Configuring 1G Traffic on 8-port 10 Gigabit
Ethernet Interface Module
The 8-port 10 Gigabit Ethernet Interface Module (8X10GE) has eight ports and is supported on the Cisco
ASR 900 RSP3 module. Prior to Cisco IOS XE Everest 16.5.1, 1G traffic support was provided only with the
devices placed in the access layer. Effective Cisco IOS XE Everest 16.5.1, 1G traffic support is also provided
with the devices in the distribution layer and that support both 1G and 10G traffic. Thus, all the eight ports
can now work in 1G mode as well as 10G mode.
The configuration of 1G Traffic on 8X10GE IM provides cost-effective solution during migration from 1G
mode to 10G mode as a single device can support both the modes. The feature is supported on Cisco ASR
900 RSP3 module.
Note
By default, the 8X10GE IM comes up in the 10G mode after reboot.
•
•
•
•
Restrictions for 1G Mode Support on 8-port 10 Gigabit Ethernet
Interface Module
• SFP+ is not supported on 1G mode, but the physical link with SFP+ in 1G mode comes up.
• Support of 1G mode on a port and 10G mode on another port in the same interface module is not supported.
• Precision Time Protocol (PTP) is not supported.
• Sync-E is not supported.
• Port channel bundling on 1G mode is not supported.
• Although 1G mode is supported on the interface module, the interface is displayed as "Te0/X/Y" depending
Restrictions for 1G Mode Support on 8-port 10 Gigabit Ethernet Interface Module, on page 1
Configuring 1G Mode, on page 2
Configuring 10G Mode from 1G Mode, on page 3
Associated Commands, on page 4
on the port numbers for both 1G and 10G modes.
Configuring 1G Traffic on 8-port 10 Gigabit Ethernet Interface Module
1
