Y
OU MUST READ THIS
BEFORE OPERATING YOUR GAS GRILL
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid
4. If odour continues, keep away from the
appliance and immediately call your
gas supplier or your fire service.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING:
1. Do not store or use petrol or other
flammable vapours and liquids in the
vicinity of this or any other appliance.
2. A gas supply cylinder not connected
for use should not be stored in the
vicinity of this or any other appliance.
WARNING: Follow all leak-check
procedures carefully in this manual
prior to barbecue operation. Do this
even if barbecue was dealer assembled.
WARNING: Do not try to light the
®
Weber
gas barbecue without first
reading the "Lighting" instructions in
this manual.
INFORMATION FOR THE INSTALLER:
This manual must remain with the owner,
who should keep it for future use.
OUTDOOR USE ONLY.
G E N E S I S
O
G
WNERS
UIDE
DANGER
®
LP Gas Grill Owners Guide
#
GB - International English
55363 08/21/02
LP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Genesis Silver-A and is the answer not in the manual?

Questions and answers

Related Manuals for Weber Genesis Silver-A

Summary of Contents for Weber Genesis Silver-A

  • Page 1 Do this even if barbecue was dealer assembled. WARNING: Do not try to light the ® Weber gas barbecue without first reading the “Lighting” instructions in this manual. INFORMATION FOR THE INSTALLER: This manual must remain with the owner, who should keep it for future use.

  • Page 2: Danger & Warnings

    Improper assembly may be dangerous. Please carefully follow the assembly instructions in this manual. After a period of storage and/or non-use, the Weber Gas Barbecue should be checked for gas leaks and burner obstructions before use. See instructions in this manual for correct procedures.

  • Page 3: Table Of Contents

    Contents Danger & Warnings ..................2 Warranty ....................4 General Instructions .................5 Cooking ....................6 Cleaning ....................6 Exploded View ..................7 Parts List ....................9 Unpacking ....................10 Assembly Instructions ................11 Gas Instructions ..................18 Leak Checking ..................19 Safe handling tips for LP Gas ..............20 Refilling the LP Cylinder ................21 Operating ....................22...

  • Page 4: Warranty

    This Warranty applies only to products sold at retail. when assembled and operated in accordance with the printed instructions accompanying it. Weber may require reasonable proof of your date of purchase. THEREFORE, YOU SHOULD RETAIN YOUR SALES RECEIPT OR INVOICE.

  • Page 5: General Instructions

    We therefore request that Annual Maintenance.”) ® you read them carefully before you use the Weber I Check that the areas under the control panel and the gas barbecue. slide out bottom tray are free from debris that might •...

  • Page 6: Cooking

    CAUTION: Do not clean your Flavorizer bars or desired. The control settings: High (H), Medium (M), cooking grates in a self-cleaning oven. For Low (L), or Off (O) are described in your Weber ® availability of replacement cooking grates and ®...

  • Page 7: Exploded View

    Exploded View ® Genesis Silver-A Euro 061202...

  • Page 8: Exploded View List

    Exploded View List Hinge Pin Burner Control Knobs Left Endcap Control Panel Shroud Control Panel Hardware ® Handle Crossover Ignition Button ® Warming Rack Crossover tube Cooking Grates Front / Rear Burner Flavorizer ® Bars Manifold Hardware Cooking Box Manifold 1/4-20 keps nut Catch Pan Slide Out Bottom Tray...

  • Page 9: Parts List

    Parts List Cooking Box ® Flavorizer Bars - 5 Assembly - 1 Warming Rack - 1 Cooking Grate - 2 Caster Frame - 1 Bottom Tray - 1 Catch-Pan Holder - 1 Wheel Frame - 1 Catch-Pan - 1 Disposable Drip Pans - 2 Thermometer - 1 Bottom Rack - 1 1 inch Bolts (1/4 x 20 x 1 inch Bolt) - 6...

  • Page 10: Unpacking

    Unpacking...

  • Page 11: Assembly Instructions

    • Arrow sticker to front. • Push down firmly until Bottom Rack Lock "locks" under rail.
  • Page 12 Push down firmly on both sides to ensure bottom rack is locked under the rails. WARNING: Do not go to next step if bottom rack is not locked in place.
  • Page 13 • Install bolts at indicated locations. Use supplied tool to tighten. Finish tightening bolt with metal spanner provided or an 11mm (7/16”) open-ended spanner.

  • Page 18: Gas Instructions

    Gas Instructions Connecting the Liquid Propane Hose to manifold connection Cylinder The hose connects to the manifold, which screws into the manifold fitting(1) or pushes onto the manifold push on fitting(2). WARNING: Make sure that the LP cylinder valve is closed.

  • Page 19: Leak Checking

    The burners have been flame-tested. As a safety precaution however, you should recheck all fittings for leaks before using your ® Weber gas barbecue. Shipping and handling may loosen or damage a gas fitting. WARNING: Perform these leak checks even if your barbecue was dealer or store assembled.

  • Page 20: Safe Handling Tips For Lp Gas

    Gas Instructions Check: Safe handling tips for Liquid Propane 1) Hose to manifold connection. WARNING: If there is a leak a connection(1), Gas Cylinders retighten the fitting with a spanner and recheck • Liquid Propane (LP) gas is a petroleum product as for leaks with soap and water solution.

  • Page 21: Refilling The Lp Cylinder

    Gas Instructions Refilling the Liquid Propane 4) Check for leaks by wetting the fitting with the soap and water solution and watching for bubbles. If bubbles Cylinder form, or if a bubble grows, there is a leak. We recommend that you refill the LP cylinder before it is If there is a leak, turn off the gas and tighten the fitting.

  • Page 22: Operating Instructions

    Replace using only Weber ® 7) After the FRONT burner is lit you can turn on the authorised replacement hose.

  • Page 23: Manual Lighting

    Operating Instructions To Extinguish Manual Lighting Turn gas supply OFF at the source, then push down DANGER and turn each burner control knob clockwise to the Failure to open lid while igniting the OFF position. barbecue’s burners, or not waiting 5 minutes to allow the gas to clear if the barbecue does not light, may result in an explosive flare-up which can cause...

  • Page 24: Troubleshooting

    Troubleshooting Problem Check Cure Clean Spider/Insect Screens. (See Burners burn with a yellow or Inspect Spider/Insect Screens for orange flame, in conjunction with possible obstructions. (Blockage of Section “Annual Maintenance”) the smell of gas. holes.) Burner does not light, or flame is Is LP fuel low or empty? Refill LP cylinder.

  • Page 25: Maintenance

    When the spider/insect screens and burners are clean, replace the burners. If the spider/insect screen becomes damaged or cannot be cleaned, call Weber-Stephen Products Customer tubes through the air shutter openings. Service for replacement parts. We recommend you inspect the Spider/Insect screens at least once a year.

  • Page 26: Replacing Main Burners

    ® The Weber gas barbecue burners have been factory ® 1) Your Weber gas barbecue must be OFF and cool. set for the correct air and gas mixture. The correct flame 2) Turn gas OFF at source. pattern is shown.

  • Page 27: Crossover Ignition System Operations

    Maintenance Crossover ® Ignition System Operations 6) Lift and twist the burner assembly slightly, to separate the crossover tube(1) from the burners. Remove the If the Crossover ® ignition system fails to ignite the Left burners from the cooking box. burner, light the Left burner with a match.
