Snell Advanced Media Vega 200 Quick Setup Manual

Vega 100 series
Hide thumbs Also See for Vega 200:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
Vega 100

Series Routers

Quick Setup Guide
www.s-a-m.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vega 200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Snell Advanced Media Vega 200

Summary of Contents for Snell Advanced Media Vega 200

  • Page 1: Series Routers

    Vega 100 Series Routers Quick Setup Guide www.s-a-m.com...

  • Page 2: Table Of Contents

    Vega 100 Series Routers Quick Setup Guide In this Quick Setup guide, we’ll cover the basic steps to get your Vega 100 Series router ‘up and running’ and controlling signal routes. For full configuration and operational details, please refer to the user manual which accompanies the product.

  • Page 3: Introduction

    Please refer to the Vega 100 Series user manual for advanced setup and configuration. Vega 100 Series Routers The Vega 100 Series offers the following router models: • Vega 200 (up to 96 ports). • Vega 400 (up to 192 ports). •...

  • Page 4: Safety And Emc

    Vega 100 Series Routers Quick Setup Guide Safety and EMC For comprehensive safety information please see the Vega 100 Series user manual. Safety Standards This equipment complies with the following standards: EN60950-1: 2006 Safety of Information Technology Equipment Including Electrical Business Equipment. UL1419 (3rd Edition) - UL File E193966 Standard for Safety Professional Video and Audio equipment.
  • Page 5 Safety and EMC Mains Safety • Caution: Double Pole/Neutral Fusing (Vega 200 and 400 models). • This equipment has more than one power supply cord. To reduce the risk of electrical shock, disconnect all the power supply cords before servicing.
  • Page 6 Vega 100 Series Routers Quick Setup Guide (1 of 2) Figure 1: Vega 200 & 400 front door (Vega 200 shown) Figure 2: Vega 200 & 400 Transit bracket screws (Vega 400 shown) Turn Right to lock Turn Left to unlock...

  • Page 7: Unpacking

    Unpack the Vega router chassis. Place it on a suitable flat surface for testing. Vega 200 & 400 Transit Brackets: Loosen the two captive fasteners on the Vega 200/400 front door (A). Open the Vega front door by pulling the door out and swinging it down.
  • Page 8 “Off”, if no second Controller fitted “Off” if no PSU 2 fitted, “Off” “Off”, if no second Crosspoint fitted Figure 8: Vega 200 & 400 Front LEDs (Vega 200 shown) “Off”, if no second Crosspoint fitted if no PSU 2 fitted, “Off”...

  • Page 9: Power & Status Check

    Power & Status Check Power & Status Check For Vega 200 & 400 - see Figure 7 and Figure 8. Note: For Vega 700 - see Figure 9 and Figure 10. Power A Vega 100 Series router is supplied with either one or two Power Supply Units (PSUs).
  • Page 10 Vega 100 Series Routers Quick Setup Guide Vega 200 CAT5 Cable Assembly Vega 400 To Network Hub, Switch or PC. Vega 700 Figure 11: Rear Ethernet Network ports Enter default IP address http://172.19.39.150/ and press Return. Vega unit home page...

  • Page 11: Browser Login

    Browser Login Browser Login Network Connection The Vega 100 Series router is supplied with either one or two controllers, depending on the redundant options purchased. For the purpose of checking signal routing functionality, it is only necessary to connect to Controller A. Connect a standard CAT5 cable to port ETH 1 on the rear of the Vega router (see Figure 11).
  • Page 12 Vega 100 Series Routers Quick Setup Guide Check box ..and then click Run Figure 13: Digital Signature message Click No Figure 14: Java Security message • Click the ‘Matrix 1’ expand box • Double-Click on ‘Level 1’ • ‘Rendering template’...
  • Page 13 Browser Login (Continued) If an application digital signature message displays (see Figure 13) Note: check the Always trust content from this publisher check box and then click Run. If a Java security message displays (see Figure 14), click the No button. Note: The browser connects to the Vega unit and a Network tree panel displays on your PC screen.

  • Page 14: Xy Panel

    Vega 100 Series Routers Quick Setup Guide XY Panel The RollCall Control Panel’s XY panel (Figure 16) displays all the currently ‘enabled’ sources and destinations. The example XY panel shown is for a router configured with 16 sources and 16 destinations (32 ports). Make your signal connections and use the XY panel to test your router functionality.

  • Page 15: External Control

    External Control External Control Vega serial and IP ports are set by default to allow external system controllers to be directly connected, to control the router. Vega Control Ports Configured Protocol Comment Serial ports 1-4 SW-P-02 in IP interface ports SW-P-02 in (IP port 2008) Video source and destination numbers are as labelled on the router rear panels.

  • Page 16: Issue 4 Rev 3

    Notes: Company policy is one of continuous product improvement. Specifications are subject to change without notice. Turnpike Road, Newbury, Berkshire, RG14 2NX, UK. + 44 1635 569777 / info@s-a-m.com www.s-a-m.com © 2016 SAM All rights reserved. Vega 100 Series Routers Quick Setup Guide Issue 4 Rev 3 www.s-a-m.com RMY3 VEGA100QSG...

This manual is also suitable for:

Vega 400Vega 700
