Axon APT5 Series User Manual

Windows ce6.0 and windows embedded handheld 6.5 classic & professional
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
5 Series
User Manual
Windows CE6.0 and Windows Embedded Handheld 6.5 (Classic & Professional)
June 08 , 2016
ISO 9001 Certified
Quality Management System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APT5 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Axon APT5 Series

Summary of Contents for Axon APT5 Series

  • Page 1 5 Series User Manual Windows CE6.0 and Windows Embedded Handheld 6.5 (Classic & Professional) June 08 , 2016 ISO 9001 Certified Quality Management System...

  • Page 3: Table Of Contents

    Contents Safety Instruction ....................................8 Chapter 1: Introduction to the APT5 Series ........................10 Overview of terminal features ............................11 APT5 and APT5 wide Front View ..........................11 APT5 Back View ................................12 APT5 wide Back View ..............................13 Hand Strap Removal and Replacement......................14 Battery ......................................
  • Page 4 Icons in the Status Bar.............................. 26 Icon Bar ..................................... 28 Icons in the Task Tray ............................... 29 Programs in Start Screen ............................29 Setting Applications ..............................30 LEDs ....................................... 33 LED Appearance upon terminal feature ......................33 Keypad ......................................34 Enter characters on Numeric Keypad .......................
  • Page 5 SDK ........................................ 82 Setup. Ini File .................................... 82 Location of SetupApp.ini file ............................ 82 Section ....................................82 Reset Type ..................................83 Application ..................................83 OS Update ....................................85 OS Update with SD Card ............................85 OS Update by PC: UDM (USB Download Manager) ................87 Wi-Fi connection through SCU (Summit Client Utility) ..................

  • Page 6: Safety Instruction

    Safety Instruction Read this instruction carefully to keep yourself safe and to avoid loss of property. Make sure that battery terminals (metal part) should not contact with any conductive  materials like a necklace or coin. Also make sure that batteries should not be damaged by teeth or a nail.
  • Page 7 Keep this Product away from magnetic products such as credit card, telephone card, bank  book and traffic ticket. The magnetic field of the terminal may affect the data. When storing a battery for a long period of time, recharge it and keep it at a room ...

  • Page 8: Chapter 1: Introduction To The Apt5 Series

    Chapter 1: Introduction to the 5 Series series is rugged mobile computer for use data capture and automation in retail, warehouse and other field applications. The series puts convenient features and capabilities at your hand, including barcode scanning, RFID tag reading and writing, image capturing with built-in camera, and real-time mobile communications through WWAN and WLAN network.

  • Page 9: Overview Of Terminal Features

    Overview of terminal features 5 and wide Front View Receiver Charging LED Indicator Scanner Window Network LED Indicator 3,5” Display (Phone only) 4.3” Display Scan LED Indicator Micro phone Scan Triggers LCD Back Light Controller Reset button DS5 wide Power button Modifier LED Indicator...

  • Page 10: Apt5 Back View

    External Power Unit Camera Flash Camera Lens Speaker Micro USB Port Stylus Pen Hand belt...

  • Page 11: Apt5 Wide Back View

    Scanner Trigger...

  • Page 12: Hand Strap Removal And Replacement

    Hand Strap Removal and Replacement To remove hand strap: 1. Rip the Velcro strap off 2. Take out the Velcro strap from the upper loop 3. Force to pull out lower loop from the terminal Battery Caution If the Product is wet, do not put it in a device that may heat the terminal (heater, microwave oven, etc.). Heating batteries may cause an explosion, deformation or fault.

  • Page 13: Power Adapter

    You may need to fully charge the battery before using your terminal for the first time. Battery can be charged using below listed accessories Charging Accessory Charging Time mini USB cable About 4hours 30minutes Desktop cradle and AC adapter About 4hours 30minutes Snap on About 4hours 30minutes 4 Slot cradle...

  • Page 14: Chapter 2: Getting Started

    Chapter 2: Getting Started This chapter will describe how to install and charge battery, mount micro SD card and start up the terminal To start up the terminal: Install Micro SD card  Mount Battery  Connect power source  Operate power of the terminal ...

  • Page 15: Installation Micro Sd Card

    Installation micro SD card Insert the micro SD card carefully as shown in the following illustrations. Make sure the micro SD card terminal position before insert the micro SD card. Push the back end of the micro SD card to fix it at the last step.

  • Page 16: Battery Mounting And Operation

    Battery Mounting and Operation Push the battery release and mount clear the Push the battery release toward the top of battery to terminal and gently release it. terminal until the battery released and lift it up Inserting the battery Remove the battery Note Battery Maintenance Lithium-ion batteries have a limited life, which is affected by several factors;...

  • Page 17: Connecting Power Source

    Disposal Rechargeable batteries should be sorted for environmental friendly recycling. Do not disposal batteries into household waste. According to the European Guideline 2006/66/EC, defective or used battery packs/ batteries, must be collected separately and disposed of in an environmentally correct manner. Batteries no longer suitable for use can be directly returned at Connecting Power Source Connect power, using one of the methods listed below.

  • Page 18: Operating Power Of The Terminal

    Operating Power of the Terminal Power On and Off Make long press Power button to turn on, or off the terminal. Select OK confirmation message, when you make long press to turn off the terminal Suspend and Resume Press power button shortly to enter Suspend, or Resume the terminal Reset If the terminal stops responding, try reset to kill running applications.

  • Page 19: Chapter 3 Getting Understanding Details

    Chapter 3 Getting Understanding Details Battery Status Below battery title bar is indicating your battery status. Battery Icon Status Battery is fully charged Battery capacity is high Battery capacity is in medium to continue work for several hours Battery is weak and a few minutes of operation remain Battery power is critical low.

  • Page 20: Clean Boot

    Clean Boot Cold boot also enables to kill all running applications. However, it deletes all stored data and entries in RAM. It makes the terminal to factory default status. Try Reset first if the terminal is not responding. Caution Clean boot set the terminal to factory default settings. All applications and stored data will be erased. Do not clean boot without your IT administrator’s support.

  • Page 21: Windows Ce Desktop

    Windows CE Desktop Icons in the task bar At the bottom of Desktop screen, the task bar displays active programs Open program & Status Icons Start Desktop Display Window Title Icons are provided in the terminal display to indicate the state of feature choices. The icons that appear in the terminal display are described in following table.

  • Page 22: Start Button

    Recharging status Battery is low (remained capacity is between 10%~14%) Battery is very low (remained capacity is under 9%) Mobile Manager. It consisted with: Wireless: WLAN and Bluetooth power control Battery: Display battery capacity in percentage Volume: Volume level adjustment Backlight: Backlight adjustment Task Manager: open task manager to manage current task and process of the terminal...

  • Page 23: Taskbar And Start Menu

    Mouse: Check double click sensitivity Network and Dial-Up Connections: Set network connections, such as Dial up, WLAN and Bluetooth Owner: Change owner’s personal Password: Set a password to terminal information PC Connection: Set direct connection Pocket Controller: Configure General to PC Settings and status information, such as Mani battery and Back up battery Power: Indicate current main battery...

  • Page 24: Windows Embedded Handheld 6.5 Home Screen

    Windows Embedded Handheld 6.5 Home Screen Status Bar Today Screen Task Tray Title Bar Icons in the Status Bar It displays current status of system of the terminal. ○ ○ ○ ○ ○ ○ ○ Input mode ○ Connectivity ○ Signal Strength ○...
  • Page 25 Connectivity (WLAN, and Active Sync) Connection is active (In case SCU activated) Connection is inactive (In case SCU activated) WLAN on, but not connected. And no networks are detected. (In case MS Zero Config) Phone is not connected to a network, and other networks are detected.

  • Page 26: Icon Bar

    Battery Battery has a full charge Battery has a high charge Battery has a medium charge Battery has a low charge Battery has a very low charge Battery is charging No battery Icon Bar Tab Status Bar to display Icon Bar. Slide Icon Bar to see more information Icon Description Enlarge screen display...

  • Page 27: Icons In The Task Tray

    Icons in the Task Tray It displays current applications status which is running on top of terminal system Icon Description Wireless Manager: power on/off Phone, WiFi and Bluetooth Barcode Tray: barcode application tool. To display this icon, refer Barcode Scanner Programs in Start Screen Icon Description...

  • Page 28: Setting Applications

    Windows Live: Access Windows Live Money: Stock market information Calculator: Calculator feature Games: Microsoft’s mobile game application Notes: Note pad program. Add, edit, Notes: Note pad program. Add, edit, save a note save a note Tasks: Write your work task and Notes Active Sync: Synchronize...
  • Page 29 Connections Beam: Connections: Set up your network connection, such as modem, ISP, VPN and dial up Domain Enroll: Register your Network Cards: Set up network cards terminal in a domain such WLAN, Bluetooth, Ethernet and others USB to PC: enable, or disable Wireless Manager: Power control to advanced network...
  • Page 30 Screen: Control display Summit: Access SCU to control WLAN orientation type, align screen, settings font setting to Clear Type and change text size, Task Manager: Stop running programs and processes Personal Buttons: Setting Hot key and Owner Information: Input customize Up/Down control. terminal owner information This function needs to set up with registry...

  • Page 31: Leds

    LEDs LED indicates status of the terminal in power sourcing, data capture, network connection Location of the 5 Status LEDs Charging LED Modem LED Data Capture Status LED Modifier LED Modifier LED LED Appearance upon terminal feature Feature Color Description Data capture status LED Blue Good read barcode, or RFID...

  • Page 32: Keypad

    Keypad 5 series comes with large numeric keypad including function 1~10, full alphanumeric keypad Full Alphanumeric (54 Key) Numeric (34 Key) Enter characters on Numeric Keypad Following explains how to make continuous character input. For single character input, please refer Key Strokes.

  • Page 33: Enter Characters On Full Alphanumeric Keypad

    Input upper character continuously Press twice Press twice, then shall be displayed right bottom of the screen. Toggle key one to four times depending on the position of the alphabet. Press one time to return lower character Press one time to return to numeric input For example type DEF Press...

  • Page 34: Enter Characters Using Sip (Soft Input Panel)

    Input Alphabet Default input is lower alphabet character In case single Alphabet character input, press then press a Alphabet In case continuous Alphabet character input, press twice then press Alphabet keys For Example Input A1a2 Press Note When you press key 1 time, it is effective only 1 time.

  • Page 35: Adjust Volume

    function lets you to switch back and forth to the brightness you have configured. Press dimmed brightness, and press again the button to back to the brighter display. Adjust Volume Press twice amber green modifier then configure level of your sound volume pressing volume up ( )and button to volume down (...

  • Page 36: Aim 1D Laser Scanner Window To Barcode

    2. Aim barcode scanner window exit to barcodes Aim 1D Laser Scanner window to barcode 1D laser scanner aiming angle recommendation  1D Laser scanner module: SE955, SE965, SE1524  Note Upon scanner module specification, decodable barcode density and reading distance is different. Also, too sharp scanning angle from barcode may make to blind the scanner from poor collection of scattered beam reflection.

  • Page 37: Scanner Module Types

    3. Press scan button, or trigger and see scanner beam is generating. When scanner read barcode in success, scan indicator notify you with sound, vibration and LED Scanner Module Types Scanner Type Scanner Module Barcode Type Remarks Laser Scanner SE955 1D barcodes Standard range.

  • Page 38: Scanner Specifications

    Vibration Vibration Vibration in scan success Hearing aid, useful to noisy and vehicle condition To setting, refer barcode tray Scanner Specifications 1D Laser Specifications (SE955/ SE96X/SE1524 Specifications) Scan Engine SE955 SE96X SE1524 Scan Angle 47° ± 3° 47° (Typical) 13.5° ± 0.7° Note This scan engine does not require margin on either...
  • Page 39 SE955 Decode Zone 4mil 2.54cm – 13.97cm 5mil 3.18cm – 20.32cm 7.5mil 3.81cm – 33.66cm 10mil 3.81cm – 44.45cm UPC 100% 3.81cm – 59.69cm 15mil 3.81cm – 74.93cm 20mil 4.45cm – 90.17cm 40mil *~40cm - * ~101.6cm 55mil *~55cm - * ~139.7cm * dependent on width of barcode...
  • Page 40 SE96X Decode Zone SE96X Decode Distance at Adaptive Mode Density/ Barcode Typical Working Range Barcode type Content/ Near W-N Ratio Contrast 5.0mil 1234 3.05cm 19.56cm Code 128 80% MRD 5.0mil ABCDEFGH 3.05cm 31.75cm Code 39; 2:5:1 80% MRD 7.5mil ABCDEF 2.79cm 46.99cm...
  • Page 41 Code 39; 2:5:1 80% MRD 10mil 1234 3.05cm* 48.26cm Code 128 80% MRD 13mil 12345678905 4.06cm 68.58cm 100% UPC 90% MRD 15mil 1234 2.54cm* 74.93cm Code 128 80% MRD 20mil 3.56cm* 132.08cm Code 39; 2.2:1 80% MRD 55mil* 8.64cm* 254.00cm Code 39;...
  • Page 42 SE955 Decode Zone Density/ Barcode Barcode Contrast Typical Working Range type W-N Ratio Near 7.5mil 80% MRD 5.08cm 55.88cm Code 39; 2.5:1 10mil 80% MRD 10.16cm 86.36cm Code 39; 2:5:1 15mil 80% MRD 12.7cm 180.34cm Code 39; 2:5:1 20mil 80% MRD 12.7cm 243.84cm Code 39;...
  • Page 43 Operational Input Voltage 3.0VDC to 6.0 VDC (23°C) 3.0 VDC to 5.5 VDC (23°C) Current Draw Max 100 mA, Standby Current 100 μA Operating Temperature -30°C to 50°C 5100/ 5300 Decode Zone Symbol Near 8.3mil 8.9cm 19.3cm Linear 10mil 7.9cm 22.9cm PDF417 13mil...
  • Page 44 Post, Canadian Post, Japanese Post, Netherlands (KIX) Post, Postnet, Planet code, OCR-A, OCR-B, E13B (MICR) Dimensions (mm) 12.5 D x 20.8 W x 17.2 H Operational Input Voltage 3.3VDC ± 5%to 6.0 VDC Current Draw 276 mA; Sleep 90μA 228 mA; Sleep 90 μA Operating Temperature -25°C to 50°C MTBF...

  • Page 45: Camera

    Camera This section explains how to use the camera on your terminal. You can take photographs and shoot video by using the built-in camera functionality. Your 5 megapixel camera products photos in JPG and BMP format, and videos in ASF format. Note series may vary upon your order configuration.

  • Page 46: Camera Options

    Camera Options Options are represented as below Icon Feature Description Allow you to take a photo in various modes. Tap the icon Camera mode to switch feature Allows you to take video. Tap to switch Camcorder Camcorder mode mode Allows you to set the flash options to Off, On, or Auto Flash flash ·...

  • Page 47: Wireless Manager

    Allows you to access Image viewer. The photo you took, will be displayed as a thumbnail in the image viewer icon. Double click a thumbnail to view the photo. Album Press navigation key board to zoom in ( ) and out ), or to move next photos To return Camera mode, press...

  • Page 48: Wi-Fi Setting

    Switch Status WiFi Bluetooth Phone Not Supported Power on Power off Wi-Fi Setting Power on WiFi power at Wireless Manager Open Summit Client Utility Configure your WLAN When you power on WiFi, following WiFi signal will be displayed at your task tray and task bar. Windows CE6.0 Windows Embedded Handheld 6.5 Radio Signal Strength...
  • Page 49 The RSSI for the current AP is stronger than -70 dBm but not stronger than -50 dBm, which means that a Summit radio should operate consistently at 54 Mbps The RSSI for the current AP is stronger than -50 dBm Configuration WLAN –...
  • Page 50 Status: Indicates if the radio is associated to an AP and, if not, indicates the radio’s current  status. Potential values include: Down (not recognized), Disabled, Not Associated, Associated, or EAP type authenticated. Radio Type- Indicates the terminal’s radio type including: ...
  • Page 51 Profile The profile settings are radio and security settings that are stored in the registry as part of configuration profile. When a profile is selected as the Active Profile on the Main tab, the setting for that profile become active. You can define up to 20 profiles. Profile changes are not saved to the profile until you click Commit Edit Profile –...
  • Page 52 Security – Values for the two primary security attributes, EAP type and encryption type, are  displayed in separate drop-down lists with the current the current values highlighted. Only an administrator can edit these security settings. Encryption – When the administrator selects and encryption type that requires the definition ...
  • Page 53 rates in megabits per second (Mbps): 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54. - Default: Auto Radio Mode – Use of 802.11 a, 802.11g, 802.11b, and 802.11n frequencies and data rates  when interacting with AP, or use of ad hoc mode to associate to a client radio instead of an When SCU operates with a Summit 802.11g radio, an administrator can select from among the following Radio Mode values: - Value:...
  • Page 54 Third Party Config ThirdPartyConfig Windows If you choose to configure , the will work with the operating system’s Zero Config (WZC) to configure radio and security settings for the radio installed in the unit. profile Choosing this means that must be used to define the following radio and security SSID Auth Type EAP Type...
  • Page 55 The following functions are available from the Diags window: (Re)connect – Disable and enable the radio, apply or reapply the current profile, and attempt  to associate and authenticate to the wireless LAN, logging all activity in the output area at the bottom.
  • Page 56 When Roam Trigger is met, a second AP’s Roam Delta 5, 10, 15, 20, 25, 30, 15 dBm signal strength (RSSI) must be Roam Delta 35, or Custom dBm stronger than moving average RSSI for current AP before radio will attempt to roam to the second AP Roam Period After association or roam scan (with no...
  • Page 57 the standard scanning that is configured through the Roam Delta, and Roam Period settings. Summit recommends that the Aggressive Scan global setting be On unless there is significant co-channel interference because of overlapping coverage from APs that are on the same channel CCX features Use of Cisco information element (IE) and Full: Use Cisco IE and...
  • Page 58 Authentication method used within secure TTLS Inner Method Auto-EAP – Any Auto-EAP tunnel created by EAP-TTLS available EAP method MSCHAPV2 MSCHAP CHAP EAP-MSCHAPV2 When WPA2 is in use, type of Pairwise PMK Caching Standard or OPMK Standard Master Key (PMK) caching to use When switching from Standard to OPMK, you must initiate a suspend...
  • Page 59 If packet size (in bytes) exceeds threshold, Frag Thresh An integer from 256 to 2346 then packet is fragmented. 2346 RTS Thresh Packet size above which RTS/CTS is required An integer from o to 2347 on link. 2347 Use of LED; DS5 is not supporting this On, Off feature Enabling of System Tray Icon.
  • Page 60 Wi-Fi Roaming Summit provides two complementary sets of roaming algorithms to provide for more reliable connectivity. Those sets of algorithms are; Standard: which manages roaming behavior under typical conditions. Users can adjust Standard Roaming parameters to customize roaming behavior for a particular environment. Aggressive: which manages roaming behavior when the station device is in areas of particularly low coverage and is in imminent jeopardy of losing its connection to the network infrastructure.
  • Page 61 The administrator can configure three parameters for the standard roaming algorithm: Roaming Trigger: Roam trigger indicates the signal strength (RSSI) (in dBm) at which the radio scans for an access point with a better signal strength. When scanning for a different access point, the radio looks for one with a RSSI at the indicated roam delta dBm level or stronger.

  • Page 62: Bluetooth Setting

    Bluetooth Setting Caution The open COM port at DS5 is COM6, COM9 At Windows CE6.0, it assigns COM6 first. If COM6 is pre-assigned, then it try to assign to COM9. At WEH 6.5, it is selectable one of COM port between COM6 and COM9 Windows CE6.0 1.
  • Page 63 4. Select your Bluetooth device and double click the device name 5. Select Trusted to open PIN input window...
  • Page 64 6. Enter your PIN number 7. After your PIN number validation, double click the Bluetooth name. then select Active Your COM information will be displayed after success...
  • Page 65 WEH6.5 1. Power on Bluetooth module. (Go to Wireless Manager to turn on Bluetooth) 2. Click Menu at bottom of display and select Bluetooth Settings 3. Select Add new device to scan Bluetooth around the terminal...
  • Page 66 4. Select your Bluetooth device. Then press next at bottom of display menu 5. Enter Passcode to secure your connection 6. When your device added, press Done at bottom of display menu...
  • Page 67 7. Assign a COMPORT. Click your Bluetooth device name 8. Select Serial Port as picture, and select Save at bottom of display menu Caution In case you don’t select Serial Port at this stage, you will have error when you delete the Bluetooth profile.
  • Page 68 10. Select Next at bottom of display menu 11. Select appropriate COM Port, which is not assigned. Then select Finish 12. Select OK...

  • Page 69: Bluetooth Setting Trouble

    Bluetooth setting trouble In any case you delete the assigned Bluetooth device and have to reassign SAME, or different Bluetooth device, please follow below delete and reassign comport process. Windows Mobile 6.5 is keeping the last registry record, and it interferes reassigning the Bluetooth device to the same port. Microsoft Windows Mobile 6.5 recommends step 8 “Select services to use from this device”...
  • Page 70 3. Set COMPORT again. 4. When you delete the assigned COMPORT, then it shall be deleted all information including recorded registry.

  • Page 71: Appendix Ⅰ Key Strokes

    Appendix Ⅰ Key Strokes 5 series inter-changeable different types of keyboards in simple manual way. Following tables are how to make key character entry using keypads. Characters are not mentioned at this key stroke sequence, it is also available in Soft Input Panel (SIP) 38-key Descriptions 54-key Descriptions...

  • Page 72: And Wide 54 Key Description

    Control It is modifier key which, when pressed in conjunction with another key, performs a special operation, for example Ctrl+C. similar to the Shift key. Pressing Blue modifier key, the function change to Alt key Space/ Back Space Space: its main purpose is to conveniently enter a space. Back Space: it moves the display cursor one position backwards, delete the character at that position.

  • Page 73: And Wide Alphanumeric Characters

    Page Up/Down Moves page, or items lists up and down. With blue modifier, it can adjust volume level Numeric Input numeric. Execute preset function, or application by your IT desk, press blue modifier for F1~F10 and orange modifier for F11 ~ F20 Alphabet Input alphabet.

  • Page 75: Ds5 And Ds5 Wide Special Functions

    5 and 5 wide Special Functions Character Numeric Keypad Full Alpha Numeric Keypad · Decimal/Full stop Plus Hyphen/Minus Asterisk Slash(Punctuatio Number Sign...
  • Page 76 Start Menu Equals < Less-than > Greater-than Colon Semicolon Comma Question Dollar Percent Caret & Ampersand ‘ Apostrophe “ Quotation Parentheses Parentheses Vertical bar...
  • Page 77 Tilde Exclamation...

  • Page 80: Sdk

    Windows CE6.0: Please download from below link. https://www.dropbox.com/s/0mdz2s9upula5d9/DS5_SDK.msi WEH6.5: DS5 uses Microsoft providing SDK. To use DTK (Developer Tool Kit), please install SDK (Software Development Kits) first. WEH 6.5 SDK & DTK Windows Mobile 6 Professional and Standard Software Development Kits Refresh http://www.microsoft.com/download/en/details.aspx?id=6135 Windows Mobile 6 Localized Emulator Images http://www.microsoft.com/download/en/details.aspx?id=7974...

  • Page 81: Reset Type

    3. [DELETEFILE] 4. [SHORTCUT] 5. [EXECUTE] Reset Type Below is type of reset and the device behaviors Reset Type Behavior Remarks ResetType=0 Applicable when all booting ResetType=1 Applicable when factory reset, Clean boot ResetType=2 Applicable when Warm boot ResetType=3 Applicable when Cold boot Only Windows CE6.0 ResetType=4 Applicable when Factory reset, Clean boot,...
  • Page 82 Setting File delete [DELETEFILE] DeleteFile=\Nand\aaa.txt Setting Short cut [SHORTCUT] ResetType=0 FileName=\NAND\MBApp\MB_BarcodeTray.exe DestPath=\Windows\Desktop\Shortcut to MB_BarcodeTray Setting exe file EXECUTE] ResetType=2 FileName=\Nand\MBApp\MB_BarcodeTray.exe Argment=\ Installing Cab file [EXECUTE] ResetType=4 FileName=\Windows\wceload.exe Argment=/noaskdest /noui /delete 0 \Nand\Install.CAB Wi-Fi power control (on) [REGISTRY] ResetType=1 [HKEY_LOCAL_MACHINE\DSIC\WirelessPower] "WLANPower"=dword:1 Wi-Fi profile setting [WLAN] ResetType=1...

  • Page 83: Os Update

    RadioMode=6 ********** PSKKey= ; Input password in case your WepType is WPA_PSK, or WPA2_PSK ********** WEPKEY= ; Input password, in case your Wep Type is WEP [REGISTRY] ResetType=1 [HKEY_LOCAL_MACHINE\Comm\SDCCF10G1\Parms\Configs] "ActiveConfig"=dword:1 "NumConfigs"=dword:1 [REGISTRY] ResetType=1 [HKEY_LOCAL_MACHINE\Comm\SDCCF10G1\Parms\Configs\GlobalConfig] "autoProfile"=dword:0 OS Update OS Update with SD Card Caution When you use OS update with micro SD card, please make sure the card is formatted, and battery is fully charged.
  • Page 84 3. While Pressing and holding together, short press RESET key for a second to enter below screen 4. When image.bin file is copied and installed in complete, below image will be displayed at your screen. 5. After DONE message like in above, press RESET button to enter Clean Boot 6.

  • Page 85: Os Update By Pc: Udm (Usb Download Manager)

    OS Update by PC: UDM (USB Download Manager) When you use OS update by PC, please run UDM program, after your proper PC setting installing driver. DS5 single cradle, driver setting to your PC, and UDM program installation on your PC is required. Necessary Utility Program Download https://www.dropbox.com/s/ndbxya2kj8ee3mf/UDM_v1001_20140411.zip?dl=0 1.
  • Page 86 PC Setting (Windows 7) 4. Select proper driver exe file as your PC version Win7 – 32bit: installer_x86.exe Win7 – 64bit: installer_x64.exe 5. Select the Install from a list or specific location (Advanced) option and click on Next...
  • Page 87 6. Select Don’t Search. I will chose the driver to install and click Next 7. Select the Have Disk……and click on Browse...
  • Page 88 8. Select USBDriver folder 9. Install driver SEC S5PC110 Test B/D and click Next...
  • Page 89 10. Take off your device from cradle and reinstall on your cradle. You can see the loaded drivers as below.
  • Page 90 How to use UDM program 1. Execute udm_v1001.exe file. Binary window to download will be pop up as below 2. Select DS5 OS file. It is binary format (.bin)

  • Page 91: Wi-Fi Connection Through Scu (Summit Client Utility)

    3. USB connect your device to PC. Device should be in update mode. Your device will start OS update automatically. 4. Check progress bar processing. Disconnect your device when your device shows Done message 5. When you OS update to multiple devices, simply reconnect different devices in update mode to the cradle with the same PC window program.
  • Page 92 Click Profile tab to set your Wi-Fi Click Scan to search Wi-Fi SSID around your device. If your AP’s SSID is in hidden mode, you are not able to see and you need to input manually. Select your SSID, and click Configure...
  • Page 93 Select Yes to save your SSID. This process to save your SSID to the device not to re-input the SSID on your device. Input your network password. Then OK. Press Commit. Go to Main tab to select your saved profile.
  • Page 94 Select your profile at Active Profile * Microsoft Zero Config is not in active when you use SCU On Windows CE6.0 or WEH6.5, Summit software includes a service that displays an icon in the Windows System Tray. This icon provides a visual status for the Summit radio in the device and it provides access to the SCU application.

  • Page 95: Remote Desktop Connection

    When the service is active, it queries the radio every three seconds for connection status. Based on the radio's response to the query, the service displays one of the following icons: Table: SCU Tray Icons The radio is not associated/authenticated to an AP. The signal strength (RSSI) for the current AP (to which the radio is associated) is -90 dBm or weaker, which means that a Summit 802.11b/g radio will operate at 802.11b data rates only.
  • Page 96 3. Select Local Resources tab. and select On the local computer at Keyboard menu. Then press key. Caution Enter key must be used in PDA keypad 4. Input your credentials to connect the local computer, then click OK...

  • Page 97: Weh6.5

    5. Your device will be connected to the local computer WEH6.5 1. Click Start , scroll down screen and click Remote Desktop Mobile...
  • Page 98 2. Input your local computer information Caution In case you don’t input necessary information, you will see below log in screen to require information.
  • Page 99 3. Your local screen will be displayed at the device...

  • Page 100: Key Map (34 Key & 54 Key)

    APT5 Key map (34 Key & 54 key) CE6.0 & WEH6.5 Common...

  • Page 101: Gprs Connection

    GPRS Connection Before you programming GPRS, you may need following 2 files. cmsample.zip : Reference project to make sample ConnectionManager_Sample_CSharp.zip: A sample referred from above file Download files at below link https://www.dropbox.com/sh/hdxre34npe6zraj/AABvfEB-AzDK6Vg89_MCO3Yqa Caution Before use the program, Beside the phone modem, turn off all your wireless radios ...
  • Page 102 3. Click “Add a new modem connection” 4. Set your name at Enter a name for the connection. Select Cellular Line (GPRS). Then press Next 5. Check APN address with your Telecom operator to fill in Access point name. Click Next 6.

  • Page 103: Using Connection Manager Sample

    Using Connection Manager Sample 1. Select MY ISP at combo box 2. Select Connect...

  • Page 104: Barcode Tray

    3. If GPRS is connecting properly, you will see the screen as below 4. If you want to disconnect GPRS, press Disconnect button Barcode Tray DS5 and DS5 wide uses same Barcode tray regardless operation system in Windows CE 6.0 and WEH 6.5.
  • Page 105 Scan Detail It is test function barcode scanning is operating properly. It shows; - Type: Type of barcode - Info: Contents in barcode Time(Sec): Time to scanning Barcode Setup (Enabling tab) Setting to able, or disable bar type to read barcode, or factory default barcode tray Enabling barcode types on Factory default - Code39, Code128, Interleaved2of5, UPCA, UPCE0, EAN13, EAN128, EAN8...
  • Page 106 Barcode Setup (Detailed tab) Setting option by barcode types such as length, change, or check sum Scan Option (Option tab) - Setting Time out, Transfer Method, Prefix/ Suffix, Timeout: Setting barcode beam lighting interval per pressing a scanning button TransMethod : Barcode value transfer method.
  • Page 107 Scan Option (Key tab) Scan Stop: When scan button getting up after pressing the button, barcode beam is out. Un-checking Scan Stop: Scanner beam out after user set time out Scan Option (Sound tab) Setting notification when scan success or fail. FileFind: setting user proprietary scanning sound...

  • Page 108: <2D Imager

    <2D Imager> Image Memu lists Details Scan Detail View to detailed barcodes Barcode Setup Setting by barcode types Scan Option Scanning setting Image Capture Imaging Capture INFO Barcode Tray version information Closing barcode tray program Scan Detail It is test function barcode scanning is operating properly. It shows; - Type: Type of barcode - Info: Contents in barcode - Time(Sec): Time to scanning...
  • Page 109 Barcode Setup (Detail tab) Setting option by barcode types such as length, change, or check sum Caution: Barcode option change may change result value, or barcode type in some case Scan Option (Option tab) - Setting Time out, Prefix/ Suffix, Transfer Method Timeout : Setting barcode beam lighting interval per pressing a scanning button TransMethod...
  • Page 110 Caution Transmethod “Clipboard” is not supporting Prefix, or suffix option. Required Prefix/ Suffix enabling application version from Windows CE Windows Mobile Scanner Type Tray Version 1.0.0.11 3.0.2.5 DLL version 2.0.1.9 2.0.0.19 3.0.2.5 3.0.0.14 Example) Applying “Ctrl+F” in prefix 1. Check your Barcode Tray and Scanner DLL is higher than Required Prefix/ Suffix enabling application version described above...
  • Page 111 2. Select “DC1” at 1 Char, and “F” at 2 Char in Prefix 3. ASCII Table HTML Char Description Number &#000; Null char &#001; Start of Heading &#002; Start of Text &#003; End of Text &#004; End of Transmission &#005; Enquiry &#006;...
  • Page 112 &#025; End of Medium &#026; Substitute &#027; Escape &#028; File Separator &#029; Group Separator &#030; Record Separator &#031; Unit Separator &#32; Space &#33; Exclamation mark " &#34; Double quotes (or speech marks) &#35; Number &#36; Dollar &#37; Procenttecken & &#38; Ampersand &#39;...
  • Page 113 &#63; Question mark &#64; At symbol &#65; Uppercase A &#66; Uppercase B &#67; Uppercase C &#68; Uppercase D &#69; Uppercase E &#70; Uppercase F &#71; Uppercase G &#72; Uppercase H &#73; Uppercase I &#74; Uppercase J &#75; Uppercase K &#76; Uppercase L &#77;...
  • Page 114 &#103; Lowercase g &#104; Lowercase h &#105; Lowercase i &#106; Lowercase j &#107; Lowercase k &#108; Lowercase l &#109; Lowercase m &#110; Lowercase n &#111; Lowercase o &#112; Lowercase p &#113; Lowercase q &#114; Lowercase r &#115; Lowercase s &#116; Lowercase t &#117;...

  • Page 115: Barcode Scanner Center Aiming (N560X Sr/ Hd)

    Scan Stop: When scan button getting up after pressing the button, barcode beam is out. Un-checking Scan Stop: Scanner beam out after user set time out Multi Scan : This is special feature at 2D barcode function. It is enabling to read continuous barcode scanning.
  • Page 116 1. Close (End) Barcode Tray program on your device. 2. Execute DS_Barcode2DADDOPTIONS program and Check Enable When it is not checked, Left:0, Right: 100, Top:0, Bottom: 100 as default. 3. Press Apply. Your setting will be saved in BarcodeGEN6Added.dat file...

  • Page 117: 1D Barcode Api

    Barcode API APT5 and APT5 wide use same Barcode tray regardless operation system in Windows CE 6.0 and WEH 6.5. However barcode API is different between 1D, and 2D, and Windows CE 6.0 and WEH6.5 1D Barcode API 2D Barcode API Windows https://www.dropbox.com/sh/pir1vr2kxkk https://www.dropbox.com/sh/dj1w0fbt...

  • Page 118: Uhf Rfid

    UHF RFID APT5 wide (4.3inch screen option) supports UHF RFID in connection with UHF Gun. It detailed programming source and application will be updated soon. UHF GUN Specification Contents Description Built in Camera 5M Pixel Auto focusing with Flash Protocol EPC Gen2 (ISO18000-6C) Frequency 860Mhz ~ 960Mhz...

  • Page 119: Appcenter - Device Lock Down Or App Locker

    UHF SDK (DS5 4.3inch version) Download UHF SDK from below link as per your operating system. [DS_UHF Demo] folder includes UHF Demo. Exe files and necessary dll files. Please copy the folder, and paste under Nand\DSICApp\ folder of your device. DS_UHFDemo.exe is execution file.
  • Page 120 User Mode It shows limited lists of program that end user can interact with the device. If text file, or image file is selected at this mode, it runs the files with default set programs. Admin Mode Select Menu at left bottom of your screen to enter ADMIN...
  • Page 121 Enter password. Initial password is 0000 Admin Mode Menu...
  • Page 122 ADD PROGRAMS This is to add user accessible program add, or delete. CHANGE Password This is to change password USER MODE This is mode change from ADMIN to USER EXIT Close program...

  • Page 123: Telnet Emulator - 3 Rd Party Solution

    Telnet Emulator – 3 Party Solution TTWin CE TTWin CE is Turbosoft’s terminal emulation solution for handhelds, Windows CE 5.0 and above , and WEH6.5 devices. Features Host Connectivity: Allows for a direct connection from the CE device or Windows based terminal to the host system Proven Technology: The Terminal Emulations that are available in TTWinCE are the most reliable and accurate on the market.

  • Page 124: Gps Connection Tool

    Colour configuration: Full colour configuration. Select from preconfigured colour sets or define your own for better readability Configuration password: Administrators can prevent users from accessing or changing device configuration. Minimizes support by eliminating unauthorized changes Device application lockdown: TTWinCE can be configured to run in full screen mode, utilising the entire display screen area and preventing the user from accessing other applications.

  • Page 126: Related Files And Link

    Related Files and Link Program Files Windows CE6.0 Windows CE 6.0 SDK https://www.dropbox.com/s/0mdz2s9upula5d9/DS5_SDK.msi Barcode API (1D) https://www.dropbox.com/sh/pir1vr2kxkkh80c/AAAwBHsS7U4MozZ4CRdGJzSza Barcode API (2D) https://www.dropbox.com/sh/dj1w0fbt67tsg40/AADuZHY82pR-yrnmtVhQYlBDa Camera API https://www.dropbox.com/sh/11z3cymhz01662r/AABmMj2PSi9SFICs7R2ksChNa Telnet Emulator Trial https://www.dropbox.com/sh/tfu445lit86vmn7/AADI14j-MvCPZ1ibDgAKaxpqa?dl=0 UHF API https://www.dropbox.com/sh/uiplxz4esrparcy/AAAFB4Ro43pqj0tui7DzJBvda?dl=0 OS Update by PC Program (UDM) https://www.dropbox.com/s/ndbxya2kj8ee3mf/UDM_v1001_20140411.zip?dl=0 WEH 6.5 GPRS Connection https://www.dropbox.com/sh/hdxre34npe6zraj/AABvfEB-AzDK6Vg89_MCO3Yqa Ping test program...
