- Page 1 BEDIENUNGSANLEITUNG MANUAL CORTEX...
-
Page 2: Table Of Contents
CO N T E NT pRELiMiNARy iNfORMATiON Operating principle and features MOUNTiNg Connecting receiver Connecting servos Mounting the CORTEX COMMissiONiNg Setup Flight operation Gyro channel / activating gyros Gyro directional test Test flight / setup flight Using gyro modes MisCELLANEOUs... -
Page 3: Operating Principle And Features
01 OpERATiNg pRiNCipLE ANd fEATUREs The CORTEX can stabilize all three flight axes using its 3-axis gyro sensor: aileron, elevator and rudder. The approved cutting edge technology of the HeliCommand/ bavarianDEMON X-series is applied here and has been effectively modified to fit fix wing aircrafts, totally independent of the airplane’s size and weight. -
Page 4: Mounting
Conventional receivers via single channels: Disconnect all servos that need to be stabilized from the receiver and connect them to the CORTEX’s output channels. Then connect the required cables A-E of the supplied cable harness to the corresponding receiver outputs where the servos were previously connected (see Section 3 for details about connection). -
Page 5: Connecting Servos
PC software for serial receiver connection. ( ! ) Even if the servos are running correctly: do not fly before setup of the CORTEX and gyration directional test is complete. Incorrect gyro effect would certainly result in a crash! 04 MOUNTiNg ThE CORTEX It is crucial that the installation position shown here is followed. -
Page 6: Commissioning
05 sETUp ( ! ) For setup, the transmitter must already be programmed ready for flight, so that the model can be flown or is already flying without CORTEX. Servo directions, possible mixers, throws etc., as well as correct trim settings for normal flight must already be set up correctly. -
Page 7: Flight Operation
06 fLighT OpERATiON Start the CORTEX in normal operation without the connected jumper. The LED flashes red for the first seconds and indicates the system’s initialization. The model must not be moved during initialization. Otherwise, the stabilization remains inactive (device flashes red permanently) until power-cycled. -
Page 8: Gyro Channel / Activating Gyros
08 gyRO ChANNEL / ACTivATiNg gyROs For the first flight and in-flight tuning, it should be possible to adjust the gyro channel and therefore gyro sensitivity in flight. It is therefore possible to find the optimum quickly, or reduce it immediately if needed, e.g. when sensitivity is too high. Check the function of the gyro channel by adjusting the modes/bench via the transmitter and comparing the LED‘s colour reaction. -
Page 9: Using Gyro Modes
11 UsiNg gyRO MOdEs The table of the gyro channel (Section 8) indicates various options. Caution: this only applies to factory programming for bench 1 and bench 2 (standard or default, i.e. without PC software). Via PC software it is possible to re-program the functions for each of the 3 gyros separately. If the transmitter has a flight condition switch, it may make sense to couple the gyro channel setting with various flight conditions. -
Page 10: Miscellaneous
Mi s C E L L AN E O Us 12 ACCEssORiEs Foam tape Acro (3 pcs) No. 92769 Foam tape Soft (3 pcs) No. 92770 Cable loom L90 (90mm) No. 92771 Cable loom L150 (150mm) No. 92772 Cable loom L250 (250mm) No. - Page 11 VERSION 1.1 LEGAL DETAILS CAPTRON Electronic GmbH Johann-G.-Gutenberg Str. 7 82140 Olching Fon +49 8142 4488 -0 Fax +49 8142 4488 -100 SERVICE AND REQUESTS Visit our website www.bavarianDEMON.com for dealers and contact information. Hiermit erklärt die CAPTRON Electronic GmbH, dass sich dieses Gerät in Übereinstimmung mit den grundlegenden Anforderungen und anderen relevanten Vorschriften der entsprechenden CE Richtlinien befindet.
