Output - JMK programmable bypass looper User Manual

Using the Midi Output of the Programmable Bypass Looper will allow you to utilize the
Midi functions of any effects you utilize. Here is some useful info to help you understand
how this functions:
• First, ensure that the Midi Output of the Programmable Bypass Looper is
connected via a 5 pin Midi Cable to the Midi Input of whatever effect you desire to
control.
• Select a Preset Bank via the Bank switch.
• As you choose a Preset from the Bank you are currently in, A Midi Program
Change (PC) message is sent via your Midi Cable.
• When you select a new Preset, either from the Bank youʼre currently in or in
another Bank, a new PC Message will be sent to your Midi connected unit.
Bank Preset
A
A
A
A
A
B
B
B
B
B
** Please Note: Midi Devices often start with Program 000, so keep in mind that your
Preset saved in the first slot in the effect device memory bank might get skipped.
This Document is designed for personal use only! Do not post this document online or use this to create a
product for sale without permission of itʼs owner:

Using the Midi Output

Preset PC Message Change List Preset PC Message Change List Preset PC Message Change List Preset PC Message Change List Preset PC Message Change List Preset PC Message Change List
Midi
Program
1 001
2 002
3 003
4 004
5 005
1 006
2 007
3 008
4 009
5 010
Bank Preset
C 1
C 2
C 3
C 4
C 5
D 1
D 2
D 3
D 4
D 5
jmkpedals@gmail.com
Midi
Program
011
012
013
014
015
016
017
018
019
020
