Instrument Overview

Front View
Reagent box
Plate In/Plate Out button
Instrument turned on/busy light
Plate carrier
A constant green light means the instrument is turned on. A flashing green light means the instrument is
busy (e.g. performing a measurement, plate in/out, priming, etc.). A faster flashing (5 flashes per second)
means an error has occurred.
Back View
On /Off
Switch
Figure 7: Back of FLUOstar OPTIMA, POLARstar OPTIMA and LUMIstar OPTIMA
2007-11-19
FLUOstar / POLARstar / LUMIstar OPTIMA Operating Manual
Figure 6: POLARstar OPTIMA
Power cable Serial number
connector
0413B0001I
RS-232
connector
Offset values (no
further notice
needed because this
number has been
entered into the
reader at the factory)
