Summary of Contents for Cyber Power PDU81001
- Page 1 Power Distribution Unit USER'S MANUAL Copyright © 2017 Cyber Power Systems, Inc. All rights reserved.
-
Page 2: Table Of Contents
Table of Contents Model List ..............1 Safety Precautions ..........1 Introduction .............2 Package Contents ..............2 1 U Models ................2 0U Modles ................3 2U Models ................4 Prorduct Features ..............5 1U 15A Models ..............5 Technical Specifications ..........4 1U 20A Models ..............6 Technical Specifications ..........6 0U 16/20A Models ............7 Technical Specifications ..........8 0U 30/32A Models ............9... -
Page 3: Model List
Model List Switched Metered by Outlet Series PDU81001 PDU81003 PDU81101 PDU81002 PDU81007 PDU81102 PDU81004 PDU81008 PDU81104 PDU81005 PDU81009 PDU81 1 05 PDU81006 PDU81404 PDU81405 Metered by Outlet Series PDU71001 PDU71003 PDU71002 PDU71007 PDU71004 PDU71008 PDU71005 PDU71009 PDU71006 Switched Series PDU41001... -
Page 4: Introduction
Introduction Package Contents 1U Models Mounting Brackets: 2 short & 2 long 12 (Flat Head M4 x 8) 6 (M5 x 12) Rack Mounting Bracket Mounting Screws Screws/Washers Cord Retention Tray 6 (M3 x 6) Cord Retention Tray Mounting Screws Cable Ties: RJ45/DB9 Serial Port Qty: 12 (NEMA outlet PDU) -
Page 5: Modles
Introduction Package Contents 0U Models Mounting Brackets with 6 (M4x5) Screws 6 (M5 x 12) Rack Mounting 6 (M3 x 6) Screws/Washers Cord Retention Tray Mounting Screws Cord Retention Tray Cable Ties: Qty. 30 (20 outlet PDU) Qty. 36 (24 outlet PDU) Qty. -
Page 6: 2U Models
Introduction Package Contents 2U Models Mounting Brackets x 2 12 (Flat Head M4 x 8) 6 (M5 x 12) Rack Mounting Bracket Mounting Screws Screws/Washers Cord Retention Tray x 2 12 (M3 x 6) Cord Retention Tray Mounting Screws Cable Ties: RJ45/DB9 Serial Port Qty: 24 (NEMA outlet PDU) Connection Cable... -
Page 7: Prorduct Features
L. Outlet Indicator (switched series only) – Indicates if the outlet is providing power to connected equipment. Rear Panel Description A. Ground Stud - Use to ground the PDU. Technical Specifications PDU81001 PDU81004 PDU71001 PDU71004 Model Name PDU41001... -
Page 8: 20A Models
Product Features (1U 20A Models) Front Panel Description NEMA Type IEC Type A. AC Inlet/ AC Power Cord - Used to connect PDU to utility power or UPS. B. AC Output Receptacles - Provides power for connected equipment. C. Status Indicator - Indicates the condition of the PDU (eg. load or environment status). -
Page 9: 16/20A Models
Product Features (0U 16/20A Models) Front Panel Description NEMA Type IEC Type A. AC Inlet/ AC Power Cord - Used to connect PDU to utility power or UPS. B. Outlet Indicator (switched series only) – Indicates if the outlet is providing power to connected equipment. C. -
Page 10: Technical Specifications
Product Features (0U 16/20A Models) Rear Panel Description A. Bracket Screw Hole – Used to secure the Mounting Brackets or Mounting Pegs. Technical Specifications PDU81101 PDU31114 PDU81104 PDU81404 Model Name PDU41101 PDU41104 PDU41404 PDU31414 PDU31101 Input Nominal Voltage 100-120V 200-240V Frequency 50/60Hz 16A UL (Derated) -
Page 11: 30/32A Models
Product Features (0U 30/32A Models) Front Panel Description NEMA Type IEC Type A. AC Inlet/ AC Power Cord - Used to connect PDU to utility power or UPS. B. Outlet Indicator (switched series only) – Indicates if the outlet is providing power to connected equipment. C. -
Page 12: Technical Specifications
Product Features (0U 30/32A Models) Rear Panel Description A. Bracket Screw Hole – Used to secure the Mounting Brackets or Mounting Pegs. Technical Specifications PDU81105 PDU81405 PDU81102 PDU41105 PDU41405 Model Name PDU41102 PDU31102 PDU31106 PDU31406 Input Nominal Voltage 100-120V 200-240V Frequency 50/60Hz Maximum Input Current... -
Page 13: Technical Specifications
Product Features (2U Models) Front Panel Description NEMA Type IEC Type A. AC Inlet/ AC Power Cord - Used to connect PDU to utility power or UPS. B. AC Output Receptacles - Provides power for connected equipment. C. Status Indicator - Indicates the condition of the PDU (eg. load or environment status). -
Page 14: Installation Guide
Installation Guide Please use only the provided screws through the entire installation process. Horizontal Installation For 1U Models Step 1. Mounting Bracket Installation Use the provided Mounting Bracket Screws (8) to attach the SHORT Mounting Brackets (2) to the PDU. If you plan on attaching the Cord Retention Tray to the PDU, you will need to use the LONG Mounting Brackets (2). -
Page 15: For 2U Models
Installation Guide Step 3. Cord Retention Tray Installation (optional) Adjust the length of the Cord Retention Tray till the screw hole on the Tray and PDU are aligned. Attach the Cord Retention Tray to the PDU with the 4 supplied Cord Retention Tray Mounting Screws. - Page 16 Installation Guide Step 2. PDU Mounting Use the supplied Washers (4) and Screws (4) to secure the PDU to your existing rack system. Step 3. Cord Retention Tray Installation (optional) Adjust the length of the Cord Retention Tray till the screw hole on the Tray and PDU are aligned.
-
Page 17: Vertical Installation
Installation Guide Vertical Installation For 1U Models Step 1. Mounting Bracket Installation Use the provided Mounting Bracket Screws (8) to attach the SHORT Mounting Brackets (2) to the PDU. Step 2. PDU Mounting Use the supplied Washers (2) and Screws (2) to secure the PDU to your existing rack system. - Page 18 Installation Guide If there is no Keyhole Slot on your rack, please choose from the following methods that is best for your rack deployment to secure the PDU. Use the supplied Washers and Rack Mounting Screws to attach the Mounting Brackets to your existing rack system. Align the Keyhole Mounts to the Keyhole Slots on the Mounting Brackets.
- Page 19 Installation Guide Method 3...
- Page 20 Installation Guide Step 2. Cord Retention Tray Installation (optional) Adjust the length of the Cord Retention Tray till the screw hole on the Tray and PDU are aligned. Attach the Cord Retention Tray to the PDU with the supplied Cord Retention Tray Mounting Screws.
-
Page 21: Power Cord Locking-For Iec Type Pdu
Installation Guide Power Cord Locking - For IEC Type PDU Input Power Cord Step 1. Align and insert the Cable Tie from the upper side of the Fixed Stand and fasten it as shown below. Step 2. Align and insert the Cable Tie from the bottom side of the Fixed Stand and fasten it as shown below. -
Page 22: Network Installation
Installation Guide Network Installation Step 1 – Attach the LAN Cable Using an Ethernet cable, attach one end to the Ethernet port on the front of the PDU, and the other end to a network port. Step 2 – Establish the PDU IP address Assigning an IP address to the CyberPower PDU requires the user to have an available IP address that is valid on the respective network. -
Page 23: Operation
Operation Remote Management The remote management function provides monitoring of the MBO PDU operational information, controlling outlets and utilizing SNMP functionality. Remote management can be performed via web interface. To access the web interface, please follow the instructions below: 1. Enter the IP address of the PDU into a web browser (Internet Explorer, Firefox). -
Page 24: Led Indicators
Operation LED Indicators Indicator Status Description Green The PDU status is ok. Orange Warning. Status Critical. The PDU power is off. On (Green) The PDU power is on. Tx/Rx Receiving/transmitting data packet. Flashing Reset finished. Indicates the PDU is connected to the LAN. -
Page 25: Firmware Upgrade
Operation Step 3. Notification Notifying the computers of potential outlet shutdown can be accomplished using the following methods: • Outlets Control Menu: Performing the task of turning off or rebooting outlets. • Scheduling Menu: Setting the application to perform the task of turning off or rebooting outlets. - Page 26 Firmware Upgrade Option 2: Single or Multiple Device Upgrade Use the following steps to upgrade the firmware. 1. Download the Upgrade and Configuration Utility from www.cyberpower.com 2. Open Upgrade and Configuration Utility from Start > All Programs > CyberPower Upgrade and Configuration Utility. 3.
- Page 27 Firmware Upgrade 6. Choose Upgrade Firmware item to popup a File Locations of Firmware & Data Window in Action menu. 7. Click Browse button and assigning the firmware file path in Firmware field (Shown in Figure 4). Figure 4 8. Same as step 6, assign the data file path in Data field. 9.
- Page 28 12. Wait for firmware upgrade to finish. 13. The result of firmware upgrade will show in Result column (Shown in Figure 7). Figure 7 Note: If you don’t want to wait for the firmware upgrade, you can stop action by choosing Abort in the Action menu. However, it’s not recommended because Abort action may cause the device to malfunction.
-
Page 29: Troubleshooting
Troubleshooting Problem Possible Cause Solution Reset Breaker, check PDU outlets do 1. Breaker tripped the plug to insure its not provide power 2. Power cord is not connected correctly. If the to connected properly plugged problem remains, contact equipment technical support. Amperage The load indicator shows displayed on... -
Page 30: Customer Service & Warranty
"Support". Cyber Power International Feel free to contact our Tech Support department with installation, troubleshooting, or general product questions. Cyber Power Systems, Inc. Web: www.cyberpower.com For USA and Canada: 4241 12th Ave East, Suite 400 Shakopee, MN55379 Toll-free: (877) 297-6937 For all other regions: Please visit our website for local contact information. -
Page 31: Appendix A-Hyper Terminal
Appendix A-Hyper Terminal Hyper Terminal software can be used for basic PDU configuration. It utilizes a text-based interface and menu system. Navigation through the interface is done by typing the number of the menu option and pressing the Enter key. For COM port setting values, please refer to p.12 Option 4: Hyper Terminal or Terminal Emulator section. - Page 32 Appendix B-Power Device Network Utility Step 3. Choose an installation directory. Select Next (Shown in Figure 2). Figure 2 Step 4. Select Install to comfirm the settings and install (Shown in Figure 3). Figure 3 Step 5. Select Finish to finalize the installation (Shown in Figure 4). Figure 4...
-
Page 33: Launch Program
Appendix B-Power Device Network Utility Launch Program To launch the Power Device Network Utility and get started, select Programs from the Start menu in Windows and locate the new folder and icons for Power Device Network Utility. Select Power Device Network Utility from the program folder (Shown in Figure 5). Figure 5. -
Page 34: Advanced Settings
Appendix B-Power Device Network Utility Step 2. Assign a valid IP Address to the PDU Option 1: Assisted Setup (recommended) With the appropriate device selected from the Equipment List, open the Network Settings menu (Shown in Figure 8) [Tools=>Device Setup]. In the Device Network Setting Menu, enter a valid IP address, subnet mask, and gateway address to setup the PDU device. - Page 35 Cyber Power Systems, Inc. www.cyberpower.com K01-0000545-01...
