- Page 1 Installation Manual Vega 100 Series Routers Flexible Video and Audio Routers Vega 200 (96 Port) Vega 400 (192 Port) Vega 700 (432 Port) www.s-a-m.com...
-
Page 2: Table Of Contents
2.7.1 Vega 200 and Vega 400 Routers ....... . 10... -
Page 3: Information And Notices
Vega 100 Series Routers Installation Manual About this Manual Information and Notices Information and Notices 1.1 About this Manual This manual describes the Vega 100 Series routers and the configuration of the various modules that can be added to them. If you have any questions regarding the installation and setup of your product, please refer to the following Customer Service contact details. -
Page 4: Safety
Vega 100 Series Routers Installation Manual Safety Safety Erklärung der Sicherheitssymbole Dieses Symbol weist den Benutzer auf wichtige Informationen hin, die in der begleitenden Dokumentation enthalten sind. Dieses Symbol zeigt an, dass gefährliche Spannung vorhanden ist. Es befinden sich keine vom Benutzer zu wartenden Teile im Geräteinneren. Dieses Gerät sollte nur von geschultem Personal gewartet werden Sicherheits-Warnhinweise Die angeführten Service-/Reparatur-Anweisungen sind... - Page 5 Vega 100 Series Routers Installation Manual Safety Simboli di sicurezza: Forklaring på sikkerhedssymboler Questo simbolo indica l'informazione importante contenuta nei Dette symbol gør brugeren opmærksom på vigtig information manuali appartenenti all'apparecchiatura. Consultare il manuale. i den medfølgende manual. Questo simbolo indica che all'interno dell'apparato sono presenti Dette symbol indikerer farlig spænding inden i apparatet.
- Page 6 Vega 100 Series Routers Installation Manual Safety Símbolos de Segurança O símbolo triangular adverte para a necessidade de consultar o manual antes de utilizar o equipamento ou efectuar qualquer ajuste. Este símbolo indica a presença de voltagens perigosas no interior do equipamento.
-
Page 7: Explanation Of Safety Symbols
Vega 100 Series Routers Installation Manual Explanation of Safety Symbols Safety 2.1 Explanation of Safety Symbols This symbol refers the user to important information contained in the accompanying literature. This symbol indicates that hazardous voltages are present inside. No user serviceable parts inside. -
Page 8: Mains Power Supplies
Vega 100 Series Routers Installation Manual Mains Power Supplies Safety 2.3 Mains Power Supplies • Caution: Double Pole/Neutral Fusing. • This equipment has more than one power supply cord. To reduce the risk of electrical shock, disconnect all the power supply cords before servicing. •... -
Page 9: Rack Mounting
Do not rack-mount the Vega 100 Series router using only the front rack ears. • The Vega 200 router weighs 10 kg (22 lbs) for a full frame (without packaging). When lifting the Vega router into a 19" rack use the correct local Health and Safety lifting guidelines. -
Page 10: Front Panel Lock
The risk of non-compliance is with the user if the router is left unlocked in normal operation. The Vega 200 and Vega 400 routers are fitted with two captive fastening screws (one on the left of the router and one on the right, see Figure 1). These fastening screws allow the router front panel to be locked and in normal operation the router must remain locked. -
Page 11: Compliance Standards
Vega 100 Series Routers Installation Manual Compliance Standards Safety 2.8 Compliance Standards This equipment complies with the following standards: EN60950-1: 2006 Safety of information Technology Equipment Including Electrical Business Equipment. UL1419 (3rd Edition) - UL File E193966 Standard for Safety - Professional Video and Audio equipment EMC Standards This unit conforms to the following standards: EN55103-1:2009 (Environment E4) -
Page 12: Installation
For Vega 100 Series routers, cooling air flow is front to rear: Air is pulled in through the front of the router and pushed out of the rear of the router. • Vega 200 router has two fans at the rear (one behind the other). • Vega 400 router has two fans at the rear (one above the other). -
Page 13: Dimensions
You must allow at least 100 mm (4 inches) of space at the rear of the router for cables, connections and ventilation. The 2RU Vega 200 router dimensions are as shown in Figure 3: Dimensions are in millimeters (inches) Figure 3... -
Page 14: Vega 400 Router Dimensions
Vega 100 Series Routers Installation Manual Dimensions Installation 3.2.2 Vega 400 Router Dimensions • For ventilation purposes, there must be a gap of at least 50 mm (2 inches) at the Important: front of the Vega router. • You must allow at least 100 mm (4 inches) of space at the rear of the router for cables, connections and ventilation. -
Page 15: Vega 700 Router Dimensions
Vega 100 Series Routers Installation Manual Dimensions Installation 3.2.3 Vega 700 Router Dimensions • For ventilation purposes, there must be a gap of at least 50 mm (2 inches) at the Important: front of the Vega router. • You must allow at least 100 mm (4 inches) of space at the rear of the router for cables, connections and ventilation. -
Page 16: Rack-Mounting The Vega 100 Series Router
3.3 Rack-mounting the Vega 100 Series Router The Vega 200 and Vega 700 a routers must be shelf-mounted in a standard 19” rack. The Vega 400 router can either be mounted on rack slides or shelf-mounted in a standard 19”... -
Page 17: Rack Slide Mounting (Vega 400 Router Only)
Vega 100 Series Routers Installation Manual Rack-mounting the Vega 100 Series Router Installation 3.3.2 Rack Slide Mounting (Vega 400 Router Only) • Do not rack-mount the Vega 100 Series router using only the front rack ears. • Make sure that sufficient space is available for the Vega router in the rack. •... - Page 18 Vega 100 Series Routers Installation Manual Rack-mounting the Vega 100 Series Router Installation Rack Mount Assembly Long L Shaped Offset Rack Bracket Threaded Bar Offset Threaded Bar 2 x Mounting Bolts 2 x Cage 2 x Mounting Nuts Bolts Rack Mounting Section of the Slide, Closed End Towards Short L Shaped...
- Page 19 Vega 100 Series Routers Installation Manual Rack-mounting the Vega 100 Series Router Installation 11. When you have confirmed correct slide operation check that all the screws are tight. 4 x Rack Bolts Figure 9 Vega 400 router installed in rack (long slide kit shown) 12.
-
Page 20: Transit Brackets
Fitting or removing crosspoint, controller, buffer cards and PSUs requires removal/refitting of transit brackets: • Vega 200 and Vega 400 routers - see section 3.4.1 • Vega 700 router - see section 3.4.2 3.4.1 Vega 200 and Vega 400 Router Transit Brackets Loosen the captive front panel fastening screws on the router (see section 2.7.1 for... -
Page 21: Vega 700 Router Transit Brackets
Vega 100 Series Routers Installation Manual Transit Brackets Installation Tighten the captive front panel fastening screws on the left and right of the router (see section 2.7.1 for details) to lock the front panel. Refitting the transit brackets for transportation is the reverse of the removal process. 3.4.2 Vega 700 Router Transit Brackets Turn the door fastening screw on the router a quarter of a turn to the left ( ) to... - Page 22 Vega 100 Series Routers Installation Manual Transit Brackets Installation Secure the Vega card transit bracket to the storage position on the rear of the door using the screws in case the Vega router needs transporting in the future, see Figure 14. Vega Card Transit Bracket and screws x 2 Figure 14 Vega 700 router card transit bracket storage on the inside of the door...
-
Page 23: Power And Fuses
Connectors. Vega 400 Router Figure 15 Vega 200 & Vega 400 Router IEC power supply connectors Each IEC connector supplies an independent feed of power to each of the two power supply modules as shown in Figure 16. The filtered IEC320 mains power connectors are suitable for standard IEC power cables. - Page 24 The router supports dual power supplies for redundancy. This is an option and so a second PSU may not be fitted. Figure 16 Vega 200 & Vega 400 IEC power supply schematic (main and redundant PSUs fitted) Issue 3 Rev 2 Page 24 ©...
-
Page 25: Vega 700 Router Power Supplies
Vega 100 Series Routers Installation Manual Power and Fuses Installation 3.5.2 Vega 700 Router Power Supplies Power Supply Filtered IEC Connectors PS2 (left) and PS1 (right) PS2 Fuse PS1 Fuse Figure 17 Vega 700 Router IEC power supply connectors Each IEC connector supplies an independent feed of power to each of the two power supply modules as shown in Figure 18. -
Page 26: Power Supply Replacement
Once the failed PSU has been removed PSU redundancy will be lost until a new PSU is fitted: Vega 200 router replacement PSU part number = VG-PSU1 (was VG-PSU096-A) Vega 400 router replacement PSU part number = VG-PSU1 (was VG-PSU192-A) Vega 700 router replacement PSU part number = VG-PSU2 (was VG-PSU432-A) •... - Page 27 Vega 700 Router Figure 19 PSU and PSU fan status LEDs Vega 2U and 4U Router Vega 700 PSU & Fan (when router Status LEDs Vega 200 & Vega 400 PSU & Fan viewed from front) PS1 LED Upper PSU Left-hand PSU...
-
Page 28: Vega 200 And Vega 400 Router Power Supply Replacement
Vega 100 Series Routers Installation Manual Power Supply Replacement Installation 3.6.1 Vega 200 and Vega 400 Router Power Supply Replacement • Caution: Double Pole/Neutral Fusing. • The fan will continue to run for 10 to 20 seconds after the power supply is removed from the router as 48 Vdc remains present for a short time. -
Page 29: Vega 700 Router Power Supply Replacement
Vega 100 Series Routers Installation Manual Power Supply Replacement Installation 3.6.2 Vega 700 Router Power Supply Replacement • The fan will continue to run for 10 to 20 seconds after the power supply is removed from the router as 48 Vdc remains present for a short time. •... -
Page 30: Rear Fan Replacement
Important: ensure the Vega router doesn’t overheat. The Vega 200 router has two fans at the rear (one behind the other). The Vega 400 router has two fans at the rear (one above the other). The Vega 700 router has three fans at the rear (one above the other). - Page 31 Vega 100 Series Routers Installation Manual Rear Fan Replacement Installation Figure 23 Vega router rear fans Vega 400 Router only: remove the two port number retaining plates shown in Figure 23 to free the fan assemblies. Pull the failed fan assembly straight back from the Vega router and support it from underneath.
-
Page 32: Specifications
Vega 400: see section 3.2.2 Vega 700: see section 3.2.3 Weight Vega 200: 10 kg (22 lb) maximum, fully loaded (all options) Vega 400: 18 kg (40 lb) maximum, fully loaded (all options) Vega 700: 31 kg (68 lb) maximum, fully loaded (all options) - Page 33 Vega 100 Series Routers Installation Manual Specifications Environmental Operating temp 5°C to 40°C Maintained spec 0°C to 30°C Storage temp -20 to +80°C Relative Humidity 5% to 95% non-condensing Ventilation Fan assisted. Front inlet, rear exhaust Compliance EMC - Emissions EN55103-1 (EU), FCC Part 15 (USA) EMC - Immunity EN55103-2 (EU)
