AETA Scoopy+ S User Manual

Mono/stereo portable audio codec for real time transmission over isdn/pots/mobile/ip
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Mono/stereo portable audio codec for real time
transmission over ISDN / POTS / MOBILE / IP

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Scoopy+ S and is the answer not in the manual?

Questions and answers

Related Manuals for AETA Scoopy+ S

Summary of Contents for AETA Scoopy+ S

  • Page 1: User Manual

    Mono/stereo portable audio codec for real time transmission over ISDN / POTS / MOBILE / IP User Manual...

  • Page 3: Table Of Contents

    Table of contents 1. Presentation – Getting started ................1 1.1. Install and connect S + S......................3 COOPY 1.2. Audio settings ............................. 3 1.3. Select and set up network to be used: wired networks ..............3 1.3.1. Set up an ISDN link ........................3 1.3.2.
  • Page 4 2.5.6. Configuration and dialling memories ..................32 2.5.7. Test functions ........................... 32 3. Operation ....................... 33 3.1. General principles – Control means ....................33 3.2. Physical description of the equipment .................... 34 3.2.1. Front panel ..........................34 3.2.2. Rear panel: transmission interfaces ..................38 3.2.3.
  • Page 5 4.7.1. Recording ..........................81 4.7.2. Playing back ..........................82 4.7.3. Simple editing ........................... 83 4.7.4. Management of recordings ...................... 84 4.8. Restricted operation mode ......................85 4.8.1. Principles ..........................85 4.8.2. Locking the front panel ......................85 4.8.3. Unlocking the front panel ......................85 4.8.4.
  • Page 6 6.1.2. Step 2: open the remote session .................... 106 6.2. Using the remote html access ....................... 107 6.2.1. Step 1: connect the S + S to the server ................107 COOPY 6.2.2. Step 2: open the remote session .................... 107 6.3.

  • Page 7: Presentation - Getting Started

     One outstanding feature of AETA codecs in ISDN mode is the 5A System : on receiving an incoming ISDN call, the unit can automatically detect the coding algorithm and parameters of the calling codec, and then adjust itself in a compatible configuration so that the connection succeeds regardless of the initial configuration and that of the remote unit.
  • Page 8 Characteristics Optional Operation modes Single wide band codec  Single codec and coordination using a mobile voice link (with HD-4G option) IP transmission interface Ethernet Interface, 10BaseT / 100BaseT; TCP/IP, UDP/IP, RTP protocols Audio transmission in unicast mode: SIP signalling protocol, SDP, RTP streaming Audio transmission in multicast mode: RTP streaming Net bit rate 16 to 256 kbit/s (depending on coding algorithm, linear coding excluded) ...

  • Page 9: Install And Connect Scoopy + S

    1.1. Install and connect S COOPY  Plug on a power source or insert 6 C-size batteries.  Switch on S + S by holding down for 3 seconds. (And hold down for 3 seconds to COOPY switch off)  Connect the necessary audio interfaces (details: page 20) ...

  • Page 10: Set Up A (Wired) Ip Link

    COOPY Setup Network AoIP Parameter STUN Server, enter the address of a STUN server (we propose our server stun.aeta-audio.com, look also the support pages on our web site www.aeta- Setup Network AoIP Parameter STUN Mode (On audio.com). Enable or disable STUN with or Off).

  • Page 11: Select And Set Up Network To Be Used: Mobile Networks

    1.4. Select and set up network to be used: mobile networks To set links over a mobile network, you must have a SIM card with a subscription suitable for the use. Specifically, for an IP mode transmission the subscription must include access to data transmission, and RTP audio streams must be allowed.

  • Page 12: Set Up A (Mobile) Ip Link

    COOPY Setup Network AoIP Parameters STUN Server, enter the address of a STUN server (we propose our server stun.aeta-audio.com, look also the support pages on our web site www.aeta- Setup Network AoIP Parameter STUN Mode (On audio.com). Enable or disable STUN with or Off).

  • Page 13: Functions

    2. Functions The following synoptic diagram shows the basic functions of the equipment. Control Interfaces Audio Input Encoding Inputs processing Routing Audio Transmission Network Supervision Monitoring monitoring Interfaces Mixing Audio Output Decoding Outputs processing Relays / GPIO Auxiliary Functions Figure 1 – Functional diagram of the equipment The audio signals to be transmitted are mixed and digitized, then the encoding function reduces the bit rate, using a selectable algorithm;...

  • Page 14: Transmission Interfaces

    2.1. Transmission interfaces The S + S features in all versions an Ethernet interface for IP protocol networks. COOPY An optional ISDN interface can be added, as well as optional PSTN/POTS and mobile network access interfaces. 2.1.1. Ethernet/IP interface The IP interface is a 10BaseT/100BaseT Ethernet interface allowing transmission of the audio programmes in a wide range of possible bit rates.
  • Page 15 Available audio coding algorithms The audio coding algorithm can be selected depending on the required quality and the available network bandwidth. The following algorithms are currently available: Codec Bit rate Bit rate Audio Typical use, main features bandwidth (coding) (total) 1 G711 64 kbit/s 86 kbit/s...
  • Page 16 "Factory" SIP account AETA has set up a public SIP server, dedicated to broadcast audio over IP applications. Our customers can subscribe accounts and register their codecs on this server.

  • Page 17: Isdn Interface

    5A stands for Aeta Audio Advanced Automatic Adjustment. This system makes it easier to set an ISDN connection, because the codec, on receiving a call, automatically adjusts itself, following the calling party algorithm and parameters.

  • Page 18: Pots Interface

    It must be noted that, thanks to the interoperation protocol, J52 codecs, when setting up a link, can negotiate automatically and agree on a configuration that is compatible with the capability of both units (regarding bit rate, channel mode, etc.). In this way, when the units differ in their capability (or make), the resulting configuration may be different from expected beforehand, but in most cases the link will work and audio will be transmitted.

  • Page 19: Mobile Network Access

    This sometimes makes people believe that HD Voice is related to the mobile IP service, but this is definitely not the case. More and more mobile phones now support this service, especially (but not only, and not all) smartphones. All AETA codecs in "Wireless" version support HD Voice, namely:  Scoop 4+ in "wireless" version ...

  • Page 20: Managing Calls

     This capability is optional.  The USB module must be from the list of devices supported by AETA. As this list is evolving, please check our web site for up to date information.  The "HD Voice" mode is not available in this way.

  • Page 21: Audio Encoding And Decoding

    2.2. Audio encoding and decoding + S features a wide range of coding algorithms. Their availability depends on the transmission COOPY network used. Besides, the MPEG family algorithms offer a great configuration flexibility. The table below synthetically describes the capabilities with the various transmission media: Frequency (kHz) Wired Mobile...

  • Page 22: G711 Coding

    2.2.1. G711 coding Application: telephony, coordination. Low latency. G711 is the standard coding used for voice transmission on public telephone networks, and features 300 to 3400 Hz audio bandwidth. This algorithm is typically used for links over IP networks with IP telephones or VoIP gateways.

  • Page 23: G722 Coding

    2.2.5. G722 coding Application: commentaries, coordination. Low latency. This mono coding algorithm at a 64 kbit/s bit rate is a reference for commentaries, and features a 50- 7000 Hz bandwidth. It is available, ISDN, IP networks (wired or mobile). For ISDN, three synchronisation modes are possible: ...

  • Page 24: Mpeg Audio Layer 2 Coding

    2.2.8. MPEG Audio Layer 2 coding Application: mono or stereo music, high quality. As shown on Table 3, this coding algorithm features a maximum flexibility, with many variations for bit rate, mono or stereo channel mode, sampling rates... The two channel modes exist in three variations: ...

  • Page 25: Opus Coding

    + S, without any audio noise or dropout. COOPY In addition, when the remote device is another AETA codec, it will automatically apply the same bit rate change to the stream it is transmitting. Opus coding is only available for IP networks, wired or mobile.

  • Page 26: Audio Interfaces And Functions

    2.3. Audio interfaces and functions The following diagram shows the main audio processing and mixing functions: M ix e r M ic p o w e r M ic /L in e 1 H P F F a d e r O n /O ff 8 0 d B L im...

  • Page 27: Line Outputs

    In mono operation, each input can be routed to the main program and/or the possible coordination line. In stereo mode, the input can be routed to left, right, or both. Input 3 can also be configured as "Sound Guide": in this case it is not included in the program mix (neither the coordination mix), but instead it is routed to the left ear of the headphone outputs, mixed with the other sources selected for monitoring.

  • Page 28: Recording/Playing Audio Files

    2.3.5. Recording/Playing audio files This feature is optional on the S + S. COOPY In mono operation, the S + S can record onto an SD card the mono "programme" signal. When COOPY transmitting, the Program feedback is also recorded on a second track. The recordings have following characteristics: ...
  • Page 29 The S + S has two main mixing buses. The diagram below shows the available mixing features on COOPY each bus: T x L P G M b u s (L ) P G M ( L ) T x R N e tw o rk P G M b u s R [C o o r d ] P G M R...
  • Page 30 The diagram below shows the routing for the audio outputs: PGM bus (L) PGM Mix Headphone Output Program FB (L) Monitoring (x2) matrix PGM bus R (x2) [Coord] PGM R Mix [Coord Mix] Program FB R [Coord FB] Switchable summing node Fixed MIC3 summing node...
  • Page 31 A monitoring matrix routes the signals to the left and right ears depending on the operation mode (mono, stereo, Program&Coord...) and the configuration selected by the user for each headphone. This routing is described in the table below. Besides, the MIC3 signal is inserted in the left ear if it has been configured as "Sound Guide".

  • Page 32: Audio Level Monitoring

    2.3.7. Audio level monitoring Audio peak level indicators (bargraphs) are available on the graphical display:  Left (and possibly right) level of the Program send (Tx L and Tx R bars).  Level of feedback signals (Rx L and Rx R bars): left of the, and right level of Program feedback or Coordination feedback (depending on current operation).

  • Page 33: Auxiliary Transmission Functions

    AARC protocol. This additional transmission exists only over ISDN and excludes INFO1/INFO2 exchanges).  These various features are only compatible with AETA products, because they are not inside the scope of independent standards. Besides, for using them they must be activated on the remote unit as well.

  • Page 34: Supervision And Control Interface

    2.5. Supervision and control interface The control and supervision of the equipment (configuration, communication management, status monitoring), is carried out either "locally" thanks to the front panel interface, or using various remote control interfaces. 2.5.1. "Local" control For local management, the front panel includes a large keypad, a graphic OLED, and various LED indicators for essential status information.

  • Page 35: Remote Access

    In such situation, it is not possible to get a connection as directly as over a LAN. The AETA Remote Access service is designed for working around this obstacle and enabling to take control over a device even in such case...
  • Page 36 Two types of service are proposed:  Remote assistance: this service allows the AETA support staff to access the codec, for help or possible investigation. Your explicit agreement is required for such operation.  Remote html access: provides access to the html pages of the codec from remote. The control device can be any device with a web browser, without the need to install any application.

  • Page 37: Gpio

    2.5.5. GPIO + S provides on its "EXTENSION" socket two isolated inputs (optocouplers) or "contacts", and two COOPY isolated "relay" outputs. Two categories of functions can be assigned to these GPIO:  Use for exchanging "INFO" boolean data with a remotye device (see above 2.4, "Auxiliary transmission functions").

  • Page 38: Configuration And Dialling Memories

    2.5.6. Configuration and dialling memories To ease the operation, it is possible to store configuration memories, called "profiles". These belong to three categories:  "Call profiles", including the parameters for calling a given destination: dial numbers, coding algorithm, etc. A profile is similar to a phone directory item, but in addition it can also hold coding parameters.

  • Page 39: Operation

    3. Operation  This chapter physically describes the unit, shows how to install it and explains teh main operation principles. The details about the menus or html pages can be found in chapters 4 and 5. 3.1. General principles – Control means The equipment control and supervision (configuration, status monitoring) is possible either in "Local"...

  • Page 40: Physical Description Of The Equipment

    3.2. Physical description of the equipment The S + S codec is housed in an ABS chassis, equipped with metal panels supporting the various COOPY connectors on the sides and the back. It is powered by an external 12V DC source, and/or by a set of rechargeable batteries (charging circuits integrated in the unit).
  • Page 41 Display and navigation keys Besides the OLED screen you can find the keys for navigating in the menus: Touche Fonction Confirm a selection, enter a sub-menu or enter data. From the base screen: switch to the root menu. Escape to upper menu level; From the base screen: switch to the root menu.
  • Page 42 LED indicators The LEDs provide the following information: Marking Color Function Green/Red Off : unit off and no DC power connected; Green : DC source connected; DC/Charge : DC source connected, internal batteries are charging Green/Red Off when unit is idle; Green when the decoder is synchronised on "Program";...
  • Page 43 "Recording" keyboard Just above the front panel you can find a small keypad, dedicated to the recording function (optional): Figure 7 - Recording keyboard Keys Function  Jump backwards by 10 s while playing back a recorded file. Playback a recorded file. ...

  • Page 44: Rear Panel: Transmission Interfaces

    3.2.2. Rear panel: transmission interfaces This panel mainly includes the interfaces to the transmission networks. Figure 8 – Rear panel The characteristics of the interfaces and their pinout are detailed in chapter 7, Technical characteristics. You can find on this panel the following items DC power ①...
  • Page 45  If you have to use a smaller format µSIM card, you can use a SIM/µSIM adapter (available on request from AETA): first set the µSIM inside this adapter, afterwards use this assembly like a regular SIM card. Antenna socket ⑩...

  • Page 46: Left Side: Inputs 1 And 3

    + S. It houses 6 C-size batteries. COOPY Use only NiMH batteries, such as those supplied as accessories by AETA (see further in 7.8). An internal charger recharges the batteries when the external DC source is connected, regardless whether the S + S is running or on standby.

  • Page 47: Putting In Service

    3.3. Putting in service Recommendations for the operation:  The unit is cooled by natural convection; you should not confine it too much for proper operation.  With the "HD-4G mobile" option, the unit includes two antennas integrated beneath the top cover.

  • Page 48: Initial Setup Of The Ethernet Interface

    3.4. Initial setup of the Ethernet interface The S + S includes a 100BaseT / 10BaseT Ethernet interface, and the audio transmission can take COOPY place over an IP network through this interface. In addition, it is always possible to use the Ethernet interface to access the embedded html server.

  • Page 49: Checking The Ip Configuration

    3.4.3. Checking the IP configuration The above configuration is kept in the unit’s memory, and reloaded at each start. (Tools / About / Local IP). To check the setting, you can read the IP address in the "About" menu You can then also check that the unit is seen on the network and at the right address: from a computer connected to the same network, enter (in the command mode, or console mode depending on the OS) "ping ipaddr", where ipaddr is the IP address of the S + S.

  • Page 50: Managing Links

    3.5. Managing links 3.5.1. Setting up and releasing links Generally speaking, once the codec is set up and the transmission interface(s) to be used is(are) configured, it is possible to manage audio links with remote devices. A transmission links/sessions have to be set, which can be done in two ways: ...

  • Page 51: First Level Maintenance

    3.6. First level maintenance 3.6.1. Using the test loops Maintenance Tests The test loops accessible from the "Tools " menu can help improve the analysis of a problem:  In order to check if the audio part functions correctly, use the "Audio" loop and check if the audio is OK at the output.

  • Page 52: Backup Reset

    Ethernet interface set for auto link mode, DHCP client enabled. Go through the following steps:  Get the reset_scoop.bin file (to be downloaded from our www.aeta-audio.com web site, a link can be found on the page dedicated to S + S). COOPY ...

  • Page 53: Detailed Operating Mode - User Interface

    4. Detailed operating mode – User interface In local mode, the unit is operated thanks to a keypad and display on the front panel. The display is an OLED graphic display. Operating from the keyboard can be protected by a password (numeric sequence, that can be programmed or erased by the user.
  • Page 54 The unit proposes a tree structure of menus, and the joystick is used to navigate through the menus. key is used to confirm choices or enter values for parameters, while the key allows to come back up to the upper menu level. Repeatedly pressing this key brings you up to the root menu, and the base screen.

  • Page 55: Dialing And Text Input Keypad

    4.3. Dialing and text input keypad The keypad is used for entering numbers and/or texts. It is used in a similar way to a mobile phone:  The keypad works in "numeric" only mode, or in "alphanumeric" mode (where both numbers and letters can be entered).

  • Page 56: Description Of The Menus

    4.4. Description of the menus The root menu shows the following three main menus:  Setup configuration of the codec  (directory): access to configuration memories or "profiles"  Tools Maintenance and miscellaneous functions, access to status information Setup Network Algorithm Audio Coordination...

  • Page 57: Network Sub-Menu

    Network 4.4.1. sub-menu Network Cha nge Network ISDN Parameters AoIP Parameters Ethernet Parameters Mobile Parameters POTS Parameters Change Network sub-menu shows a selection among the available network interfaces. This is how you select the "default" interface for the Program link: ...
  • Page 58 Ethernet Parameters This sub-menu groups all settings for the Ethernet interface, and it is useful especially when setting up on a local area network. Ethernet Parameters Mode DHCP Manual PPPoE BGAN Network Qua l i ty Very high High Middle Very Bad BGAN Detection Network Config...
  • Page 59 Config.: only appears when DHCP is active, in which case this sub-menu displays the addressing parameters that the Scoopy+ S got from the server: Using the joystick, you can browse the various settings: local IP, sub-network mask, etc. Exit this display with the key.
  • Page 60 AoIP Parameters This sub-menu groups the settings related to the Audio over IP (AoIP) transmission. It is relevant for the Ethernet interface but also for using a mobile access network, be it with the integrated module or an external module via USB. AoIP Parameters Defa ul t protocol Direct RTP...
  • Page 61 Server: enter the address of the STUN server, either in numeric form or with a symbolic name. This kind of server allows Scoopy+ S to discover its public IP address when it accesses the Internet through a router with NAT. You can use AETA’s server: stun.aeta-audio.com.
  • Page 62  RTP Port (SIP): the default port for RTP/SIP audio streams is 5004 (UDP), but you can enter a custom value here if desired.  RTP Port (Direct): port allocated to the transmission in Direct RTP mode; should not be the same as the RTP port for SIP.
  • Page 63 ISDN Parameters This sub-menu is not available on versions with no active ISDN interface. ISDN Parameters Protocol Euro ISDN NI-1 Loca l Number 1 <Entry> Loca l Number 2 <Entry> Sub-Addres s 1 <Entry> Sub-Addres s 2 <Entry> SPID <Entry> Codec Mode Notes: ...
  • Page 64 POTS Parameters This sub-menu is only visible on units with the POTS option. POTS Parameters Di a l i ng Mode Tone Pulse Di a l Tone Wait Ignore Country Code Argentina … United States Ma x Speed 12 kbit/s …...
  • Page 65 Mobile Parameters This sub-menu is only visible on units with a "wireless" option. If more than one mobile access module is available (example: integrated module and "mobile key" on the USB socket), then one such sub-menu is presented for each module. Mobile Parameters <Entry>...
  • Page 66  Save: if this option is checked, the unit saves the PIN code and unlocks the SIM card automatically when the unit is switched on. It is recommended to disable this feature before changing for another SIM card (and possibly another PIN).

  • Page 67: Algorithm Sub-Menu

    Algorithm 4.4.2. sub-menu This sub-menu allows to select the desired configuration for an outgoing call, using the current transmission interface. Algorithm Other G722 … OPUS Previous (1) Previous (2) … It is possible to quickly recall the last used configurations ("Previous" above), scrolling the list and selecting one of these recent settings.

  • Page 68: Audio Sub-Menu

    Audio 4.4.3. sub-menu Audio Inputs Gl oba l Ga i n xx dB Input n Settings Power Ga i n xx dB Fi l ter Li mi ter Ini tia l Setti ng Memorized Audi o Routing Program [Left] Coordination Line [Right] PGM &...

  • Page 69: Coordination Sub-Menu

     Line Out Level: gain setting for the outputs. The value is the maximum level (absolute level expressed in dBu) found at the output when the digital signal (send or receive) is at its maximum (0 dBFS).  Headphone n: selection of the monitoring mode on the headphone. The presented choice depends on the operation mode (mono/stereo, with coordination, etc.), and especially on the type of mono routing that is currently selected (next setting in this menu).

  • Page 70: Directory Menu

    Directory 4.4.5. menu This is the only menu available in restricted access mode. Call Profiles 0 : CALLPROF_1 Load Call Update Delete Presets 0 : PRESET_0 Load Delete Snapshots 0 : Snapit Load Delete Recordings Record_xxx.wav Play Rename Delete Send Takes Record_xxx Play...
  • Page 71 To use the profiles, just scroll the list, select one of the recorded profiles, and press : a choice is presented:  Load this profile, recalling the memorized parameters;  Delete the profile (not available when in restricted access);  Call the remote destination in the profile (choice available only for a call profile): in this case the codec recalls the memorized parameters, and then sets the call to the memorized...

  • Page 72: About Sub-Menu

    STUN server (configured via the "AoIP parameters" menu, see in 4.4.1).  Type: in addition to the above public IP, thanks to STUN Scoopy+ S can detect the type of NAT.  Version: S + S firmware version global identification.

  • Page 73: Misc Sub-Menu

    Misc 4.4.7. sub-menu Misc Reset Reset Call History Reset Algo. History Reset Snapshots Reset Presets+CallPro Reset Recordings Reset Settings Factory SIP account Factory Reset Aux. Functions Da ta Cha nnel Ba ud Ra te Rel a ys GPIO Inputs Assignment Input 1 Disabled Info 1...
  • Page 74 "Factory "Factory SIP account" allows to reload (into the AoIP settings) cannot be cancelled! Lastly, the "factory" registration account on the AETA SIP Server.  Aux. Functions: this sub-menu allows to enable the auxiliary functions (details on these functions can be found in 2.4, Auxiliary transmission functions), and select the baud rate for the data channel.

  • Page 75: Maintenance Sub-Menu

    + S does not include the "Remote Access" option, this sub-menu is entitled "Remote COOPY assistance" and it allows to make the unit accessible for remote assistance by AETA; the "Codec Password" parameter does not appear in the menu in this case.

  • Page 76: Setting Up A Link

    4.5. Setting up a link For dealing with links with the S + S, generally you should go through the following steps: COOPY Select the basic options that will essentially determine the operation: audio operation (mono/stereo, with/without coordination), transmission network type. This is described below (4.5.1, Basic options).

  • Page 77: Preparing The Network Interface(S)

    4.5.2. Preparing the network interface(s) This part describes how to prepare the network interfaces for the subsequent connections, in order to be ready to handle calls. This should also be done to get the unit ready to possibly receive calls from a remote device.
  • Page 78 Public IP Check that the public address discovery has succeeded: sub-menu: information (its mere presence shows the discovery has succeeded). The type of NAT detected by the Scoopy+ S is also Type). shown in this sub-menu (NAT If you wish to use the "Direct RTP" mode instead of SIP for outgoing calls, select "RTP Direct" for the first protocol).
  • Page 79 Mobile network (integrated module) This part applies to units equipped with the "HD-4G mobile" option, which integrate a mobile network access module and antennas. Prerequisites A mobile network can be used as interface for AoIP connections. It can be used in voice mode as well (regular telephone links), especially for the coordination channel (case 3 or 4 mentioned above in 4.5.1).
  • Page 80 Once these settings are done, you can check the mobile network registration status in the sub-menu Setup Network Mobile Parameters Network Status: operator, current radio technology, radio signal strength. In addition, icons on the base screen provide information on the mobile network: radio strength bars, double arrow showing that the data connection is active Data connection is active ...

  • Page 81: Setting The Coding Configuration

    4.5.3. Setting the coding configuration Setup / Algorithm. This configuration is accessible through the sub-menu When entering the sub-menu, a list of the most recently used configurations is displayed: you can scroll this list and select a configuration (enter OK) for loading it directly. For setting another configuration, select "Other".

  • Page 82: Launching Calls (Outgoing)

    4.5.4. Launching calls (outgoing) Once the preliminary settings are done, the procedure for setting a call is rather straightforward: dial a destination "number" and launch the call. First go back to the base screen: if necessary press the key several times. Preliminary notice about call "numbers"...
  • Page 83 Releasing/Hanging up To stop a link and release the line, press the "hang up" key . Confirmation is required; press the key again for confirming (this is a security to avoid an undesired release).  The S + S features an automatic release for AoIP connections: whenever a connection is COOPY established, but the unit does not receive a stream for more than 30 seconds, it automatically releases the link and comes back to the "idle"...

  • Page 84: Receiving Calls

    COOPY however accept incoming ISDN calls, provided that it is not already busy with another connection. Once the connection is released, the Scoopy+ S will come back to its previous default interface. AoIP incoming calls Such calls are accepted if they are presented on the interface that is selected as default for outgoing calls.
  • Page 85 "Network quality" setting Depending on the quality of service provided on the network, especially its jitter performance, it is possible to change the stability/latency compromise used by the S + S. For this purpose, a setting is COOPY available among the settings of each IP interface (for instance, for the Ethernet interface: sub-menu Setup Network Ethernet Parameters...

  • Page 86: Management Of The Configuration Profiles

    4.6. Management of the configuration profiles The configuration profiles ease configuration changes and the setting up of routine links. There are three types of profiles:  "Call profiles", which include call parameters for a given destination (number(s), coding, etc.). Such a profile is similar to a directory entry, but in addition it can memorize the coding parameters.

  • Page 87: Recording Function

    4.7. Recording function To use this (optional) function, you must insert in the suitable slot (on the rear side) an SD card, FAT32 formatted (only file system supported).  The SD card must be inserted when the unit is off (no "hot plug" capability). Recordings are handled thanks to the "transport"...

  • Page 88: Playing Back

    The file is one-channel (mono) if the recording is performed while idle, without an active transmission. The "Program Send" signal is recorded. If you start recording while a link is active, the recording is two-channel ("stereo" ): Program Send in channel 1 ("left") and Program Feedback/Return in channel 2 ("right").

  • Page 89: Simple Editing

    4.7.3. Simple editing From a recorded file, it ispossible to create virtual "takes". A take is made by setting a start point or take begin marker, and an output point or take end marker. This set (recording + begin marker + end marker) can be saved and named.

  • Page 90: Management Of Recordings

    4.7.4. Management of recordings It is possible to extract the SD card from S + S, insert it into a computer and recover the various COOPY recorded files for editing and further use. The wav format makes this easier for all types of available tools.

  • Page 91: Restricted Operation Mode

    4.8. Restricted operation mode 4.8.1. Principles + S can be locked in a restricted user access mode, which limits user access to the essential COOPY controls and features. For routine operation, this mode allows to avoid risks such as random settings, with unpredictable effects, handling or adjustment mistakes, accidental erasure of useful memories, etc.

  • Page 92: Lost The Password

    4.8.4. Lost the password? You have forgotten or lost the password ? The only way to restore full access is to clear all the settings, which will also clear the passwords. The unit will be accessible again. Chapter 4.9 below shows the procedure for such erasure. ...

  • Page 93: Specific Display Screens

    4.11. Specific display screens 4.11.1. Display statistics about the IP transmission During an AoIP connection, one can find, on the right side of the screen, 6-segment transmission quality indicators (full bar = 100%): Transmission quality indicators The left bar shows the quality estimated on the transmit direction, the right bar shows the quality in the receive direction.

  • Page 94: Case Of The Opus Algorithm: Bit Rate Change "On The Fly

    The modified setting is applied at least in the transmit direction, towards the remote codec. If this codec is another AETA codec, it will "follow" and change its transmitted stream as well, and the selected value will apply in both transmission directions.

  • Page 95: Operating Mode - Embedded Html

    5. Operating mode – Embedded HTML pages The embedded html server in S + S provides a comfortable and efficient means to control and COOPY monitor the unit. It just needs the S + S to be connected to an IP network and to be reachable from COOPY a computer, or another device with an html browser: tablet, smartphone…...

  • Page 96: Principles Of Operation With Html

    5.2. Principles of operation with html pages The picture below shows a typical page. Tabs Refresh the "SIP" block Help area On top you find a bar of tabs corresponding to the various categories of functions and parameters for the S + S.

  • Page 97: Status " Tab

    5.3. " " tab TATUS This tab leads to the "S " page, which is also the home page. It provides an overview of the essential TATUS settings and parameters, sufficient for basic monitoring. Active transmission interface highlighted Link monitoring Program level This page is accessible without a log in, and without a password.

  • Page 98: Connections " Tab

    5.4. " " tab ONNECTIONS This tab leads to the "C " tab, allowing to remote control the links: monitoring, outgoing call ONNECTIONS set up and call releasing. Link monitoring 1. Use a profile 2. Dial directly then 3. Launch the call Status of the relays Bit rate change...

  • Page 99: Profiles " Tab

    5.5. " " tab ROFILES This tab proposes three secondary pages, one for each profile type. 5.5.1. "C " page ALL PROFILES Select a profile Select a profile, edit the parameters, and click this button edit the parameters and and click this button to delete a profile click this button to create a profile...

  • Page 100: Network " Tab

    5.6. " " tab ETWORK This tab leads to several pages, which correspond, just like the sub-menu "Network" of the front panel interface (see 4.4.1 above), to the various network interfaces. For this reason, the number of pages actually proposed depends on the version and the options of the unit (with or without ISDN, mobile access, etc.).

  • Page 101: Ip Parameters " Page

    In case control is lost after an error, you must regain control and correct the settings using the front panel of S + S. COOPY Note: if a secondary Ethernet interface is available, it is also shown in this page, in an "E 1"...

  • Page 102: Pots Parameters " Page

    5.6.5. "POTS P " page ARAMETERS This page is only visible for units equipped with the POTS option. See more details on the parameters in 4.4.1, POTS Parameters.  Remember to save the changes, clicking the "Save" button! 5.6.6. "M "...

  • Page 103: Audio " Tab

    5.7. " " tab UDIO Audio See all details for these parameters in 4.4.3, sub-menu. Like the "S " page, this page shows TATUS the audio level transmitted/received to/from the network. After changes on the audio parameters, make sure to save the changes, clicking the "Save" button. This page includes the management of snapshots, memorizing the parameters controlled in this page.

  • Page 104: Coding " Tab

    5.8. " " tab ODING "C " tab groups the selection of the algorithm and its parameters, as well as the auxiliary ODING Algorithm Misc functions. See details on all these parameters in 4.4.2, sub-menu and 4.4.7, sub-menu. The available coding algorithms depend on the current network interface. The coding parameters depend on the algorithm and the network interface.

  • Page 105: Misc " Tab

    5.9. " " tab This tab groups several settings that can be found in the "Misc" sub-menu of the front panel user Misc interface (see 4.4.7, sub-menu): auto redialing configuration and activation, GPIO configuration, SMS reception enabling/disabling… Two items come in addition: ...

  • Page 106: Maintenance " Tab

    YSTEM UPDATE This page allows you to upload a file into the unit and update the firmware. The firmware update file must be provided to you by AETA (usually available for downloading from the web site). The procedure is rather simple: ...

  • Page 107: Reset " Page

    "Factory SIP Accounts" : reloads the credentials for the "factory" SIP account of the unit, and registers the unit on the AETA SIP server. The page also allows you to reboot the unit by remote, clicking the "Reboot" button. The device is actually reboot when you confirm by clicking "OK"...

  • Page 108: Event Log " Page

    5.10.5. "E " page VENT LOG This page displays a history if the system events, which can be useful for operational records, or for investigating operation issues, etc. Events are logged by the codec in its internal memory; they are recorded in plain text (unformatted ASCII), and the web page displays the 200 last lines of this log (with a scroll bar).

  • Page 109: Setup Transfer " Page

    5.10.6. "S " page ETUP RANSFER This page provides a means to backup all the settings of the unit into a file, and reciprocally to restore a complete configuration from a file previously saved in this way. Partial exports are also possible, selecting the items you wish to include: call profiles, presets, snapshots, settings…...

  • Page 110: Emote Access " Page

    5.10.7. "R " page EMOTE ACCESS You find on this page the settings related to the remote assistance and/or remote access. These settings Maintenance Remote Access). are the same found on the unit's local menu (Tools > > There are some differences depending on the installed options: ...

  • Page 111: Alarm " Tab

    5.11. " " tab LARM "A " tab switches to red as soon as at least one anomaly is detected. In addition the number of LARM abnormal conditions is shown in brackets. Clicking the tab, you reach this "A " page showing all the alarm conditions. All possible issues are LARM listed, but only those actually detected are highlighted with the icon.

  • Page 112: How To Use The Remote Access Service

    6.1.2. Step 2: open the remote session Tell the AETA technician the MAC address of the codec; this is the unique identifier for the device. AETA can then set a control session over the codec. The link is secure and encrypted.

  • Page 113: Using The Remote Html Access

    + S to the server COOPY First you must connect the codec to the AETA server so that it is accessible. To protect the access to the unit, you can define a "codec password" that allows to get control over it.
  • Page 114 You reach the AETA remote html access portal: 1. Select the product type (S + S) from the drop-down list. COOPY 2. Enter the serial number (leading "0" don't care). 3. Enter the codec password. 4. Click the "Login" button.

  • Page 115: Security Aspects

    If a firewall prevents this connection, it may be necessary to enable packet exchanges with the AETA server: domain cloud.aeta.com (or, at the time of writing, the IP address 80.154.26.106).

  • Page 116: Technical Characteristics

    7. Technical characteristics 7.1. Characteristics of the audio interfaces 7.1.1. Mic/line inputs Audio characteristics are measured over a 20 to 20 000 Hz bandwidth except when differently stated. The inputs are balanced type, using 3-pin female XLR sockets. Microphone powering: Phantom 48V Maximum input level: +19 dBu (+39 dBu for channel 3 with Pad)

  • Page 117: Audio Performance

    7.1.4. Audio performance The audio performance in this part applies to the system without coding/decoding. The additional effect of the audio encoding and decoding on audio performance depends on the coding algorithm used and its parameters. Except when differently stated, the following measurements are done at a +6 dBu input level and on the AD/DA path, with maximum input and output level set at +16 dBu.

  • Page 118: Characteristics Of Network Interfaces

    7.2. Characteristics of network interfaces 7.2.1. Ethernet Interface This RJ45 socket has standard Ethernet pinout (for use of a normal "straight" cable to an Ethernet hub or switch). The interface normally operates in 100BaseT full-duplex mode, with auto negotiation, but it is possible to force other configurations.

  • Page 119: Network Protocols And Ports

    Scoop Manager  123 NTP For querying an NTP server  514 SYSLOG For sending messages to a SYSLOG server  2382 AETA enumeration Used by "AetaScan"  3478 STUN For querying a STUN server  5004 For audio streaming (SIP) ...

  • Page 120: Miscellaneous Interfaces

    7.3. Miscellaneous interfaces 7.3.1. GPIO ("EXTENSION" socket) The "EXTENSION" socket includes the GPIO interfaces: 2 inputs (optocouplers) and 2 relays. Name In/Out Function and characteristics +5V Source Output Source provided by the S + S; can be used for COOPY powering devices connected to this interface (low power) OPTO1...

  • Page 121: Power Supply

    7.4.2. Batteries The unit can be powered by 6 type "C" or LR14 NiMH cells. Only rechargeable NiMH batteries can be used, such as those provided by AETA as accessories (see further, 7.8). Make sure to observe the proper polarity when inserting the batteries.

  • Page 122: Environmental Characteristics

    7.6. Environmental characteristics The equipment operates over a 0°C to 45°C ambient temperature range (32°F to 113°F), and a 5% to 90% humidity ratio range. The S + S complies with "CE" directives regarding safety and EMC. COOPY  Safety: compliance with EN60950 ...

  • Page 123: Accessories And Related Products

    7.8. Accessories and related products The S + S is delivered with an AC/DC adapter and a CAT5 Ethernet cable. COOPY The POTS option includes an RJ11 cable. The "HD-4G Mobile" option is delivered with an external multiband antenna. An SD Card is included with the "Recording" option. Additional accessories or spare parts are available: Code Description...

  • Page 124: Annexes

    Data channel  Other auxiliary information: relay transmission. The insertion of this auxiliary information is an extension (AETA proprietary format) to MPEG. However, the frame structure remains compliant. 8.1.2. Reed-Solomon encoding (ISDN only) In order to cope with possible transmission errors in the ISDN network, Reed-Solomon error correction coding can be added, compliant with J52 recommendation.

  • Page 125: Overview Of The Sip Protocol

    S c o o p y + Figure 11 – Setting up an SIP session with server(s) 1 Scoopy+ is a portable audio codec from AETA; the description here applies to any other SIP compliant codec. + S - User Manual...

  • Page 126: Setting A Link Without A Sip Server

    What happens then on the network: the Scoopy+ sends the request  (INVITE in SIP protocol) to a proxy server (often the same device is also the registrar). To make things simple, this proxy then relays and routes the request  to its destination. Resolving the SIP URI to a physical network and address uses mechanisms similar to those used for resolving URLs.

  • Page 127: Some Methods To Deal With Nat Routers And Firewalls

    8.3. Some methods to deal with NAT routers and firewalls Problems arise when the desired connection has to go through a NAT router, and/or a firewall, that blocks a direct IP communication. This is a very common issue, especially if one needs to set up a transfer via the Internet. It is impossible here to describe in details the possible ways to deal with this problem, but the following just shortly discusses some typical solutions.
  • Page 128 It is recommended to check that the server is operative. Moreover, numeric addresses may change, even if the domain name stays the same. A list of servers can also be found on the support page of our web site http://www.aeta-audio.com. 1 Although not with so called "symmetric" NAT routers...
  • Page 129 Standard NAT router Situation: codec A behind a NAT router with no specific programming (a codec accessing Internet via a mobile network is almost always in such situation). Besides, we assume that the other codec (B) is accessible with a public address. Once codec A is configured for using a STUN server: ...
  • Page 130 Method suitable for mobile network access  For a fast implementation, you can use SIP accounts on AETA’s SIP server sip.aeta-audio.com. This server is dedicated to a professional broadcast usage, and housed in a safe site, available 24/7. Contact AETA for subscribing SIP accounts.

  • Page 131: Summary And Reminder Of Essential Rules

    8.3.3. Summary and reminder of essential rules The table below sums up the situations where a link can be set up (not using a SIP proxy server) and reminds the needed specific settings: Codec A Possible Codec B Notes access calls access ...

  • Page 132: Notice Regarding Open Source Code

    License (or "GPL"), available for example at following address: http://www.gnu.org/licenses/gpl.txt Under this license, the source code for concerned elements is available on our Internet site ("Download" page); otherwise it can be obtained on request by e-mailing AETA Audio Systems (open_source@aeta- audio.com).

  • Page 133: Index

    9. Index 4SB, ADPCM ............17 J52 ............. 11, 17, 118 5AS ..............1, 11, 57 L16 ................19 L20 ................19 L24 ................19 AAC ................18 Linear............... 19 ADPCM ..............17 Local address ............71 Antenna ............. 13, 39 Loop Auto redial............
  • Page 134 protocol ............. 8, 9, 119 registration ............119 Take ................ 83 server ..............120 TDAC ............... 17 URI ..............119 Tech 3326 (N/ACIP) ........113, 119 SNR (Signal to Noise Ratio) ........111 Temperature ............116 Sound Card(USB) ..........21, 38 Test loop ..............
  • Page 136 92350 L LESSIS OBINSON . +33 1 41 36 12 00 – F +33 1 41 36 12 69 ÉL http://www.aeta-audio.com Specifications subject to change – All rights reserved by AETA AUDIO SYSTEMS 55 000 098 - B February 2018...

Table of Contents
