User's
Manual
Y okogawa Electric Corporation
Model 810518803
AQ2200-631
10Gbit/s Optical Receiver
Remote Commands
IM 810518803-17E
1st Edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQ2200-631 and is the answer not in the manual?

Questions and answers

Related Manuals for YOKOGAWA AQ2200-631

Summary of Contents for YOKOGAWA AQ2200-631

  • Page 1 User’s Model 810518803 Manual AQ2200-631 10Gbit/s Optical Receiver Remote Commands IM 810518803-17E 1st Edition Y okogawa Electric Corporation...

  • Page 2: Introduction

    This manual is useful if the operator have forgotten proper operation steps during operation. In addition to this manual, two kinds of manuals shown below are provided for the AQ2200-631. Therefore, you need to read the following two manuals, as well as this user's manual.

  • Page 3: How To Use This Manual

    How to Use This Manual Structure of This Manual This user's manual consists of the following sections: Chapter Title Description Functional Description This Chapter describes the overview, specifications, and command format of the remote function of this unit. Preparations for Connection This Chapter describes how to set up the GP-IB and Ethernet interfaces of this unit.

  • Page 4: Table Of Contents

    Contents Introduction......................... i How to Use This Manual ................... ii Chapter 1 Functional Description Overview.......................1-1 Connections....................1-1 Specifications of Remote Control Functions ..........1-1 Command Format..................1-2 Chapter 2 Preparations for Connection Connecting through GP-IB................2-1 Connecting through Ethernet................2-2 Chapter 3 Common Commands Common Commands..................3-1 Chapter 4 Unit Specific Commands 7 App Unit Specific Commands................4-1...

  • Page 5: Chapter 1 Functional Description

    1.1 Overview This remote control function remotely controls the AQ2200-series Frame Controller using an external controller, such as personal computer through the GP-IB or Ethernet interface. This user’s manual describes the remote control functions of “AQ2200-631 10Gbit/s Optical Receiver”. 1.2 Connections For details about connections, see the Remote Command Reference for AQ2201/AQ2202 Frame Controller.

  • Page 6: Command Format

    1.4 Command Format 1.4 Command Format (1) When the frame No., slot No., and device No. are specified, this manual describes each No. as shown below. Frame: → 0 Frame controller Slot No.: AQ2201 → 1 to 3 AQ2202 → 1 to 9 (2) The command in the portion enclosed by [ ] can be omitted.

  • Page 7: Chapter 2 Preparations For Connection

    2.1 Connecting through GP-IB Chapter 2 Preparations for Connection 2.1 Connecting through GP-IB When connecting multiple units, a different address needs to be set for the GP-IB address. Follow the steps below to set the GP-IB address. Press the [SYSTEM] key to display the SYSTEM screen. With the [ ] or [ ] key, move the cursor to "GP-IB Address"...

  • Page 8: Connecting Through Ethernet

    2.2 Connecting through Ethernet 2.2 Connecting through Ethernet A different address needs to be set for the network address of each unit in order to identify the unit to be connected to the network. Follow the steps below to set the network address. Press the [SYSTEM] key to display the system screen.

  • Page 9: Chapter 3 Common Commands

    3.1 Common Commands This Chapter describes the commands common to all modules. :SLOT[n]:IDN? description Obtains the module information. response <Manufacturer>,<Model>,<Serial Numbers>,<Firmware Revision> example :SLOT:IDN? → YOKOGAWA,AQ2200-631,813D00051,01.00 :SLOT[n]:OPC? description Obtains the command process status. response <status> Type: integer Range: 0 | 1 0: Process is in progress.
  • Page 10 3.1 Common Commands :SLOT[n]:TST? description Obtains the self-test results. response <result> Type: integer Range: Correct Value other than “0”: Faulty If the value is not “0”, the bit value corresponding to the fault item becomes “1”. Item Name Upgrade Memory error ID Information Memory error Temperature alarm Not used.

  • Page 11: Chapter 4 Unit Specific Commands

    4.1 Unit Specific Commands Chapter 4 Unit Specific Commands 4.1 Unit Specific Commands This Chapter describes the function commands of the AQ2200-631. :STATUS[n]? description Obtains the alarm information. response <alarm> Type: integer Item Name Obtained Value 1 – 0 Temperature alarm...
  • Page 12 4.1 Unit Specific Commands :OUTPut[n]:STATe syntax :OUTPut[n]:STATe <state> description Sets the data output to ON or OFF. parameters <state> Type: discrete Range: OFF | ON OFF: Data output is OFF. Data output is ON. Default: example :OUTP:STAT ON :OUTPut[n]:STATe? description Obtains the data output status.
  • Page 13 4.1 Unit Specific Commands :SENSe[n]:LOS[:LEVel] syntax :SENSe[n]:LOS[:LEVel] <los> description Sets a LOS detection level. parameters <los> Type: decimal Range: -19.0 to 2.0 (0.1dBm Step) Default: -16.0 (Wavelength is 1500nm.) -15.0 (Wavelength is 1300nm.) example :SENS:LOS -10.0 :SENSe[n]:LOS[:LEVel]? description Obtains the set value of the LOS detection level. response <los>...

  • Page 14: Chapter 5 Remote Command Errors

    5.1 Remote Command Errors Chapter 5 Remote Command Errors 5.1 Remote Command Errors This Chapter describes errors that occur when using the remote command. The following shows the error messages caused by the remote command. For details about other errors, see the list of error codes stated in the Operation Manual for AQ2200 multi-application system.
  • Page 15 5.1 Remote Command Errors Remote Command Errors (2/2) Code Item Description 2031 Message Invalid update memory Contents Update Memory of the Firmware is faulty. Remedy Update the firmware again. Type 2032 Message Invalid ID information memory Contents Update Memory of the Firmware is faulty. Remedy Hardware is faulty.

  • Page 16: Chapter 6 Troubleshooting

    6.1 Troubleshooting Chapter 6 Troubleshooting 6.1 Troubleshooting (1) The setting does not become valid even though the setting command is sent. Send ":SYST:ERR?" command to check the error contents. After that, send the correct command. (Example) Parameter value beyond the setting range is specified. >...

  • Page 17: Appendix

    Appendix 1 List of Commands Appendix Appendix 1 List of Commands Common Commands Command Description Page :SLOT[n]:IDN? Obtains the module information. :SLOT[n]:OPC? Obtains the command processing status. :SLOT[n]:OPTions? Obtains the module information. :SLOT[n]:PRESet Returns the set information to its factory default setting. :SLOT[n]:TST? Obtains the self-test results.
