Cabinet Dimensions

The following diagrams show the cabinet dimensions for the P452W_P452H_P502W_P502H.
Dimensions are in inches. For millimeters multiply by 25.4.
5.3
AC INLET
IR RECEIVER
LAMP COVER
LENS SHIFT
14.3
www.necdisplay.com
P452W/P452H/P502W/P502H
Page 5 of 9
