OPERATIONS
1. Install the software normally. DJ Software like Deckadance and Traktor Pro can be used
with this unit. Please visit http://www.djtechpro.com for downloading mapping file (TSI
file) for Traktor.
2. Connect the MIXER ONE to computer and DC adaptor to MIXER ONE. Driver will be
installed automatically. No Driver is needed.
3. Connect other USB controllers (if applicable) like DJ Tech Kontrol One to the USB Port
at the MXIER ONE rear panel. Sample connection as below:
DC Adaptor (Included)
USB
KONTROL ONE
(Not Included)
4. Open the DJ software and enable the unit in setup page. For example in Deckadance:

SPECIFICATION

POWER SUPPLY: DC 6V 1.5A
DIMENSION: 160(W) × 291(D) × 105.6(H) mm
WEIGHT: 1.7kg
USB
KONTROL ONE
Mixer One
(Not Included)
3
USB
Computer
