Before installation be sure to reference the instruction manual attached in order to install the bed
portion of your Abbott Library bed.
When installing the Murphy bed be sure to leave plenty of room for the
surrounding bookcases. The Abbott fully assembled is; queen 129.5" wide,
full 117.5" and twin 87.5." Be sure that you have allowed room for these
dimensions. Once you have successfully installed and properly placed the bed.
You can start placing and putting together the bookcases as well as the main
crown.
Note
Advertisement
Table of Contents
Related Manuals for Murphy Abbott Library
Summary of Contents for Murphy Abbott Library
- Page 1 Abbott Library bed. Note When installing the Murphy bed be sure to leave plenty of room for the surrounding bookcases. The Abbott fully assembled is; queen 129.5” wide, full 117.5” and twin 87.5.” Be sure that you have allowed room for these dimensions.
- Page 2 (1 Piece) Bookcase Bookcase (2 Pieces) Base Covers (2) (2 Pieces) (2 Pieces) Step 1 Place the 2 stationary bookcases ush along both sides of the installed Murphy bed. These two bookcases will not need to be secured to the wall.
- Page 3 Step 2 Now that the stationary bookcases are aligned with the bed, place one of the main crown assemblies on the partially assembled unit. Front Main Crown 2 Pieces Step 3 With the rst half of the main crown in place, slide both rolling bookcases under the previously placed crown.
- Page 4 Step 5 Now that the crown is placed properly and aligned, nish connecting the two pieces using the provided nut onto the pan-head bolt and washer. Step 6 Place the provided flip-bolt in the slot. Tighten as needed until the center gap between the crown pieces become flush to one another.
- Page 5 Step 7 Now that the bed and bookcases are joined together by the crown make sure that everything operates smoothly. The bookcases should slide with ease and the bed should fold down properly once fully completed. Step 8 Now that the bed, bookcases and crown are in position;...
- Page 6 Step 9 If for some reason the sliding bookcases do not roll smoothly or seem to not be level, you can easily adjust the bookcases by tightening or loosening the adjustment bolts located at the bottom of the two units. Note After adjusting the bookcases to the appointed position, use...
