Interface Your Voice Paging System with
Virtually Any Telecom or IP Phone System
Viking's FXI-1 universal paging interface allows you to provide paging
from virtually any type of phone system instead of from a microphone.
You can also provide background music and electronic night bell over
the audio system.
The FXI-1 provides 30V talk battery for interfacing with an FXO or
unused analog line input/trunk port. With the flip of a switch, the unit
can connect to a FXS or PABX station ring trip port. No power
supply is required in this mode. In the event that it must be
connected to a "dry" 600 ohm paging port, the built-in voice activation
(VOX) is in control. This configuration is useful when interfacing with
systems that do not provide a paging contact closure, such as
Panasonic, South Western Bell, Intertel, etc.
In all modes the FXI-1 provides normally open or normally closed
relay contacts to activate the central paging amplifier equipment or
connect to an external background music source. After paging, the
FXI-1 auto disconnects on CPC, busy signal, silence or default
disconnect timer. An electronic night bell over paging feature can be
activated from a momentary phone system contact closure (FXO and
page port mode only).
Features
• Select: FXO (loop start), FXS (ring trip) or paging port
(VOX relay) interface mode
• No power supply required in FXS interface mode
• Up to 6 units can be powered from one adapter in the
FXO or VOX mode
• 30V DC talk battery for interfacing with FXO or unused
phone system line input/trunk port
• Floating 600 ohm paging output with volume control
• Normally open or closed relay for external paging amp
activation or interfacing the paging amp with an
external background music source
• 800 Hz pre-page page tone (on/off)
• Compatible with 24 to 48 volt FXS operation
• Calling party control (CPC) detection for immediate
disconnect
• Busy signal detect disconnect
• 2.5 second VOX silence disconnect timer
• Programmable VOX trigger sensitivity
• Disconnect timer: 16, 36, 60 seconds or disabled
• Screw terminal block connections
• Wall mount housing: (2) #6x3/4 panhead screws
included
www.vikingelectronics.com
Information: (715) 386-8861
PRODUCT MANUAL
Applications
• Integrate your paging system with virtually any POTS,
Centrex, Digital or IP phone system
• Suppress background music during paging
• Provides contact closure to activate paging system if
not provided by the phone system
• Add pre-page tone to your paging system
Specifications
Power: 12-24V DC @ 100mA, 120V AC/12V DC @
500mA, UL listed adapter included (not required in FXS
mode)
Dimensions: 111mm x 76mm x 36mm (4.38" x 2.97" x
1.38")
Shipping Weight: .48 kg (1.06 lbs)
Environmental: 0°C to 32°C (32°F to 90°F) with 5% to
95% non-condensing humidity
Relay Contacts: 30V DC@1A, 110V DC@0.3A, 125V
AC@0.5A
VOX Minimum Audio Signal to Activate Relay: -28dbm
minimum / -25dbm minimum @ 1KHz with VOX
sensitivity switch at normal / lower positions
VOX Time Out Disconnect: 2.5 seconds
Default Time Out Disconnect: 16, 36, 60 seconds or
disabled
Talk Battery: 30V DC
FXI-1
FXO / FXS / Telecom
Smart Paging Interface
December 15, 2015
