Summary of Contents for EML ARG100
- Page 1 ARG100 Rain Gauge User Manual UM-780-001-ARG100 – V1.00...
- Page 2 The contents are subject to change without prior notice. Please observe that this manual does not create any legally binding obligation for EML towards the customer or end user. All legally binding commitments and agreements are included exclusively in the applicable supply contract or Conditions of Sale.
-
Page 3: Table Of Contents
Maintenance and Calibration ...................... 11 Basic Maintenance ..........................11 Calibration ............................11 Specifications ..........................12 Gauge Specifications ......................... 12 Cable Specifications (if fitted) ......................12 Appendix A – ARG100 products, accessories and spares ..............13 UM-780-400-SBS Manual – V2.00 P a g e... -
Page 4: List Of Figures
Table 4 - Cable Specifications (if fitted) ....................12 Table 5 – ARG100 products ........................13 Table 6 - Accessories for the ARG100 ....................13 Table 7 - Spare parts for the ARG100 ....................13 UM-780-400-SBS Manual – V2.00 P a g e... -
Page 5: General Information
1. General Information About this Manual This manual is intended as a general guide for installing, wiring and using the ARG100 rain gauge. The information contained in this manual may not cover all aspects of ARG100 applications. Please refer to associated equipment manuals or consult papers and technical notes on the EML website (www.emltd.net). -
Page 6: Introduction
The gauge should ideally be no closer than at least twice the height of the obstruction. Although the ARG100 rain gauge is designed to operate in higher wind speeds, care must still be taken to avoid over-exposing the gauge where possible. -
Page 7: Baseplate Method Of Levelling
Baseplate method of levelling 1. Assemble the rain gauge base and the baseplate as in Figure 1 2. Fix the baseplate on soft ground using the 4 pegs supplied. If force is needed then remove the rain gauge first. RAIN GAUGE BASE BASEPLATE Figure 1 –... -
Page 8: Paving Slab Method Of Levelling
‘false-tipping’ of the bucket mechanism and thus contribute to erroneous or inaccurate measurements. There are options which can be used to mount the ARG100 above the ground. The ARG100 can be purchased with a rain gauge pedestal and guy kit or a rain gauge pedestal only. UM-780-400-SBS Manual – V2.00... -
Page 9: Wiring Guidelines
ARG100/EC rain gauge The ARG100/EC is supplied fitted with a 6-metre extension cable. One wire is attached to the resistor and covered with adhesive type heatshrink. The other wire is attached, covered with heatshrink and the entire joint covered again with heatshrink. The cable passes through a grommet in the outer base. -
Page 10: Operation
5. Operation Operation of the gauge Rainfall is measured by the well-proven tipping bucket method. Precipitation is collected by the funnel and flows through a plastic gauze filter, trapping and removing any leaves, dirt, etc. Figure 4. Water then drips from the nozzle into one of the two halves of the tipping bucket. Figure 4 - Filter and filter cap (left) / Nozzle delivering water into tipping bucket (right) The internal tipping bucket assembly rotates around precision rolling pivot bearings. -
Page 11: Maintenance And Calibration
NOTE: A spares kit is available with filter, cap, and screws. Contact EML sales (sales@emltd.net) for more information. -
Page 12: Specifications
WMO Compliant Output Contact Closure (Reed Switch) Typical Accuracy 99% up to 120mm/hr Rainfall Intensity 0-500 mm/hr (with mathematical correction - contact EML) Operating Temperature 1°C - 70°C Funnel Diameter 25.4cm / 10 Inch Funnel Area 506.7cm2 / 78.54 sq. Inch Height 31.5cm or 40.0cm max with baseplate... -
Page 13: Appendix A - Arg100 Products, Accessories And Spares
P-780-001 ARG100/STD – Standard P-780-010 ARG100/EC - Standard with 6m cable P-780-002 ARG100/L - Standard with plug for internal EML logger ARG100 with other cable length available on request Table 6 - Accessories for the ARG100 Product code Description P-780-188...
