Connection Examples
Connecting Using a Computer Cable
If you output
audio
Connect the ports in either of the following combinations.
When using [Computer1] input port
When using [Computer2] input port
Connecting Using a USB Cable
If you output
audio
•
For projectors which audio can be input with the USB cable in the USB
Display function, there is no need to connect the audio cable.
•
Be sure to connect the projector and the computer directly, not via a
USB hub.
[Audio1] port
[Audio2] port
Connecting with HDMI Cables
HDMI
MHL
If you use a thick HDMI cable, it may disconnect under its own weight.
Use the HDMI cable clamp to secure the cable.
•
When the projector only has one HDMI port, make sure you connect the HDMI
cable to the [HDMI1/MHL] port.
•
You may not be able to connect an MHL cable to all devices. Also, depending on
the model or settings of the device, images may not be projected correctly.
•
When connecting an MHL cable, make sure the cable meets the MHL standards.
If the cable does not meet the MHL standard, the connected device may
malfunction.
•
If you connect using a commercially available MHL-HDMI conversion adapter,
you may not be able to charge the connected device or you may not be able to
perform operations from the projector's remote control.
•
If images are not projected correctly using an MHL cable, disconnect and then
reconnect the MHL cable.
•
If you switch the HDMI1/MHL source and the HDMI2 source while playing a movie,
the movie may freeze. Stop the movie before switching sources.
2
