- Page 1 ST-100 SERIES ULTRASONIC TRANSDUCER Instruction Manual PL-419 December 1994 33454190 PRR - 1.1...
- Page 2 We endeavour to design equipment that is simple to use and reliable in its operation, with the aim of satisfying our customers’ needs. Milltronics has been designing and manufacturing process equipment since 1954. Our fields of expertise include ultrasonic and capacitance level measurement in-line weighing of dry bulk solids and motion sensing.
-
Page 3: About The Transducer
ABOUT THE TRANSDUCER transducer The ST-100 series of transducers operates in association with Milltronics ultrasonic level monitoring products. transducer The transducer converts the electrical energy of face the transmit pulse from the transceiver into acoustical energy. It then converts the acoustical –3 db... -
Page 4: Do's And Don'ts
284 mm (11.2") 229 mm (9.0") 51mm (2.0") mounting holes 13 mm (0.5") dia. (3 places) radiating face 102 mm (4.0") Milltronics terminal block transceiver in junction box red (hot) black transducer cable RG62 A/U cable shield green to approved shield... - Page 5 MOUNTING DO’S AND DON’TS VERY IMPORTANT Mount the transducer so that it is above the maximum material level by at least the blanking value. Refer to the associated transceiver manual. Do not overtighten mounting. Hand tightening of the mounting hardware is sufficient. On liquid applications, the transducer must be mounted so that the axis of transmission is perpendicular to the liquid surface.
- Page 6 MOUNTING Typical Solids Application to junction box mounting plate threaded studs provide adjustment for sighting transducer refer to mounting detail bolt washer Mounting Detail rubber washers or grommet mounting plate or blind flange washer Typical Liquid Applications conduit connection Blind Flange blind flange spacer Flange, gasket and...
- Page 7 APPLICATIONS LIQUID APPLICATIONS - STANDPIPES In many applications access must be made via a standpipe. In such cases, Milltronics can provide flange mounted transducers that will readily mate to the flanged standpipe. Another option is to hang the transducer from a blind flange.
- Page 8 LIQUID APPLICATIONS - VOLUME "Preferred" "Bad" "Alternate" tank manufacturer’s full level span: corresponds to 7° beam angle tank manufacturer’s empty level rise empty level for "alternate" location. Below this level, echo would reflect away tank manufacturer’s from the transducer. empty level discharge 1.
- Page 9 SOLIDS APPLICATIONS - TYPICAL bin wall seams filling profile emptying profile 1. Transducer angled to avoid seams 3. Transducer too close to in bin wall and aimed at discharge in material inlet. Falling order to read bin when empty. material will intersect sound beam and cause 2.
- Page 10 APPLICATIONS WITH AGITATOR STORAGE BIN WITH AGITATOR infeed agitator 1. Transducer should be kept away from infeed. 2. Where agitators are in use, use the Agitator Discrimination parameter on transceivers where available. 3. Transducer should be aimed away from wall projections. PL-419...
